WeatherDeck™ Water Resistant Fuse PanelPN: 4304Color: GrayFeatures: Panel front rated IP67 when properly mounted with watertight mounting gasket IP67 – protected against immersion up to 1 meter for 30 minutes Designed for flybridge and open cockpit applications Independent label back lighting circuit for remote switching and dimming Each panel can be mounted in four different orientations Integrated ATO/ATC fuse based circuit protection Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel. Specifications: Weatherproof: Waterproof Positions: 4 Nominal Voltage: 12v DC Circuit Protection: Fuse Maximum Amperage: 15A @ 12v DC (per circuit) Panel Cumulative Rating: 60A Backlit Label: Bicolored LED Backlighting Amperage: 10mA/illuminated Circuit Backlighting Voltage: 12v DC Height: 4.3" Width: 3.88" Depth: 2.5" Included: (4) 4138 WeatherDeck® Toggle Switch Boot - Black (4) 4150 WeatherDeck® Toggle Switch SPST - ON-OFF (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1 (4) 5242 ATO/ATC Fuse - 15 Amp WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Waterproof: Waterproof Max Breaker Quantity: 4 AC/DC: DC Voltage: 12v Box Dimensions: 4"H x 6"W x 7"L WT: 0.9 lbs UPC: 632085043049 Quick Guide (pdf)

Read more less

120 Volt AC Main + 6 Position - VerticalFeatures: All circuit label positions are backlit "ON" indicating LEDs installed in all circuit positions Includes 4206-Square Format Label Set Specifications: Positions: 6 Nominal Voltage: 120V AC Maximum Amperage*: 100A Height: 7.75" (196.85mm) Width: 4.88" (123.95mm) Depth: 3.00" (76.2mm) Weight: 2.70lb (1.22kg) Includes:(6) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4206 - Basic AC Label Kit - 30 Black Square Labels [LABEL](1) - 7414 - A-Series Flat Rocker Circuit Breaker - Double Pole 30A (Main)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Box Dimensions: 6"H x 6"W x 12"L WT: 2.6 lbs UPC: 632085012021 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

WeatherDeck™ Water Resistant Fuse PanelPN: 4306Color: GrayFeatures: Panel front rated IP67 when properly mounted with watertight mounting gasket IP67 – protected against immersion up to 1 meter for 30 minutes Designed for flybridge and open cockpit applications Independent label back lighting circuit for remote switching and dimming Each panel can be mounted in four different orientations Integrated ATO/ATC fuse based circuit protection Bicolored LEDs illuminate circuit labels to quickly identify OFF (Red), ON (Green), or Blown (No Color) circuits. No lights in any position likely indicate there is no power to the panel. Specifications: Weatherproof: Waterproof Positions: 6 Nominal Voltage: 12v DC Circuit Protection: Fuse Maximum Amperage: 15A @ 12v DC (per circuit) Panel Cumulative Rating: 90A Backlit Label: Bicolored LED Backlighting Amperage: 10mA/illuminated Circuit Backlighting Voltage: 12v DC Height: 6.0" Width: 3.88" Depth: 2.5" Included: (6) 4138 WeatherDeck® Toggle Switch Boot - Black (6) 4150 WeatherDeck® Toggle Switch SPST - ON-OFF (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1 (6) 5242 ATO/ATC Fuse - 15 Amp WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Waterproof: Waterproof Voltage: 12v AC/DC: DC Max Breaker Quantity: 6 Box Dimensions: 5"H x 6"W x 9"L WT: 1.5 lbs UPC: 632085043063 Quick Guide (pdf)

Read more less

120 Volt AC 8 PositionFeatures: All circuit label positions are backlit "ON" indicating LEDs installed in all circuit positions Includes 4206-Square Format Label Set Specifications: Positions: 8 Nominal Voltage: 120V AC Maximum Amperage*: 100A Height: 7.75" (196.85mm) Width: 4.88" (123.95mm) Depth: 3.00" (76.2mm) Weight: 2.68lb (1.22kg) * Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.Includes:(8) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4206 - Basic AC Label Kit - 30 Black Square Labels [LABEL]WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Box Dimensions: 5"H x 7"W x 12"L WT: 2.6 lbs UPC: 632085012281 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

1520 Remote Control Switch - 360 Panel - 3 BlankThe 360 Panel System Blank switch panel accepts three Carling Contura switches that are sold separately. The blank switch panel accepts 3 switches. Features: 360 Panel System Blank switch panel accepts 3 Carling Contura switches Backlit labels Lockout slides Switches sold separately Specifications: Mounting Type: Panel Mount Material: Plastic Terminal: Screw Voltage: 12V DC Connector Type: Quick Connect Operation Mode: ON-OFF Product Dimensions: 7.87 x 3.94 x 1.97 inches WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

