Electrical - Charger/Inverter Combos

CombiMaster 24V - 3000W - 60 Amp (230V)Designed with the customer in mind and using the latest technology, the CombiMaster range is all about user-friendliness and reliability. But don’t let that friendly appearance misguide you: the powerful CombiMaster range drives even the heaviest and most sensitive loads with ease!With the CombiMaster, power dips and failures belong to the past. The automatic AC transfer system switches between generator or mains and inverter output, ensuring a constant power supply. Its Power Assist function prevents tripping of the mains fuse in case you’re connected to a weak land line or small generator.The CombiMaster range delivers unmatched performance and value for money. As you would expect from Mastervolt, the CombiMaster is completed with MasterBus, CZone and NMEA 2000 compatible communication, allowing for a broad range of monitoring and system integration options.Features: Most compact and lightweight Combi in its class. Reliable, hum-free and longer operation from your batteries. Starts even the heaviest and most sensitive loads. Intelligent 3-step+ battery charger for faster and safer charging. Automatic switching between mains and inverter mode. Power Assist prevents blown mains fuses. Generator compatible. Integrated CZone*, MasterBus and NMEA 2000 communication. Quick installation with heavy duty connections. E-mark certified. Remote Control & Monitoring Options: MasterBus compatible via SmartRemote or EasyView 5 display. CZone* / NMEA 2000 compatible via Touch 5 or Touch 10 display. NMEA 2000 compatible via 3rd party multifunctional display WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

MultiPlus Inverter/Charger 12 VDC - 3000VA - 120AMP Battery Charger - 50AMP Transfer Switch (UL LISTED)Features: Multifunctional -The MultiPlus, as the name suggests, is a combined inverter and charger in one elegant package. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, plus multiple system integration features. Unique PowerAssist feature - The MultiPlus will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery Uninterrupted AC power (UPS function) -  In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. Virtually unlimited power thanks to parallel operation -Up to 6 Multis can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible. Please check our datasheets to see which models have paralleling, three phase and split phase capabilities. Remote Monitoring and Control - Monitor and control your MultiPlus and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your MultiPlus to setting a Geofence for hire vehicles and more... Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Inverter Output Voltage: 120v Inverter Input Voltage: 9.3-17v Inverter Cont. Output Wattage: 3000w Outlet Qty: None Charger Output Voltage: 12v Charger Output - Amps: 120a Charger Input - Voltage: 94-140v Charging Banks: 1+1 Box Dimensions: 13"H x 13"W x 18"L WT: 49.25 lbs UPC: 8719076046615 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Xantrex Freedon SW2012 Inverter/Charger815-201212V, 2000W - 120 Vac / 60 HzPowerful. Configurable. Versatile... The Freedom SW series represents highly sophisticated and advanced inverter/ chargers available in 3000 W with 150 A charger and 2000 W with 100 A charger models. Product DescriptionThe second generation 2000 watt model has been completely redesigned to include many of the same great features found in its high power counterpart.A key feature enhancement is 'Generator Support Mode' which enables the Freedom SW to supplement a generator when AC loads exceed the generator's capacity. The new generation models also feature improved AC transfer/AC input detection time, providing the ability to transfer AC loads to batteries in less than 10 milliseconds when the incoming grid or generator power is lost. Connected loads are almost unable to feel the power transition due to this quick transfer time. Both models are approved to UL458 with marine supplement, CSA, ABYC and FCC, Class B requirements.PARALLEL AND SERIES STACKINGParallel stacking enables the Freedom SW inverter/chargers to double the AC output in inverter mode. Series stacking enables the Freedom SW inverter/chargers to generate 120/240 V split phase output2 2 AC source must be split phase, requires Stacking Cable (part# 808-9005)ApplicationDesigned for a variety of mobile applications such as commercial, emergency and recreational vehicles, marine vessels, construction and military equipment.Product Features Pure sine wave output to operate sensitive electronics Advanced configuration options for customized applications Parallel and series stacking capability Built-in transfer switch automatically transfers between inverter power and incoming AC power Power factor corrected, multi-stage charger for fast, efficient charging Temperature compensated charging for a vareity of climate conditions Ignition lockout feature helps prevent unnecessary battery drain when the alternator is not providing power3 Wide operating temperature range: -4°F to 140°F (-20°C to 60°C) Conformal coated circuit boards for humid environments Dual input / Dual output AC interface for 3000 W model Ability to charge batteries drained to extremely low voltage Compatible with the Xantrex Automatic Generator Start4 (Part# 809-0915) 3When used with the remote panel4Sold separatelyProtection Features Battery over-voltage and under-voltage protection Over-temperature shutdown Automatic overload protection Short-circuit protection Integrated, resettable AC breakers WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Output - Amps: 75a Charger Output Voltage: 12v Charging Banks: 1 Outlet Qty: Optional Inverter Output Voltage: 120v Inverter Input Voltage: 12v Charger Input - Voltage: 120v Inverter Cont. Output Wattage: 2000w Box Dimensions: 13"H x 18"W x 21"L WT: 61.7 lbs UPC: 715535917036 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

