X-23BU RitchieSport Compass - Dash Mount - Black/BlueFeatures: 2″ (51 mm) Direct Reading Dial Easily Installed, Fits Standard 2 1/16″ (5.50 cm) Instrument Hole The View Adjusts up to 30 degrees Scientifically Matched Sapphire Jewel & Hardened Steel Pivot Dial Movement Exclusive Built-in Green NiteVu Lighting High-Temperature Composite Construction for Extended Operating Range DirectiveForce Magnets Exclusive 5-Year Ritchie Warranty Specifications:Approx. Shipping Weight: 5oz (142g)Notes: X-23 Compasses do not have Built-in Compensators. It comes standard with 12V lighting Some custom-built OEM models may have different lighting. Specifications: Backlight: Yes Lubber Lines: Yes Mounting Style: Dash Read: Front Box Dimensions: 3"H x 4"W x 5"L WT: 0.55 lbs UPC: 010342171214

Read more less

The Micro Compass proved a huge advantage over competitors using glass ball compasses. To win races you must react to even small wind shifts. Readable, precise and reliable heading information from you compass is critical. Digital compasses deliver this data right into your natural field of view, where you need it, how you need it, when you need it. The Micro Compass's tactical scale gives you clear stable figures corresponding on port and starboard tack. The readings whilst tacking are always the same, meaning you never have to remember numbers.Data Displayed: Heading Tactical Scale Race Timer Features: No wires or connections to make Simple to set-up and use Totally waterproof (submersible from 10m) Lightweight only .34 lbs. Ultra wide viewing angles Battery level indicator Easy-to-read large digits Owner's Manual (pdf)

Read more less

SC130 Satelite Compass with DisplayThe SC130 are the latest satellite compasses built on FURUNO’s commercial-grade technology platform. These satellite compasses prove their value by increasing the accuracy of other devices, such as Radar, ARPA, Scanning Sonar, Current Indicator, Chart Plotter, ECDIS and Autopilots. They provide a highly accurate heading input to these other technologies by utilizing the very latest GNSS (Global Navigation Satellite System). This satellite system is comprised of GPS, Galileo and GLONASS to ensure the highest precision and a continuous coverage.The Satellite Compass provides a variety of data, including GPS Positioning, SOG (Speed Over Ground), COG (Course Over Ground), ROT (Rate Of Turn) and 3-axis speed (bow, stern and longitudinal). All of these data assist with critical maneuvers, such as berthing. The Compass is maintenance-free - a great asset for any vessel - and connects easily into the existing shipboard network via Ethernet connection.The SC130 provides highly accurate heading data of 0.25° for autopilot, Radar, ARPA, Scanning Sonar, Current Indicator, Chart Plotter, ECDIS and Autopilots. It is ideal for medium to large vessels navigating in crowded ports and making precise maneuvers, such as berthing and docking, and is IMO Type-approved as THD, GPS and ROTI, complying with the IEC/ISO requirements. It features a rapid follow-up rate 40°/s, twice the IMO high-speed craft requirement of 20°/s.Package Contains: SC701 Junction Box  SC702 Display 4.5"  SC1303 Antenna 3GPS **DOES NOT INCLUDE CABLE**This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Backlight: Yes Box Dimensions: 7"H x 15"W x 17"L WT: 71.7 lbs Brochure (pdf)

Read more less

Helmsman CompassFeatures: 3 3/4″ (95 mm) Open Face Dial or CombiDial Easily Installed, Fits 4″ (102 mm) Mounting Hole Exclusive Built-in Green NiteVu Night Illumination Built-in Compensators to Easily Adjust for Deviation Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on Movable Sun Shield 45 Degree Lubber Lines High Temperature Composite Construction for Extended Operating Range Adapter Rings Available. Sold separately. 6″ (153 mm) 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 2lbs (907g)Notes:All magnetic compasses come standard with 12v lighting. 24 & 32v lighting options are available. Specifications: Read: Rear Lubber Lines: Yes Backlight: Yes Mounting Style: Flush Box Dimensions: 5"H x 6"W x 9"L WT: 2.1 lbs UPC: 010342138255 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

