Marine Plumbing & Ventilation - Bilge Pumps

1100 Replacement Motor F/ Tournament Series Livewell PumpRule 47DR 12v 1100 GPH Replacement Motor for Rule 405FC Livewell - Baitwell pump.WARNING: This product can expose you to chemicals including STYRENE which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications: Type: Replacement Motors Box Dimensions: 4"H x 5"W x 8"L WT: 0.85 lbs UPC: 042237095985

Read more less

380 Bilge Pump - 12 VDC, 380 GPHQuality bilge pumps you can trust. SHURFLO's bilge pumps are built for the harsh marine environment to withstand the toughest conditions. Standard with 3' tinned wire assembly for below waterline installations and water cooled motors for extended life.Features: 3' Tinned Wire Assembly Anti-Airlock Tough Nylon Housing Ignition Protected Water Cooled Motors - Extended Life 3 Year Warranty CE Listed Specifications: Volts: 12v Operation: Non-Automatic Gallons Per Hour: 380 GPH Type: Electric Box Dimensions: 3"H x 7"W x 9"L WT: 1.1 lbs UPC: 752324010073

Read more less

Aqua Void 800 GPH Bilge Pump - 12VWith its industry-first quick-change motor connection and new reinforced click-in basket, this bilge pump simplifies cleaning and installation, and it's convenient and efficient. Its enhanced motor ensures reliability and performance in any condition. Experience worry-free boating with Aqua Void.Experience the Industry-First Quick-Change Motor ConnectionJohnson Pump's groundbreaking product features a quick-change motor connection for hassle-free cartridge motor changes or capacity upgrades.Take Control of the Boating Experience with Unparalleled ConvenienceThe Aqua Void Cartridge Bilge Pump is designed with single-handed access, perfect for tight bilge spaces. The pump body is easy to install or remove, and an innovative reinforced click-in basket simplifies installation, cleaning, or inspection.Enjoy Enhanced Efficiency and Higher Flow RatePowered by an enhanced motor and high-flow impeller, the Aqua Void achieves increased efficiency and a higher flow rate while conserving energy consumption.Trust in Reliable Performance Under Demanding ConditionsJohnson Pump Marine is renowned for its industry-leading reliability. The Aqua Void lives up to this reputation with its robust construction and meticulous engineering.Enjoy a worry-free time on the water and experience Reliability On Board. The Aqua Void Bilge Pump is a game-changing solution that sets a new standard in bilge pumps. Don't miss this opportunity to enhance the boating experience. Get the Aqua Void today!Features: Heightened efficiency with an increased flow rate - high-flow impeller design  Quick-change motor connection enjoys quick and hassle-free cartridge motor changes or capacity upgrades. Industry-first and only cartridge motor pump with included harness connection requiring no cutting and splicing of wires Water-cooled motor for long service intervals Compact, all-in-one motor/Impeller unit with stainless steel (316) Shaft No tools are needed for maintenance, no need for complete disassembly. You can now leave the pump casing attached to both the boat and the hoses.  Easy-to-install dura-port discharge ports to eliminate stress cracking caused by over-tightened hose clamps Include both a straight and a 90-degree smooth elbow dura-port as well as a removable check valve Meets the international standard, ISO 8849 marine Molded T-Slot - Easy Installation with Switches Specifications: Pump Size: 800 GPH Capacity Straight (12V): 795 GPH (50 I/min) Voltage: 12V Amp: 3.7A Fuse: 5A Hose Connection: 3/4 in. Wire Size: 16 GA, TAC Weight: 12.6 oz (0.36 kg) Body: ABS Dura Port: PA66/GF - Nylon Shaft: 316 Stainless Steel Shaft Seal: Nitrile Rubber Motor Cartridge: PC-ABS Pump Dimensions (W x H x L): 2.75 x 4.69 x 5.24 inches (70 x 119 x 133 mm) Specifications: Gallons Per Hour: 800 GPH Operation: Non-Automatic Outlet Size: 3/4" Type: Pumps/Drives Volts: 12v Box Dimensions: 4"H x 5"W x 6"L WT: 1.1 lbs UPC: 7330717015152 Quick Guide (pdf)