CombiMaster Inverter/Charger - 24/3500-100 Amp - 120VThe CombiMaster inverter/charger provides the most power and charging in the series. The 3500W version comes in 12V and can be paralleled stacked in a single system up to 10.5kW. The 24V models in 3500W and 5000W can create parallel stacked systems up 35kW. The 1500W version delivers 1500W of pure sine wave inverter power and 60 amps multi chemistry battery charging. The 1500W is the smallest form factor in the series. All models provide pure sine wave inverter power and over 60-200 amps multi-chemistry battery charging, plus the intelligent design is NMEA 2K and MasterBus compatible.Specifications: Nominal DC Voltage: 24V (10.2-16V) Continuous Power at 104° F: 3500W Peak Power 30 seconds: 4500W Surge Power 5 seconds: 6000W Parallel Stacking: Yes, Up to 7 Synchronize with Mains/Generator: Yes Output Waveform: Pure Sine

Read more less

CombiMaster Inverter/Charger - 12/1500-60 Amp - 120VThe CombiMaster inverter/charger provides the most power and charging in the series. The 3500W version comes in 12V and can be paralleled stacked in a single system up to 10.5kW. The 24V models in 3500W and 5000W can create parallel stacked systems up 35kW. The 1500W version delivers 1500W of pure sine wave inverter power and 60 amps multi chemistry battery charging. The 1500W is the smallest form factor in the series. All models provide pure sine wave inverter power and over 60-200 amps multi-chemistry battery charging, plus the intelligent design is NMEA 2K and MasterBus compatible.Specifications: Nominal DC Voltage: 12V (10.2-16V) Continuous Power at 104° F: 1500W Peak Power 30 seconds: 2250W Surge Power 5 seconds: 3000W Parallel Stacking: No Synchronize with Mains/Generator: Yes Output Waveform: Pure Sine

