Electrical

XD Series Triple Flex 2 Relay-ACR-Relay with Knobs & Tinned WiresThe Egis relay replaces three individual high-amp relays with one compact module, reducing space significantly, eliminating the cost of external link cable connections, eliminating the risk of link cable connections vibrating loose, and providing clear, unambiguous awareness of how to operate manual controls and what state the manual controls have forced the relay into.Applications:  Designed to replicate common multi-battery switching and charge management functions - common dual battery load switching via the outer relays and a central automatic charging relay to share charge current are easily implemented Multiple automatic charging relays (ACR) into one device - for 3-4 battery systems that require 2 or 3 ACRs, a single three-relay ACR provides drastic improvements in off-state quiescent current draw, space used, and reduces unnecessary interconnection cables.  Expandable with link and cross-link busbars to additional dual, triple, or single XD relays - supports 3 or 4 battery systems with standard busbar interconnect accessories. Features: Bullet-proof construction - sealed to IP67/IP6K9K, high temperature electronics and materials allow mounting anywhere; stainless steel cable lug studs; large mounting holes accept 1/4-20 / M6 attachment hardware Intuitive manual control option simplifies operation and increases awareness of the state of the manual override and whether the device is being left in a locked-off or locked-on state (not available on competitive solutions) Simple programming via simple dip switches allows each relay function significant flexibility for OEMs and installers. 35-75% reduction in mounting space and product weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts Plug and play compatible with legacy competitor products - single, dual, and triple relay options are available with DTM/ATM connector pins compatible with ML Series bi-stable relays 90-95% less off-state current compared to competitive products and system solutions that require multiple devices for similar functionality Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Mechanical Switching Life: 1,000,000 Cycles Voltage Range (VDC): 8-36 Off-State Current Draw (mA): 1.3 State Change Current: 5A @ 12 VDC; 3A @ 24 VDC Focal Features:Led Status DisplayThe easy-to-see front-facing LED indicator provides visual device status, and the remote LED replicates the local on-device LED. 3-Position Manual overrideForce each relay open or closed, and optionally leave the knob in either position to lock the relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for the included weatherproof label set make circuit and relay identification easy. Blank labels for custom applications. Protective Cover includedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground. Stainless Hardware Corrosion is no issue with quality stainless steel studs and self-locking flanged nuts.ProgrammableVia dip switches located under the protective cover. An easy-to-use configuration guide on the reverse makes custom settings a breeze to configure for a wide variety of applications. Smaller FootprintXD relays offer a high amp rating in a smaller package than competitive solutions, reducing installation space requirements to a minimum. Integrated VentHigh-quality Gortex vents regulate internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

ATM/MINI 7.5 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 25 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 10 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 20 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

ATM/MINI 30 AMP Circuit Breaker - Type 3Features: Extremely Compact Circuit Breakers significantly reduce the space required to implement resettable circuit protection in mobile electrical systems. 32 Max VDC Rating easily supports 12- and 24-VDC systems. Manual push-to-reset Type 3 operation allows simple re-closing of the circuit breaker after any potential fault situations are investigated and cleared.   Color-coded enclosure variations, depending on continuous current, help reduce installation errors and ensure correct replacements. Harsh Environment design with high temperature materials and tin-plated copper alloy conductors. Supports ABYC Compliant Systems when wire sizes are reduced for branch circuit distribution.

Read more less

MRBF Terminal Fuse - 60 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 60 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 60a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 6"L WT: 0.05 lbs UPC: 850053879579

Read more less

MRBF Terminal Fuse - 80 Amp Transparent easy visual of fuse status Ignition-protected SAE/J1171-ISO8846 High interrupt rating satisfies ABYC requirements for DC main circuit protection on larger battery banks Color-coded for easy ID of amperage rating Features: Protects Electrical Circuits from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition Protected safe for installation in closed compartments with potentially explosive gases Harsh Environment design with shock and vibration resistance ideal for marine and vehicle electrical systems. Sealed Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 58 Vdc Rating: easily supports 12 to 48V nominal applications. High Interrupt Current: safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty: We stand behind our product's ability to meet your needs. Specifications: Continuous Current (Amps): 80 Max Voltage (VDC): 58 Interrupt Rating @ 14 VDC (Amps): 10,000 Interrupt Rating @ 48Vdc (Amps): 5,000 Interrupt Rating @ 58Vdc (Amps): 2,000 Ingress Protection: IP66 Specifications: Amperage: 80a Fuse Type: Terminal Type: Fuses Box Dimensions: 1"H x 2"W x 6"L WT: 0.05 lbs UPC: 850053879593

