Electrical - Accessories

Smart Battery Sense Long Range (Up to 10M)The VE.Bus Smart dongle is a Bluetooth Smart enabled VE.Bus interface, with battery temperature-and-voltage sensing. It communicates system information straight to your smart phone - using the free-to-use VictronConnect app.  When used with Multi- inverter/chargers the dongle provides on-battery temperature and voltage sensing capabilities - allowing compensation for possible cable losses which can occur during charging and discharging. Temperature sensing allows accurate temperature-compensation during battery charge cycles. The dongle is, at present, the only way to add an “on-battery” sensing capability to the MultiPlus-II models, if they are not also connected to a GX device and CANbus battery.The dongle can be used in systems with or without a GX device - such as the CCGX. In systems with a GX device, and another source of temperature and voltage data (eg from a CANbus battery), the CCGX data will override temperature and voltage information from the dongle. In this role the dongle will still provide live-information via its VictronConnect interface; and it will provide firmware updates without requiring an internet connection.When the dongle is used in systems which do not have a GX device, the dongle's voltage and temperature data becomes the primary source of that information, and can be used by other connected devices for voltage compensation.In systems with a Multiplus-II, dongle and GX device, but no other source of temperature and voltage, the data from the dongle will also be used.At this time, the VE.Bus Smart dongle cannot send its temperature and voltage data as part of a VE.Smart network.The VE.Bus Smart dongle is able to sense battery temperature in two ways: The default method is the dongle's on-board temperature sensor. When the dongle is mounted directly onto the battery case (using its adhesive attachment) it will sense the battery temperature directly from the battery casing. The second method - which provides improved battery temperature sensing - is available by using an optional battery-terminal mounted sensor. When this sensor is connected, the default sensor is overridden and the dongle will use this method instead.What's in the Box? VE.Bus Smart Dongle Red battery (+) connection wire with 10mm eyelet and inline fuse. Black battery (-) connection wire with 10mm eyelet Connector block with screw terminals Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

BF32 Female Connector/Gasket Kit This SmartPlug service kit provides electrical components, hardware and gaskets.Compatible With:BF32 SmartPlug Features: Ease of Use – Easily replaces missing or damaged pieces Interchangeable with SmartPlug Connectors *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Parts Box Dimensions: 4"H x 5"W x 6"L WT: 0.5 lbs UPC: 682500440403

Read more less

TILE USB-C Interior Charging Socket - 12/24V - Black BezelTILE Series offers sleek, high-performance charging solutions designed specifically for marine interiors. These chargers blend seamlessly into luxury marine environments. Featuring a compact 40mm (1.57”) footprint and requiring just a 29mm (1.14”) hole saw for easy installation, the TILE Series combines functionality and style, making it the ideal choice for modernizing your vessel’s interior. Enhance your boat’s space with this practical, sophisticated solution for charging your everyday devices.Tile USB is FAST! It will charge at 36W on a 12V system or up to 60W on a 24V system. This makes it perfect for charging modern laptops and large tablets, phones, and any other USB-C-powered devices onboard.USB–C output60W max on 24V system, 36W max on 12V systemUniversalUniversal fit for any USB-C connectors. Fast charge (60W max) up to 2 devices at a time.Important informationTo maximize charge performance, use the cable supplied with your tablet, phone, etc. (C to C, or C-lightning) Phones charge at the same speed on either a 12 or 24V system, but a 24V system must be used to get the full 60W output suitable for laptops.WARNINGTILE USB products are designed for interior use only. Do not install in locations where water exposure is possible, as this may lead to product failure.Features: 12V & 24V  USB-A and USB-C Ultra-low profile Front fit Tiny footprint Available in 316 stainless steel or matte black Conformal coated electronics, protected against moisture Modernize your boat's interiors Specifications: Input Voltage Range: 10-32V DC (12/24V system) Input current max: Max 6A (10A fuse recommended)  Output (Type C): 12V System: 5V=3A, 9V=3A, 12V=3A Max, 24V System: 5V=3A, 9V=3A, 12V=3A, 15V=3A, 20V=3A Max Standby Power: 0.01W Certification: CE, FCC, UKCA, C-Tick, ROHS, WEE

Read more less

Flip Pro Duo - USB-A & USB-C with 12V Power SocketCombining the features of the high-power Flip Pro USB-A / C charger and 12V power sockets into a beautiful multi-power solution. When not in use, the spring-loaded caps remain tightly closed, protecting the ports from the elements.Universal: Universal fit for any USB-A & C connectors Fast charge (60W max) up to 2 devices at a time Marine Ready: IPX4 waterproof with the cover closed UV resistant 316 stainless steel hinge and spring Installation:Easy Install, using a standard Ø32mm (1.25 in.) hole sawSpecifications: Watt Max. Power: 120 -150W max power, 12V system only (12V Socket) Input Voltage: 10-32V DC Input Current Max: 6A (10A fuse recommended) Output Type C (12V System): 5V 3A, 9V 3A, and 12V 3A MAX Output Type C (24V System): 5V 3A, 9V 3A, 12V 3A, 15V 3A, and 20V 3A MAX Output Type A Max: 5V 1.5A, 9V 1.5A, and 12V 1.5A/3A MAX Waterproof Rating: IPX4 Standby Draw: 0.01W Certification: CE, FCC, UKCA, C-Tick, and ROHS Quick Guide (pdf)

Read more less

VE-Can to CAN-bus BMS Type B Cable - 1.8M (5.9')Use this cable to connect a CAN bus-enabled battery, not from Victron, to a Victron system. There are two types, A and B. See the manual for details on which cable to use for which brand of batteries.Please contact your dealer for any returns, repairs or support issues related to this product.