Read more less

Heavy Duty Bilge Pump 4000 GPH - 24VFeatures: Limited 1 Year Warranty  Capacities of 1600, 2200, or 4000 GPH Liquid-cooled, 12-pole motor with double ball bearings for extended service life The shaft of stainless steel (SS2343) The impeller is carefully designed and tested to maximize head and flow 4000 GPH features a robust motor design, mechanical shaft seal, high impact ABS plastic, and unique threaded port design Universal base plate and choice of two different ports makes for a simple installation Removable check valve included Heavy Duty Submersible Pumps can be combined with either an electronic float switch or the Ultima Switch for automatic operation Specifications: Capacity 1.0M head (13.6V/27.2V): 164 l/min - 2600 GPH Capacity straight (13.6V/27.2V): 252: l/min -4000 GPH 24V 7.5A Fuse Size: 15A Connection 1.5" and 2"

Read more less

750 GPH Cartridge Combo Series 12VCombines the line of cartridge bilge pumps with automatic operation. Equipped with a non-clogging electronic float switch.CE-ApprovedFeatures: Compact, all-in-one motor/impeller unit No tools needed for maintenance Extremely energy efficient Water-cooled motor for long service intervals Meets the international standard, ISO 8849 marine Pump Body: Thermoplastic Shaft Seal: Lip seal Shaft: Stainless steel (SS2343) Voltage: 12 V DC Capacity 3 ft (0.9 m) head (13.6 V): 44 l/min - 700 GPH Capacity straight (13.6 V): 50 l/min - 800 GPH Amperage: 3 A Fuse Size: 5 A Connection: 3/4" Specifications: Gallons Per Hour: 750 GPH Operation: Automatic Outlet Size: 3/4" Volts: 12v Type: Electric Box Dimensions: 4"H x 7"W x 8"L WT: 1.2 lbs UPC: 729321057035

Read more less

3 Way Bilge Pump ControlSwitch panel that gives full control of your equipment. Just push the button for manual or automatic bilge pumping. The automatic feature operates in combination with the automatic bilge switches or the electronic float switch. The three-position switch panel in matte black finish has an integrated fuse holder and operating light. Fuses included. Size: 73 mm/2.99" x60 mm/2.17", 40 mm/ 1.57" depth. Specifications: Volts: 12v Type: Switches Box Dimensions: 1"H x 5"W x 7"L WT: 0.2 lbs UPC: 729321820448 Owner's Manual (pdf)

Read more less

Ultima Bilge PumpUltimaBilge Pumps are the latest addition to the Johnson Pump brand lineup. Integration of the Ultima "field effect" sensing technology into the bilge pump body creates a sleek, reliable and compact unit with integrated switch ready to install and run for years and years of unerring service. Available in 600-800-1000-1250 GPH versions. Voltage 12 V DC. For UltimaBilge 600 GPH-1000 GPH, we have easy-to-install Dura-Port discharge ports to eliminate stress cracking caused by over-tightened hose clamps. These pumps will be delivered including both a straight and a 90 degree smooth elbow Dura-Port. All version are delivered with a removable check valve.The Ultima Bilge pumps may be manually operated via the Johnson Pump bilgecontrol panel.CE-ApprovedFeatures: Compact, all-in-one unit Integrated Ultima Switch sensing right into the pump body No Mercury Removable clip on basket design Removable impeller cover allows for easy clean out 3-wire device can be run in auto or manual override mode No tools needed for maintenance Extremely energy efficient Water-cooled motor for long service intervals Pump Body: ABS Shaft Seal: Lip Seal Shaft: Stainless steel (SS2343) Voltage: 12 V DC Capacity 3 ft (0.9 m) head (13.6 V): 44 l/min - 700 GPH Capacity straight (13.6 V): 64 l/min - 1000 GPH Amperage: 3.2 A Fuse Size: 5 A Connection: 3/4" Length:142 mm - 6" Width:82 mm - 3.2" Height:105 mm - 4.1" Weight:0.66 kg - 23.3 oz. Specifications: Gallons Per Hour: 1000 GPH Operation: Automatic Outlet Size: 3/4" Volts: 12v Type: Electric Box Dimensions: 4"H x 8"W x 9"L WT: 1.4 lbs UPC: 729321472609 Owner's Manual (pdf)

