316 Stainless Steel T-Bolt Clamp 3/4" Band - Range 8.25" to 8.69" *10-CountVery strong and secure clamp for critical installations. Trident Marine T-Bolt Clamps are built with safety in mind. With a 3/4″ (19 mm) wide band, this clamp ensures a greater area of coverage for a positive and strong union. It is recommended that two clamps be used on each end of a wet exhaust installation. These clamps can be used on any hose connection with peace of mind that they will last you a very long time. These clamps are sold in 2 configurations; part numbers ending in “L” signify that a long T-Bolt is being used and is for our Rubber Hose products. The part number without the “L” is for our Silicone and PVC products. 3-Year Warranty. Quick Guide (pdf)

Read more less

3/4" x 50' Coil Flex Marine Wet Exhaust & Water Hose - BlackTrident Flex wet exhaust hose for longer bent connections. In smaller I.D.’s for engine intake, critical water, drain, scupper bilge & sanitation uses. Resists heat, ozone, exhaust, panting, and collapse. Black High Temp EDPM Rubber 250°F (121°C) Max.Features:  Extra heavy tube and cover with wire helix between 2 ply reinforcement provides excellent flexibility and bend radius  Resists heat, ozone, exhaust, sani chemicals, panting and collapse Exceeds SAE J2006-R2, ABYC & NMMA P-1 exhaust standards, and Lloyd’s Registry Type Approved Application: Trident Flex wet exhaust hose for longer bent connections In smaller I.D.’s for engine intake, critical water, drain, scupper bilge & sanitation uses Construction: Tube & Cover: High temp EDPM rubber Color: Black with blue stripe Reinforcement: Multi-ply, high-tenacity polyester, steel helix Temperature Range: 250°F (121°C) Length: 50’ (15.24m) Specifications: Inner Diameter: (inch) 3/4" / (mm) 20 Outer Diameter: (inch) 1.15" / (mm) 29 Working Pressure: (Psi) 100 / (bar) 6.9 Bend Radius: (inch) 1" / (mm) 25 Weight: (Lb./50ft.) 23 / (Kg/m) 10.3 *Burst Pressure is 4 x Working Pressure Specifications: ID Diameter (inches): 3/4" Length (Feet): 50' Box Dimensions: 4"H x 22"W x 22"L WT: 22.2 lbs UPC: 704917004327 Quick Guide (pdf)

Read more less

3/8" Low Permeation Type A1-15 Fuel Line Hose - Black - Sold by the FootTrident Barrier Lined A1-15 Fuel Hose for both gasoline (including ethanol blends up to 85%) and diesel (including bio diesel blends up to B100). This hose is built with the best fuel, fire, and age-resistant formulation, and a unique "Barrier Liner" on the inside surface of the tube, so fuel is not in direct contact with rubber.Features:  Sold by the foot Provides extraordinary resistance to fuel permeation, aging, and also to fire, heat, cold, and the ozone  Also provides excellent bend-ability NMMA Type Accepted & CE certified Applications: Marine Fuel Hose (distribution, return, vent and transfer) For all marine fuels including gasoline, alcohol blends (CE-10), diesel and bio-diesel Construction: Tube: Nylon Internal Barrier, NBR  Cover: NBR/PVC Blend  Reinforcement: Polyester 2 spiral  Temperature Range: -20°F to 212°F (-28ºC to 100ºC) Specifications: Inner Diameter: (inch) 3/8" / (mm) 9.50 Outer Diameter: (inch) 0.681 / (mm) 17.3 Burst Pressure: (psi) 400 / (mpa) 2.76 Working Pressure: (psi) 100 / (mpa) 0.69 Bend Radius: (inch) 2" / (mm) 50.8 Weight: (lb/100 ft.) 15.6 / (kg/m) 0.233 Permeation Rate: <10 (Standard is 10g/m2/24 hrs (CE10) *The #365 series exceeds ABYC H-24 & H-33, SAE J1527, ISO 7840, USCG Type A1-15; CARB Executive Order RM-17-008 and EPA Certified low permeation Type A1-10This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: ID Diameter (inches): 3/8" Length (Feet): Sold By The Foot Box Dimensions: 1"H x 1"W x 1"L WT: 0.17 lbs Quick Guide (pdf)

Read more less

316 SS T-Bolt Clamp - 3/4" Band - 8.62"-9.19"  RangeVery strong and secure clamp for critical installations. Trident Marine T-Bolt Clamps are built with safety in mind. With a 3/4" (19 mm) wide band, this clamp ensures a greater area of coverage for a positive and strong union. It is recommended that two clamps be used on each end of a wet exhaust installation.Specifications: Band & Housing: 316 stainless steel 3/4 in. wide band T-Bolt and Nut: 18-8 stainless steel with nylon insert Hose Inner Diameter (inch): 8" Hose Outer Diameter (inch): 8.62" to 9.19" Quick Guide (pdf)

