Freedom X 1200 Inverter Truesine 1000W 120AC 12VDC Hardwire, TransferThe Xantrex Freedom X 1200 is engineered specifically to meet the needs of heavy-duty trucks and is ideal for installation in all types of commercial and recreational vehicles. This inverter provides up to 1200 watts of continuous utility grade, sine wave power from a battery bank and is designed to handle loads such as microwave ovens, TVs, DVD/Blu-ray players, and power tools. In addition, the Freedom X 1200's high-surge capability lets you handle many hard-to-start loads, including full-size residential refrigerators.The Freedom X 1200 has a built-in 30 Amp transfer switch that automatically transfers between inverter power and shore power from recreational facilities such as boat docks or campsites to ensure power is always available. If incoming shore power is interrupted by external events like brownouts, the Freedom X 1200 automatically becomes an independent power source that supplies utility-grade AC power to your loads.The Freedom X 1200 offers comprehensive built-in protection features to safeguard your batteries from the unnecessary drain while protecting your equipment. Features include selectable low battery shutdown voltage, low voltage shutdown delay timer, power save mode, low battery voltage alarm, and shutdown. The Freedom X 1200 also features configurable AC transfer speed, output frequency, and voltage, making it extremely versatile and the perfect blend of performance and cost.Features: Input: 12 VDC Output voltage: 120 VAC, 60 Hz Continuous Power: 1200W (10.0 A) Surge Power: 2400W (20.0 A) Output waveform: Pure sine wave Transfer relay: 30A Dimensions: 14.8 x 10.4 x 3.5 in (376 x 263 x 91 mm) Inverter weight: 10.4 lbs (4.7 kg) Shipping weight: 13.0 lbs (5.9 kg) Warranty: 2 years

Read more less

FREEDOM X 1200 PRO Inverter Truesine 1000W 120AC/12VDC Hardwire TransferEngineered specifically to meet the needs of heavy-duty trucks, the FREEDOM X 1200 offers a perfect blend of performance and cost. The FREEDOM X 1200 is ideal for installation in all types of commercial vehicles.Robust. Durable. Flexible.Its rugged, industrial design ensures optimum performance in all conditions. Quick-connect terminals at AC input & output and pre-wired pigtail cables enable fast and easy installation on the assembly line. Conformal-coated circuit boards and heavy-duty metal casing make the FREEDOM X 1200 ideal for mobile applications. It also features true sine wave output, 2x continuous power surge rating, a built-in transfer switch, and low battery voltage shutdown among other features. The FREEDOM X 1200 Pro has a built-in communication card for integration with third-party monitoring and control display panels through RV-C connectivity.Certifications: H.A.L.T ETL listed to CSA Standard C22.2 No. 107.1 FCC Part 15, Class B UL458* for marine supplement compliance drip shield in specific mounting orientations when required Applications: Recreational vehicles Heavy-duty truck Work truck Specifications:Power Output Continuous: 1200WThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

Freedom X 2000 True Sine Wave Power Inverter - 12VDC - 120VAC - 2000WTrue sine wave 120 Vac inverter with built-in transfer switch. Designed for recreational and commercial applications.The Freedom X inverter offers premium performance in a lightweight compact package. It cranks out full output from -4°F - 104°F for operation in all climate temperatures. The extended surge rating of the Freedom X makes it ideal to start difficult loads including fridge and microwave. The quick connect terminals at AC IN/OUT make installation a breeze.Features: Extended Surge Rating: Surges to 2X continuous power for 2 seconds for motor loads True Sine Wave AC Power: For operation of sensitive and motor loads Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Built-in 30A AC Transfer Relay: Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power (shore or generator). The unit also automatically switches from invert mode to charge mode Quick Installation: Huge wiring bay for easy access and quick connect AC in/out terminals for fast & easy wiring WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Inverter Cont. Output Wattage: 2000w AC Connection Type: Hardwire DC Connection Type: Hardwire GFCI: Optional Outlet Qty: Optional Inverter Surge Rating: 4000w Inverter Input Voltage: 12v Inverter Output Voltage: 120v Waveform: True Sine Wave Box Dimensions: 9"H x 15"W x 20"L WT: 18.8 lbs UPC: 715535901387 Owner's Manual (pdf)Brochure (pdf)

