Marine Plumbing & Ventilation - Ballast Pumps

Ballast King Bronze DC Pump with Deutsch Connector - No Reversing Switch - 15 GPM Wakeboard and Ski Boat Ballast PumpFeatures: Flow rate: 15 US gallons/min (57 Litres/min) Self-priming from dry up to 1.2m (4ft) Adds approx 125lbs (56kgs) of ballast per minute Reversible to both fill and empty tanks Simple design means fewer wearing parts ISO 8846 MARINE (Ignition protection) Applications:The Ballast King is designed to pump water into Wakeboard Liquid Ballast Tanks and when reversed will also pump water out of them. It has a flow rate of 15 gallons per minute, so it can fill most ballast tanks in about five minutes. It is equipped with a Run-Dry Protection Device (patent pending) to automatically shut-off the pump and protect the impeller from run-dry damage should the pump be mistakenly left on after the Ballast Tank is empty. Specifications: Body Materials: Bronze Impeller: Jabsco Neoprene compound Seal: Lip Type Port(s): 1/2" Internal Pipe Threads 1" External Hose Barb  Voltage: 12 (Vdc) Amp Draw: 19 (amp) Fuse Size: 25 (amp) Motor Type: Equipped with Run-Dry Protection Device (Patent Pending) Permanent Magnet Type Fully Enclosed Stainless Steel Shaft Ball Type Shaft Bearing Reversible  Duty Cycle: 30 Minutes Max Dimensions: 3 5/8 x 8 x 4 3/4 (inches) Brochure (pdf)

Read more less

Mastercraft Ballast Pump - 12VThe Jabsco Wake/Surf boat Ballast pump is the direct replacement for Mastercraft part number 300249. The Jabsco pump comes standard with a green Run Dry Impeller and has the standard electrical quick connector already installed. Just connect your hoses, mount the pump in the boat, plug the power leads together and your surfing and wakeboarding again.Features: Same electrical connection as original OEM Same mounting as the OEM unit, no need to drill more holes The leader for flexible Impeller Ballast Pumps WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Volts: 12v Box Dimensions: 5"H x 6"W x 10"L WT: 6.8 lbs UPC: 671880629003

Read more less

Talulah Ballast Pump - 13.5 GPM - 12VFeatures: Built in Thermal Overheat Protection: Automatic reset after cooling down Monitor Filling: Tanks must have overfill protection Retrofit Possible: Important to have full bore hoses – without restriction Dry Run Impeller* Intermittent Duty Important to have good electric installation and proper wire size (Acc. to ISO 10133) Recommend fresh batteries and engine running (alternator running) to ensure power supply *Dry Run

Read more less

Talulah High Flow Ballast Pump - 30 GPM - 12VWith an extraordinary 30GPM rating, the Johnson Pump Talulah HighFlow Ballast Pump represents the industry gold standard of high speed, reliable and efficient reversible ballast pumps. Built with ball bearings, a solid bronze pump head, and built-in thermal protection, this ballast pump is exceptionally durable and built to last. The compact size allows for flexibility in system design without using valuable storage space and without sacrificing the versatile high volume connections unique to the design of the pump head. The Talulah HF also offers run dry protection, the integrated Run-Dry Protection circuit monitors the current draw of the pump and automatically shuts it off if conditions indicate water is no longer flowing through the pump. This innovative feature can help minimize any damage to the new neoprene orange impeller, which itself delivers faster fill/drain times and is more reliable than the previous models. In addition, the ignition protected design makes this pump suitable for installation in the bilge compartment of the boat without risk of fire or explosion due to fuel vapors. Whether for use in a new automated ballast system installation or to upgrade the pumps in an existing system for faster fill and drain times, the Talulah HF 30GPM Ballast Pump delivers the next generation of pump performance in the wakeboarding world.Features: Built in Thermal Overheat Protection: Automatic reset after cooling down Monitor Filling: Tanks must have overfill protection Retrofit Possible: Important to have full bore hoses – without restriction Dry Run Impeller* Intermittent Duty Important to have good electric installation and proper wire size (Acc. to ISO 10133) Recommend fresh batteries and engine running (alternator running) to ensure power supply *Dry Run

