Electrical - Battery Management

BatteryProtect 48V - 100AThe BatteryProtect disconnects the battery from nonessential loads before it is completely discharged (which would damage the battery) or before it has insufficient power left to crank the engine.The BatteryProtect is a unidirectional device. It can only deal with current in one direction, so either current to a load, or current from a charger, but not both currents at the same time. In addition to this, current can only flow from the Battery terminal to the Load terminal. In case of use with a load, the battery connects to the Battery terminal, and in case of use with a charger, the charger connects to the Battery terminal.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

SmartSolar MPPT 150/100-TR VE.CanThe MPPT VE.Can SmartSolar charger uses the latest and fastest technology to convert energy from a solar array into energy that optimally charges battery banks.The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulfated or otherwise damaged.MPPT: Ultra Fast Maximum Power Point TrackingThe MPPT VE.Can SmartSolar charger connects to a PV array of 150 or 250 Volt Voc and will automatically detect and charge your 12, 24, or 48V battery bank with current ranging from 70 to 100A depending on the model.The charge settings are fully programmable and can even be set up for different battery chemistries, like lead-acid, lithium, and others.Control Your Charger RemotelyThe MPPT VE.Can SmartSolar charger can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, and historical data.Daisy Chain Additional UnitsThe VE.Can SmartSolar charger is equipped with CAN bus ports. This allows for communication with additional VE.Can SmartSolar chargers. The additional units are simply "daisy-chained" to each other with a single RJ45 cable between the individual units.When connected to each other, all individual VE.Can SmartSolar chargers, will synchronize their charge stages. They can also send their data, via a single cable, to a GX monitoring device.Remote Monitoring and ControlIf the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your solar charger(s).SmartSolar Control DisplayThe VE.Can SmartSolar charger is also equipped with a VE.Direct port like our other MPPT solar chargers. This port can be for single-unit monitoring or for streetlight control. The remote on/off connector can be externally controlled by a third-party device like a lithium battery. An optional plug-in LCD display/control provides live data, setup, and management, straight from the face of the device.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Filax 2 Transfer Switch 110V/50Hz-120V/60HzFilax: the ultra-fast transfer switch. The Filax has been designed to switch sensitive loads, such as computers or modern entertainment equipment from one AC source to another. The priority source typically is the mains, a generator, or shore power. The alternate source typically is an inverter. With its switching time of less than 20 milliseconds, sensitive loads will continue to operate without disruption. The Filax is not intended to supply high-power household equipment like washing machines or electric motors.Please contact your dealer for any returns, repairs or support issues related to this product.