SuperSport CompassDeveloped for and tested on offshore race boats the SuperSport Series compasses feature the PowerDamp® Plus dial. This dial technology features the PowerDamp® dial skirt to prevent oscillation, larger DirectiveForce™ magnets for quick lock on and extra-large steel pivots and jewels for smooth fast action.Features: 5" (127 mm) PowerDamp Plus, High-Visibility Blue Open Face Dial with Extra Large White Numerals Easily Installed, Fits 6 1/4″ (15.88 cm) Mounting Hole Built-in Compensators to Easily Adjust for deviation Internal Gimbal Systems for Maximum Stability During Adverse Pitch and Roll Conditions 12v Green LED lighting Standard 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 5 lbs 12 oz (2.6 kg) Notes:12v lighting standard – 24 & 32v lighting options are available. Specifications: Mounting Style: Flush Lubber Lines: Yes Backlight: Yes Read: Rear Box Dimensions: 9"H x 10"W x 11"L WT: 5.8 lbs UPC: 010342050182 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Navigator CompassFeatures: 4 1/2″ (115 mm) PowerDamp Open Face Dial with Large Numerals Ideal for both Power and Sailboats Fits all Popular Sailboat Steering Pedestals Easily Installed Stainless Housing selections: Brushed stainless, powder-coated black, or powder-coated white 12v Green LED lighting Standard Built-in Compensators to Easily Adjust for Deviation Movable Sun Shield 45 Degree Lubber Lines High Temperature Construction for Extended Operating Range Weather Shield available. Model No. WS-P 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 3lbs 10oz (1.65 kg)Notes:12v lighting standard - 24 & 32v lighting options are available. Specifications: Mounting Style: Binnacle Lubber Lines: Yes Read: Rear Backlight: Yes Box Dimensions: 7"H x 8"W x 8"L WT: 3.6 lbs UPC: 010342150219 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

NMEA0183 GNSS SAT Compass with 49' Cable & Pole MountExperience superior navigation from the accurate heading and positioning performance available with the V200 SAT Compass. The multi-GNSS V200 supports GPS, GLONASS, BeiDou, Galileo, and QZSS and offers an amazing world-wide 30cm (11.8") RMS accuracy via the optional Atlas GNSS global correction service. The Vector V200 offers an incredible combination of simple installation, small form factor, and amazing performance. The compass - measuring only 35cm (13.7") in length - mounts easily to a flat surface or pole. The stability and maintenance-free design of the Vector V200 provides simple integration into autopilots, chart plotters, and AIS systems.Features: Uses all known Satellite Systems GPS, GLONASS, Galileo, BeiDou, QZSS 30cm (11.8") RMS world-wide positioning accuracy with Atlas correction subscription  0.75 degree heading accuracy in an amazingly small form factor Excellent in-band and out-of-band interference rejection Integrated gyro and tilt sensors help deliver fast start-up times and provide heading updates during temporary loss of satellites Provides heading, positioning, heave, roll and pitch Specifications: Output Type: NMEA 0183 Mounting Style: Surface Lubber Lines: No Backlight: No Box Dimensions: 9"H x 9"W x 15"L WT: 8.65 lbs UPC: 010407520568 Brochure (pdf)

