3-Position Sealed Nylon Ignition Switch - OFF/Ignition & Accessory/Ignition & StartSealed keyed switches with integral Deutsch connectors feature fully sealed contact areas with O-rings and ultrasonic welding to IP67 waterproof rating. High-impact plastic for corrosion resistance and tested to SAE J259 for ignition switches.Features: Nominal voltage is 12V/24V DC Rated for 10A at 12V DC, 5A at 24V DC Fits panels up to 3/8" thick Same as Cole Hersee part number 95060-60 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

PT-24-20U Battery Charge“Smart” marine battery charging technology for 24-volt systems aboard workboats, military vessels, commercial vessels, and recreational craft. This charger interacts with batteries, providing the optimum three-stage charge process for fast recovery and conditioning, maximizing performance, and extending battery life.A selector switch adjusts output voltage to adapt to gel-cell, flooded lead-acid, or AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries’ ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance.Features: 24-volt model “Smart” circuitry provides three-stage charging – bulk, absorption, float Gel-cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages Multiple isolated output banks; ammeter indicates total output current The optional sensor adjusts output voltage based on battery temperature Current limiting prevents damage from overloading Use as a power supply; can power loads without a battery in line Built to last – rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry Protection: Current Limiting, Thermal Protection, Forced Air Cooling, Drip Shield Install in conjunction with PT-MCU for additional control and monitoring ABS-type approval for battery charging and power supplies Specifications: Input VAC (50-60 Hz.): 85 – 135, 170 – 270 Input Amps @ Full Load: @ 115 VAC: 6.8, @ 230 VAC: 4.3  Power Factor: .7 Max Output Amps: 20 Output Banks: 3 Battery Capacity (Amp-Hours): 40– 200 Operating Temp. Rating Reference: T-3 Case Size Reference: A-2 Case Size (H x W x D): 13.85B x 9.5 x 4.8B inches (35.2B x 24.1 x 12.2B centimeters) *Note with Dripshield installed B add .75” (1.9 cm) to height and 1.35” (3.4 cm) to depth Weight Lbs./Kg: 12/6 Optional Temp. Sensor Model: TCS-12/24     Remote Panel Model: NA Compliance Reference: CG, ABS Temperature Rating References: Temperature: -20 degrees C to +60 degrees C     Derate Linearly From 100% @ 50 degrees C to 60% @ 60 degrees C Nominal Output Voltages at Gel/Flooded Switch Settings (without Temperature Compensation): Gel-Cell: 28.0 VDC Charge @ 50% load and 27.2 VDC Float @ .5 amp load Flooded/AGM: 28.4 VDC Charge @ 50% load and 26.8 VDC Float @ .5 amp load Compliance References: UL: UL 1950 (per DNB report) CG: USCG CFR 183.410 (Ignition protected) EN: EN 60335-1 CE: Carries the CE mark ABS: PT Series meets SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13. This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Input - Voltage: 115/230v Charger Output - Amps: 20a Charger Output Voltage: 24v Charging Banks: 3 Inverter Input Voltage: 115/230v Inverter Output Voltage: 24v Outlet Qty: Hardwire Portable: No Box Dimensions: 11"H x 15"W x 20"L WT: 14.3 lbs Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Solar Starter Cable KitXantrex's Solar Starter Cable Kit provides weather-resistant, certified cables for connecting a solar panel to a charge controller, and from the charge controller to the battery.Features: Designed to connect a PV array to a charge controller and battery Weather-resistant and certified cables PV and battery cables both have built-in ferrule terminations for quick connections to the charge controller Battery cables have built-in fuse and ring terminals In the Box: (1) Pair of (black/red) 20-foot MC4-type PV cables (1) Pair of (black/red) 10-foot MC4-type battery cablesBuilt-in 30A DC ATC fuse on the red cable

Read more less

Medium Duty Battery Selector Switch - 250A ContinuousFeatures: For use with 6 to 32 Volt Marine Electrical Systems Capacity - 250 AMPS Continuous, 360 AMPS Intermittent When used with Non-Unitized Alternators, these models will interrupt the field current (reducing the possibility of damage) if turned "OFF" with the engine running Specs: Diameter: 5-1/4" Depth: 2-5/8"

Read more less

30A 125V Sealing Collar with Threaded RingThis sealing collar provides maximum moisture protection between the cordset and adapter. Designed for use with 20 and 30 amp locking systems. At Marinco, we make electrical products that stand up to the harshest environments. Every product we make is designed to withstand the rigors of life at sea.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Misc Box Dimensions: 2"H x 3"W x 3"L WT: 0.15 lbs UPC: 093344003509

