Electrical

2610 Terminal Block 65AMP - 10 CircuitFeatures: Closed back design completely insulates power from the mounting surface Each screw pair is 1 isolated circuit Jumpers allow creation of common circuits WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

12-10 Gauge - #8 Heat Shrink Ring Terminal - 25-PackGauge Size: 12-10Screw Size: #8Quantity: 25Product Features: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC. Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief. Nylon insulator, preferred by experts, for Marine Grade resistance to sunlight, water, oil, chemicals, vibration and cut-through damage. UL Listed and CSA Recognized Highest shrink ratio - shrinks to 1/3 original size. Shrinks at 257 deg. F/125 deg. C. Operating temperature range 40 deg. C to 110 deg. C. ANCOR heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing Shrinks to form a water tight seal and the ultimate vibration and strain relief. Tinned for corrosion resistance. Pure copper for maximum current flow. Brazed seam for maximum strength. Wire Range: 12-10 mm: 3-5 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Ring Terminals Post Size: #8 Package Qty: 25 Heat Shrink: Yes Gauge: 12-10 AWG Box Dimensions: 1"H x 4"W x 4"L WT: 0.2 lbs UPC: 091887316049 Quick Guide (pdf)

Read more less

Wire Dockside Receptacle50Amp/125V 2 Pole, 3-Wire Dockside Receptacle Black, glass filled nylon body and face provide excellent resistance in harsh environments Corrosion resistant, marine grade construction WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Receptacles Box Dimensions: 3"H x 4"W x 7"L WT: 0.5 lbs UPC: 093344007200

Read more less

Deutsch DT Receptacle & Wedge Lock Kit - 4 Position - 10 PackProtecting electrical connections is an absolute must, and Deutsch Connectors are built for just that. DT Kit connectors are designed to create environmentally sealed electrical connections. Waterproof and resistant to vibration and shock, these Kits are built to last. What are DT series connectors? Well, DT Series connectors are specifically designed for 20-14 AWG applications. These connectors offer users the ability to use multiple size 16 contacts (20-14 AWG). These DT kits are perfect for field use. They are easy to install, connect, and disconnect. Pacer's DT Kits contain housing and wedge lock only. Pins and sockets to accompany these kits are sold separately. Contact a Pacer expert today with any questions that you have.Features:Kits with cavities (2, 3, or 4) include housing (10 pieces) and wedge lock (10 pieces)Applications: Wire-to-wire applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics: Wedgelocks ensure contact alignment and retention Redundant Silicone Seals Hand-insertable and removable contacts Compliances: Ingress Protection (IP) Level: IP67 EU RoHS/ELV Standard UL-94 Recognized Specifications: Number of Cavities: 4 Cavity Style: Receptacle (Pin) Package Size: 10 Housing: Rectangular Receptacle, Plastic reinforced with glass fiber Contact Size: 16 (13 Amp) Wire Size: 20-14 AWG Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

Alternator 120 Amp 12V 1-2" Single Foot Single K6 Pulley with Isolated GroundingAlternator, 621 Series, 120A, 12V, Spindle Mount (Single Foot), 1-2in, K6 Serpentine Pulley, Isolated Ground 1″ Motorola-Style Mounting;  Typical for Westerbeke, Lehman, Hino & Pathfinder Engines 2″ Delco-Style Mounting;  Typical for Volvo Penta (Gas & Diesel), John Deere, Perkins, Mercruiser, Pleasurecraft, Crusader, Indmar, Marine Power & other GM-based Engines.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 120a Voltage: 12v Box Dimensions: 9"H x 10"W x 11"L WT: 13.35 lbs UPC: 676205750813 Brochure (pdf)

Read more less

Black 12 AWG Tinned Copper Wire - 250'Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600V, 105°C dry and 75°C wet, stays flexible even in extreme cold (-40°F/C) and resists salt water, battery acid, oil, gasoline, heat, abrasion and ultra-violet radiation. Highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing.Wire Gauge: 12 AWGWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Length (Feet): 250' Gauge: 12 AWG Box Dimensions: 5"H x 6"W x 6"L WT: 6.8 lbs UPC: 091887100655

Read more less

AC Rotary Switch Panel 30 Ampere 2 positions + OFF, 2 PolePoles: 2Voltage: 120vAmperage: 30Positions: 2 + OFF Switches 2 - 120 Volt AC sources Includes 9011 heavy duty industrial rated switch Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Red reverse polarity LED indicators Green power available LED indicators Compact solution when circuit protection is provided elsewhere WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Max Breaker Quantity: 2 +OFF Voltage: 120v Box Dimensions: 5"H x 7"W x 9"L WT: 0.7 lbs UPC: 632085083670 Owner's Manual (pdf)

Read more less

Tinned Copper Battery Cable, 3/0 AWG (81mm²) - Black - 50'Ancor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC, and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C), and resists salt water, battery acid, oil, gasoline, heat, abrasion, and ultra-violet radiation. The highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing. Specifications: Length (Feet): 50' Gauge: 3/0 AWG Color: Black Box Dimensions: 1"H x 1"W x 11"L WT: 33.75 lbs UPC: 091887118049 Brochure (pdf)