Read more less

Freedom X 3000 Truesine Inverter - 120AC/12DC HardwireTrue sine wave 120 VAC inverter with built-in transfer switch. Designed for recreational and commercial applications.The Freedom X inverter offers premium performance in a lightweight compact package. It cranks out full output from -4°F - 104°F for operation in all climate temperatures. The extended surge rating of the Freedom X makes it ideal to start difficult loads including fridge and microwave. The quick connect terminals at AC IN/OUT make installation a breeze. The Freedom X has become a popular choice for boaters in a short span of time. Xantrex has now added another product to this series — Freedom X 3000, a 3000-watt pure sine wave inverter with built-in 30A transfer relay. The Freedom X 3000 delivers full output up to 40°C/104°F with a 2 second surge of 6000 watts. The Freedom X 3000 features a large wiring bay with quick connect AC terminals for fast, reliable & easy wiring.Features: Extended Surge Rating: Surges to 2X continuous power for 2 seconds for motor loads True Sine Wave AC Power: For operation of sensitive and motor loads Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Built-in 30A AC Transfer Relay: Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power (shore or generator). The unit also automatically switches from invert mode to charge mode Quick Installation: Huge wiring bay for easy access and quick connect AC in/out terminals for fast & easy wiring Specifications: Inverts: 12 Volt DC To 120 Volt AC Continuous Output Power (W): 3000 Watt With Volt/Watt Meter: No With Thermal Protection: No With Battery Cables: No With Fuse: No WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Inverter Cont. Output Wattage: 3000w AC Connection Type: Hardwire DC Connection Type: Hardwire GFCI: Optional Outlet Qty: Optional Inverter Surge Rating: 6000w Inverter Input Voltage: 12v Inverter Output Voltage: 120v Waveform: True Sine Wave Box Dimensions: 9"H x 16"W x 20"L WT: 19.9 lbs UPC: 715535901493

Read more less

FREEDOM X Combox NMEA2K Communication Device for BoatsThe FREEDOM X Combox connects the FREEDOM X and XC families of inverter/chargers to an RV-C or NMEA2000 bus to support seamless integration with third-party monitoring and control systems.Features: Configure connectable products via RV-C or NMEA2000 Compatible with the Freedom X Bluetooth Remote Panel USB port for firmware upgrade and configuration Applications: Recreational Vehicles Marine Compatible with: FREEDOM X - 817-1000, 817-2000, 817-2000-21, 817-3000 FREEDOM XC - 817-1050, 817-2080

Read more less

FREEDOM X Combox RV-C Communication Device for RVs CaravanThe FREEDOM X Combox connects the FREEDOM X and XC families of inverter/chargers to an RV-C or NMEA2000 bus to support seamless integration with third-party monitoring and control systems.Features: Configure connectable products via RV-C or NMEA2000 Compatible with the Freedom X Bluetooth Remote Panel USB port for firmware upgrade and configuration Applications: Recreational Vehicles Marine Compatible with: FREEDOM X - 817-1000, 817-2000, 817-2000-21, 817-3000 FREEDOM XC - 817-1050, 817-2080

Read more less

Freedom X GFCI OptionFeatures: Adds fault protected outlet to the Freedom X/XC Includes factory wired connector WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Freedom XC 1000 True Sine Wave Inverter/Charger - 12VDC - 120VAC - 1000W/50ATrue sine wave 120 Vac inverter/charger with built-in transfer switch. Designed for recreational and commercial applications.The Freedom XC inverter/charger offers premium performance in a lightweight compact package. It cranks out full output in invert or charge mode from -4°F - 104°F for operation in all climate temperatures. The extended surge rating of the Freedom XC makes it ideal to start difficult loads including fridge and microwave. The quick connect terminals at AC IN/OUT make installation a breeze.Inverter Features: Extended Surge Rating: Surges to 2X continuous power for 2 seconds for motor loads True Sine Wave AC Power: For operation of sensitive and motor loads Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Programmable AC Under-Voltage (85-110VAC) Shutdown: Feature ideal to operate under weak shore power or generator input Built-in 30A AC Transfer Relay: Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power (shore or generator). The unit also automatically switches from invert mode to charge mode Built-In Charger Features: Power Factor Corrected Multi-Stage Charging: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances and reduces the likelihood of tripping shorepower breakers Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V Battery Equalization: Maximizes flooded battery life Dead Battery Charging Down to 0 Vdc Power Share: Prioritizes AC loads by reducing the charge current and maintaining the total input current to less than the breaker setting WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: DC Connection Type: Hardwire AC Connection Type: Hardwire Inverter Input Voltage: 12v Inverter Surge Rating: 2000w Outlet Qty: Optional GFCI: Optional Waveform: True Sine Wave Inverter Output Voltage: 120v Inverter Cont. Output Wattage: 1000w Box Dimensions: 9"H x 15"W x 20"L WT: 16.5 lbs UPC: 715535901318 Owner's Manual (pdf)Brochure (pdf)

