Self-Locking Long D Shackle - Diameter 5mm - 3/16"Features: Self-locking long shackle forged in grade 316L stainless steel The pin is locked into one of the indentations No risks of loosening due to vibrations Outstanding working and breaking loads WLL: only for industrial applications CE Marking and batch number Applications: Standard applications of shackle requiring more length Attachment applications: blocks, head... Specifications: Materials 316 stainless steel grade Working load (lb) 880 WLL (lb) 440 Breaking load (lb) 2200 Weight (lb) 0.037 Dimensions (see 2nd image): A (inch) 1-9/64" B (inch) 25/64" C (inch) 13/64" D (inch) 25/64" D diameter (inch) 13/64" E (inch) 5/32" F (inch) 1-39/64" G (inch) 1-1/32"

Read more less

1-3/8" Snap Shackle with Fixed Eye - 35mmFeatures: Forged snap shackle (316L) with fixed eye The plunger pin is set captive into the hook and cannot become detached Excellent working and breaking loads Easy to open by pulling the plunger pin (possibility to attach a lanyard) Applications: Snap shackle applications with fixed eye Use for applications where the free rotation is not required

Read more less

1/2 Eye Nut - 1-1/16" DiameterFeatures: A complete range of single piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: 1-1/16" Diameter 1/2 Eye Nut

Read more less

1/2" Eye Nut - 13/16" Diameter Features: Imperial thread A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes  Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications:Materials: 316L stainless steel gradeDimensions: Diameter: (inch) 13/16" / (mm) 20.6 Thread UNC (Unified Coarse): 1/2" x 13" *Sold as an Individual

Read more less

1/4 Eye Nut - 1/2" DiameterFeatures: A complete range of single piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: 1/2" Diameter 1/4 Eye Nut

Read more less

10mm Eye Nut - Thread M10 x 150mm Features: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 10580 / (kg) 4800 Weight: (lb) 0.218 / (g) 99 Dimensions: A: (mm) M10 x 150 B: (inch) 55/64" / (mm) 22 C: (inch) 1 13/16" / (mm) 46 D: (inch) 25/64" / (mm) 10 E: (inch) 1 7/64" / (mm) 28 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

10mm Eye Nut - Thread M12 x 175mmFeatures: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 11460 / (kg) 5200 Weight: (lb) 0.209 / (g) 95 Dimensions: A: (mm) M12 x 175 B: (inch) 55/64" / (mm) 22 C: (inch) 1 13/16" / (mm) 46 D: (inch) 25/64" / (mm) 10 E: (inch) 1 7/64" / (mm) 28 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

12mm Eye Nut - Thread M12 x 175mmFeatures: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 15430 / (kg) 7000 Weight: (lb) 0.386 / (g) 175 Dimensions: A: (mm) M12 x 175 B: (inch) 1 1/16" / (mm) 27 C: (inch) 2 13/64" / (mm) 56 D: (inch) 15/32" / (mm) 12 E: (inch) 1 11/32" / (mm) 34 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

12mm Eye Nut - Thread M14 x 200mmFeatures: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 19840 / (kg) 9000 Weight: (lb) 0.377 / (g) 171 Dimensions: A: (mm) M14 x 200 B: (inch) 1 1/16" / (mm) 27 C: (inch) 2 13/64" / (mm) 56 D: (inch) 15/32" / (mm) 12 E: (inch) 1 11/32" / (mm) 34 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

12mm Eye Nut - Thread M16 x 200mmFeatures: A complete range of single-piece forged products for fastenings applications Outstanding breaking loads Available in different sizes  Applications: Various fastening applications Towing application Waterskiing lines attachment Specifications: Materials: 316L stainless steel grade Breaking load: (lb) 22040 / (kg) 10000 Weight: (lb) 0.364 / (g) 165 Dimensions: A: (mm) M16 x 200 B: (inch) 1 1/16" / (mm) 27 C: (inch) 2 13/64" / (mm) 56  D: (inch) 15/32" / (mm) 12 E: (inch) 1 11/32" / (mm) 34 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less