Read more less

The Prowatt SW remote provides the convenience of a simple on/off remote function to the user. It also has an automatic ignition lockout feature to shut down the inverter's output when the vehicle's ignition or a 12 VDC enable is not engaged. A 25' remote cable is included with the remote panel.WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

3123 - SMS Panel Enclosure with ELCI (32A) & 3 Blanks - 230V ACThe 3123-panel enclosure is built for Equipment Leakage Circuit Interrupters (ELCI) main circuit breakers and other large frame devices.  Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10' of AC shore power inlet.Features: Blank apertures for custom breaker loading Glass-filled polycarbonate base Clear cover allows easy view of circuit breaker status Overlapping cover for strength and increased gasket protection Oversized, formed in place seamless PUR gasket Easily removable stainless steel hinge pin for unobstructed installation Stainless steel latch secures cover without penetrating the enclosure Blank circuit positions accommodate Carling Technologies™ A and C Series Flat Rocker and ELCI Main circuit breakers Includes waterproof glands LED lights for backlighting and ON indication Technical Specifications: Circuit Breaker Type - 1 x ELCI (32A) Main 230V and 3 x Blanks Dimensions (Overall) (H x W x D) - 7.6" x 7.4"" x 4.7" (192 x 188 x 120mm) Dimensions  (Enclosure) (H x W x D) - 6" x 6" x 4" (152 x 152 x 102mm) LEDs Installed - 1 x Red (Reverse Polarity - 230V AC and 3 x Green ON (230V AC) In the Box: 3123 Enclosure Glands x 6 Labels Mounting hardware Instruction manual *Sold as an Individual Quick Guide (pdf)Brochure (pdf)

Read more less

7065 ATO/ATC-Style Low Profile Circuit Breaker - 2-Pack - 15 Amp Use a manually resettable circuit breaker instead of an ATO or ATC fuse.Features: Drop in replacement for ATO and ATC blade style fuses Manual push button reset complies with ABYC circuit protection requirements Compatible with Water-Resistant ST-Blade Fuse Block with cover secured Compatible with all other ST-Blade Fuse blocks without cover Amperage: 15 Amp Color: Blue Maximum Voltage: 28V DC Circuit Breaker Type: Thermal Trip, Manual Reset Interrupt Capacity: 2000A @ 28V DC Minimum Operating Temperature: -30° C Maximum Operating Temperature: 77° C WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 15a Box Dimensions: 1"H x 2"W x 4"L WT: 0.5 lbs UPC: 632085070656

Read more less

8 AWG - #10 Nylon Ring Terminal - 25-PackAncor's Marine Grade terminals differ from automotive terminals by being designed for the harsh marine environment. Nylon insulators are easy to crimp and will not split. Barrels are designed to tightly grip the wire with the least effort. Tinned copper gives the least electrical resistance but the most corrosion protection.Features: Nylon insulated with insulation grip Double crimp, funnel entry UL 486C WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Ring Terminals Post Size: #10 Package Qty: 25 Heat Shrink: No Gauge: 8 AWG Box Dimensions: 1"H x 3"W x 4"L WT: 0.2 lbs UPC: 091887212327 Brochure (pdf)

Read more less

12V DC Dual USB Charger Socket - WhiteEasy to install in existing 12V DC socket hole providing convenient access for charging mobile devices.Specs: Maximum Output Current: 2.1A DC Cut Out Dimensions: 1 1/8 in (28.58 mm) dia. hole Input Voltage: 12V DC Input Voltage Range: 9-16V DC Output Voltage: 5V DC +/- 5% Parasitic Current Draw: 15mA DC Reverse Polarity Protection: Yes Short Circuit Protection: Yes Thermal Overload Protection: Yes WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

Single Pole Small Case 2" Flat Rocker Circuit BreakerPN:   7405Amperage:   25 AmpFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 250 Volts AC / 80 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 25a Box Dimensions: 1"H x 3"W x 5"L WT: 0.05 lbs UPC: 632085074050

Read more less

8385 DC 8 Position HorizontalFeatures: Voltage 12 VDC/24 VDC Amperage 100A All positive, negative and grounding buses installed, fully pre-wired Panels with meters include toggle switch for mounting up to 3 battery banks All panels with analog meters are owner upgradable to 24 Volts with 8240 or 8243 (18-32V DC meters) All circuit label positions are backlit on standard panels - No kit required "ON" indicating LEDs installed in all circuit positions MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Industry standard height and width Countersunk mounting holes throughout Detailed installation instructions and cutout template included Includes set of 30 common Large Format Panel Labels Over 500 individual labels available WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Max Breaker Quantity: 8 AC/DC: DC Voltage: 12/24v Box Dimensions: 5"H x 9"W x 12"L WT: 3 lbs UPC: 632085083854 Quick Guide (pdf)Owner's Manual (pdf)