Read more less

Lynx Smart BMS 1000 NG (M10) MGMT SystemThe Lynx Smart BMS NG is a dedicated Battery Management System (BMS) designed specifically for the Victron Lithium NG batteries. These batteries utilize Lithium Iron Phosphate (LiFePO4) technology and are available in 12.8 V, 25.6 V, and 51.2 V variants with various capacities. They can be configured in series, parallel, and series/parallel arrangements, allowing for the creation of battery banks with system voltages of 12V, 24V, or 48V. The maximum number of batteries in a single system is 50, enabling a maximum energy storage of 192kWh in a 12V system and up to 384kWh in a 24V and 48V system. For comprehensive details about these batteries, visit the Victron Lithium NG battery product page. Out of the various BMSes available* for the Lithium NG batteries, the Lynx Smart BMS NG is the most feature-rich and complete option and integrates seamlessly with other M10 products in the Lynx Distributor system. It is available in 500 A (M10) and 1000 A (M10) versions1).Built-in 500 A or 1000 A Contactor  Lynx Smart BMS NG 500A A Lynx Smart BMS NG 1000A  Available in 500 A (M10) and 1000 A (M10) versions Acts as a secondary safety system to protect the battery in case primary controls (ATC, ATD, and/or DVCC) fail Suitable as a remote controllable main system switch Pre-charge Circuit  Prevents high inrush currents when connecting capacitive loads like inverters Eliminates the need for external pre-charging devices Monitoring & Control  Bluetooth connectivity for monitoring and control via the VictronConnect App or VE.Can connectivity in combination with GX devices such as the Cerbo GX or Ekrano GX and the VRM portal Readout of cell voltages and temperatures also on GX devices and the VRM portal Built-in battery monitor provides data such as state of charge, voltage, current, historical data, status info, and more in real-time Diagnostic at a glance with Instant Readout DVCC Closed Loop Control as well as ATC/ATD Contacts  Compatible Victron inverter/chargers, the Orion XS 12/12-50A DC-DC battery charger, and solar charge controllers are automatically controlled via a connected GX device and DVCC. ATC/ATD contacts can be used to control other chargers and loads that have a remote on/off port Programmable Relay  Can be used either as an alarm relay (combined with the pre-alarm) or to control an alternator via its external regulator (ignition cable) Features Alternator ATC mode for safe alternator disconnection before battery disconnects AUX Terminal  Onboard auxiliary power supply (1.1 A @ system voltage) for powering specific loads (i.e. a GX device) post-BMS shutdown Automatic shutdown of BMS and AUX connection if no charge voltage is detected within 5 minutes after a low voltage event VE.Can and NMEA 2000 Data Communication  Easy connection and communication with GX devices via VE.Can using a standard RJ45 network cable Integration into marine networks via NMEA 2000 protocol (requires a VE.Can to NMEA 2000 micro-C male cable) Lynx Distributor Fuse Monitoring  Monitor fuse status of up to 4 connected Lynx Distributors via VictronConnect or GX devices Receive alarms in case of blown fuses 1) Up to 5 BMS-es can be paralleled. This requires a firmware update, expected in Q3 2024.SpecificationsPower: Battery Voltage Range: 9 – 60 VDC  Maximum Input Voltage: 75 VDC  Supported System Voltages: 12, 24, or 48 V  Reverse Polarity Protection: No  Main Safety Contactor Continuous Current Rating: 1000 A continuous  Main Safety Contactor Peak Current Rating: 1200 A for 5 minutes Power Consumption OFF Mode: 0.3 mA for all system voltages  Power Consumption in Standby Mode: Approximately 0.6 W (50 mA at 12 V)  Power Consumption in ON Mode: Approximately 4.2 W (350 mA at 12 V) depending on the state of the relays Minimum Load Resistance for Pre-Charging: 10 Ω and above for 12 V systems 20 Ω and above for 24 V and 48 V systems  AUX Output Maximum Current Rating: 1.1 A continuous, protected by resettable fuse  Allow-to-Charge Port Maximum Current Rating: 0.5 A at 60 VDC, protected by resettable fuse  Allow-to-Discharge Port Maximum Current Rating: 0.5 A at 60VDC, protected by resettable fuse Alarm Relay (SPDT) Maximum Current Rating: 2 A at 60 VDC Connections: Busbar: M10 (Torque: 33 Nm) – can be combined with all M10 Lynx products  VE.Can: RJ45  I/O: Removable multi-connector with screw terminals  Battery BTV Cables: Male and female circular 3-pole connector with M8 screw ring Up to 50 batteries can be connected in one system  Lynx Distributor Fuse Monitoring (up to 4 modules): RJ10 (cable ships with each Lynx Distributor) Physical: Enclosure Material: ABS  Enclosure Dimensions (H x W x D): 230 x 180 x 100 mm Unit Weight: 2.7 kg  Busbar Material: Tinned copper  Busbar Dimensions (H x W): 8 x 30 mm Environmental: Operating Temperature Range: -40 °C to +60 °C  Storage Temperature Range: -40 °C to +60 °C  Humidity: Max. 95 % (non-condensing)  Protection Class: IP22 Standards: Safety: EN-IEC 63000:2018  EMC: EN-IEC 61000-6-3:2007/A1:2011/AC:2012  QMS: NEN-EN-ISO 9001:2015 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

BlueSolar PWM-Light Charge Controller - 12/24V - 20AMPFeatures: Load output with low battery voltage disconnect function. Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable. Load output protected against over load and short circuit. Protected against reverse polarity connection of the solar array and/or battery. Day/night timing options: see manual for details Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less

60 AMP MPPT Charge ControllerEnhanced Energy Optimization & SmartSolar Performance.The Xantrex Solar Charger Controller MPPT60 delivers superior efficiency and performance, supporting up to 150V and 60A for optimal power harvesting and seamless scalability in your solar system. Featuring advanced Maximum Power Point Tracking (MPPT) technology, it offers up to 30% more power compared to PWM charge controllers, enhancing overall energy efficiency. Compatible with 12V, 24V, 36V, and 48V battery systems, the MPPT60 optimizes performance across various energy requirements. This controller provides real-time energy monitoring and comprehensive historical data, empowering informed decisions for improved system performance, energy savings, and reliability.Features: Ultra-fast tracking speed including multiple power point peaks with a 99.5% efficiency rating Xantrex MPPT control algorithm maximizes solar system efficiency and energy harvesting effectiveness Manages and optimizes power output from a diverse array of solar panels under varying environmental conditions Regulates power and current flow to protect and prolong battery lifespan The battery’s status is monitored, and the charging current is adjusted to prevent overcharging when fully charged Protection against short-circuiting enhances safety, while protection against input overloading enhances system reliability and longevity Battery temperature compensation boosts both system performance and charging efficiency Real-time monitoring provides data on energy usage and solar power system efficiency Dynamic power reduction prevents overheating and improves battery performance and safety Specifications: LED indicators display PV charging, charger stage, and event status Remote panel for monitoring and setting (requires the Solar MPPT Remote Panel) 30% Higher than the PWM load RV short-circuit protection, charge over-current protection RV-C, Modbus, and Bluetooth built-in 12/24/36/48V System Voltage MPPT tracking efficiently is up to 99.5% Lead-acid, AGM (Sealed), Gel, Flooded, Lithium batteries and custom Current-limiting charging mode Xantrex App for ultimate control Compliance: UL1741CSA C22.2#107.1