Read more less

Freedom XC PRO Marine 2000W Inverter/Charger - 12VA true sine wave inverter with a built-in lithium-ion battery charger and transfer switch in a compact, lightweight footprint. Configure and monitor system performance via Bluetooth app available on the optional Bluetooth remote panel (# 808-0817-02). Seamless integration with Micro-C NMEA 2000 Connector.The Freedom XC PRO Marine inverter/charger, supporting CANbus NMEA 2000 protocol, is the most versatile and flexible AC power solution in the market today. It supports seamless integration with third-party monitoring and control systems. It also features a 100 amp (2000W model) / 150 amp (3000W model) battery charger and offers all of the configurable features of the Freedom XC series inverter/charger in a compact, lightweight package. It cranks out full output in invert or charge mode from -4°F (-20°C) - 104°F (40°C) for operation in all climate temperatures. The extended surge rating enables compressor loads such as an A/C or a fridge to start reliably.Features: Extended Surge Rating: Surges to 2X continuous power for 5 seconds for motor loads True Sine Wave AC Power: For the operation of sensitive and motor loads Ignition Control: Feature to turn the inverter on/off via a 12 VDC signal and to minimize battery drain by switching the inverter off when the ignition key is turned off Wide 10-18 VDC Input Range: Ensures inverter operation on high voltage alternators found on many new vehicle chassis Programmable AC Under-Voltage (85-110VAC) Shutdown: Feature ideal to operate under weak shore power or generator input Built-in 50A AC Transfer Relay (3KW model): Senses when outside AC Power is present and transfers the load from the inverter to the source of incoming power Built-In Charger Features: Power Factor Corrected Multi-Stage Charging: Utilizes less shorepower when charging batteries. This frees up more usable AC power for running electrical devices and appliances and reduces the likelihood of tripping shorepower breakers Programmable: Configurable 3 stage temperature compensated battery charge algorithm for optimal charging of almost any battery type up to 18V Battery Equalization: Maximizes flooded battery life Dead Battery Charging Down to 0 Vdc Power Share: Prioritizes AC loads by reducing the charge current and maintaining the total input current to less than the breaker setting Easily configurable settings to charge any lithium-ion battery This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Quick Guide (pdf)

Read more less

CombiMaster 24V - 3000W - 70 Amp (120V)Designed with the customer in mind and using the latest technology, the CombiMaster range is all about user-friendliness and reliability. But don’t let that friendly appearance misguide you: the powerful CombiMaster range drives even the heaviest and most sensitive loads with ease!With the CombiMaster, power dips and failures belong to the past. The automatic AC transfer system switches between generator or mains and inverter output, ensuring a constant power supply. Its Power Assist function prevents tripping of the mains fuse in case you’re connected to a weak land line or small generator.The CombiMaster range delivers unmatched performance and value for money. As you would expect from Mastervolt, the CombiMaster is completed with MasterBus, CZone and NMEA 2000 compatible communication, allowing for a broad range of monitoring and system integration options.Features: Most compact and lightweight Combi in its class. Reliable, hum-free and longer operation from your batteries. Starts even the heaviest and most sensitive loads. Intelligent 3-step+ battery charger for faster and safer charging. Automatic switching between mains and inverter mode. Power Assist prevents blown mains fuses. Generator compatible. Integrated CZone*, MasterBus and NMEA 2000 communication. Quick installation with heavy duty connections. E-mark certified. Remote Control & Monitoring Options: MasterBus compatible via SmartRemote or EasyView 5 display. CZone* / NMEA 2000 compatible via Touch 5 or Touch 10 display. NMEA 2000 compatible via 3rd party multifunctional display. WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Outlet Qty: Hardwire Inverter Output Voltage: 120v Charger Output - Amps: 70a Charger Input - Voltage: 120v Inverter Input Voltage: 24v Inverter Cont. Output Wattage: 3000w Charger Output Voltage: 24v Box Dimensions: 10"H x 16"W x 23"L WT: 26.15 lbs UPC: 816882022333 Owner's Manual (pdf)Brochure (pdf)

Read more less

CombiMaster 12V - 3000W - 160 Amp (120V)Designed with the customer in mind and using the latest technology, the CombiMaster range is all about user-friendliness and reliability. But don’t let that friendly appearance misguide you: the powerful CombiMaster range drives even the heaviest and most sensitive loads with ease!With the CombiMaster, power dips and failures belong to the past. The automatic AC transfer system switches between generator or mains and inverter output, ensuring a constant power supply. Its Power Assist function prevents tripping of the mains fuse in case you’re connected to a weak land line or small generator.The CombiMaster range delivers unmatched performance and value for money. As you would expect from Mastervolt, the CombiMaster is completed with MasterBus, CZone and NMEA 2000 compatible communication, allowing for a broad range of monitoring and system integration options.Features: Most compact and lightweight Combi in its class. Reliable, hum-free and longer operation from your batteries. Starts even the heaviest and most sensitive loads. Intelligent 3-step+ battery charger for faster and safer charging. Automatic switching between mains and inverter mode. Power Assist prevents blown mains fuses. Generator compatible. Integrated CZone*, MasterBus and NMEA 2000 communication. Quick installation with heavy duty connections. E-mark certified. Remote Control & Monitoring Options: MasterBus compatible via SmartRemote or EasyView 5 display. CZone* / NMEA 2000 compatible via Touch 5 or Touch 10 display. NMEA 2000 compatible via 3rd party multifunctional display WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Outlet Qty: Hardwire Inverter Output Voltage: 120v Inverter Input Voltage: 12v Inverter Cont. Output Wattage: 3000w Charger Output Voltage: 12v Charger Output - Amps: 160a Charger Input - Voltage: 120v Box Dimensions: 10"H x 16"W x 24"L WT: 27.1 lbs UPC: 816882022319 Owner's Manual (pdf)Brochure (pdf)