Read more less

Replacement Cartridge for Tsunami 500 MK2Attwood replacement motor cartridge for T500 model Tsunami series bilge pumps. Sold per each.

Read more less

Sahara MK2 S1200 Bilge Pump 1200 GPH - 12V - AutomaticEngineered for extended service life, these pumps feature a cool-running design and quality components, including permanent magnet motors, stainless steel shafts, and steel-reinforced seals.Features: Sahara Mk2 is the only automatic bilge pump that eliminates air-locks  Patented X-Air™ Impeller ejects trapped air in the pump and pipework. Sahara Mk2 is the easiest automatic bilge pump to install and service  External mounting feet and integrated outlet reduces time and effort. Universal mounting pattern makes replacement simple. Service pump cartridge from hard-to-reach areas using only one hand. Sahara Mk2 is the most reliable automatic bilge pump in freshwater and saltwater applications  Attwood’s SteadySwitch™ reduces cycling and extends the life of the pump. 40% better protection against water ingress and electrolysis - vs. MK1. 2X better protection against water ingress and electrolysis - than the leading competition. Universal mounting patterns make it backwards compatible with the most popular bilge pumps on the market. Specifications: Gallons Per Hour: 1200 GPH Operation: Automatic Outlet Size: 1" or 1-1/8" Volts: 12v Type: Pumps/Drives Box Dimensions: 4"H x 6"W x 7"L WT: 1.35 lbs UPC: 022697023483 Owner's Manual (pdf)Brochure (pdf)

Read more less

Bilge Pump Heavy Duty 1750 GPH - 12VSubmersible heavy duty bilge pump 12V with pump capacity 110 L/min (1750 GPH) and 85 L/min (1350 GPH) at 1m head. Stainless steel shaft, double ball bearings, mechanical seal, tough thermoplastic ABS housing and a robust long-life motor design.Universal base plate with strainer and pin (for “T-slot”) to attach a level switch for automatic operation. Including check valve, 32mm (1,25″) and 38mm (1,5″) ports. Features: Heavy Duty Submersible For pleasure or commercial boats above 10m (30Ft) length  Interchangeable with Rule 1500, Johnson Pump 16004-00 /32-1600-01 Specifications: Weight: 0.7 kg/1 lb Dimensions: 150/6L x 170/6.7H x 130/5W mm/in  Fuse: 6A *CE marked 94/25/ECC, ISO8846 Small Craft, Electromagnetic compatibility 89/336/EEC, EN51014 1993/radio disturbance Specifications: Type: Electric Gallons Per Hour: 1750 GPH Gallons Per Minute: 29 GPM Operation: Non-Automatic Outlet Size: 1-1/4" or 1-1/2" Volts: 12v Box Dimensions: 6"H x 7"W x 8"L WT: 4.6 lbs UPC: 7340176600103

