Electrical - Accessories

1810Features: Accurate - used with the Vessel Systems Monitor VSM 422 PN 1800 - can be precisely calibrated for each tank* Reliable - SSI Technologies, Inc. Fluid-Trac® is non-contacting eliminating any mechanical moving parts that can wear and cause intermittent or complete signal loss Digital filtering - Eliminates errors due to liquids sloshing in mobile tanks * Calibrated for use with Blue Sea Systems Vessel Systems Monitor VSM 422 only WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Original Equipment Quality Replacement Solenoid for BRP-OMC & Evinrude E-TECReplacement solenoid that will fit BRP-OMC, EVINRUDE E-TEC, 2010-UP 15 HP-300 HP.Replaces:BRP-OMC 587020*ARCO Assurance 12-month part and labor warranty protectionThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Type: Parts Box Dimensions: 3"H x 3"W x 3"L WT: 0.4 lbs UPC: 693006010526

Read more less

Flip Pro Multi - Dual USB-C & 12V Power SocketCombining the features of the high-power Flip Pro Max and 12V Power Sockets into a beautiful multi-power solution.When not in use, the spring-loaded caps remain tightly closed, protecting the ports from the elements.Universal: Universal fit for any USB-C connectors Fast charge (60W max) up to 2 devices at a time Marine Ready: IPX4 waterproof with the cover closed UV resistant 316 stainless steel hinge and spring Electrical Information: 120 -150W max power (12V system only) Input voltage: 10-30V DC (12/24V System) Input current Max: 6A (10A fuse recommended) Key Information: To maximize charge performance, use the cable supplied with your tablet, phone, etc. (C to C, or C-lightning) Phones charge at the same speed on either a 12 or 24V system, but a 24V system must be used to get the full 60W output suitable for laptops Quick Guide (pdf)

Read more less

XD Relay Link BusbarThis tin-plated copper is to ensure reliable circuit connectivity and an anti-corrosive feature that will keep it long-lasting.ApplicationsLink Together XD Single, Dual, and Triple XD relays to each other in multiple configurations and even to Egis's 8700 Mechanical Disconnect. Linking relays together creates compact installations and allows for robust circuit switching and battery management.Features: Great electrical conductivity with anti-corrosion tin plating keeps connections reliable This bus bar is tough and built to withstand high amperage loads and resist deformation from nut-tightening Save install space by linking XD Relays together for even more capability and maintain a professional-looking install Specifications: Continuous Current (Amps): 500 Max Voltage (VDC): 72 Material: Tin-plated copper Size (L x W): 47.8mm x 22.8mm  Thickness: 2.8mm (1/8”) Terminal Stud Hole Size: 10.5mm (3/8”) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

XD Series Single Flex 2 Relay-ACR with Knobs - DTM ConnectorThis Egis relay provides a 35-75% reduction in mounting space and product weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. The relay is expandable with link and cross-link busbars to additional dual, triple, or single XD relays. Also, the relay supports 2 or 3 battery systems with standard busbar interconnect accessories.Applications:  Improved replacement/alternative to legacy solenoids and remote battery switches; Wire-for-wire compatible with Blue Sea ML-solenoid and ML-remote battery switch products Forward-facing input studs make landing large wires easily, and a protective cover with integrated label recesses enables easy identification while providing anti-contact short protection Features: Bullet-proof construction, sealed to IP67/IP6K9K, and high temperature electronics and materials allow mounting anywhere; Stainless steel cable lug studs; Large mounting holes accept 1/4-20 / M6 attachment hardware The intuitive manual control option simplifies operation and increases awareness of the state of the manual override and whether the device is being left in a locked-off or locked-on state (not available on competitive solutions) Simple programmability via simple dip switches allows each relay function significant flexibility for OEMs and installers Plug-and-play compatible with Legacy competitor products: Single, dual, and triple relay options are available with DTM/ATM connector pins for pin compatibility with ML Series bi-stable relays 90-95% less off-state current compared to competitive products and system solutions that require multiple devices for similar functionality Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Mechanical Switching Life: 1,000,000 cycles Voltage Range (VDC): 8-36 Off-State Current Draw (mA): 1.3 State Change Current: 5A @ 12 VDC; 3A @ 24 VDC Focal Features:Led Status DisplayThe easy-to-see front-facing LED indicator provides visual device status, and the remote LED replicates the local on-device LED. 3-Position Manual OverrideForce each relay open or closed, and optionally leave the knob in either position to lock the relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for the included weatherproof label set make circuit and relay identification easy. Blank labels for custom applications. Protective Cover IncludedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground. Stainless Hardware Corrosion is no issue with quality stainless steel studs and self-locking flanged nuts.ProgrammableVia dip switches located under the protective cover. An easy-to-use configuration guide on the reverse makes custom settings a breeze to configure for a wide variety of applications. Smaller FootprintXD relays offer a high amp rating in a smaller package than competitive solutions, reducing installation space requirements to a minimum. Integrated VentHigh-quality Gortex vents regulate internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