Read more less

Lynx Smart BMS 500 NG (M10)The Lynx Smart BMS NG is a dedicated Battery Management System (BMS) designed specifically for the Victron Lithium NG batteries. These batteries utilize Lithium Iron Phosphate (LiFePO4) technology and are available in 12.8 V, 25.6 V, and 51.2 V variants with various capacities. They can be configured in series, parallel, and series/parallel arrangements, allowing for the creation of battery banks with system voltages of 12V, 24V, or 48V. The maximum number of batteries in a single system is 50, enabling a maximum energy storage of 192kWh in a 12V system and up to 384kWh in a 24V and 48V system. For comprehensive details about these batteries, visit the Victron Lithium NG battery product page. Out of the various BMSes available* for the Lithium NG batteries, the Lynx Smart BMS NG is the most feature-rich and complete option and integrates seamlessly with other M10 products in the Lynx Distributor system. It is available in 500 A (M10) and 1000 A (M10) versions1).Built-in 500 A or 1000 A Contactor  Available in 500 A (M10) and 1000 A (M10) versions Acts as a secondary safety system to protect the battery in case primary controls (ATC, ATD, and/or DVCC) fail Suitable as a remote controllable main system switch Pre-Charge Circuit  Prevents high inrush currents when connecting capacitive loads like inverters Eliminates the need for external pre-charging devices Monitoring & Control  Bluetooth connectivity for monitoring and control via the VictronConnect App or VE.Can connectivity in combination with GX devices such as the Cerbo GX or Ekrano GX and the VRM portal Readout of cell voltages and temperatures also on GX devices and the VRM portal Built-in battery monitor provides data such as state of charge, voltage, current, historical data, status info, and more in real-time Diagnostic at a Glance with Instant Readout DVCC Closed Loop Control as well as ATC/ATD Contacts  Compatible Victron inverter/chargers, the Orion XS 12/12-50A DC-DC battery charger, and solar charge controllers are automatically controlled via a connected GX device and DVCC. ATC/ATD contacts can be used to control other chargers and loads that have a remote on/off port Programmable Relay  Can be used either as an alarm relay (combined with the pre-alarm) or to control an alternator via its external regulator (ignition cable) Features Alternator ATC mode for safe alternator disconnection before battery disconnects AUX Terminal  Onboard auxiliary power supply (1.1 A @ system voltage) for powering specific loads (i.e. a GX device) post-BMS shutdown Automatic shutdown of BMS and AUX connection if no charge voltage is detected within 5 minutes after a low voltage event VE.Can and NMEA 2000 Data Communication  Easy connection and communication with GX devices via VE.Can using a standard RJ45 network cable Integration into marine networks via NMEA 2000 protocol (requires a VE.Can to NMEA 2000 micro-C male cable) Lynx Distributor Fuse Monitoring  Monitor fuse status of up to 4 connected Lynx Distributors via VictronConnect or GX devices Receive alarms in case of blown fuses 1) Up to 5 BMS-es can be paralleled. This requires a firmware update, expected in Q3 2024.SpecificationsPower: Battery Voltage Range: 9 – 60 VDC  Maximum Input Voltage: 75 VDC  Supported System Voltages: 12, 24, or 48V  Reverse Polarity Protection: No  Main Safety Contactor Continuous Current Rating: 500 A continuous  Main Safety Contactor Peak Current Rating: 600 A for 5 minutes  Power Consumption OFF Mode: 0.3 mA for all system voltages  Power Consumption in Standby Mode: Approximately 0.6 W (50 mA at 12 V)  Power Consumption in ON Mode: Approx. 2.6 W (217 mA at 12 V) depending on the state of the relays  Minimum Load Resistance for Pre-Charging: 10 Ω and above for 12 V systems 20 Ω and above for 24 V and 48 V systems  AUX Output Maximum Current Rating: 1.1 A continuous, protected by resettable fuse  Allow-to-Charge Port Maximum Current Rating: 0.5 A at 60 VDC, protected by resettable fuse  Allow-to-Discharge Port Maximum Current Rating: 0.5 A at 60VDC, protected by resettable fuse Alarm Relay (SPDT) Maximum Current Rating: 2 A at 60 VDC Connections: Busbar: M10 (Torque: 33 Nm) – can be combined with all M10 Lynx products  VE.Can: RJ45  I/O: Removable multi-connector with screw terminals  Battery BTV Cables: Male and female circular 3-pole connector with M8 screw ring Up to 50 batteries can be connected in one system  Lynx Distributor Fuse Monitoring (up to 4 modules): RJ10 (cable ships with each Lynx Distributor) Physical: Enclosure Material: ABS  Enclosure Dimensions (H x W x D): 190 x 180 x 80 mm  Unit Weight: 1.9 kg  Busbar Material: Tinned copper  Busbar Dimensions (H x W): 8 x 30 mm Environmental: Operating Temperature Range: -40 °C to +60 °C  Storage Temperature Range: -40 °C to +60 °C  Humidity: Max. 95 % (non-condensing)  Protection Class: IP22 Standards: Safety: EN-IEC 63000:2018  EMC: EN-IEC 61000-6-3:2007/A1:2011/AC:2012  QMS: NEN-EN-ISO 9001:2015 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Cyrix-Li-ct 12/24V-230A Intelligent Li-Ion Battery CombinerThe Cyrix Battery Combiner is a microprocessor controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged), and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is virtually no voltage loss, so the output voltage of alternators or battery chargers does not need to be increased.The functionality of the Cyrix-Li-ct is analogous to the Cyrix-ct.The Cyrix-Li-ct will parallel connect a lead acid starter battery and a LiFePO4 battery: If the charge disconnects the output of the VE.Bus BMS is high, and If it senses 13,4 V (resp. 26,8 V) or more on one of its power terminals. The Cyrix will disengage immediately: When its control output becomes free floating, signaling cell over voltage or cell over temperature, and when battery voltage drops below 13,2 V Start assist function: a short negative pulse will close the relay for 30 seconds A built-in transient voltage suppressor will limit the voltage spike that may occur when the Cyrix suddenly disengages due to cell overvoltage or over-temperature Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

