Electrical - Circuit Breakers

C-Series Toggle Single PolePN: 7250Poles: 1Color: WhiteAmperage: 100AFeatures: Provides overcurrent protection for inverters, bow thrusters, and windlasses Combines switching and circuit protection into a single device "Trip Free" - cannot be held closed after trip WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 100a Box Dimensions: 3"H x 3"W x 5"L WT: 0.6 lbs UPC: 632085072506

Read more less

A-Series Flat Rocker Circuit Breaker - Double Pole - 16AFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition International ON/OFF symbols support vertical or horizontal mounting Specifications: Amperaget: 16A AC / 16A DC Actuator Style: Flat Rocker Poles: 2 Maximum Voltage: 120V AC / 240V AC / 32V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: t6 in-lb (0.68 Nm) Screw Terminal Torque: 14 in-lb (1.58 Nm) Switching Cycles: 10000 Terminal Screw: #10-32 Stainless Steel Weight: 0.38lb (0.17 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 16a Box Dimensions: 2"H x 3"W x 5"L WT: 0.35 lbs UPC: 632085074128

Read more less

7459 UL-489 Circuit Breaker - 50A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 50A AC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 5000A Specifications: Amperage: 50a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074593

Read more less

Single Pole Small Case 2" Slot Reset Rocker Circuit BreakerPN:   7428Amperage:   15 AmpFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 250 Volts AC / 80 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 15a Box Dimensions: 1"H x 2"W x 3"L WT: 0.15 lbs UPC: 632085074289

Read more less

7444 UL-489 Circuit Breaker - 30A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 30A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 30a Box Dimensions: 2"H x 3"W x 5"L WT: 0.3 lbs UPC: 632085074449

Read more less

7068 ATO/ATC-Style Low Profile Circuit Breaker - 2-Pack - 30 AmpUse a manually resettable circuit breaker instead of an ATO or ATC fuse.Features: Drop in replacement for ATO and ATC blade style fuses Manual push button reset complies with ABYC circuit protection requirements Compatible with Water-Resistant ST-Blade Fuse Block with cover secured Compatible with all other ST-Blade Fuse blocks without cover Amperage: 30 Amp Color: Green Maximum Voltage: 28V DC Circuit Breaker Type: Thermal Trip, Manual Reset Interrupt Capacity: 2000A @ 28V DC Minimum Operating Temperature: -30° C Maximum Operating Temperature: 77° C WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 1"H x 2"W x 4"L WT: 0.1 lbs UPC: 632085070687

Read more less

7312 COTS Military Grade A-Series 15 AmpMay be suitable for use when military specifications are required under CFR 46.Specifications: Amperage: 15A Actuator Style: Metal Toggle Poles: 2 Max Voltage: 277V AC, 65V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Interrupt Capacity: 1500 A AC, 7500A DC Min Operating Temp: -40°C Max Operating Temp: 85°C Mounting Boss: 1/2-32 Hex Nut SS Mounting Nut Torque: 30"-lb Screw Terminal Torque: 14"-lb Switching Cycles: 6000 Electrical/4000 Mechanical Terminal Screw: #10-32 SS Weight: 0.13lb (0.06 kg) UL 1077 Specifications: Amperage: 15a Box Dimensions: 2"H x 3"W x 4"L WT: 0.35 lbs UPC: 632085173128

Read more less

7443 UL-489 Circuit Breaker - 20A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 20A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 20a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074432

Read more less

Push Button Reset Only Screw Terminal Circuit Breaker - 7 AmpsFeatures: Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels Compact design enables high density circuit protection configurations Push-to-reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasoline powered boats Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking Specifications: Amperage: 7A Maximum Voltage: 32V DC Mounting: Panel Mount 3/8-27 UNS Circuit Breaker Type: Thermal trip, manual push-button reset only Terminal Type: #8 Screw Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V Minimum Operating Temperature: -10° C Maximum Operating Temperature: t60° C Screw Terminal Torque: 6 in-lb (0.68 Nm) Weight: 0.09lb (0.04 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 7a Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085021313

Read more less

7235 A-Series Double Pole Toggle - 15AMP - WhitePoles: 2Color: WhiteAmperage: 15AMPFeatures: Meets American Boat and Yacht Council (ABYC) standards UL 1077 recognized, TUV certified, CE marked for Europe and CSA certified for Canada The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Used as AC Main circuit protection "Trip Free" design cannot ben held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 15a Box Dimensions: 2"H x 3"W x 5"L WT: 0.3 lbs UPC: 632085072353

Read more less

7059Push Button Thermal with Quick Connect Terminals30A Ideal for 24-hour circuit protection Incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels Push to reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasonline powered boats With male quick connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 2"H x 3"W x 4"L WT: 0.1 lbs UPC: 632085070595

Read more less

187 - Series Thermal Circuit Breakers - Panel Mount150 Amp Circuit BreakerPN:  7048Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Self-trimming case eliminates the need for mounting panels or trim bezels Round case permits easy installation with standard sized hole saw Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 150a Box Dimensions: 2"H x 5"W x 7"L WT: 0.5 lbs UPC: 632085070489

Read more less
