360 Panel - Rocker Switch DPDT - ON-ONThe 360 Panel System uses an open frame to mount a broad selection of modules, allowing multiple functions to be combined in a single panel.This innovative design offers a wide choice of panel features, can accommodate future changes and permits rapid assembly. With options ranging from battery management to source selection, the 360 Panel System provides unmatched design flexibility.For use in 360 panels in the following modules: Gauge, DC Push Button + Switch, and DC Battery ManagementSpecifications: Action*: ON-ON Pole/Throw**: DPDT Maximum Amperage***:8A @ 125V AC / 5A @ 12V DC / 5A @ 24V DC / 4A @ 250V AC Terminal Type: Wire Leads Terminal Size: 6.00" (152.4mm) Weight:0.08lb (0.04kg) *Action () = Momentary ON**Pole/Throw: SPST - Single Pole/Single ThrowSPDT - Single Pole/Double ThrowDPST - Double Pole/Single ThrowDPDT - Double Pole/Double Throw***Maximum Amperage - Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Throw/Pole: DPDT Color: Black Action: ON-ON Box Dimensions: 1"H x 2"W x 7"L WT: 0.1 lbs UPC: 632085074913 Quick Guide (pdf)Brochure (pdf)

Read more less

9093 Switch AC 120 + 120/240VAC OFF+2 Positions Features: Switches between 2 - 120 Volt AC shore power sources and 1 - 240 Volt AC source to 2 - 120V AC load groups Switches both lines (hot) and neutral Compact solution when circuit protection is provided elsewhere Allows connecting one of two different AC sources to one circuit Mounts in panels up to 0.16" (4.00mm) thick Heavy duty industrial rated switch Intuitive function - One hand operation UL listed 600 Volt AC Max WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Box Dimensions: 4"H x 6"W x 7"L WT: 1.7 lbs UPC: 632085090937 Owner's Manual (pdf)

Read more less

7218 AC/DC Single Pole Magnetic World Circuit Breaker - 25AMPThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.Color:   WhiteAmperage:   25 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 25a Box Dimensions: 1"H x 3"W x 4"L WT: 0.17 lbs UPC: 632085072186

Read more less

Class T Fuse Block with Insulating Cover - 225 to 400AAllows the use of Class T fuses for fast acting circuit protection of inverters and other electronics Four stud design provides ample access around connecting stud to install large cable lugs without obstruction from the fuse Insulating cover satisfies ABYC/USCG insulation requirements Cover breakouts allow wire access in any direction Stud design ensures secure fuse mounting even with high heat Stainless steel studs provide resistance to corrosion and high torque One-piece stainless flange nuts ensure safe and secure connections UL 94-V0 base resists high heat Technical Specifications: Cable Size: Up to 4/0 AWG Ignition Protected: Yes Maximum Amperage: 320A Maximum Voltage: 160V DC Fuse Mounting Blocks: Tin-Plated Copper Terminal Stud Size: 5/16"-18 (M8) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: Class T Type: Fuse Blocks Box Dimensions: 3"H x 8"W x 8"L WT: 1.8 lbs UPC: 632085550219

Read more less

Black 16 AWG Tinned Copper Wire - 250'Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600V, 105°C dry and 75°C wet, stays flexible even in extreme cold (-40°F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing.Wire Gauge: 16 AWGWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Length (Feet): 250' Gauge: 16 AWG Box Dimensions: 5"H x 7"W x 7"L WT: 3.6 lbs UPC: 091887100211

Read more less

Black 16 AWG Tinned Copper Wire - 500'Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600V, 105°C dry and 75°C wet, stays flexible even in extreme cold (-40°F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing.Wire Gauge: 16 AWGWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Length (Feet): 500' Gauge: 16 AWG Box Dimensions: 5"H x 7"W x 7"L WT: 7 lbs UPC: 091887103366

Read more less

Adhesive Lined Heat Shrink Tubing (ALT) - 3/8" x 12" - 5-Pack - BlackPackage of 5 Black 12"(30.5cm) long sections with a 3/8"(9.5mm) diameter that shrinks to 1/8"(3.2mm)Wire Range: 12-8 AWGFeatures: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief Highest shrink ratio - shrinks to 1/3 original size Shrinks at 257°F / 125°C Operating temperature range of -40°C to 110°C UL 224 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Heat Shrink Box Dimensions: 1"H x 3"W x 15"L WT: 0.1 lbs UPC: 091887303407

