Communication - Mobile Broadband

TracPhone® V3HTS World’s fastest, lightest ultra-compact marine VSAT.  The rugged 37 cm TracPhone V3 hts offers global connectivity and crystal-clear voice calls via advanced next-generation high-throughput satellites (HTS) from Intelsat and SKY Perfect JSAT on the mini-VSAT Broadband SM HTS network. The result is an ultra-compact SATCOM solution that outperforms the leading competing 60-85 cm Ku-band antennas.Features: Ultra-high efficiency antenna using KVH’s RingFire™ design and groundbreaking dielectric rod feed ensures excellent Ku-band reception even in bad weather Advanced antenna controller for high-speed tracking Dynamic, gyro-stabilized system  seeks the optimum satellite within the mini-VSAT roadband HTS network and tracks it through the full dynamic motion experienced at sea The powerful ICM, with its high-throughput modem, Voice over IP (VoIP) adapter, versatile network  management software, and built-in Wi-Fi and Ethernet, is the streamlined all-in-one belowdecks unit that drives the TracPhone V3hts Service: Network: mini-VAST Broadband HTS Network Antenna Type: Ku-band Service Coverage Area: Seamless Worldwide Regions Specifications: Speed - Max: 6 Mbps/2 Mbps (down/up) Wireless: Yes Box Dimensions: 21"H x 24"W x 39"L WT: 74.3 lbs UPC: 028327013572 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Cellular/Wi-Fi World Band Galaxy AntennaThe Galaxy 5239 antenna is Shakespeare's smallest Galaxy antenna, but don't let the size fool you. This World-band antenna provides coverage for 2G/3G/4G and WLAN systems for Cellular, PCS, AWS and LTE frequencies, as well as 802.11n Wi-Fi. This compact, feature rich antenna is at home on virtually any watercraft, and is fitted with a stainless steel ferrule and N-connector that are compatible with nearly all Shakespeare 1in -14 threaded mounts.Features: Full Band (698 - 2700 MHz) Broadband 2G/3G/4G and WLAN systems Wi-Fi 802.11n compatible Designed for marine use Omni-directional antenna 3-4 dB Gain. Easy to install Includes FME Cables Specifications: Frequency: 698-960/1700-2700 MHz Input Impedence: 50 ohm Antenna Gain: 2-3dB @ 698-960/3-4dB @ 1700-2700 MHz VSWR: ≤ 1.8 Power Rating (W): 10 Polarization Type: Vertical Radiation: Omni-Directional Maximum Power (W): 100 Connector Type: N-female Dimension: 9.25" H x 2.625" D Color: White Operating Temperature (F): -22 to +176 Mounting: 1" x 14 Thread Mount Ground Plane: Internal Material: Fiberglass Specifications: Length (Inches): 9.25" Construction: Fiberglass Color: White Box Dimensions: 5"H x 5"W x 11"L WT: 1.8 lbs UPC: 719441900960

