C-Series Solar Charge Controller - 40 AmpsPV charge, diversion and load controllerThe C35 and C60 are field configurable for 12 V and 24 V operation. The C40 may be configured for 12 V, 24 V, or 48 V operation. C35, C40 and C60 charge controllers can be used as a charge, diversion, or load controller and come with a standard multi-color charge status LED face plate.A Controller for Virtually any DC Charging Source. The C60 is a fully solid state, microprocessor-driven controller that is UL and cUL listed. C Series controllers may be configured for PV battery charging, or DC load control or DC diversion operation. Whatever the charging source, a C Series controller is sure to meet your DC controller needs.Silent Microprocessor Control-All C Series controllers have a powerful microprocessor at their core which increases system performance and maximizes battery life. They are fully solid state and operate silently.Features: Improve battery life with pulse width modulated (PWM) multi-stage temperature compensated charging Two-year standard warranty PV charge, diversion, load controller Available remote display with cumulative AMP hours Electronic protection against short-circuit, overload, and over-temperature conditions Tolerance to hostile environments with conformal-coated boards and powder-coated enclosure Field adjustable voltage and battery set point Automatically disconnects from the battery at night Compatible with negative ground and ungrounded systems WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

C-Series Solar Charge Controller - 60 AmpsPV charge, diversion and load controllerThe C35 and C60 are field configurable for 12 V and 24 V operation. The C40 may be configured for 12 V, 24 V, or 48 V operation. C35, C40 and C60 charge controllers can be used as a charge, diversion, or load controller and come with a standard multi-color charge status LED face plate.A Controller for Virtually any DC Charging Source. The C60 is a fully solid state, microprocessor-driven controller that is UL and cUL listed. C Series controllers may be configured for PV battery charging, or DC load control or DC diversion operation. Whatever the charging source, a C Series controller is sure to meet your DC controller needs.Silent Microprocessor Control-All C Series controllers have a powerful microprocessor at their core which increases system performance and maximizes battery life. They are fully solid state and operate silently.Features: Improve battery life with pulse width modulated (PWM) multi-stage temperature compensated charging Two-year standard warranty PV charge, diversion, load controller Available remote display with cumulative AMP hours Electronic protection against short-circuit, overload, and over-temperature conditions Tolerance to hostile environments with conformal-coated boards and powder-coated enclosure Field adjustable voltage and battery set point Automatically disconnects from the battery at night Compatible with negative ground and ungrounded systems WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

50 feetWARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

DC Battery Cables (4G) + Fuse L-KitPre-terminated DC battery cables and fuse block kit for a fast and easy installation between your inverter and battery.Specifications: 1400-2300W Inverters 8’ foot 2-0 Cables + Fuse L-Kit Specifications: Type: Cables Box Dimensions: 4"H x 10"W x 13"L WT: 8.8 lbs UPC: 715535915346

Read more less

DC Battery Cables (4G) + Fuse M-KitPre-terminated DC battery cables and fuse block kit for a fast and easy installation between your inverter and battery.Specifications: 900-1300W Inverters 8’ foot 2AWG Cables + Fuse M-Kit Specifications: Type: Cables Box Dimensions: 4"H x 10"W x 13"L WT: 5 lbs UPC: 715535915384

Read more less

DC Battery Cables (4G) + Fuse S-KitPre-terminated DC battery cables and fuse block kit for a fast and easy installation between your inverter and battery.Specifications: 600-800W Inverters 8’ foot 4AWG Cables + Fuse S-Kit Specifications: Type: Cables Box Dimensions: 4"H x 10"W x 13"L WT: 3.5 lbs UPC: 715535915469

Read more less

DC Battery Cables (4G) + Fuse XL-KitPre-terminated DC battery cables and fuse block kit for a fast and easy installation between your inverter and battery.Specifications: 2400-3000W Inverters 8’ foot 4-0 Cables + Fuse XL-Kit Specifications: Type: Cables Box Dimensions: 6"H x 11"W x 15"L WT: 15 lbs UPC: 715535915421

Read more less

Freedom 458 Inverter/ChargerAC Power Inverter with High Surge Capability, 3-Stage ChargerWith filtered modified sine wave output, Freedom inverter/chargers run virtually anything, from electrical equipment to appliances and electronics in your RV. Temperature controlled multistage charging ensures that your batteries are recharged quickly, and automatic shutdown and other safety features protect your expensive deep-cycle batteries from excessive depletion. For inverter/charger control and basic system monitoring, use the Freedom Basic Remote. For advanced battery monitoring and remote control, Freedom 458 systems can be paired with optional Link instrumentation.Product Features MSW AC power inverter with high surge capability Automatic 3-stage battery charger Temperature compensation with equalization stage provides optimal charging of deep cycle batteries Built-in transfer switch automatically transfers between inverter power and incoming AC power Power sharing prevents source AC input circuit breaker from tripping Customized settings can be programmed with the Freedom Basic Remote or Link 1000 panels Includes battery temperature sensor 30 month warranty Protection Features Over voltage and under voltage protection Over-temperature protection Overload protection Short circuit protection Electrical Specifications - Inverter Output power (continuous): 2000W Surge power (AC amps): 50A Output frequency regulation: 60Hz Inverter voltage regulation: 120V +/-5% true RMS Output wave form: Modified sine wave Efficiency (full load): 85% Peak efficiency: 92% No load current draw (idle mode): 0.12A AC output connections: Dual - 20/15 Circuit Breakers AC input connections: Single AC transfer switch: 30A Electrical Specifications - Charger Charge rate: 100A DC AC input voltage range: 90 130 VAC Battery voltage (nominal): 12 VDC Battery voltage range: 10.0 15.5 VDC Low battery cut-out: 10.0 VDC AC input (max. charge mode): 21A AC Bulk charge voltage: 14.3 VDC*** Float charge voltage: 13.4 VDC*** Equalize charge voltage: 16.3 VDC Charge control: 3-stage Battery type settings: Wet / Gel 1 / Gel 2 / AGM Equalization: Yes Temperature sensitive charging: Yes ***Default value varies with battery type and temperatureWARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Outlet Qty: None Charging Banks: 1 Inverter Output Voltage: 120v Inverter Input Voltage: 12v Charger Input - Voltage: 120v Inverter Cont. Output Wattage: 2000w Charger Output Voltage: 12v Charger Output - Amps: 100a Box Dimensions: 13"H x 15"W x 19"L WT: 55.7 lbs UPC: 647912106149 Owner's Manual (pdf)Brochure (pdf)