Read more less

4" ID 45-Degree EPDM Black Rubber Molded Wet Exhaust Elbow with 4 T-Bolt ClampsTrident EPDM marine wet exhaust connections are molded of high-temperature black EPDM rubber with a smooth bore and cover; except elbows of 6” I.D. or bigger have molded reinforcing ribs on the outside.Features: Four stainless steel clamps are included This elbow has excellent resistance to ozone, salt water, diesel fumes and splashes, cold, heat, and aging Exceeds (SAE J2006-R1, and ABYC & NMMA P-1 exhaust standards) Black high-temp EDPM rubber  Construction: Color: Black Reinforcement: Reinforcing ribs on 6” I.D. and above Temperature Range: up to 250°F (121°C) Specifications: Inner Diameter: (inch) 4” / (mm) 101.6 Outer Diamter: (inch) 4.5" / (mm) 114.3 A: (inch) 1.5” / (mm) 38.1 B: (inch) 1.5” / (mm) 38.1  C: (inch) 5.5” / (mm) 139.7 W: (inch) 0.25” / (mm) 6.35 Elbow Degree: 45 degrees Weight: (Lb/Ea) 0.95 / (Kg/Ea) 0.43 Specifications: ID Diameter (inches): 4" Box Dimensions: 8"H x 8"W x 9"L WT: 2.1 lbs UPC: 704917000459 Quick Guide (pdf)

Read more less

316 SS T-Bolt Clamp - 3/4" Band - 6.30"-6.74" RangeVery strong and secure clamp for critical installations. Trident Marine T-Bolt Clamps are built with safety in mind. With a 3/4" (19 mm) wide band, this clamp ensures a greater area of coverage for a positive and strong union. It is recommended that two clamps be used on each end of a wet exhaust installation.Specifications: Band & Housing: 316 stainless steel 3/4 in. wide band T-Bolt and Nut: 18-8 stainless steel with nylon insert Hose Outer Diameter (inch): 6.30" to 6.74"

Read more less

316 SS T-Bolt Clamp - 3/4" Band - 6.53"-7.10" RangeVery strong and secure clamp for critical installations. Trident Marine T-Bolt Clamps are built with safety in mind. With a 3/4" (19 mm) wide band, this clamp ensures a greater area of coverage for a positive and strong union. It is recommended that two clamps be used on each end of a wet exhaust installation.Specifications: Band & Housing: 316 stainless steel 3/4 in. wide band T-Bolt and Nut: 18-8 stainless steel with nylon insert Hose Inner Diameter (inch): 6" Hose Outer Diameter (inch): 6.53" to 7.10" Quick Guide (pdf)

Read more less

Compact Carbon CanisterCarbon canister systems utilize an engineered charcoal canister to reduce hydrocarbons entering the atmosphere. Other components of a carbon canister system are designed to ensure the tank fills to the proper level every time without spit-back or well-back. All Attwood carbon canister systems are designed to ensure liquid fuel or water does not reach the canister and are compatible with Jerry Can and marine nozzle refueling.Features: This is a single pack that contains two Compact Carbon Canisters Brackets OEM Installed Low permeation shell reduces overall system emissions Can be mounted in any orientation using brackets provided EPA / CARB Certified Fits a 5/8" vent hose Specifications:  Trailerable Vessel Capacity (EPA Rating): 70 Gallon Non-Trailerable Vessel Capacity (EPA Rating): 110 Gallon Trailerable Vessel Capacity (CARB Rating): 56 Gallon Non-Trailerable Vessel Capacity (CARB Rating): 110 Gallon  *Compatible with Ethanol blended fuels Quick Guide (pdf)

Read more less

316 SS Non-Perforated Worm Gear Hose Clamp - 15/32" Band - (1-1/16" – 1-1/2") Clamping Range - 10-Pack - SAE Size 16Premium Marine Grade, all AISI 316 (high tensile strength) Stainless Steel “HD NON-PERF” Worm Gear Hose Clamp. The 11.7 mm (0.46”) wide band is Non-Perforated and Smooth on the inside with Rolled Edges. This eliminates hose damage with increased clamping force. The High Strength, Compact, One Piece 16mm (0.63”) wide Housing provides one of the highest clamping force ratings of any worm gear style clamp.  Features: The screw head is 7mm Long service life and safety for most general-purpose hose applications and connections Recommendations: Measure hose O.D. before selecting clamp size for proper fit Double clamp on each hose end for critical applications Consider using our #720 Series wide band 316 SS T-Bolt Clamps for larger I.D. hoses (i.e. Exhaust Hose, etc.) Construction: Band & Housing: 316 Stainless Steel 11.7 mm wide band – 0.9mm thick Screw Drive: 316 Stainless Steel 7.0 mm screw head Specifications: SAE Size: 16 Hose Inner Diameter: (inch) 7/8" – 1" Clamping Range: (inch) 1-1/16"– 1-1/2" / (mm) 26-38 Recommended Torque Inch lbs: 35-45 Quick Guide (pdf)