Read more less

Quad Pump - 12VDCBILGE-B-DRY is the world’s only Smart Device enabled Dry Bilge System on the market! Enjoy simple installation and customized scheduling control at your fingertips with our Mobile App for Apple or Android devices. Due to size and placement, traditional bilge pumps cannot remove the last few inches of excess water accumulating in your bilge. With BILGE-B-DRY, you can finally eliminate cabin odors, reduce mold or corrosion, and protect your electrical wiring by removing every last drop of water from your bilge. Combined with our newest innovative product, EVACUATOR+, your cabin will be odor-free and your bilge will be the driest and cleanest at the marina!Why choose BILGE-B-DRY? Take advantage of:           The world’s ONLY Smart Device enabled Dry Bilge System on the market with customized operation. An efficient, reliable method to remove excess bilge water on all boats, including stepped-hull boats where water sits forward of the “step.” Use BILGE-B-DRY after washdown, when there is heavy rain or sea spray accumulation, rough seas, untreated leaks, etc. A compact pump design for easy installation in tight or awkward spaces in any orientation (horizontal or vertical) An environmentally friendly low-profile bilge water pickup design with a proprietary filter system Configured to automatically cycle (5) five times per day for (2) two minutes if you decline Smart Device connectivity. BILGE-B-DRY connects to your Smart Device (if desired) through the free Mobile App on the APPLE & GOOGLE PLAY stores. Customizable operation is at your fingertips with two options: Run the “TIMER” option up to 20 minutes after boating in heavy seas or upon washdown. Choose the “SCHEDULE” option for five customizable run times during the day, up to 20 minutes.  This is a great option if you will be away from your boat for a few weeks.  Example:With your Smart Device, schedule your BILGE-B-DRY to run at 9:00 AM for three minutes and again at 3:00 PM for two minutes. The schedules will run daily until canceled.  If at 8:00 PM you still see water in your bilge, run the on-demand Timer for up to 20 minutes to remove the remaining water.  BILGE-B-DRY is available in four 12vdc pump configurations:  (24vdc requests by special order, excluding Quad pump configuration) Single pump (1 motor/diaphragm pump - 12 feet of tubing provided) Dual pump (2 motors/diaphragm pumps - 12 feet of tubing for pickup, 6 feet for discharge provided) Triple pump (3 motors/diaphragm pumps - 18 feet of tubing for pickup, 6 feet for discharge provided) Quad pump (4 motors/diaphragm pumps - 24 feet of tubing for pickup, 6 feet for discharge provided)   Meets ISO 8846 standards, Section 5, Protection against ignition of surrounding flammable gases.Power Required:12VDC (available in 24vdc special order only, excluding Quad pump)Pump: Working voltage: 8-13vdc Maximum flow: 0.3 - GPM Current: less than 500mA Pump head: 10 feet Pump suction: 5 (vertical) feet Diaphram design, able to run dry for extended periods without damage Life expectancy >1000 hours Control board: Wireless Connectivity Static current: 20mA Working current: 50mA Working voltage: 12vdc [10-14V] Life expectancy: 100,000 cycles Working temperature: - 40 85 °C Wi-Fi & RF Grant FCC Rule Part 15C Dimensions (in): Enclosure:  3.0 H x 5.0 W x 5.0 L Rectangular Pickup: 0.98 H x 2.4 W x 3.9 L  Dimensions (mm): Enclosure: 76 H x 128 W x 128 L Rectangular Pickup: 50 H x 60 W x 100 L Included with your BILGE-B-DRY purchase are low-profile bilge water pickups. Our uniquely designed low-profile bilge water pickup (bracket sold seperately) with an integrated filter helps reduce harmful overboard discharge of heavy metals, solids, and petroleum. Place the pickups wherever you wish to remove water, such as the lowest part of your bilge, A/C evaporator or hard-to-reach compartments. Twenty small holes along the bottom of the pickup provide a debris barrier. The pickup’s integrated filter contains a proprietary blend of materials to prevent damage to the BILGE-B-DRY pump and to reduce oil discharge, which unlike other dry bilge systems, eliminates the need for a secondary filter.  For optimum performance of your BILGE-B-DRY unit, replace the low-profile bilge water pickups when flow rate has decreased.  BILGE-B-DRY orders DO NOT INCLUDE the stainless holddown bracket!