3117 - SMS Panel Enclosure with 2 ELCI (30A) - 120V ACThe 3117 panel enclosure is built for Equipment Leakage Circuit Interrupters (ELCI) main circuit breakers and other large frame devices.  Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10' of AC shore power inlet.Features: Blank apertures for custom breaker loading  Glass filled polycarbonate base Clear cover allows easy view of circuit breaker status Overlapping cover for strength and increased gasket protection Oversized, formed in place seamless PUR gasket Easily removable stainless steel hinge pin for unobstructed installation Stainless steel latch secures cover without penetrating the enclosure Blank circuit positions accommodate Carling Technologies™ A and C Series Flat Rocker and ELCI Main circuit breakers Includes waterproof glands LED lights for back lighting and ON indication Technical Specifications: Circuit Breaker Type - 2 x ELCI (30A) Main 120V  Dimensions (Overall) (H x W x D) - 7.6" x 7.4"" x 4.7" (192 x 188 x 120mm) Dimensions  (Enclosure) (H x W x D) - 6" x 6" x 4" (152 x 152 x 102mm) LEDs Installed - 2 x Red (Reverse Polarity - 120V AC and 2 x Green ON (120V AC) In the Box: 3117 Enclosure Glands x 6 Labels Mounting hardware Instruction manual *Sold as an IndividualWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Voltage: 120 Box Dimensions: 7"H x 10"W x 10"L WT: 4.4 lbs UPC: 632085031176 Quick Guide (pdf)Brochure (pdf)

Read more less

12 Volt DC 12 PositionFeatures: 4 to 32 branch circuits with installed 15 Ampere circuit breakers Available with voltmeters, ammeters, and digital multimeters Includes 4205-Square Format Label Set Specifications: Positions: 12 Nominal Voltage: 12V DC Maximum Amperage*: 100A per bus Height: 10.75" (273.05mm) Width: 4.88" (123.95mm) Depth: 3.00" (76.2mm) Weight: 4.85lb (2.2kg) * Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.Includes:(12) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4205 - Basic DC Label Kit - 30 Black Square Labels [LABEL]WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: DC Box Dimensions: 5"H x 9"W x 12"L WT: 4.5 lbs UPC: 632085012236 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

12 Volt DC 8 Position - VerticalFeatures: 4 to 32 branch circuits with installed 15 Ampere circuit breakers Available with voltmeters, ammeters, and digital multimeters Includes 4205-Square Format Label Set Specifications: Positions: 8 Nominal Voltage: 12V DC Maximum Amperage*: 100A Height: 7.75" (196.85mm) Width: 4.88" (123.95mm) Depth: 3.00" (76.2mm) Weight: 2.60lb (1.18kg) * Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.Includes:(8) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4205 - Basic DC Label Kit - 30 Black Square Labels [LABEL]WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: DC Box Dimensions: 6"H x 6"W x 16"L WT: 2.3 lbs UPC: 632085012007 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

WeatherDeck® 12V DC Waterproof Switch Panel - 4 Position Integrated switch guards reduce the risk of accidental switching Panels can be mounted in four different orientations Panel front rated IP67 when properly mounted with watertight mounting gasket UV stabilized weather-resistant faceplate snaps on and off providing access to components and concealing mouting screws Weatherproof: WaterproofPositions: 4Nominal Voltage: 12V DC/24V DCCircuit Protection: NoneMaximum Amperage: 15A @ 12V DC (per circuit)Panel Cumulative Rating: 45AMaterial: Reinforced PolycarbonateHeight: 4.30"(109.22 mm)Width : 3.88"(98.55 mm)Depth: 2.50"(63.5 mm)Weight: 0.90lb (0.41 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Waterproof: Waterproof AC/DC: DC Max Breaker Quantity: 4 Voltage: 12/24v Box Dimensions: 4"H x 6"W x 7"L WT: 0.7 lbs UPC: 632085043056 Owner's Manual (pdf)

Read more less

AC Rotary Switch Panel 30 Ampere 3 positions + OFF, 2 PolePoles: 2Voltage: 120vAmperage: 30Positions: 3 + OFF Switches 3 - 120 Volt AC sources Includes 9010 heavy duty industrial rated switch Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Red reverse polarity LED indicators Green power available LED indicators Compact solution when circuit protection is provided elsewhere WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Max Breaker Quantity: 3 +OFF Voltage: 120v Box Dimensions: 5"H x 6"W x 10"L WT: 1 lbs UPC: 632085083663 Owner's Manual (pdf)

Read more less

8077 AC Main Only Toggle Circuit Breaker PanelFeatures: Red reverse polarity indicating LED Safety ground screw on panel back Combines switching and circuit protection into a single device "Trip Free" design cannot be held "ON" during fault current condition Specifications: Nominal Voltage: 120v AC Maximum Voltage: 277v AC / 65v DC Height: 3.75" Width: 2.63" Included: (1) 8034 LED - 120v AC Green (1) 8066 LED - 120v AC Red (1) 7238 A-Series White Toggle Circuit Breaker - Double Pole 30A (Main) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Max Breaker Quantity: 1 Voltage: 120v Box Dimensions: 3"H x 4"W x 7"L WT: 0.7 lbs UPC: 632085000004

Read more less

120 Volt AC Main + 2 PositionsFeatures: All circuit label positions are backlit "ON" indicating LEDs installed in all circuit positions Includes 4206-Square Format Label Set Specifications: Positions: 2 Nominal Voltage: 120V AC Height: 4.75" (120.65mm) Width: 4.88" (123.95mm) Depth: 3.00" (76.2mm) Weight: 1.58lb (0.72kg) Includes:(2) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4206 - Basic AC Label Kit - 30 Black Square Labels [LABEL](1) - 7414 - A-Series Flat Rocker Circuit Breaker - Double Pole 30A (Main)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Box Dimensions: 6"H x 7"W x 9"L WT: 1.58 lbs UPC: 632085012144 Quick Guide (pdf)Owner's Manual (pdf)