Read more less

316 SS Non-Perforated Worm Gear Hose Clamp - 15/32" Band - (7/8" – 1-1/4") Clamping Range - 10-Pack - SAE Size 12Premium Marine Grade, all AISI 316 (high tensile strength) Stainless Steel “HD NON-PERF” Worm Gear Hose Clamp. The 11.7 mm (0.46”) wide band is Non-Perforated and Smooth on the inside with Rolled Edges. This eliminates hose damage with increased clamping force. The High Strength, Compact, One Piece 16mm (0.63”) wide Housing provides one of the highest clamping force ratings of any worm gear style clamp.  Features: The screw head is 7mm Long service life and safety for most general-purpose hose applications and connections Recommendations: Measure hose O.D. before selecting clamp size for proper fit Double clamp on each hose end for critical applications Consider using our #720 Series wide band 316 SS T-Bolt Clamps for larger I.D. hoses (i.e. Exhaust Hose, etc.) Construction: Band & Housing: 316 Stainless Steel 11.7 mm wide band – 0.9mm thick Screw Drive: 316 Stainless Steel 7.0 mm screw head Specifications: SAE Size: 12 Hose Inner Diameter: (inch) 5/8" – 1-1/8" Clamping Range: (inch) 7/8" – 1-1/4" / (mm) 22-32 Recommended Torque Inch lbs: 35-45 Quick Guide (pdf)

Read more less

316 SS Non-Perforated Worm Gear Hose Clamp - 15/32" Band - (1-1/2" - 2") Clamping Range - 10-Pack - SAE Size 24Premium Marine Grade, all AISI 316 (high tensile strength) Stainless Steel “HD NON-PERF” Worm Gear Hose Clamp. The 11.7 mm (0.46”) wide band is Non-Perforated and Smooth on the inside with Rolled Edges. This eliminates hose damage with increased clamping force. The High Strength, Compact, One Piece 16mm (0.63”) wide Housing provides one of the highest clamping force ratings of any worm gear style clamp.  Features: The screw head is 7mm Long service life and safety for most general-purpose hose applications and connections Recommendations: Measure hose O.D. before selecting clamp size for proper fit Double clamp on each hose end for critical applications Consider using our #720 Series wide band 316 SS T-Bolt Clamps for larger I.D. hoses (i.e. Exhaust Hose, etc.) Construction: Band & Housing: 316 Stainless Steel 11.7 mm wide band – 0.9mm thick Screw Drive: 316 Stainless Steel 7.0 mm screw head Specifications: SAE Size: 24 Hose Inner Diameter: (inch) 1-5/16" - 1-3/8" Clamping Range: (inch) 1-1/2" - 2" / (mm) 38-50 Recommended Torque Inch lbs: 35-45 Quick Guide (pdf)

Read more less

316 SS Non-Perforated Worm Gear Hose Clamp - 3/8" Band - 11/32"-25/32" Clamping Range - 10-Pack - SAE Size 6Premium Marine Grade, all AISI 316 (high tensile strength) Stainless Steel Compact “HD NON-PERF” Worm Gear Hose Clamp. The 9.7 mm (0.382”) wide band is Non-Perforated and smooth on the inside with rolled edges. This eliminates hose damage with increased clamping force. The high strength, compact, one-piece 14mm (0.55”) wide housing provides one of the highest clamping force ratings of any worm gear style clamp.Features: The screw head is 7mm Long service life and safety for most general-purpose hose applications and connections Recommendations: Measure hose O.D. before selecting clamp size for proper fit Double clamp on each hose end for critical applications Construction: Band & Housing: 316 Stainless Steel 9.7 mm wide band – 0.8mm thick Screw Drive: 316 Stainless Steel 7.0 mm screw head Specifications: SAE Size: 6 Hose Inner Diameter: (inch) 5/16" - 3/8" Clamping Range: (inch) 11/32" – 25/32" / (mm) 13-20 Recommended Torque Inch lbs: 25-35 Quick Guide (pdf)

Read more less