Read more less

Freedom XC 2000 True Sine Wave Inverter/Charger - 12VDC - 120VAC - 2000W/80ATrue sine wave 120 Vac inverter/charger with built-in transfer switch. Designed for recreational and commercial applications.The Freedom XC inverter/charger offers premium performance in a lightweight compact package. It cranks out full output in invert or charge mode from -4°F - 104°F for operation in all climate temperatures. The extended surge rating of the Freedom XC makes it ideal to start difficult loads including fridge and microwave. The quick connect terminals at AC IN/OUT make installation a breeze.Inverter Features: Extended Surge Rating: Surges to 2X continuous power for 2 seconds for motor loads True Sine Wave AC Power: For operation of sensitive and motor loads Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Programmable AC Under-Voltage (85-110VAC) Shutdown: Feature ideal to operate under weak shore power or generator input Built-in 30A AC Transfer Relay: Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power (shore or generator). The unit also automatically switches from invert mode to charge mode Built-In Charger Features: Power Factor Corrected Multi-Stage Charging: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances and reduces the likelihood of tripping shorepower breakers Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V Battery Equalization: Maximizes flooded battery life Dead Battery Charging Down to 0 Vdc Power Share: Prioritizes AC loads by reducing the charge current and maintaining the total input current to less than the breaker setting WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Waveform: True Sine Wave Inverter Output Voltage: 120v Inverter Input Voltage: 12v Inverter Surge Rating: 4000w Outlet Qty: Optional GFCI: Optional DC Connection Type: Hardwire AC Connection Type: Hardwire Inverter Cont. Output Wattage: 2000w Box Dimensions: 10"H x 16"W x 20"L WT: 19.4 lbs UPC: 715535901349 Owner's Manual (pdf)Brochure (pdf)

Read more less

Freedom XC Pro 2000 Inverter/Charger - 2000W - 100A - 120V - 12V2000 Watt pure sine wave inverter with 100 Amp built-in lithium-ion battery charger and transfer switch in a compact, lightweight footprint. Configure and monitor system performance via Bluetooth app available on the optional Bluetooth remote panelThe Freedom XC PRO inverter/charger, supporting RV-C and J1939 protocols, is the most versatile and flexible AC power solution in the market today. It also features a 100 amp (2000W model) / 150 amp (3000W model) battery charger and offers all of the configurable features of the Freedom XC series inverter/charger in a compact, light weight package. It cranks out full output in invert or charge mode from -4°F (-20°C) - 104°F (40°C) for operation in all climate temperatures. The extended surge rating enables compressor loads such as an A/C or a fridge to start reliably.Features: Extended Surge Rating: Surges to 2X continuous power for 5 seconds for motor loads True Sine Wave AC Power: For operation of sensitive and motor loads Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Built-in 50A AC Transfer Relay: Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power (shore or generator) Power Factor corrected Multi-Stage: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V Specifications: Continuous Power: 2000 Watts Continuous Current: 16.7 Amps Surge Power: 4000 Watts Frequency: 60 (or 50) Hz (selectable) Output Voltage: 108, 110, 120 Volts AC (selectable) Input Voltage: 12 Volts DC nominal Safety: ETL listed to CSA 107.1, UL458 (UL458 Marine Supplement with optional drip shield, part number 808-1050) Dimensions: 15.4" x 10.8" x 4.9" Unit weight: 17.1 lbs 2 year warranty This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

Freedom XC Pro 3000 Inverter/Charger - 3000W - 150A - 120V - 12VA true sine wave inverter with a built-in lithium-ion battery charger and transfer switch in a compact, lightweight footprint. Configure and monitor system performance via Bluetooth app available on the optional Bluetooth remote panel (# 808-0817-02).The Freedom XC PRO inverter/charger, supporting RV-C and J1939 protocols, is the most versatile and flexible AC power solution in the market today. It also features a 100 amp (2000W model) / 150 amp (3000W model) battery charger and offers all of the configurable features of the Freedom XC series inverter/charger in a compact, light weight package. It cranks out full output in invert or charge mode from -4°F (-20°C) - 104°F (40°C) for operation in all climate temperatures. The extended surge rating enables compressor loads such as an A/C or a fridge to start reliably. Features: Extended Surge Rating: Surges to 2X continuous power for 5 seconds for motor loads True Sine Wave AC Power: For operation of sensitive and motor loads Ignition Control: Feature to turn inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Programmable AC Under-Voltage (85-110VAC) Shutdown: Feature ideal to operate under weak shore power or generator input Built in 50A AC Transfer Relay (3KW model): Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power Built-In Charger Features: Power Factor Corrected Multi-Stage Charging: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances and reduces the likelihood of tripping shorepower breakers Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V Battery Equalization: Maximizes flooded battery life Dead Battery Charging Down to 0 Vdc Power Share: Prioritizes AC loads by reducing the charge current and maintaining the total input current to less than the breaker setting Easily configurable settings to charge any lithium ion battery This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less