Read more less

MultiPlus-II 48/3000 - 35-50 - 120V - UL ApprovedThe MultiPlus-II, an inverter/charger, combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A). It also has all the features of the MultiGrid with built-in anti-islanding and increasingly long list of country approvals.PowerAssistThe MultiPlus-II will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.ESS: Energy Storage SystemsThe MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters.Uninterrupted AC power (UPS function)In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will operate without disruption.Remote Monitoring and ControlWhen coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, from adjusting your Multi to auto starting a backup generator and more.Specifications:  PowerControl & PowerAssist: Yes Transfer Switch: 50A Maximum AC Input Current: 50A Inverter Specifications: DC Input Voltage Range: 38 – 66 V Output: Output Voltage 120 VAC ± 2% / Frequency 60 Hz ± 0,1% (1) Continuous Output Power at 25°C (3): 3000 VA Continuous Output Power at 25°C: 2400 W Continuous Output Power at 40°C: 2200 W Continuous Output Power at 65°C: 1700 W Maximum Apparent Feed-In Power: 2500 VA Peak Power: 5500 W Maximum Efficiency: 95% Zero Load Power: 11 W Zero Load Power in AES Mode: 7 W Zero Load Power in Search Mode: 2 W Charger Specifications: AC Input: Input Voltage Range 90-140 VAC / Input Frequency: 45 – 65 Hz Charge Voltage 'Absorption': 57,6 V Charge Voltage 'Float': 55,2 V Storage Mode: 52,8 V Maximum Battery Charge Current (4): 35 A Battery Temperature Sensor: Yes General Specifications: Auxiliary Output: Yes (32 A) External AC Current Sensor (optional): 100 A Programmable Relay (5): Yes Protection (2): a – g VE.Bus Communication Port: For parallel, split phase and three phase operation, remote monitoring and system integration General Purpose Com. Port: Yes, 2x Remote On-Off: Yes Operating Temperature Range: -40 to +65°C (-40 – 150 °F) (fan assisted cooling) Humidity (Non-Condensing): Max 95% Enclosure Specifications: Material & Color: Steel, blue RAL 5012 Protection Category: IP22 Battery-Connection: M8 bolts 120 V AC-Connection: Screw terminals 13 mm² (6 AWG) Weight: 9 kg Dimensions (hxwxd) (mm): 536 x 275 x 147 Standards: Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, UL458 Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 *Note: For a short period of time this product was called MultiGrid-II.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 120VAC Charger Output - Amps: 35A Charger Output Voltage: 120VAC Charging Banks: 2 Inverter Cont. Output Wattage: 3000AVA / 2400W Inverter Input Voltage: 48VDC Inverter Output Voltage: 120VAC Outlet Qty: None Box Dimensions: 10"H x 14"W x 25"L WT: 44 lbs UPC: 8719076059226 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Freedom HF 1000Compact inverter/charger to power the comforts of home on your boat, RV, or truckWith modified sine wave output, Freedom HF 1000 inverter/charger is designed to run entertainment systems and small appliances in smaller boats, RV's and trucks. The Freedom XMIC inverter/charger is the smallest, lightest, and least expensive model in the Xantrex lineup.Freedom HF is designed for demanding marine and RV conditions. Temperature-controlled multistage charging ensures that your batteries are recharged safely and efficiently. Both models include an automatic transfer switch and a detachable digital remote control panel display that provides precise system information and can be mounted wherever you require the information.Product Features: Designed to power loads such as microwave