Read more less

SmartRemoteChecking your Mastervolt product has never been easierThe SmartRemote completes any MasterBus or CZone* system. With its good looks and compact size, the SmartRemote is ideal as a remote panel in entry level power systems or as a local device readout in larger systems. Applications include boats, vehicles and stationary systems.Local device monitoringMastervolt products enable intelligent power systems with advanced multi-device monitoring and control. However, in situations where the local device readout is hard to reach or too limited, an entry-level color display for local device monitoring would be ideal. This is where the SmartRemote comes in.Easy to useThe SmartRemote single-device display is unique in many ways. It communicates with Mastervolt devices**, shows key parameters, allows simple device settings and is fun to use. Checking your batteries, adjusting your shore fuse or controlling your Mastervolt charger/inverter has never been easier.Easy to installThe SmartRemote display can be panel mounted or may be integrated into a Blue Sea Systems Custom 360 bezel. Connection is easy as 1-2-3: simply click the network cable into a Mastervolt device and off you go.Features: Full color display for local device monitoring. Displays four key parameters. Control key device functions. CZone* and MasterBus network compatible. Universal, easy mounting. Plug & Play – no configuration, no power supply needed. Blue Sea Systems Custom 360 integration. Think Global, Act Local… Smart Remote!(**) SmartRemote supports CombiMaster communication over the MasterBus network. Support for Mastervolt battery chargers, inverters, charger/inverters, MLI batteries and MasterShunt devices is under development. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

XD Series Single Flex 2 ACR-Relay with Knobs - DTM ConnThis Egis relay provides a 35-75% reduction in mounting space and product weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Also, this relay eliminates dead-start batteries by sharing charging on either of two batteries and isolating batteries when no charge sources are present.Applications:  Supports multiple engines or independent charge systems by incorporating two independent start or engine isolation inputs to allow isolation of charge sources when both are active to maximize charging performance.  Expandable with link and cross-link busbars to additional dual, triple, or single XD relays; supports 2 or 3 battery systems with standard busbar interconnect accessories. Features: Bullet-proof construction, sealed to IP67/IP6K9K, and high temperature electronics and materials allow mounting anywhere; Stainless steel cable lug studs; Large mounting holes accept 1/4-20 / M6 attachment hardware The intuitive manual control option simplifies operation and increases awareness of the state of the manual override and whether the device is being left in a locked-off or locked-on state (not available on competitive solutions) Simple programmability via simple dip switches allows each relay function significant flexibility for OEMs and installers Plug-and-play compatible with Legacy competitor products: Single, dual, and triple relay options are available with DTM/ATM connector pins for pin compatibility with ML Series bi-stable relays 90-95% less off-state current compared to competitive products and system solutions that require multiple devices for similar functionality Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Mechanical Switching Life: 1,000,000 Cycles Voltage Range (VDC): 8-36 Off-State Current Draw (mA): 1.3 State Change Current: 5A @ 12 VDC; 3A @ 24 VDC Focal Features:Led Status DisplayThe easy-to-see front-facing LED indicator provides visual device status, and the remote LED replicates the local on-device LED. 3-Position Manual OverrideForce each relay open or closed, and optionally leave the knob in either position to lock the relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for the included weatherproof label set make circuit and relay identification easy. Blank labels for custom applications. Protective Cover IncludedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground. Stainless Hardware Corrosion is no issue with quality stainless steel studs and self-locking flanged nuts.ProgrammableVia dip switches located under the protective cover. An easy-to-use configuration guide on the reverse makes custom settings a breeze to configure for a wide variety of applications. Smaller FootprintXD relays offer a high amp rating in a smaller package than competitive solutions, reducing installation space requirements to a minimum. Integrated VentHigh-quality Gortex vents regulate internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

1520 Remote Control Switch - 360 Panel - 3 BlankThe 360 Panel System Blank switch panel accepts three Carling Contura switches that are sold separately. The blank switch panel accepts 3 switches. Features: 360 Panel System Blank switch panel accepts 3 Carling Contura switches Backlit labels Lockout slides Switches sold separately Specifications: Mounting Type: Panel Mount Material: Plastic Terminal: Screw Voltage: 12V DC Connector Type: Quick Connect Operation Mode: ON-OFF Product Dimensions: 7.87 x 3.94 x 1.97 inches WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Mains Cord NEMA 5-15P 120VAC for Smart IP43 SKYLLA-S Phoenix - 2M Power CordThis plug is for 120V systems.  One end plugs into the Phoenix Smart IP43 charger.  The cord is 2M long and the male plug end is a NEMA 5-15P plug.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

SolidSwitch 104 for DC Loads Up To 70V/4AFeatures: The SolidSwitch 104 will switch DC loads of up to 70V/4A and can be controlled by a low-power digital signal. The DC load can be resistive, capacitive or inductive (such as the coil of a high-power contactor). The SolidSwitch is not reverse polarity protected and not short circuit proof. Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

RJ12 UTP Cable - 0.3MA cable to connect the BMV shunt to the BMV head unit. An RJ12 cable ships standard with a BMV battery monitor, but if this cable is too long or too short, it can be replaced by one of these cables, lengths available from 0.3 up to 30 meters.Please contact your dealer for any returns, repairs or support issues related to this product.

Read more less

2M Extension Cable - 25AVictron's 2-meter extension cable is an accessory for the Blue Smart IP65 Charger with a DC connector.Specifications: Length: 2M 25A

Read more less
