Boat Outfitting - Gauges

52mm (2-1/16") ViewLine Fuel Tank Level Gauge - 0 to 1/1 - Black Dial & Round BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 12 - 24 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Voltage - Input Range (Volts): 12/24 V Series: ViewLine Gauge Type: Fuel Level Gauge Size: 2-1/16" Box Set: No Box Dimensions: 2"H x 4"W x 4"L WT: 1 lbs UPC: 7640178722897 Owner's Manual (pdf)

Read more less

52mm (2-1/16") VMH Flex Multifunction Gauge - NMEA2000Small but powerful, the VMH Flex is the perfect com­­­pro­mise to display a large amount of boat data in a compact device. No matter if you are wearing gloves or if it is raining on your deck, the innovative laser touch button allows you to scroll up to 5 different screens. Every screen can be freely customized with your most important information, and the setup – including alarms – is easily done with your smartphone just with a tap.Features: Up to 5 scrollable screens in single or dual layout Functions - Rudder, Trim, Speed, Engine revolution, Engine hours, Fuel level, Fresh water level, Wastewater level, Coolant temperature, Oil temperature, Engine oil pressure, Transmission oil pressure, Boost pressure, Depth, Clock, Compass, Battery Innovative laser touch-button reliable in every practical condition NMEA 2000® connectivity 2x analog resistive inputs for direct sensor connections Embedded analog to NMEA 2000® converter LIN port for Intelligent Battery Sensor Technical Specifications: Nominal Voltage - 12/24V Operating Voltage - 9-32V Protection Class - IPX7 Dimensions - 60mm (outer), 52mm (mounting hole) Display - 1.44" sun-readable color TFT display Resolution - 125 x 125 pixels Analog Inputs - 1x resistive, 1x frequency Connectors - Tyco / Hirschmann MQS connector 8 pin / Micro-C M12 5Pin Digital Ports - NMEA2000, LIN bus Wireless Interface - NFC In the Box: 1x VMH Flex – NMEA 2000® 1x 52 mm Spinlock Nut 1x Rubber Sealing Gasket  1x Wiring Harness – NMEA 2000® 1x Safety Instructions and Veratron Card Owner's Manual (pdf)

Read more less

85mm (3-3/8") VMH-35D Diesel Multifunction GaugeThe VMH 35-D is the perfect standalone solution for monitoring your diesel engine. With a configurable dial scale of 3000 or 4000 RPM, the VMH 35-D is a compact display that shows a wide amount of data from your engine, battery, tank, and GPS.Specific information about your diesel engine is provided with alarms, either received from the SAE J1939 bus or locally set through the embedded menu. Both 12V and 24V systems are supported, and EasyLink connectivity allows your dashboard to be expanded with additional VMH 14 satellite displays to keep your sensitive data under control. The embedded high-performance GPS receiver further enhances the display capabilities by adding speed, position, and heading data.The Veratron VMH 35 is designed with a mineral glass front that's optically bonded to the sun-readable hybrid display. A sleek brushed stainless steel bezel surrounds the device and fits into classic and modern marine décors.The embedded NMEA 2000 gateway distributes sensor data inputs such as fuel, trim, and tachometer to other devices like chartplotters, saving the need for an additional external converter.Powered by the latest microprocessor, the Veratron VMH 35 is blazingly fast. Yet even when set at full brightness, it draws a mere 170mA of power—a fraction of what comparably-sized TFT screens use.Features: High-performance GPS embedded 4x analog input for external sensorsWaterproof to IPX7 NMEA 2000 certified with embedded analog gateway SAE J1939 CAN portEasyLink output for up to 16 VMH 14 satellites In the Box: VMH35-D Gauge Mounting Spinlock Wire harness  Safety Instructions  *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 3-3/8" Gauge Type: Multifunction Series: VMH-35 Voltage - Input Range (Volts): 12-24v Box Dimensions: 4"H x 6"W x 6"L WT: 0.75 lbs UPC: 7640190290466 Owner's Manual (pdf)