Read more less

5G Xtream System with 3 Antennas & 7M CableFor boat owners looking for ultra-fast internet on board, the new 5G Xtream from Digital Yacht offers 4G and 5G connectivity as well as integration with Starlink satellite systems for the best and most affordable blended internet afloat.The 5G Xtream can support 5G (shoreside) connection speeds up to 3.1GB/s but also integrates a 4G Cat 20 modem, which offers connectivity up to about 25NM from shore at speeds of up to 2GB/s. The system uses three external antennas with dual high-gain vertical antennas and a separate compact dome for the higher 5G frequencies. This MIMO technology and, critically, separate antennas give optimum performance. There’s support for dual SIMs with auto (failover) or manual switching between operators.The 5G Xtream features dual-band (2.4 and 5GHz) wireless connections, so users on board simply search for the secure wifi point and connect. There are also 4 LAN ports (10/100/1000 MB) for wired devices like smart TVs and a WAN port that is optimized for Starlink satellite connectivity, allowing the 5GX to act as a sophisticated and fast router for all on-board internet communications.The Wi-Fi router can also be configured to access marina wifi hotspots as an additional method of internet access. This also supports the very latest 5GHz marina wifi services, and there's also a high-gain external wifi antenna available as an accessory.For advanced users, the 5G Xtream allows for user management, VPNs, blacklists, and IOT applications. NMEA 0183/2000 data can also be connected using Digital Yacht’s LANLink devices. The integrated GPS allows for SMS reporting of boat position or even a geofence/drift setting when the boat is at anchor or in port.The Digital Yacht 5G Xtream is supplied as a complete solution with antennas, mounts, and cabling – all that’s additionally required is a cellular SIM.ConfigurationConfiguration is very simple. Just insert the SIM cards. The 5G Xtream has two standard SIM slots, and it is possible to fit two SIMs from two different network operators. By default, the 5G Xtream will query the SIM that is installed and automatically select the APN settings from its internal database.However, it is very important that users “lockdown” their wireless network with their network name (SSID) and wireless password. This task only takes a couple of minutes and is done via the 5G Xtream web interface.User InterfaceAccessing 5G Xtream functionality is done via an easy web interface. Any locally connected device can simply enter the IP address into the password-protected interface to set up functions, view traffic and logs, and configure wifi.Once set up, there should be no requirement to log in other than for diagnostics and configuration. Users simply access the internet through the wifi connection, just as they would in the home or office.Features: Ultra-fast 5G internet afloat solution with speeds up to 3.1GBs plus also integrates the latest 4G Cat 20 LTE MIMO technology with a range up to 25NM offshore (network dependent) and 4G connection speeds up to 2GBs Dual SIM slots with auto-failover or manual selection Two external, high-gain, wide-bandwidth antennas plus a compact high-gain dome antenna for higher 5G frequencies Dual-band integrated wifi router (2.4 & 5 GHz)—independently configurable Built-in GPS with an external patch antenna for IOT and tracking/anchor alarm applications 4 x LAN ports 1 x WAN port for additional internet connectivity, optimized for Starlink satellite systems Digital input/output connectivity for IoT/control applications SMS capability 12/24v Weight: 3800 gDimensions: 180 x 125 x 55 mm operation Specifications: Operating Temperature: -40 to +75 degrees C Dimensions: 180 x 125 x 55mm (excluding antennas) Weight: 3,8 kg Protection: IPX4 Technology: 5G Sub-6Ghz SA/NSA. Up to 2.1/3.3Gbps downlink (4×4 MIMO); 4G (LTE) CAT 20 up to 2GB/s 5G/LTE: 5G Sub-6Ghz SA/NSA. Up to 2.1/3.3Gbps downlink (4×4 MIMO); 4G (LTE) CAT 20 up to 2GB/s 3G/4G Fallback (Support bands): 5G (NSA): n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77; 5G (SA): n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78; 4G (LTE-FDD): B1, B3, B5, B7, B8, B20, B28, B32; 4G (LTE-TDD): B38, B40, B41, B42, B43 4G & 5G Antennas: Dual Wi-Fi band independent 2.4 & 5 GHz (maximum 150 connections); dual 48cm external wideband high gain MIMO supplied with 7-meter cables and mounting bases. (10 & 20m options available) PLUS additional 100mm dome antenna for 4 x 4 MIMO operation and optimized for 5G (7m cable only) Interfaces: 4 x LAN 10/100 Ethernet Port; 1 x WAN 10/100 Ethernet Port ; WiFi; 802.11 b/g/n/ac What’s in the Box? 1 x 5G Xtream Modem Unit 1 x DC Power/IO cable 2 x External antennas 2 x E179F antenna bases 2 x 7m LMR200 antenna cables (N male to N male) 1 x 5G dual element dome antenna with pole/1” adaptor mount and integrated 7m cables 2 x Internal wifi antennas 1 x Internal GPS antenna Options (sold separately): 1” antenna adaptors and range of mounts 10 & 20m LMR400 antenna cable packs for 4G antennas AC 110/220v power adaptor 4GXWL hi power external wifi option LANLink NMEA 0183/2000 interface Specifications: Speed - Max: 3.1GB/s Wireless: Yes Box Dimensions: 4"H x 10"W x 27"L WT: 10.15 lbs UPC: 703791696659

