Lighting

Newt - Livewell & Courtesy Light - Blue DimmingWet or dry, it doesn't matter. Lumitec's Newt line was originally designed as a livewell light. But when our customers saw its small size, amazing output, and ease of installation it found use under cabinets, in storage lockers, lighting toe kicks, and even overhead. Choose white, red, or blue light. Completely sealed and IP67 compliant. Silicone gasket included.Specifications: Voltage: 10 - 16V DC 12V DC Amps: 45mA 24V DC Amps: N/A Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 2 Lumens (White): 19 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 0.88" (2.22cm) Height: 0.88" (2.22cm) Depth: 0.78" (1.98cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Bulb Type: LED Voltage - Input Range (Volts): 10-16v Housing: Clear LED Color: Blue Dimming: Yes Box Dimensions: 1"H x 4"W x 4"L WT: 0.05 lbs UPC: 089300103482 Quick Guide (pdf)Brochure (pdf)

Read more less

Rail2 12" Light - White/Red DimmingLumitec's original rail light amazed customers when it was first introduced in 2008. With up to 3 times greater output than its predecessor and a sleek new look, Rail2 raises the bar. The integrated microprocessor controls dimming and color change from two wires, with no external control modules. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Proudly made in the USA.Specifications: Voltage: 10 - 30V DC 12V DC Amps: 920mA 24V DC Amps: 430mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 12 Lumens (White): 490 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 11.72" (29.76cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Bulb Type: LED Voltage - Input Range (Volts): 10-30v Housing: White LED Color: White/Red Dimming: Yes Box Dimensions: 1"H x 3"W x 15"L WT: 0.3 lbs UPC: 089300103451 Quick Guide (pdf)Brochure (pdf)

Read more less

Aurora LED Dome Light - White Finish - White/Blue DimmingCustomers told us they wanted a high quality LED replacement for the ubiquitous dome light. It had to be bright, with wide even light. They wanted a clean look, an intuitive and reliable switch, and a notable level of quality. We delivered, and then added IP67 immersion protection. We then raised the bar with multiple color output options and dimming. Lumitec's Aurora Dome Light stands apart.Specifications: Voltage: 10 - 30V DC 12V DC Amps: 290mA 24V DC Amps: 160mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 4 Lumens (White): 180 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 4.00 (10.16cm) Height: 4.00" (10.16cm) Depth: 0.73" (1.84cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: LED: Yes Voltage - Input Range (Volts): 10-30v Dimming: Yes Housing: White LED Color: White/Blue Box Dimensions: 4"H x 6"W x 8"L WT: 0.3 lbs UPC: 089300103383 Quick Guide (pdf)Brochure (pdf)

Read more less

MiniRail2 6" Light - White Non DimmingSmall. Attractive. Powerful. Made in the USA and priced right. What else could you ask for? Lumitec's MiniRail2 delivers. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Choose White, Red, or Blue output.Specifications: Voltage: 10 - 30V DC 12V DC Amps: 360mA 24V DC Amps: 200mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 6 Lumens (White): 145 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 5.90" (14.97cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Bulb Type: LED Voltage - Input Range (Volts): 10-30v Housing: White LED Color: White Dimming: No Box Dimensions: 1"H x 3"W x 9"L WT: 0.2 lbs UPC: 089300103413 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

MiniRail2 6" Light - Red Non DimmingSmall. Attractive. Powerful. Made in the USA and priced right. What else could you ask for? Lumitec's MiniRail2 delivers. As with all Lumitec luminaires, the Rail2 is IP67 compliant, which means despite its great looks it is just at home on a spray-drenched hard top as a teak-adorned salon. Choose White, Red, or Blue output.Specifications: Voltage: 10 - 30V DC 12V DC Amps: 360mA 24V DC Amps: 200mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 6 Lumens (White): 145 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 5.90" (14.97cm) Height: 1.11" (2.82cm) Depth: 0.60" (1.53cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Bulb Type: LED Voltage - Input Range (Volts): 10-30v Housing: White LED Color: Red Dimming: No Box Dimensions: 1"H x 3"W x 9"L WT: 0.2 lbs UPC: 089300103437 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Aurora LED Dome Light - White Finish - White/Red DimmingCustomers told us they wanted a high quality LED replacement for the ubiquitous dome light. It had to be bright, with wide even light. They wanted a clean look, an intuitive and reliable switch, and a notable level of quality. We delivered, and then added IP67 immersion protection. We then raised the bar with multiple color output options and dimming. Lumitec's Aurora Dome Light stands apart.Specifications: Voltage: 10 - 30V DC 12V DC Amps: 290mA 24V DC Amps: 160mA Correlated Color Temperature: 5000 Color Rendering Index: 70+ Rated Watts: 4 Lumens (White): 180 Operating Temp (°F): -31 to + 131 F Operating Temp (°C): -35 to +55 C Width: 4.00 (10.16cm) Height: 4.00" (10.16cm) Depth: 0.73" (1.84cm) WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: LED: Yes Voltage - Input Range (Volts): 10-30v Dimming: Yes Housing: White LED Color: White/Red Box Dimensions: 3"H x 5"W x 9"L WT: 0.3 lbs UPC: 089300103390 Quick Guide (pdf)Brochure (pdf)