Read more less

MultiPlus 12/1200 - 50-16 - 120V - VE. BusThe MultiPlus is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology, and a high-speed AC transfer switch in a single compact enclosure. Next to these primary functions, the MultiPlus has several advanced features, as outlined below.Parallel Operation and Three-Phase CapabilityUp to six Multis can operate in parallel to achieve higher power output.  In addition to parallel connection, three units can be configured for three-phase output.  PowerControl - Dealing with Limited Generator, Shore Side or Grid PowerWith the Multi Control Panel, a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.  PowerAssist - Boosting the Capacity of Shore or Generator PowerThis feature takes the principle of PowerControl to a further dimension. It allows MultiPlus to supplement the capacity of the alternative source. Where peak power is often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load is reduced, the spare power is used to recharge the battery.  Four Stage Adaptive Charger and Dual-Bank Battery ChargingThe main output provides a powerful charge to the battery system using advanced ‘adaptive charge’ software. The software fine-tunes the three-stage automatic process to suit the condition of the battery and adds a fourth stage for long periods of float charging. The adaptive charge process is described in more detail on the Charger datasheet and Victron's website under Technical Information. In addition to this, the MultiPlus will charge a second battery using an independent trickle charge output intended for a main engine or generator starter battery.  High Start-Up PowerIt is needed to start high-inrush loads such as power converters for LED lamps, halogen lamps, or electric tools.  Search ModeWhen Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode, the Multi, when operating in inverter mode, is switched off in case of no load or very low load and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.Programmable RelayBy default, the programmable relay is set as an alarm relay, i.e. the relay will de-energize in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).  Remote On/Off/Charger OnThree pole connector.  On-Site System Configuring, Monitoring, and ControlAfter installation, the MultiPlus is ready to go. Some settings can be changed with DIP switches. 500/800/1200VA models: remote switch/battery charge voltage/inverter frequency/search mode. 1600/2000VA models:  battery charge voltage/search mode. For more settings use VE-Config or the VE. Bus Smart dongle.  Remote Configuring and MonitoringInstall a Cerbo GX or other GX product to connect to the internet. Operational data can be stored and displayed on Victron's VRM (Victron Remote Management) website, free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed. Specifications: PowerControl: Yes PowerAssist: Yes Transfer Switch (A): 16 Inverter Specifications: Input Voltage Range (V DC): 9,5 – 17 V, 19 – 33 V, 38– 66 V  Output voltage: 230 VAC, ± 2% / Frequency 50 Hz ± 0,1% Continuous Output Power at 25°C (VA): 1200 Continuous Output Power at 25°C (W): 1000 Continuous Output Power at 40°C (W): 900 Continuous Output Power at 65°C (W): 600 Peak Power (W): 2400 Maximum Efficiency (%): 93 / 94 / 95% Zero Load Power (W): 10 / 9 / 10 W Zero Load Power in Search Mode (W): 3 / 3 / 3 W Charger Specifications: AC Input: Input voltage range: 187-265 VAC / Input frequency: 45 – 65 Hz Charge Voltage Absorption (V DC): 14,4 / 28,8 / 57,6 Charge Voltage Float (V DC): 13,8 / 27,6 Storage Mode (V DC): 13,8 / 27,6 / 55,2 Charge Current House Battery (A): 50 / 25 / 13 A Charge Current Starter Battery (A): 1A (12 V and 24 V models only) Battery Temperature Sensor: Yes General Specifications: Programmable Relay: Yes (1x) Protection: a - g VE.Bus Communication Port: For parallel and three-phase operation, remote monitoring and system integration  (RJ45-splitter ASS030065510 needed for 500 / 800 / 1200 VA models) Remote On-Off: On/off/charger only DIP Switches: Yes Internal DC Fuse: 200 / 100 / 50 A Operating Temperature Range: -40 - +65°C / -40 to 150°F (fan-assisted cooling), Humidity (non-condensing) max 95% Enclosure Specifications: Common Characteristics: Material & Color: aluminum (blue RAL 5012) / Protection category: IP 21 Battery-Connection: 35 / 25 / 10 mm² 230 V AC-Connection: G-ST18i connector Weight: 8.2 kg Dimensions (H x W x D): 406 x 250 x 100 mm / 15.98 x 9.84 x 3.94 in. Standards: Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1 Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3  Automotive Directive: ECE R10-5 Can be adjusted to 60Hz and 240V  Protection: Output short circuit, Overload, Battery voltage too high, Battery voltage too low, Temperature too high, 230VAC on inverter output, Input voltage ripple too high Non-linear load, crest factor 3:1                                                                               Up to 25°C ambient                                                                                                                          A programmable relay that can be set for General alarm, DC under voltage or generator start/stop signal function, AC rating: 230V/4A, DC rating: 4A up to 35VDC, 1A up to 60VDC  Remote/battery charge voltage/inverter frequency/search mode  Battery charge voltage/search mode Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Solar Splitter Pair MC4-Y (1x M-2F / 1x F-2M)This Victron solar splitter pair was designed to split one solar connector (MC4) into two separate MC4 connectors. This enables the parallel connection of two solar panels.Features:Constructed to last even after exposure to various types of weather conditionsPlease contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

Phoenix Inverter 12 VDC - 500W - 120 VAC - 50/60HzInverters allow you to power domestic equipment - requiring 230V/120V AC - using 'leisure' or 'automotive' batteries rated at 12V, 24V or 48V DC.Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Waveform: Pure Sine Wave Outlet Qty: 1 Duplex NEMA 5-15R Inverter Cont. Output Wattage: 350w GFCI: No DC Connection Type: Hardwire AC Connection Type: Hardwire Inverter Surge Rating: 900w Inverter Output Voltage: 120v Inverter Input Voltage: 9-17v Box Dimensions: 6"H x 9"W x 14"L WT: 9.55 lbs UPC: 8719076035992 Quick Guide (pdf)Brochure (pdf)

Read more less

SmartSolar MPPT 150/35 - 150V - 35AA solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.MPPT: Ultra Fast Maximum Power Point TrackingBy constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.Remote Monitoring and ControlRemotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.VictronConnectVictronConnect lets you get live status information and configure any Victron products which either have Bluetooth built-in, or are connected to a VE.Direct Bluetooth Smart Dongle.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Brochure (pdf)

Read more less