Read more less

Standard Duplex Cable - Flat 14/2 AWG - 2 x 2mm² Red/Black - 100'Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600 Volts, 105°C dry and 75°C wet, stays flexible even in extreme cold (-40°F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Red/Black Length (Feet): 100' Gauge: 14/2 AWG Box Dimensions: 5"H x 6"W x 7"L WT: 5.6 lbs UPC: 091887123081

Read more less

16-14 Gauge - 5/16" Heat Shrink Ring Terminal - 25-PackWire Range:16-14Screw Size:5/16"Quantity: 25Product Features: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief Nylon insulator, preferred by experts, for Marine Grade™ resistance to sunlight, water, oil, chemicals, vibration and cut-through damage UL Listed and CSA Recognized Highest shrink ratio - shrinks to 1/3 original size Shrinks at 257° F/125° C Operating temperature range 40° C to 110° C ANCOR heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing Shrinks to form a water tight seal and the ultimate vibration and strain relief Tinned for corrosion resistance Pure copper for maximum current flow Brazed seam for maximum strength WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 16-14 AWG Type: Ring Terminals Post Size: 5/16" Package Qty: 25 Heat Shrink: Yes Box Dimensions: 1"H x 3"W x 4"L WT: 0.09 lbs UPC: 091887313161 Quick Guide (pdf)

Read more less

12-10 Gauge - 5/16" Heat Shrink Ring Terminal - 3-PackGauge Size: 12-10Screw Size: 5/16"Quantity: 3Product Features: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief Nylon insulator, preferred by experts, for Marine Grade™ resistance to sunlight, water, oil, chemicals, vibration and cut-through damage UL Listed and CSA Recognized Highest shrink ratio - shrinks to 1/3 original size Shrinks at 257° F/125° C Operating temperature range 40° C to 110° C ANCOR heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing Shrinks to form a water tight seal and the ultimate vibration and strain relief Tinned for corrosion resistance Pure copper for maximum current flow Brazed seam for maximum strength WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 12-10 AWG Type: Ring Terminals Post Size: 5/16" Package Qty: 3 Heat Shrink: Yes Box Dimensions: 1"H x 2"W x 4"L WT: 0.02 lbs UPC: 091887316148 Quick Guide (pdf)

Read more less

22-18 Gauge Heat Shrink Step-Down Multi-Wire Connectors - 25-PackAncor's assortment of adhesive lined heat shrink butt connectors can be used as a step-down from one gauge size to another or as a multi-wire connector for one gauge size wire. These connectors offer a sealed alternative for products such as a quick-tap or 3-way connector in areas where corrosion is a concern.Features: 4:1 shrink ratio tubing to ensure a watertight seal between wires Flared barrel with uniform copper wall ensures an easy and proper mechanical crimp Crimp indicator on barrel for proper placement of installation tool Clear heat shrink tubing ensures crimp accuracy Colored stripes on the barrel indicate which crimp die to use, regardless of application WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 22-18 AWG Type: Butt Connectors Package Qty: 25 Heat Shrink: Yes Box Dimensions: 2"H x 3"W x 4"L WT: 0.14 lbs UPC: 091887983296 Quick Guide (pdf)

Read more less

12-10 Gauge - #10 Heat Shrink Ring Terminal - 100-PackGauge Size: 12-10Screw Size: #10Product Features: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief Nylon insulator, preferred by experts, for Marine Grade™ resistance to sunlight, water, oil, chemicals, vibration and cut-through damage UL Listed and CSA Recognized Highest shrink ratio - shrinks to 1/3 original size Shrinks at 257° F/125° C Operating temperature range 40° C to 110° C ANCOR heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing Shrinks to form a water tight seal and the ultimate vibration and strain relief Tinned for corrosion resistance Pure copper for maximum current flow Brazed seam for maximum strength WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 12-10 AWG Heat Shrink: Yes Type: Ring Terminals Post Size: #10 Package Qty: 100 Box Dimensions: 1"H x 3"W x 8"L WT: 0.43 lbs UPC: 091887316124 Quick Guide (pdf)

Read more less