Read more less

LED Bulkhead/Livewell Light "The Shortie"Bezels: WhiteLED Color: White Operates 9-16 Volt DC Systems Rated at 100,000 Hours of Service Life Grommet requires 3/4" Hole Shock and Vibration Proof Cool to the Touch No Corrosion Rated for Underwater Use Can also be used as accent lighting on yachts, boats, RV's and trailers WARNING: This product can expose you to chemicals including BISPHENOL A (BPA) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Bulb Type: LED Voltage - Input Range (Volts): 9-16v Housing: White LED Color: White Dimming: No Box Dimensions: 1"H x 4"W x 6"L WT: 0.1 lbs UPC: 601373095473

Read more less

LED Bulkhead/Livewell Light "The Shortie"Bezels: WhiteLED Color: Blue Operates 9-16 Volt DC Systems Rated at 100,000 Hours of Service Life Grommet requires 3/4" Hole Shock and Vibration Proof Cool to the Touch No Corrosion Rated for Underwater Use Can also be used as accent lighting on yachts, boats, RV's and trailers WARNING: This product can expose you to chemicals including BISPHENOL A (BPA) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Bulb Type: LED Voltage - Input Range (Volts): 9-16v Housing: White LED Color: Blue Dimming: No Box Dimensions: 1"H x 4"W x 6"L WT: 0.1 lbs UPC: 601373092472

Read more less

Battery Navigation Light Requires 4 AA batteries (not included) Molded one piece body construction Shock resistant neoprene accents Incandescent or LED available Rated at 100,000 hours LED service life LED uses 90% less energy than incandescent Sealed heavy duty On/Off switch Insert molded brass threaded mounting bushings Removable lamp carriage assembly 6.18" x 2.53"WARNING: This product can expose you to chemicals including BISPHENOL A (BPA) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Lens Color: Clear Housing: White Voltage - Input Range (Volts): 4 AA Batteries (Not Included) LED: Yes Box Dimensions: 2"H x 7"W x 12"L WT: 0.8 lbs UPC: 601373564276

Read more less

Stealth Series - Universal Replacement Pole Light(1347)A reduced glare globe preserves night vision while under way. Adjustability of the globe allows for proper horizontal alignment reguardless of base configuration. Black Plastic 3/4 Inch Diameter Anodized Aluminum Tube 2 Collars - Threaded and Locking 2 Screw Positions Wide 40° Adjustable Head Gold Plated Contacts Locking CollarFits Bases: 1045, 1046, 1047, 1059 & 1060 (2 Pin)Large Threaded CollarFits Bases: 1048 (2 Pin) Specifications: Lens Color: White Visible Range (Miles): 2nm Housing: Black Voltage - Input Range (Volts): 12v LED: Yes Box Dimensions: 4"H x 7"W x 39"L WT: 1.3 lbs UPC: 085226771262 Quick Guide (pdf)

Read more less

Omega SeriesUniversal Replacement Reduced Glare DesignCertified for use on power driven vessels under 20 Meters in lengthPole Length - 36"A reduced glare globe preserves night vision while under way. Adjustability of the globe allows for proper horizontal alignment regardless of base configuration.Omega's L.E.D. Light Source Takes TheDelta Design One Step FurtherOmega Offers:Long Life Vibration Resistance Low Power Drain Improved Corrosion Resistance Low Operating Temperatures Sealed from the Environment 2 Collars - Threaded and Locking 2 Screw Position Wide 40° Adjustable Head Gold Plated Contacts Specifications: Lens Color: White Visible Range (Miles): 2nm Voltage - Input Range (Volts): 12v Housing: Black LED: Yes Box Dimensions: 5"H x 7"W x 42"L WT: 2.3 lbs UPC: 085226359927 Quick Guide (pdf)

Read more less

Locking Collar Pole Light Mounting Base(2 Pin) - Plug-In Type Base5° RakeConstructionChrome Plated Zinc Alloy Black Plastic Waterproof snap-on cover Pigtail LeadsFits Figs. 1343, 1348, 1400, 1445, 1451, 1455, 1456, 1465 and 1470 Series All-Round Pole Lights Quick Guide (pdf)

Read more less
