Electrical - Switches & Accessories

DPDT Rocker Switch - 12V/24V - ON/OFF/ONDouble pole, double throw switch turns two of four circuits on at a time.Features: Nominal voltage is 12V DC Rated for 25A at 12V DC Six 1/4" blade terminals Snap-in mounting to fit panel hole 1.45" x .83" into panels .093" to .187" thick Same as Cole Hersee part number 58027-07 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Throw/Pole: DPDT Color: Black Action: On/Off/On Box Dimensions: 2"H x 3"W x 5"L WT: 0.1 lbs UPC: 870216046334

Read more less

4161 SS Push Button Switch - Off-(On) - Blue - 10A 10A continuous Single Pole Double Throw or Single Pole Single Throw Can be wired for normally open or normally closed Installs with .110inch quick connects (included in retail package) Specifications Action: OFF-(ON) Amperage: 10A @ 12V DC Nominal Voltage: 12V DC Maximum LED Operating Current: 20mA Minimum Operating Temperature: -10° C Maximum Operating Temperature: 70° C Minimum Storage Temperature: -55° C Maximum Storage Temperature: 85° C Illumination: Independent – Separate contacts for LED power Mounting Hole: 19mm Switching Cycles: 18,000 Termination: 5 – 0.110inch Quick Connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Stainless Action: (On)/Off Box Dimensions: 2"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085041618

Read more less

8267Contura Switch Mounting PanelEnd Mounting Panel Modular design permits easy assembly in groups of varying sizes Designed for mounting in 6 different panel thicknesses: 0.06" (1.57mm) 0.09" (2.36mm) 0.13" (3.17mm)0.19" (4.75mm) 0.25" (6.35mm) 0.38" (9.52mm) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

360 Panel - Rocker Switch DPDT - (ON)-OFF-(ON)The 360 Panel System uses an open frame to mount a broad selection of modules, allowing multiple functions to be combined in a single panel.This innovative design offers a wide choice of panel features, can accommodate future changes and permits rapid assembly. With options ranging from battery management to source selection, the 360 Panel System provides unmatched design flexibility.For use in 360 panels in the following modules: Gauge, DC Push Button + Switch, and DC Battery ManagementSpecifications: Action*:t(ON)-OFF-(ON) Pole/Throw**:tDPDT Maximum Amperage***:8A @ 125V AC / 5A @ 12V DC / 5A @ 24V DC / 4A @ 250V AC Terminal Type:tWire Leads Terminal Size: 6.00" (152.4mm) Weight:0.08lb (0.04kg) *Action () = Momentary ON**Pole/Throw: SPST - Single Pole/Single ThrowSPDT - Single Pole/Double ThrowDPST - Double Pole/Single ThrowDPDT - Double Pole/Double Throw***Maximum Amperage - Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Throw/Pole: DPDT Color: Black Action: (On)/Off/(On) Box Dimensions: 2"H x 3"W x 6"L WT: 0.3 lbs UPC: 632085074951 Quick Guide (pdf)Brochure (pdf)

Read more less

Lighted Tip Toggle Switch SPST On-Off 4 BladeIndependent illumination switches can be wired for dependent operation. Tip of handle is illuminated red in the On position, clear in the Off position. Tip of handle is illuminatedRed in the On position, illuminated Clear in the Off position. Silver contacts. 15/32" -32 thread mounting stem. Nickel-plated brass hexnut. Black plastic handle, housing and facenut. Keyway in the down position. Blade terminals. 25A at 12V DC. Plastic facenut can be replaced with black metal facenut 83252.WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Action: On/Off Color: Black Throw/Pole: SPST Box Dimensions: 1"H x 3"W x 4"L WT: 0.2 lbs UPC: 632850559089

Read more less

Water Resistant Contura Switch - Black PN: 8286 Pole: Double Throw: Double Action ( ) = momentary: ON - OFF - ON Embedded LEDs: 2 Features: Vibration, shock, thermoshock, moisture and salt spray resistant Specially manufactured for mounting in Blue Sea Systems' water resistant panels Ignition Protected - Safe for installation aboard gasoline powered boats Meets UL1500 and ISO8846 ignition protection requirements Specifications   Rating: 12 Volts DC 20 Amperes  Rating: 24 Volts DC 15 Amperes Lighted LED rated 100,000 hours 1/2 life Seals Internal and external gasket panel seal Temperature Rating -40°C to 85°C Mounting Hole 1.45" x 0.83" LED Amperage 18 Milliamperes WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Throw/Pole: DPDT Action: On/Off/On Box Dimensions: 2"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085082864

Read more less

4153WeatherDeck Toggle Switch Boot Pole/Throw SPDT Action (ON)-OFF-ON Specially manufactured by Carling Technologies for use in Blue Sea Systems' WeatherDeck™ Panels When mounted with a WeatherDeck Toggle Switch Boot Rated IP67-temporay immersion for 30 minutes Nickel-plated brass and phenolic non-corrosive construction WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Throw/Pole: SPDT Box Dimensions: 1"H x 2"W x 3"L WT: 0.2 lbs UPC: 632085041533

Read more less

Push-Pull Switch DPTT 3-Position Off-On-OnFeatures: Two-circuit push-pull switch, normally off (pull for ON) Allows (2) circuits to be operated independently with one switch Heavy-duty corrosion-resistant construction Supplied with mounting hardware: brass face nut, washer, and hex nut Installs in panels up to 1" thick 3-Position Off-On-On Push Button

Read more less

SPST PVC Coated Toggle Switch - OFF/(ON)Single pole, single throw toggle switch turns one circuit on and off. Common applications include intermittent horn or windshield wiper control. This toggle switch is PVC coated.Features: Nominal voltage is 12V/24V DC Rated for 25A at 12V DC, 15A at 24V DC 8" 16 AWG wire lead terminals Mounting stem 15/32" fits panels up to 1/4" thick Same as Cole Hersee part number 55020-04 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Action: (On)/Off Throw/Pole: SPST Box Dimensions: 2"H x 3"W x 5"L WT: 0.1 lbs UPC: 870216046624

Read more less

2-Position SPST Push-Pull Switch w/Wire Leads - OFF/ONSingle pole, single throw switch turns one circuit on and off. Heavy-duty, noncorrosive construction with moisture-repellent insulators. Brass case, stem, terminals and mounting hardware. Plasticized body helps seal out moisture and dirt. All knobs are screw-on type.Features: Nominal voltage is 6-36V DC Rated for 10A at 12V DC Two 8" 16 AWG wire leads for terminals Fits panels up to 5/8" thick Same as Cole Hersee part number M-606 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Chrome Action: On/Off Throw/Pole: SPST Box Dimensions: 2"H x 3"W x 5"L WT: 0.2 lbs UPC: 870216046006

Read more less

Paneltronics LED Indicator Light - 5/32" - 120 VAC - Green Ideal for use as Status or Alarm Indicators Large T-1 size LED's Nylon housing is classified UL Press to fit into 0.166" diameter Pigtails are tin plated, 22 copper, 7" in length stripped 1/4" (ABYC E-11.12.1.10 and ABYC E-11.16.1.1.2. Exceptions 3, 4, and 5) Specifications: Color: Green Box Dimensions: 1"H x 1"W x 1"L WT: 0.1 lbs UPC: 602290700112

Read more less

8171LED Indicator LightRed12/24V DC5 Milliamperes Easily installed in any Blue Sea Systems circuit breaker panel Simple push-in installation mounts in any thickness material Useful as general indicator and alarm lights WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Red Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085081713

Read more less