ovens, TVs, DVD players, small appliances and other electronic equipment Removable digital display to provide system status Automatic three-stage battery charger Designed to be hardwired using a terminal strip, or by connecting AC through GFIC receptacles (Included) Built-in 30-amp relay to automatically transfer between inverter power and incoming AC utility power Protection Features: Battery over-voltage and under-voltage protection Over-temperature shutdown Automatic overload protection Short-circuit protection Ground-fault protection ETL listed for use in mobile RV and marine applications WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Inverter Output Voltage: 120v Inverter Input Voltage: 12v Charger Input - Voltage: 120v Outlet Qty: 1 Duplex GFCI Charging Banks: 1 Inverter Cont. Output Wattage: 1000w Charger Output Voltage: 12v Charger Output - Amps: 20a Box Dimensions: 6"H x 11"W x 18"L WT: 12.95 lbs UPC: 715535890414 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Quattro-II - 12/3000 - 120-50/50 - 2X 120VSimilar to the MultiPlus-II 2x120V, the Quattro-II 2x120V is a combined inverter and charger specifically designed for standard North American 50A 120/240VAC split-phase applications. Additionally, it can accept two AC inputs and automatically connect to the active source.120/240V Input and Output, or 120V Input and Output (Always 120V Output When in Inverter Mode)The two AC inputs can be supplied from a split-phase 120/240V source or a single-phase 120V source. When one of the AC sources is available, the Quattro will feed through the AC to its output. The output will therefore mirror the AC input.The inverter/charger connects to the neutral and the preferred input line (L1). The power needed to charge the batteries will therefore be drawn from L1.The Quattro switches to inverter operation when no AC source is available. The inverter output is 120V single-phase. In invert mode, the Quattro connects both output lines (L1 and L2) together to provide 120VAC to loads on either line.Any 240V loads will therefore be supplied only when the Quattro is supplied by a split-phase AC source. This prevents heavy loads such as water heaters or 240V air conditioners from discharging the battery.PowerControl and PowerAssist - Boosting the Capacity of the Grid or a GeneratorA maximum grid or generator current can be set. The Quattro will then take account of other AC loads and use whatever is extra for battery charging, thus preventing the generator or grid from being overloaded (PowerControl function).PowerAssist takes the principle of PowerControl to a further dimension. Where peak power is often required only for a limited period, the Quattro will compensate for insufficient generator, shore, or grid power with power from the battery. When the load reduces, the spare power is used to recharge the battery (available on L1 input only).Two AC Inputs and Two AC OutputsThe Quattro can be connected to two independent AC sources, for example,shore-side power and a generator, or two generators. The Quattro-II will automatically connect to the active source.The main output has no-break functionality. The Quattro takes over the supply to the connected 120V loads in the event of a grid failure or when shore/generator power is disconnected. The transfer time of the L1 output is less than 18 milliseconds, so computers and other electronic equipment will continue to operate without disruption. The transfer time of the L2 output is longer: approximately 40 milliseconds.The second (auxiliary) output is live only when AC is available on the input of