Read more less

Wi-Fi Booster for 4GXtream4GXtream is the latest, premium LTE (cellular) internet access onboard product with an NMEA 2000 interface.  It ships as a complete package with dual external antennas, deck mounting hardware, and cabling.  Alternative antenna mounts are available as options.Using MIMO technology and two external wide band LTE antennas, it offers fast connectivity at up to 300 MBs (network dependent).  It has a built-in dual band wifi router supporting multiple connections, dual SIM slots (with auto fail-over if required), built-in GPS (for IOT and tracking applications) as well as an NMEA 2000 interface for navigation and instrument data connectivity and wireless interfacing.  There’s also a Bluetooth interface for future connectivity applications.It will sit alongside our existing 4G Connect Pro as a premium product and is ideal for use on large yachts, workboats, tugs, and commercial ships where reliable, low-cost coastal internet and in-port connectivity are required. 4GXtream features independent dual band (2.4 & 5GHz) wifi for interconnection to mobile devices.  This also provides the connectivity for NMEA data so apps on mobile devices can utilize the boat's navigation and instrumentation data.For external hi-power wifi (to access shoreside hotspots) our booster WiFi kit is recommended which connects to the WAN port.  4GXtream can then act as a router for this connection and allow the user to switch from wifi to LTE.Features: Latest Cat 6 LTE MIMO technology with a range of up to 25NM offshore (network dependent) Dual SIM slots with auto fail-over or manual selection Two external, high gain, wide bandwidth antennas Dual-band integrated wifi router (2.4 & 5 GHz) – independently configurable Built in NMEA 2000 interface to transmit NMEA 2000 data over the wireless and wired network to compatible apps Built in GPS with external patch antenna for IOT and tracking applications Built in Bluetooth with antenna for future applications 3 x LAN ports 1 x WAN port for additional internet connectivity – eg: WL510 high power wifi system Digital input/output connectivity for IOT/control applications (Available Q3 2021) SMS addressable Brochure (pdf)

Read more less

4G Xtream Internet & NMEA 2000 SolutionDigital Yacht's 4G Xtream is the latest, premium LTE (cellular) Internet access product. It ships as a complete package with dual external antennas, deck mounting hardware, and cabling. Alternative antenna mounts are available as options.Using MIMO technology and two external wideband LTE antennas, it offers fast connectivity at up to 300 MBs (network dependent). It has a built-in dual-band wifi router supporting multiple connections, dual SIM slots (with auto-failover if required), built-in GPS (for IOT and tracking applications) as well as an NMEA 2000 interface for navigation and instrument data connectivity and wireless interfacing. There’s also a Bluetooth interface for future connectivity applications.Features: Latest Cat 6 LTE MIMO technology with a range up to 25NM offshore (network dependent) Dual SIM slots with auto-failover or manual selection Two external, high gain, wide bandwidth antennas Dual-band integrated wifi router (2.4 & 5 GHz) –independently configurable Built-in NMEA 2000 interface to transmit NMEA 2000 data over the wireless and wired network to compatible apps Built-in GPS with external patch antenna for IOT and tracking applications Built-in Bluetooth with antenna for future applications 3 x LAN ports 1 x WAN port for additional internet connectivity –eg: WL510 high power wifi system Digital input/output connectivity for IOT/control applications (Available Q4 2021) SMS addressable Brochure (pdf)