Read more less

80A Surface Mount Circuit Breaker - 285 SeriesThis 80A Egis circuit breaker protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction.Applications: Automatic circuit protection and manual on/off switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems regardless of the location Features: Sealed against dust and water intrusion to ensure reliable circuit protection for the life of the electrical system installation  High Voltage (48 Vdc) Rating - easily supports 12 and 24 VDC applications while offering advanced protection for 36 and 48 VDC High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current High Interrupt Current - safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 80 Max Voltage: 48 Cycling Endurance: 6,000 Interrupt Current @16 VDC (Amps): 5,000 Interrupt Current @28 VDC (Amps): 3,000 Ingress Protection Rating: IP67 Focal Features:ON/OFF High Visibility ControlsSealed against dust and moisture penetration. The high temperature rating for all installation locations.Integrated Terminal InsulatorsProtects against inadvertent shorts from positive terminals to adjacent grounded surfaces.Stainless Steel Hardware / Serrated Flange NutsCorrosion and vibration resistance for harsh environment applications.Proudly Made in the USAMade in the USA of high-quality components.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 80a Box Dimensions: 3"H x 3"W x 5"L WT: 0.35 lbs UPC: 850035199169 Quick Guide (pdf)

Read more less

XD Relay Cross-Over Bus BarThe XD Relay Cross-Over Bus Bar allows users to link together Egis XD Single, Dual, and Triple XD Relays to each other in multiple configurations and even to the Egis 8700 Mechanical Disconnect.  Linking relays together creates compact installations and allows for robust circuit switching and battery management.Features: Tin-plated copper ensures reliable circuit connectivity and anti-corrosive features keep it last long term. Robust Protective Insulation ensures no accidental contact shorts between XD relays. Specifications: Continuous Current (Amps): 500 Max Voltage (VDC): 72 Material: Tin-plated copper Size (L x W): 90 x 47mm Thickness: 2.8mm (1/8") Terminal Stud Hole Size: 10.5mm (3/8”) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Pro Series Dolphin Battery Charger - 12V, 90A, 110/220VAC - 50/60HzThe Dolphin Series of battery chargers has always been recognized for its outstanding quality, which the manufacturer is proud to support with a 2-year warranty. Due to production on a wide scale, Dolphin is able to offer high-quality, truly international battery chargers at a reasonable price.The Pro Range, which allows battery banks of up to 1000 amps to be charged, can be equipped with an optional touch-view touchscreen. It provides an intuitive display of measurements as well as charging phases (boost, absorption, and float), the allocated available power, and possible operating faults. The Pro range is equipped with communication via CAN bus, which means it can be used professionally in all land and industrial energy management sectors.Features: 12V-90A Dolphin Pro All Dolphin Battery Chargers and accessories are CE-marked and manufactured to UL and ABYC specifications The Pro Touch Range features a built-in TouchView remote in place of the standard display panel on the Pro chargers The Touchview control panel gives the user more information and control of the charger functions LED Display for programming and monitoring functions Temperature sensor for battery compensation Switch mode technology and a three-stage charging design with a power supply Modern, lightweight, and compact design with white aluminum powder-coated casing 4 screw simple install with easy access removable panel ISO 9002-certified manufacturing plant Three-Stage Charging CurveBulk Stage: A high current is sent to the battery until it reaches approximately 80% of its full charge.Absorption Stage: The voltage level is maintained and the current is reduced until the battery is 100% charged. Float Stage: Voltage and current are reduced to maintain the battery. Float gives what the battery requires. Specifications: Charger Input - Voltage: 110/220v Charger Output - Amps: 90a Charger Output Voltage: 12v Portable: No Box Dimensions: 9"H x 16"W x 19"L WT: 16.65 lbs UPC: 786142995014 Owner's Manual (pdf)

Read more less

187 - Series Thermal Circuit Breakers - Panel Mount70 Amp Circuit BreakerPN:  7041Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Self-trimming case eliminates the need for mounting panels or trim bezels Round case permits easy installation with standard sized hole saw Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 70a Box Dimensions: 3"H x 5"W x 8"L WT: 0.6 lbs UPC: 632085070410

Read more less