Read more less

52mm (2-1/16") VMH-14 Multifunction GaugeThe VMH 14 instrument is a new-generation 52 mm EasyLink satellite instrument.Every VMH Master can control up to 16 VMH 14 satellites, and the installation cannot be more easy with the Veratron well-known daisy chain concept.Launch the App, define your settings, and then simply hold your mobile device in proximity of the VMH 14 device to transfer the configuration. And the configuration can also be done powerless! Features: Stylish black-glass design with brushed stainless-steel ring Digital display with configurable color bar graph Easily configured with a smartphone App One single device to support 8 different data types Technical Specifications: Voltage - 12v Connectivity - EasyLink & NFC  Required mounting depth - 40mm Operating Temperature - -20°C to +60°C  Storage Temperature - -30°C to +80°C  In the Box: VMH 14 Gauge 52mm Mounting Spinlock 52mm Rubber Sealing Gasket Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 2-1/16" Gauge Type: Multifunction Series: VMH Voltage - Input Range (Volts): 12v Box Dimensions: 3"H x 3"W x 4"L WT: 0.3 lbs UPC: 7640178729971 Owner's Manual (pdf)

Read more less

85mm (3-3/8") VMH-35 Multifunction GaugeThe Veratron VMH 35 is engineered for single inboard or outboard engine applications. The Veratron VMH 35 has an embedded NMEA 2000 gateway that distributes sensor data inputs such as fuel, trim, and tachometer to other devices like chartplotters.  This saves the need for an additional external converter.  Highly adaptable to a wide range of onboard networks, it's equipped with analog inputs, making it ideal for refitting with older engines.An integrated GPS makes the VMH 35 the perfect standalone navigation solution.  It integrates speed, compass, and position into the engine data information.  A dedicated Veratron IBS (Intelligent Battery System) input can provide critical 12V battery monitoring capabilities.The Veratron VMH 35 has a mineral glass front that's optically bonded to the sun-readable hybrid display.  A sleek, brushed stainless steel bezel surrounds the device and fits into classic and modern marine décors.  Because small boat consoles are often fully exposed, the round display is waterproof to IPX7 criteria, both front and back.  It fits a standard 3-3/8" panel cutout size.Features: Integrated high-performance GNSS receiver Integrated Analog to NMEA 2000 Gateway Waterproof to IPX7 Stylish black-glass design with brushed stainless-steel ring New generation sun-readable color hybrid display Intelligent Battery Sensor (IBS) port NMEA 2000® certified In the Box: VMH35 Gauge Mounting Spinlock Wire harness  Safety Instructions  *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 3-3/8" Gauge Type: Multifunction Series: VMH-35 Box Dimensions: 4"H x 6"W x 6"L WT: 0.75 lbs UPC: 7640178729773 Owner's Manual (pdf)Brochure (pdf)

Read more less

52MM (2-1/16") ViewLine Oil Temperature Gauge 120-300°F - Black Dial & BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Box Set: No Gauge Size: 2-1/16" Series: ViewLine Voltage - Input Range (Volts): 12/24 V Gauge Type: Oil Temp Box Dimensions: 5"H x 5"W x 5"L WT: 0.35 lbs UPC: 7640178723054 Owner's Manual (pdf)Brochure (pdf)

Read more less

52MM (2-1/16") ViewLine Transmission Oil Pressure 30 Bar/435 PSI - Black Dial & Round BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Voltage - Input Range (Volts): 12/24 V Series: ViewLine Gauge Type: Oil Pressure Gauge Size: 2-1/16" Box Set: No Box Dimensions: 3"H x 3"W x 4"L WT: 0.35 lbs UPC: 7640178723009 Owner's Manual (pdf)

Read more less

52MM (2-1/16") ViewLine Trim Indicator Gauge Up/Down - Black Dial & Round BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Series: ViewLine Gauge Type: Trim Guage Gauge Size: 2-1/16" Box Set: No Voltage - Input Range (Volts): 12/24 V Box Dimensions: 3"H x 3"W x 4"L WT: 0.35 lbs UPC: 7640178723085 Owner's Manual (pdf)

Read more less

Chesapeake White SS 4" Tachometer - 6000 RPM (Gas) (Inboard & I/O)Perimeter-lighted White dial with stylish Blue and White graphics, polished stainless steel bezel, contoured White pointer and domed glass lens.Electronic tachometers work by counting pulses generated by the ignition system, alternator, tach signal generator or magnetic pickup sender. The tach is hooked up to +12VDC, Ground and one of the signal sources listed.By selecting the right tach and setting the switch on the back to the correct position you let the tachometer know how many pulses are sent per each engine revolution.4" - Hole size: 3.375" (85mm)Specifications: Anti-scratch glass lens Plastic Cases for corrosion resistance and long life 12 VDC negative ground Can be adapted for 24 VDC systems Factory P/N TC9796*Sold as an Individual**Gauge Cover not IncludedThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Gauge Type: Tachometer Series: Chesapeake White Voltage - Input Range (Volts): 12/24 V Gauge Size: 4" Box Set: No Box Dimensions: 5"H x 6"W x 6"L WT: 0.7 lbs UPC: 759266338074 Quick Guide (pdf)