Read more less

Ballast PumpThis Wake/Surf boat Ballast pump is the same one utilized by most major boat builders. The Jabsco pump comes standard with a green Run Dry Impeller. This pump has the standard electrical quick connector installed. Just connect your hoses, mount the pump into the boat, in its orginal position, plug the power leads together and your surfing and wakeboarding again. Impeller # 6303-0007-P - Always Carry a Spare Orignial OEM Ballast Pump Replacement Run Dry Impeller - Green Same electrical connection as Original OEM Same mounting as the OEM unit, no need to drill more holes The leader for Flexible Impeller Ballast Pumps WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Ballast PumpToday's Wakeboard and Ski tow boats need to be able to take on water ballast to modify their wake formation. A development of our tried and tested Puppy Pumps lets these specialist craft rapidly take on and dump ballast, while modern electronics guard against dry running damage to the impellerThe choice of motor boat builders for ski and wakeboard ballast systems. Includes Run-Dry Protection Device 9 GPM (34 LPM) flow rate Approximately 80 pounds of water ballast per minute Self-priming to 3' Reversible pump both fills and empties ballast tanks Reversing switch Ignition protected Ports 1" (25mm) hose barb external 1/2" NPT internal WARNING: This product can expose you to chemicals including LEAD which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gallons Per Minute: 9 GPM Volts: 12v Reversible: Yes Box Dimensions: 4"H x 6"W x 10"L WT: 7.15 lbs UPC: 671880535090 Owner's Manual (pdf)

Read more less

Ballast King Bronze DC Pump with Reversing Switch - 15 GPMWakeboard and Ski Boat Ballast PumpFeatures: Flow rate: 15 US gallons/min (57 Litres/min) Self-priming from dry up to 1.2m (4ft) Adds approx 125lbs (56kgs) of ballast per minute Reversible to both fill and empty tanks Simple design means fewer wearing parts. ISO 8846 MARINE (Ignition protection). Applications:The Ballast King is designed to pump water into Wakeboard Liquid Ballast Tanks and when reversed will also pump water out of them. It has a flow rate of 15 gallons per minute, so it can fill most ballast tanks in about five minutes. It is equipped with a Run-Dry Protection Device (patent pending) to automatically shut-off the pump and protect the impeller from run-dry damage should the pump be mistakenly left on after the Ballast Tank is empty. Specifications: Body Materials: Bronze Impeller: Jabsco Neoprene compound Seal: Lip Type Port(s): 1/2" Internal Pipe Threads 1" External Hose Barb  Voltage: 12 (Vdc) Amp Draw: 19 (amp) Fuse Size: 25 (amp) Motor Type: Equipped with Run-Dry Protection Device (Patent Pending) Permanent Magnet Type Fully Enclosed Stainless Steel Shaft Ball Type Shaft Bearing Reversible  Duty Cycle: 30 Minutes Max Dimensions: 3 5/8 x 8 x 4 3/4 (inches) WARNING: This product can expose you to chemicals including NICKEL (METALLIC) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications: Gallons Per Minute: 15 GPM Volts: 12v Box Dimensions: 6"H x 6"W x 12"L WT: 8.6 lbs UPC: 671880628846 Brochure (pdf)

Read more less

Ballast SuperKing Pump with Deutsch Connector - 20 GPMWhen you’re having fun on a wakeboard, skis, or a tube, a bigger wake will create a more exhilarating ride. Xylem’s Jabsco ballast pumping systems, including the Ballast Puppy, Ballast King, and Ballast SuperKing, make taking on weight easy with tanks that rapidly fill at the touch of a button. Systems can be emptied quickly as well.Features: Run dry impellers Flow rates 9-25 gallons per minute (GPM) or 34-95 liters per minute (LPM) Adds approximately 80-200 pounds (36-91 kgs) of ballast water per minute Self-priming to 3 or 4 feet (0.9 or 1.2 meters) All comply with USCG 183.410 and ISO 8846 Marine (Ignition Protection) Reversing Polarity Switch available (Puppy and King products only) Specifications: Ports: 1-1/4" (32 mm) hose barb Deutsch connector No reversing switch Ballast SuperKing Impeller (2 needed) Quick Guide (pdf)

Read more less