Read more less

Triple Pump - 12VDCBILGE-B-DRY is the world’s only Smart Device enabled Dry Bilge System on the market! Enjoy simple installation and customized scheduling control at your fingertips with our Mobile App for Apple or Android devices. Due to size and placement, traditional bilge pumps cannot remove the last few inches of excess water accumulating in your bilge. With BILGE-B-DRY, you can finally eliminate cabin odors, reduce mold or corrosion, and protect your electrical wiring by removing every last drop of water from your bilge. Combined with our newest innovative product, EVACUATOR+, your cabin will be odor-free and your bilge will be the driest and cleanest at the marina! Why choose BILGE-B-DRY? Take advantage of:           The world’s ONLY Smart Device enabled Dry Bilge System on the market with customized operation. An efficient, reliable method to remove excess bilge water on all boats, including stepped-hull boats where water sits forward of the “step.” Use BILGE-B-DRY after washdown, when there is heavy rain or sea spray accumulation, rough seas, untreated leaks, etc. A compact pump design for easy installation in tight or awkward spaces in any orientation (horizontal or vertical) An environmentally friendly low-profile bilge water pickup design with a proprietary filter system Configured to automatically cycle (5) five times per day for (2) two minutes if you decline Smart Device connectivity. BILGE-B-DRY connects to your Smart Device (if desired) through the free Mobile App on the APPLE & GOOGLE PLAY stores. Customizable operation is at your fingertips with two options: Run the “TIMER” option up to 20 minutes after boating in heavy seas or upon washdown. Choose the “SCHEDULE” option for five customizable run times during the day, up to 20 minutes.  This is a great option if you will be away from your boat for a few weeks.  Example:With your Smart Device, schedule your BILGE-B-DRY to run at 9:00 AM for three minutes and again at 3:00 PM for two minutes. The schedules will run daily until canceled.  If at 8:00 PM you still see water in your bilge, run the on-demand Timer for up to 20 minutes to remove the remaining water.  BILGE-B-DRY is available in four 12vdc pump configurations:  (24vdc requests by special order, excluding Quad pump configuration) Single pump (1 motor/diaphragm pump - 12 feet of tubing provided) Dual pump (2 motors/diaphragm pumps - 12 feet of tubing for pickup, 6 feet for discharge provided) Triple pump (3 motors/diaphragm pumps - 18 feet of tubing for pickup, 6 feet for discharge provided) Quad pump (4 motors/diaphragm pumps - 24 feet of tubing for pickup, 6 feet for discharge provided)   Meets ISO 8846 standards, Section 5, Protection against ignition of surrounding flammable gases.Power Required:12VDC (available in 24vdc special order only, excluding Quad pump)Pump: Working voltage: 8-13vdc Maximum flow: 0.3 - GPM Current: less than 500mA Pump head: 10 feet Pump suction: 5 (vertical) feet Diaphram design, able to run dry for extended periods without damage Life expectancy >1000 hours Control board: Wireless Connectivity Static current: 20mA Working current: 50mA Working voltage: 12vdc [10-14V] Life expectancy: 100,000 cycles Working temperature: - 40 85 °C Wi-Fi & RF Grant FCC Rule Part 15C Dimensions (in): Enclosure:  3.0 H x 5.0 W x 5.0 L Rectangular Pickup: 0.98 H x 2.4 W x 3.9 L  Dimensions (mm): Enclosure: 76 H x 128 W x 128 L Rectangular Pickup: 50 H x 60 W x 100 L  Included with your BILGE-B-DRY purchase are low-profile bilge water pickups. Our uniquely designed low-profile bilge water pickup (bracket sold seperately) with an integrated filter helps reduce harmful overboard discharge of heavy metals, solids, and petroleum. Place the pickups wherever you wish to remove water, such as the lowest part of your bilge, A/C evaporator or hard-to-reach compartments. Twenty small holes along the bottom of the pickup provide a debris barrier. The pickup’s integrated filter contains a proprietary blend of materials to prevent damage to the BILGE-B-DRY pump and to reduce oil discharge, which unlike other dry bilge systems, eliminates the need for a secondary filter. For optimum performance of your BILGE-B-DRY unit, replace the low-profile bilge water pickups when flow rate has decreased.  BILGE-B-DRY orders DO NOT INCLUDE the stainless holddown bracket!

Read more less