the Quattro. Loads that should not discharge the battery can be connected to this output.Virtually Unlimited Power Thanks to Parallel and Three-Phase OperationUp to 6 Quattros can operate in parallel to achieve a higher power output. In addition to parallel connections, three units of the same model can be configured for three-phase output. In multi-phase setups, L2 is disabled on all units.On-Site System Configuring, Monitoring and ControlSettings can be changed in a matter of minutes with the VictronConnect app or VEConfigure software (computer or laptop and MK3-USB interface are needed). Several monitoring and control options are available: Cerbo GX, Color Control GX, laptop, computer, Bluetooth (with the optional VE.Bus Smart dongle), Battery Monitor, and Digital Multi Control Panel.Remote Configuration and MonitoringInstall a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on our VRM (Victron Remote Management) website free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed.Specifications: PowerControl & PowerAssist: Yes (on L1 input) Transfer Switch: 50 A Maximum AC Input Current: 50A (each leg) Inverter Specifications: DC Input Voltage Range: 9.5-17V Output When in Inverter Mode: Output voltage: 120 Vac ± 2% / Frequency: 60 Hz ± 0.1% (1) Cont. Output Power at 25°C: 3000 VA Cont. Output Power at 25°C: 2400 W Cont. Output Power at 40°C: 2200 W Cont. Output Power at 65°C: 1700 W Maximum Apparent Feed-in Power: 2500 VA Peak Power: 5500 W Maximum Efficiency: 93% Zero Load Power: 15W Zero Load Power in AES Mode: 10W Zero Load Power in Search Mode: 4W Charger Specifications: AC Input: Split-phase: 180-280Vac 45 – 65Hz / Single-phase: 90-140Vac 45 – 65Hz Charge Voltage 'Absorption': 14.4V Charge Voltage 'Float': 13.8V Storage Mode: 13.2V Maximum Battery Charge Current: 120A Battery Temperature Sensor: Yes General Specifications: Auxiliary Output: 50 A (each leg) External AC current Sensor (optional): 100A Programmable Relay: Yes Protection: a – g VE.Bus Communication Port: For parallel and three-phase operation, remote monitoring and system integration General Purpose com. Port: Yes, 2x Remote On-Off: Yes Operating Temperature Range: -40 to +65°C (-40 -150°F) Fan assisted cooling Humidity (non-condensing): Max 95% Enclosure Specifications: Material & Color: Steel, blue RAL 5012 Protection Category: IP22 Battery-Connection: 2x2 M8 bolts 120/240 V AC-Connection: Screw terminals 21 mm² (4 AWG) Weight: 32.8 kg / (52 lb) Dimensions (hxwxd): 579 x 319 x 168 mm / (23 x 13 x 7 inch) Standards: Safety: EN-IEC 60335-1, EN-IEC 60335-2-29 Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 Can be adjusted to 50 Hz Protection key: Output short circuit, overload, battery voltage too high, battery voltage too low, temperature too high, 120Vac on inverter output, input voltage ripple too high Non-linear load, crest factor 3:1. Up to 75-degrees F / 25-degrees C ambient temperature Switches off when no external AC source is available. Programmable Relay That Can for Example Be Set for General Alarm or DC under Voltage or Genset Start/Stop Function: AC rating: 120Vac / 4A / DC rating: 4A up to 35dc, 1A up to 60Vdc Use, for example, to communicate with a lithium battery BMS Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 120VAC Charger Output - Amps: 50A Charger Output Voltage: 14VDC Charging Banks: 2 Inverter Cont. Output Wattage: 3000VA / 2400W Inverter Input Voltage: 9.5 - 17VDC Inverter Output Voltage: 120VAC Outlet Qty: None Box Dimensions: 11"H x 17"W x 27"L WT: 60 lbs UPC: 8719076057369 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