BMV-700 Battery MonitorThe BMV-700 is a high precision battery monitor. The essential function of a battery monitor is to calculate ampere hours consumed and the state of charge of a battery. Ampere hours consumed are calculated by integrating the current flowing in or out of the battery.Features: Battery voltage, current, power, ampere-hours consumed and state of charge  Remaining time at the current rate of discharge  Programmable visual and audible alarm  Programmable relay, to turn off non critical loads or to run a generator when needed  500 Amp quick connect shunt and connection kit  Shunt selection capability up to 10.000 Amps  VE.Direct communication port  Stores a wide range of historical events, which can be used to evaluate usage patterns and battery health  Wide input voltage range: 6,5 – 95V  High current measurement resolution: 10 mA (0,01A)  Low current consumption: 2,9Ah per month (4mA) @12V and 2,2Ah per month (3mA) @ 24V VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Non-Inverting Remote On-Off CableUse this cable to connect the following products to the VE.Bus BMS: Skylla-TG all models Battery Protect models BP40i, BP60i, and BP200i (all discontinued). The cable translates the remote on/off driver logic from the VE.Bus BMS (normally high, and open circuit in case of alarm) to the logic needed by above products: active pull down to switch off. Quick Guide (pdf)Brochure (pdf)

Read more less

Battery Selector Switch with AFDPart No. 2110ADescriptionContinuous Amps: 230Momentary Amps: 345Dimensions: 5"D x 2-3/4"H Product FeaturesAlternator field disconnect (AFD) allows selection of any positions, including "off" without damage to alternator or electrical system. AFD is required on some electrical systems.Heavy duty copper sweep contacts"Make before break" contacts allow selection of all positions except "off" while engine is runningUse with 6, 12, 24 or 36 volt systemsNew design is easy to retrofit into existing hole patternsBuilt-in skirt protects connectionsExclusive flat 360 degree "sweep" contact design provides up to 60% more contact area than other switch designsSurface or rear panel mountingMarine grade constructionOne year warrantyWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

SmartSolar MPPT 150/100-MC4 VE-CanThe MPPT VE.Can SmartSolar charger uses the latest and fastest technology to convert energy from a solar array into energy that optimally charges battery banks.The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulfated or otherwise damaged.Models: 12/24/36/48 VoltFeatures: Ultra-fast Maximum Power Point Tracking (MPPT) Advanced Maximum Power Point Detection in case of partial shading conditions  Outstanding conversion efficiency Flexible charge algorithm Extensive electronic protection  Bluetooth Smart built-in  Internal temperature sensor and optional external battery voltage and temperature sensing via Bluetooth Fully discharged battery recovery function  VE.Can: the multiple controller solution VE.Direct or VE.Can Remote on-off Programmable relay Optional: SmartSolar pluggable LCD Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less