Flip Pro Plus Fast Charge USB-A & USB-C SocketThe revolutionary ultra-fast combination USB A & USB C charger.Flip Pro Plus is designed for use with either a 12V or 24V input and features 1x 60W USB-C and 1x36W USB-A charging ports for maximum choice and performance. Juggling different devices with different cables? Then this is the option.Features: 12/24V fast charge, dual USB socket Redesign to match other Flip Pro aesthetics Low profile Type A/C dual USB charger The Flip Pro Plus is a combination of Scanstrut's most sought-after chargers, designed to be used with either a 12V or 24V input, and features 1x USB-A and 1x USB-C to create a rapid, universal, ultra-fast charging solution. The Flip Pro Plus is a redesign of Scanstrut’s classic Flip Pro to ensure the boat's aesthetics stay aligned with Scanstrut's other designs in the Flip Pro range.  When not in use, the spring-loaded caps remain tightly closed, protecting the ports from the elements.Featuring a super-compact footprint that matches the rest of Scanstrut’s Flip Pro range, it is constructed from premium, marine-grade materials. Flip Pro Plus has been rigorously tested and is IPX4 waterproof, making it completely washdown-ready.Flip Pro Plus is FAST! It will charge at 36W on a 12V system or up to 60W on a 24V. With a PD chip, this charger is truly universal, making it perfect for charging modern laptops via the USB-C port. It is also designed for charging large tablets, offering an effortless charge for both an iPad Pro & iPhone at the same time.USB – C output: 60W max on 24V system 36W max on 12V system USB-A – A output:36W maxThe install cut-out matches Scanstrut's Flip Pro Max, Duo, and Multi USB sockets (32mm (1 1/8”) for a seamless look across the range. Now users can keep up with the heavier power draws of modern electronic devices while keeping premium, universal USB chargers all around the boat.Universal Universal fit for any USB-A or USB-C connectors Fast charge up to 2 devices at a time Easy Install, using a standard USB mounting hole - 32mm (1 1/8”) Is supplied with an optional front mount bezel Washdown Proof IPX4 waterproof with the cover closed Marine Ready PCB /or electronic with a protective coating UV resistant Plastics 316 stainless hinge and spring Electrical Information Input voltage: 10-30V DC (12/24V System) Input current Max: 6A (10A fuse recommended) Standby power draw: 0.01W Important informationThe charge cable supplied with the device (tablet, phone, action camera, etc) must be used to achieve maximum charge performance from this charger. Phones will charge at the same speed, whether on a 12V or 24V input voltage system. However, a 24V system must be used to get the full 60W output suitable for fast-charging laptops. Specifications: Type: Chargers Box Dimensions: 3"H x 4"W x 4"L WT: 0.2 lbs UPC: 5060114798878

Read more less

ROKK 10W Wireless Active Charging Cradle for Phone The IPX6 waterproof 12/24V Qi certified waterproof wireless charging range enables wireless charging for the outdoor environment, without the need for phone charging cables.  Designed from the ground up, this is the world’s first waterproof wireless charge system created specifically for use onboard. The unique technology is housed in an IPX6, fully encapsulated and sealed unit.The simple one-handed operation allows you to dock your phone easily and instantly start charging, perfect for boat consoles or any vehicle working outside in the elements.  No connection is needed.The high-grip, self-aligning jaws ensure your phone is held tightly and in the optimum charging position every time.Featuring Qi-certified wireless charging technology and a “Smart” LED that indicates when your phone is charging.  Throw in foreign object detection and thermal cut-off and you’re guaranteed safe, reliable charging in all environments.Compatible with wireless charging-enabled phones of all sizes from all major brands including Samsung, Apple, and many more.  Charging is also possible through non-metallic, waterproof cases.Our new upgraded 10W chargers are up to 60% faster and have been designed for the latest generation of power-hungry devices and apps.Our improvements don’t just stop there, now featuring easier phone alignment with a larger charging area, and electrical componentry that has been enhanced to significantly improve your phone's charge times, even in the harshest outdoor environments.With the same great look, ROKK Wireless is tried and tested in all corners of the globe in all weathers, and conditions.Case Compatibility:ROKK wireless is designed to work with most slimline phone cases up to .11" (3mm)Features: Installation is simple on any boat, RV, ATV or outdoor location.  Four screws secure the unit onto any flat surface with a simple installation guide and drilling template.  A waterproof cable pass-through completes the IPX6 sealed installation. Compatible with all Qi Wirelessly charging electronics. Includes a “Smart” LED that indicates when your phone is charging.  Throw in foreign object detection and thermal cut-off and you’re guaranteed safe, reliable charging in all environments.  Technical Specifications: Input Voltage Range - 10-30V DC (12/24V system)  Input current max - 2A   Output Power - 10W (9V,1.1A) IPX6 Waterproof Qi-certified wireless charging Protection - UV Resistant Dimensions (W x L) - 2.9" (74mm) x 8.1" (206mm) In the Box: Charger/Mount Instruction manual  *Sold as an Individual Specifications: Type: Chargers Box Dimensions: 2"H x 3"W x 9"L WT: 0.6 lbs UPC: 5060114797932 Quick Guide (pdf)