Read more less

Freedom 458 Inverter/Charger - 2000W120 Vac / 60 HzWith filtered modified sine wave output, the Freedom 458 inverter/charger has the ability to run electrical equipment, appliances and even sensitive electronics. Perfect for any RV, the temperature controlled multistage charging ensures that your batteries are recharged quickly, and safety features such as automatic shut down protects your expensive deep-cycle batteries from excessive depletion.AC Power Inverter with High Surge Capability, 3-Stage ChargerWith filtered modified sine wave output, Freedom inverter/chargers run virtually anything, from electrical equipment to appliances and electronics in your RV. Temperature controlled multistage charging ensures that your batteries are recharged quickly, and automatic shutdown and other safety features protect your expensive deep-cycle batteries from excessive depletion.For inverter/charger control and basic system monitoring, use the Freedom Basic Remote. For advanced battery monitoring and remote control, Freedom 458 systems can be paired with optional Link instrumentation.Product Features: MSW AC power inverter with high surge capability Automatic 3-stage battery charger Temperature compensation with equalization stage provides optimal charging of deep cycle batteries Built-in transfer switch automatically transfers between inverter power and incoming AC power Power sharing prevents source AC input circuit breaker from tripping Customized settings can be programmed with the Freedom Basic Remote or Link 1000 panels Includes battery temperature sensor 30 month warranty Hardwired AC Output (Single In/Single Out) Protection Features: Over voltage and under voltage protection Over-temperature protection Overload protection Short circuit protection WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Output Voltage: 12v Charger Output - Amps: 100a Inverter Output Voltage: 120v Inverter Input Voltage: 12v Charger Input - Voltage: 120v Inverter Cont. Output Wattage: 2000w Outlet Qty: None Charging Banks: 1 Box Dimensions: 12"H x 15"W x 19"L WT: 55 lbs UPC: 647912105630 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Freedom 458 Inverter/Charger - 2500W120 Vac / 60 HzWith filtered modified sine wave output, the Freedom 458 inverter/charger has the ability to run electrical equipment, appliances and even sensitive electronics. Perfect for any RV, the temperature controlled multistage charging ensures that your batteries are recharged quickly, and safety features such as automatic shut down protects your expensive deep-cycle batteries from excessive depletion.AC Power Inverter with High Surge Capability, 3-Stage ChargerWith filtered modified sine wave output, Freedom inverter/chargers run virtually anything, from electrical equipment to appliances and electronics in your RV. Temperature controlled multistage charging ensures that your batteries are recharged quickly, and automatic shutdown and other safety features protect your expensive deep-cycle batteries from excessive depletion.For inverter/charger control and basic system monitoring, use the Freedom Basic Remote. For advanced battery monitoring and remote control, Freedom 458 systems can be paired with optional Link instrumentation.Product Features: MSW AC power inverter with high surge capability Automatic 3-stage battery charger Temperature compensation with equalization stage provides optimal charging of deep cycle batteries Built-in transfer switch automatically transfers between inverter power and incoming AC power Power sharing prevents source AC input circuit breaker from tripping Customized settings can be programmed with the Freedom Basic Remote or Link 1000 panels Includes battery temperature sensor 30 month warranty Hardwired AC Output (Dual In/Dual Out) Protection Features: Over voltage and under voltage protection Over-temperature protection Overload protection Short circuit protection WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Output - Amps: 130a Charging Banks: 1 Inverter Output Voltage: 120v Inverter Input Voltage: 12v Charger Input - Voltage: 120v Outlet Qty: None Charger Output Voltage: 12v Inverter Cont. Output Wattage: 2500w Box Dimensions: 12"H x 15"W x 19"L WT: 61 lbs UPC: 647912105791 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Freedom Communication Card Mating Connector Assembly with 10" LeadThe Xantrex 808-0820 20-Pin Communications Harness connects to the 20-pin CC port of Freedom XC PRO Series Inverter/Chargers, enabling the unit to control the vehicle’s ignition control system (commonly referred to as ACC) via one control wire and to connect to a vehicle’s onboard display via three wires using the CANbus/RV-C, J1939 protocol.

Read more less