Read more less

Ultra-Compact TracPhone® V30 with DC-BDUThe wait is over. Ultra-compact, fast, and affordable VSAT for your boat!Live, work, and relax onboard… just like home, while TracPhone® V30 keeps you connected when you want to be. Stream HD content, chat via WhatsApp,™ connect with the office, get weather information, browse the Internet, check emails, whether you are at the dock, along the coast, or offshore. This 37 cm digital system makes VSAT accessible and affordable, delivering the highest speeds, fast and easy installation, next-generation technology, and flexible airtime plans. VSAT is within reach with this innovative solution that delivers: Rugged digital Satcom system with improved signal efficiency Data speeds as fast as 6 Mbps/2 Mbps (down/up) Choice of metered and unlimited use global airtime plans with no overages Highlights: The smallest, lightest, lowest powered maritime VSAT system Simple installation using a single new or existing coax cable, rotary joint for unlimited rotation, DC power (AC power option available), and compact VSAT-Hub belowdecks unit Global connectivity and crystal-clear voice calls via KVH’s mini-VSAT Broadband HTS network Powerful network management tools providing valuable insight and control over data usage via KVH Manager Optimized system performance thanks to KVH’s integrated IoT Proactive Performance Monitoring Providing Broadband Connectivity WorldwideKVH’s TracPhone HTS Network systems offer the fastest global broadband connections available via the mini-VSAT Broadband HTS network. Explore our coverage to see where we’re delivering affordable Internet access, IoT connectivity, real-time communications via video and voice, valuable operations data, news and entertainment, and more.Exclusive Technology: The Lightest, Ultra-fast, High-Efficiency Antenna  Global Connections, Unmatched Speed VSAT-Hub – Small, Fast, and Smart in Every Exclusive Multi-level Cybersecurity Program Precision Management of Your Data Improved Performance through Proactive Monitoring KVH OneCare Global Support Program myKVH & KVH ManagerThe secure myKVH™ portal offers easy access to a wide range of account details, reports, and the KVH Manager suite of tools. Enjoy unmatched transparency in data use and system performance, plus valuable tools to customize your data use with exclusive category controls, manage your network configuration and alerts, and more.Flexible Airtime PlansKVH offers affordable airtime options, including global metered and unlimited plans, dual high-speed and unlimited channel plans, and dual channels plus C-band. Choose the plan and system best suited to your unique needs and enjoy the convenience of flexible month-to-month subscriptions and more. Specifications: Wireless: Yes Speed - Max: 6 Mbps/2 Mbps (down/up) Box Dimensions: 21"H x 24"W x 30"L WT: 48 lbs UPC: 028327014166 Quick Guide (pdf)Brochure (pdf)

Read more less

Multi-WAN 7 Source Gigabit Router (Rackmountable) GB Ethernet 110/220VAC PowerAigean’s Multi-WAN routers enable networks to switch between multiple internet sources without adversely affecting the onboard local network. Coupled with advanced features such as failover and smart switching, a vessel’s connection to the internet is more robust, secure, and faster than with a single-source configuration.Most modern vessels are equipped with multiple means of connecting to the internet, via ship-to-shore Wi-Fi, cellular, and satellite providers. Aigean’s Multi-WAN routers couple these sources together, creating a seamless experience, ensuring you are always connected.Aigean’s MFR models are extremely easy to use and get started with. Forget tinkering with networking settings to get your system online, no networking knowledge is required.Features: Program alerts and limits on incoming sources to prevent airtime overages Easily switch between mulitple internet sources Simple failover capability to ensure the nework is always online Full Gigabit transfer speeds on all ports Intel x86 hardware for maximum performance and longevity Desk or Rack Mount capable 1 year warranty from the date of purchase for parts and labor.   Specifications: Speed - Max: 2.9 GHz Wireless: Yes Box Dimensions: 6"H x 14"W x 21"L WT: 11 lbs Quick Guide (pdf)Brochure (pdf)

Read more less