Read more less

65A PVC Coated Continuous Duty SolenoidRemotely switch high amperage loads with a low amperage on-off switch.Features: Continuous duty, 65A at 12V DC Intermittent rating 100A: 10 seconds Copper #10-32 thread signal terminals Copper 5/16”-24 thread contact terminals PVC coated steel case Bracket mounting holes 5/16” x 19/32”, 2-13/64” on centers UL and CE approved Same as Cole Hersee part number 24117-01 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

APS-70 Automatic Power Selector - 70AThe Automatic Power Selector (APS) is a solid-state device that enables the installation of a seamless, redundant power system for critical electronic loads. It selects the higher voltage of two independent DC power sources and routes power to the load. Should one source falter or fail, the other will automatically supply the load with no transfer delay, and the operation continues uninterrupted.Two independent power sources are wired to the APS and routed as a single output to the vital load. Alarm sense wires can be easily attached to input studs, providing a loss of power source signal. Features: Easy installation Rugged, rust-proof anodized aluminum case Specifications: Max Loads: 70 amps Voltage Rating: 6 – 50 VDC, neg. ground Stud Terminal Size: 6mm Dimensions (inches): 3.25 x 4.5 x 3.1 Weight (lbs): 2 Quick Guide (pdf)

Read more less

DTP Deutsch Socket for 14-12 AWG Wire - Size 12 Contact (25 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability which are just a few of the reasons that the professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is the fact that they are simple to use and require little time for installation.Features: Easy to install Field serviceable  Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics:Hand-insertable contactsCompliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized Specifications: Cavity Style: Plug (socket) Connector Type: DTP Wire Size: 14-12 AWG Current Rating: 25 Package Size: 25 Contact Size: 12 Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

DTP Deutsch Socket for 14-12 AWG Wire - Size 12 Contact (10 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability which are just a few of the reasons that the professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is the fact that they are simple to use and require little time for installation.Features: Easy to install Field serviceable  Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality  Characteristics:Hand-insertable contacts Compliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized Specifications: Cavity Style: Plug (socket) Connector Type: DTP Wire Size: 14-12 AWG Current Rating: 25 Package Size: 10 Contact Size: 12 Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

ROKK 10W Edge Wireless Phone Charging MountThe IPX6 waterproof 12/24V Qi certified waterproof wireless charging range enables wireless charging for the outdoor environment without needing phone charging cables.  Designed from the ground up, this is the world’s first waterproof wireless charge system created specifically for use on board, with the unique technology housed in an IPX6, fully encapsulated and sealed unit.Right up to the Edge - with the smallest footprint, Edge now means you have even more choice of how and where you install your phone mount and charger combo.  Crowded consoles, side-mounting, and flat and vertical surfaces are all suitable.Put your phone on its Edge - Rotate it from portrait to landscape to view your favorite navigation app or simply fine-tune the position for the optimum viewing angle.12/24V and IPX6 waterproof, ROKK Wireless – Edge is perfect for boat consoles tight on space or any vehicle working outside in the elements, with the simple one-handed operation you can easily dock and instantly start charging your phone.  No cable is required.The self-aligning, high-grip jaws accommodate all wireless charging phones and securely hold your device in the optimum charging position every time.  Couple this with the innovative adjustable body of Edge and you’ll have your phone fully charged, right where you need it.Install Edge 10W on any surface: a secure 3-point fixing system and a footprint of just 50mm (1.96”) diameter maximize your choice of location and a watertight cable pass-through completes the install.Our upgraded 10W chargers are up to 60% faster and have been designed for the latest generation of power-hungry devices and apps.Our improvements don’t just stop there, now featuring easier phone alignment with a larger charging area, and electrical componentry that has been enhanced to significantly improve your phone's charge times, even in the harshest outdoor environments.With the same great look, ROKK Wireless is tried and tested in all corners of the globe in all weathers, and conditions.Featuring Qi-certified wireless technology and a “Smart” LED that indicates when your phone is charging.  Throw in foreign object detection and thermal cut-off and you’re guaranteed safe, reliable charging in all environments.  Charging is also possible through non-metallic, waterproof cases. Case Compatibility:ROKK wireless is designed to work with most slimline phone cases up to .11" (3mm)Features: Install Edge on any surface - a secure 3-point fixing system and a footprint of just 50mm (1.96”) diameter maximize your choice of location and a watertight cable pass-through completes the install. Compatible with all Qi Wirelessly charging electronics. Includes a “Smart” LED that indicates when your phone is charging.  Throw in foreign object detection and thermal cut-off and you’re guaranteed safe, reliable charging in all environments.  Technical Specifications: Input Voltage Range - 10-30V DC (12/24V system)  Input current max - 2A   Output Power - 10W (9V,1A) IPX6 Waterproof Qi-certified wireless charging Protection - UV Resistant Dimensions (H x L) - 7.71" (196mm) x 3.7" (94mm) In the Box: Charger/Mount Instruction manual  *Sold as an Individual Specifications: Type: Chargers Box Dimensions: 3"H x 6"W x 7"L WT: 1.1 lbs UPC: 5060114797949 Quick Guide (pdf)

Read more less