MultiPlus 12/500 - 20-16 - 120V - VE. Bus UL ApprovedThe MultiPlus is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact enclosure. Next to these primary functions, the MultiPlus has several advanced features, as outlined below.Parallel Operation and Three-Phase CapabilityUp to six Multis can operate in parallel to achieve higher power output.  In addition to parallel connection, three units can be configured for three-phase output.  PowerControl - Dealing with Limited Generator, Shore Side or Grid PowerWith the Multi Control Panel, a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.  PowerAssist - Boosting the Capacity of Shore or Generator PowerThis feature takes the principle of PowerControl to a further dimension. It allows the MultiPlus to supplement the capacity of the alternative source. Where peak power is often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load is reduced, the spare power is used to recharge the battery.  Four Stage Adaptive Charger and Dual-Bank Battery ChargingThe main output provides a powerful charge to the battery system using advanced ‘adaptive charge’ software. The software fine-tunes the three-stage automatic process to suit the condition of the battery and adds a fourth stage for long periods of float charging. The adaptive charge process is described in more detail on the Charger datasheet and Victron's website under Technical Information. In addition to this, the MultiPlus will charge a second battery using an independent trickle charge output intended for a main engine or generator starter battery.  High Start-Up PowerIt is needed to start high-inrush loads such as power converters for LED lamps, halogen lamps, or electric tools.  Search ModeWhen Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode, the Multi, when operating in inverter mode, is switched off in case of no load or very low load and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.Programmable RelayBy default, the programmable relay is set as an alarm relay, i.e. the relay will de-energize in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).  Remote On/Off/Charger OnThree pole connector.  On-Site System Configuring, Monitoring, and ControlAfter installation, the MultiPlus is ready to go. Some settings can be changed with DIP switches. 500/800/1200VA models: remote switch/battery charge voltage/inverter frequency/search mode. 1600/2000VA models:  battery charge voltage/search mode. For more settings use VE-Config or the VE. Bus Smart dongle.  Remote Configuring and MonitoringInstall a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on Victron's VRM (Victron Remote Management) website, free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed. Specifications: PowerControl: Yes PowerAssist: Yes Transfer Switch (A): 16 Inverter Specifications: Input Voltage Range (V DC): 9,5 – 17 V, 19 – 33 V, 38– 66 V  Output voltage: 230 VAC, ± 2% / Frequency 50 Hz ± 0,1% Continuous Output Power at 25°C (VA): 500 Continuous Output Power at 25°C (W): 430 Continuous Output Power at 40°C (W): 400 Continuous Output Power at 65°C (W): 300 Peak Power (W): 900 Maximum Efficiency (%): 90 / 91 / 92% Zero Load Power (W): 6 / 6 / 7W Zero Load Power in Search Mode (W): 2 / 2 / 3W Charger Specifications: AC Input: Input voltage range: 187-265 VAC / Input frequency: 45 – 65 Hz Charge Voltage Absorption (V DC): 14,4 / 28,8 / 57,6 Charge Voltage Float (V DC): 13,8 / 27,6 Storage Mode (V DC): 13,8 / 27,6 / 55,2 Charge Current House Battery (A): 20 / 10 / 6 A Charge Current Starter Battery (A): 1A (12 V and 24 V models only) Battery Temperature Sensor: Yes General Specifications: Programmable Relay: Yes (1x) Protection: a - g VE.Bus Communication Port: For parallel and three-phase operation, remote monitoring and system integration  (RJ45-splitter ASS030065510 needed for 500 / 800 / 1200 VA models) Remote On-Off: On/off/charger only DIP Switches: Yes Internal DC Fuse: 125 / 60 /30 A Operating Temperature Range: -40 - +65°C / -40 to 150°F (fan-assisted cooling), Humidity (non-condensing) max 95% Enclosure Specifications: Common Characteristics: Material & Color: aluminum (blue RAL 5012) / Protection category: IP 21 Battery-Connection: 16 / 10 / 10 mm² 230 V AC-Connection: G-ST18i connector Weight: 4,4 kg Dimensions (H x W x D): 311 x 182 x 100 mm / 12.2 x 7.2 x 3.9 in. Standards: Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1 Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3  Automotive Directive: ECE R10-5 Can be adjusted to 60Hz and 240V  Protection: Output short circuit, Overload, Battery voltage too high, Battery voltage too low, Temperature too high, 230VAC on inverter output, Input voltage ripple too high Non-linear load, crest factor 3:1                                                                               Up to 25°C ambient                                                                                                                          A programmable relay that can be set for General alarm, DC under voltage or generator start/stop signal function, AC rating: 230V/4A, DC rating: 4A up to 35VDC, 1A up to 60VDC  Remote/battery charge voltage/inverter frequency/search mode  Battery charge voltage/search mode Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less