Read more less

Voyager CompassFeatures: 3″ (76 mm) CombiDamp Dial Easily Installed Exclusive Built-in Green NiteVu Night Illumination Built-in Compensators to Easily Adjust for Deviation Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on Movable Sun Shield High Temperature Composite Construction for Extended Operating Range 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 1lb 8oz (680g)Notes:Uses 2 sets of lights.Comes standard with 12v lighting. 24 & 32v lighting options are available. Some custom built OEM models may have different lighting. Specifications: Read: Both Lubber Lines: Yes Backlight: Yes Mounting Style: Flush Box Dimensions: 6"H x 6"W x 6"L WT: 1.3 lbs UPC: 010342140074 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Navigator CompassFeatures: 4 1/2″ (115 mm) Open Face Dial with Large Numerals Easily Installed, Fits 4.75″ (121 mm) to 5.125″ (130 cm) Mounting Hole Scientifically Matched Sapphire Jewel and Hardened Steel Pivot Dial Movement Powerful DirectiveForce Magnets for Fast Heading Lock-on 12v Green LED lighting Standard Built-in Compensators to Easily Adjust for Deviation Movable Sun Shield 45 Degree Lubber Lines High Temperature Construction for Extended Operating Range 100% Repairable Exclusive 5-Year Ritchie Warranty Approx. Shipping Weight: 2 lbs 10oz (1.19kg)Notes:Comes standard with 12v lighting. 24 & 32v lighting options are available. Some custom built OEM models may have different lighting. Specifications: Backlight: Yes Lubber Lines: Yes Read: Rear Mounting Style: Flush Box Dimensions: 7"H x 8"W x 8"L WT: 2.9 lbs UPC: 010342150004 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

SCX21 Satellite CompassUtilizing four separate GNSS Antennas for the ultimate in responsiveness, the SCX21 sets a new standard for reliable and accurate heading for all of your marine electronics. The four antennas ensure reliable heading performance, even under the most challenging of conditions. The unprecedented quad antenna design of the SCX21 makes it capable of calculating extremely accurate heading, pitch, roll, and heave information, even when line of sight is limited to only a single satellite. They greatly enhance the performance of onboard equipment such as Radar, Fish Finders, Sonar, and Autopilots.Features: Outputs accurate Time, Position, Heading, COG/SOG, ROT (10 degrees/second), Roll/Pitch/Heave 3-Axis Speed, Air Temperature and Air Pressure data Unprecedented heading accuracy for Radars, Sonars, and Navigation 1.0 degree heading accuracy, 0.02 knot speed accuracy Extremely compact with easy & flexible installation for reduced susceptibility to multi-path interference This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

Ritchie H-741-C Helmsman & SuperSport Compass Cover - 2004 to Present - WhiteProtective cover for Helmsman and SuperSport compasses.For Compass Models:HB-740, HB-741, HB-845, HF-742, HF-742W, HF-743, HF-743W, HD-744, HD-745, SS-1002, and SS-1002WApprox. Shipping Weight: 1lb (454g)

Read more less

NMEA2000 GNSS SAT Compass with Pole Mount (No Cable Included)Experience superior navigation from the accurate heading and positioning performance available with the V200 SAT Compass. The multi-GNSS V200 supports GPS, GLONASS, BeiDou, Galileo, and QZSS and offers an amazing world-wide 30cm (11.8") RMS accuracy via the optional Atlas GNSS global correction service. The Vector V200 offers an incredible combination of simple installation, small form factor, and amazing performance. The compass - measuring only 35cm (13.7") in length - mounts easily to a flat surface or pole. The stability and maintenance-free design of the Vector V200 provides simple integration into autopilots, chart plotters, and AIS systems.Features: Uses all known Satellite Systems GPS, GLONASS, Galileo, BeiDou, QZSS 30cm (11.8") RMS world-wide positioning accuracy with Atlas correction subscription  0.75 degree heading accuracy in an amazingly small form factor Excellent in-band and out-of-band interference rejection Integrated gyro and tilt sensors help deliver fast start-up times and provide heading updates during temporary loss of satellites Provides heading, positioning, heave, roll and pitch Specifications: Output Type: NMEA 2000 Mounting Style: Surface Lubber Lines: No Backlight: No Box Dimensions: 9"H x 9"W x 15"L WT: 5.1 lbs UPC: 010407520575 Brochure (pdf)