Read more less

Euro Black 4" Tachometer w/Systemcheck 7000 RPM (Gas) f/ Johnson / Evinrude Outboard)Perimeter-lighted Black dial with bold White graphics, Black aluminum bezel, contoured White pointer and flat glass lens.Electronic tachometers work by counting pulses generated by the ingition system, alternator, tach signal generator or magnetic pickup sender. The tach is hooked up to +12VDC, Ground and one of the signal sources listed above.By selecting the right tach and setting the switch on the back to the correct position you let the tachometer know how many pulses are sent per each engine revolution.These tachometers have a warning light system built into the dial that show off warning indicators when a fault is detected from the engine.4" - Hole size: 3.375" (85mm)For Engine Types:Johnson and Envinrude OutboardSystemCheck Warnings: No Oil Engine Overheat Check Engine Low Oil Specifications: Anti-scratch glass lens Plastic Cases for corrosion resistance and long life Perimeter-lighted Black dial Can be adapted for 24 VDC systems Factory P/N TC9951*Sold as an Individual**Gauge Cover not IncludedThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Gauge Type: Tachometer w/System Check Series: Euro Black Voltage - Input Range (Volts): 12/24 V Gauge Size: 4" Box Set: No Box Dimensions: 5"H x 6"W x 6"L WT: 0.7 lbs UPC: 759266328501 Quick Guide (pdf)

Read more less

LinkUp Analog to NMEA 2000 GatewayThe resistive-type LinkUp gateway provides an easy method to convert vessel and engine information to NMEA 2000.Easily installed, the LinkUp Gateway replaces the original wiring, delivering power to both the LinkUp device and sensor from the NMEA 2000 backbone while still being complaint with the NMEA 2000 certification requirements. Configuring the LinkUp Gateway is simple using a mobile device and the companion LinkUp Configuration App for Android or IOS.Each device has a built-in passive NFC antenna, so the parameters of the sensors are wirelessly configured to type, instance and warning threshold on the mobile device which is then "tapped" against the LinkUp device for instant data download. Features: User-friendly configuration through wireless interface and companion smartphone App Sensor Cable length - 25cm NMEA 2000 Cable length - 25 cm Tap to download parameters Mobile App for Android or IOS No power required to program No certification required Bi-directional communication, programming interface or data recovery Supported Sensors: Fuel Level Oil/Boost Pressure Fresh/Waste Water Level Oil/Gear Oil/Coolant Temperature Trim Tabs Rudder Angle Technical Specifications: Standard M12 NMEA 2000 plug LED Notification  Operating Voltage - 6 - 16.5V Nominal Voltage - 12 V (from NMEA 2000 network) IPX7 Rated Sensor Plug - Superseal Female 2 Pin Counterpart Sensor Plug - - Superseal Male 2 Pin *Sold as an Individual This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Owner's Manual (pdf)Brochure (pdf)

Read more less

52MM (2-1/16") ViewLine Tank Level Gauge E/F - 3-180 Ohm -  Black Dial & BezelVeratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use.  ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in identical color. Interchangeable bezel option.Features: 8 pole Tyco/Hirschmann MQS plug  Red LED Via Plus And Min Warning Light Operating voltage 8–32 V  Input signal: standard Ω values  Optional make-point switch can be connected  Reverse polarity protection  Anti-fog double lens  Front side protection rating IP67  52 mm installation diameter  50 mm installation depth  In the Box: Gauge Connection Cable Bezel Rubber Seal Spinlock Installation Instructions Safety Instructions *Sold as an IndividualThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Voltage - Input Range (Volts): 12/24 V Series: ViewLine Gauge Size: 2-1/16" Box Set: No Gauge Type: Tank Level Box Dimensions: 3"H x 3"W x 4"L WT: 0.3 lbs UPC: 7640178724983 Owner's Manual (pdf)

Read more less
