Marine Plumbing & Ventilation - Bilge Pumps

1100GPH Standard Bilge Pump - 12VCustomers talk about flow, they want the water out of the bilge, andfast. Improved design and performance means that our next generation 1100GPH pump will produce this flow at just 24V rather than 27.2V as previously required...more typical of on board voltage supply.Our next generation of Rule pumps include check valves and to do this, we've created hidden air vent to prevent airlocking. Under each strainer tab there is a small hole that vents any air trapped in the pump housing preventing airlocks...and that's how we do it.We have true electromagnetic suppression (EMC). We have a built-in thermal cell that protects the pump and the vessel when things get too hot.We've re-engineered the inside and outside of our bilge pumps, starting with a blank slate. And we're just getting startedFeatures: Non-automatic - used with a panel switch or Rule float switch Submersible and Ignition Protected High efficiency, low amp motor Stainless-steel shaft Includes backflow preventer WARNING: This product can expose you to chemicals including 1,3-Butadiene which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Electric Gallons Per Hour: 1100 GPH Operation: Non-Automatic Outlet Size: 3/4" Volts: 24v Box Dimensions: 4"H x 7"W x 7"L WT: 0.8 lbs UPC: 042237104762 Brochure (pdf)

Read more less

Rule 4000Non-Automatic 12vDesigned for the toughest applications, the 4000 gph (15140 lph) pump optimizes Rule's exclusive design features to produce the highest capacity available for a pump its size. 2" (51mm) discharge outlet. 12 Volts DC unless noted.Voltage: 12 Vdc Amp Draw: 15.5 amp Fuse Size 25 amp Height: 7 3/4 inches 196.8 mm Width: 4 7/8 Inches 124 mm Weight: 5-8 lb 2.5 kg WARNING: This product can expose you to chemicals including FORMALDEHYDE (GAS) which is known to the State of California to cause cancer. For more information go to P65Warnings.ca.gov. Specifications: Gallons Per Hour: 4000 GPH Operation: Non-Automatic Outlet Size: 2" Volts: 12v Type: Electric Box Dimensions: 7"H x 8"W x 11"L WT: 5.9 lbs UPC: 042237083487 Owner's Manual (pdf)

Read more less

Rule-Mate® 500 Fully Automated Bilge Pump - 12VFeatures: State-of-the-art water sensing technology Pump turns on when water level rises and shuts off when water is removed No float switch required 500 GPH/1893LPH Anti-fouling impeller Submersible Ignition protected Includes back flow preventer 3-year warranty Specifications: Type: Electric Operation: Automatic Gallons Per Hour: 500 GPH Volts: 12v Box Dimensions: 4"H x 7"W x 9"L WT: 1.1 lbs UPC: 042237106230

Read more less

500GPH Electronic Sensing Bilge Pump - 24VIn the next generation sensing bilge pumps, the 500GPH 24V S series pump works on the principle of impeller resistance. The pump will turn on every 2-1/2 minutes for about one second to sense for water. If water is present, the pump will sense resistance and continue to run until all water is removed. After that, it will resume checking for water every 2-1/2 minutes. Water is kept in check between 1/8" and 3/8"!!! Great idea when power conservation is needed and as an added benefit, no float switch is needed!All that plus the added benefits of our standard bilge pump: Check valve included with hidden air vent to prevent airlocking True electromagnetic suppression (EMC) A built-in thermal cell that protects the pump and the vessel when things get too hot These are the smallest automatic pumps available on the market!!!Features: Completely automatic with manual override - No Float Switch Needed! Submersible and Ignition Protected High efficiency, low amp motor Stainless-steel shaft Includes backflow preventer WARNING: This product can expose you to chemicals including 1,3-Butadiene which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Electric Gallons Per Hour: 500 GPH Operation: Automatic Volts: 24v Box Dimensions: 4"H x 7"W x 7"L WT: 1 lbs UPC: 042237104793

Read more less

Rule-Mate® 1100 Fully Automated Bilge Pump - 12VFeatures: State-of-the-art water sensing technology Pump turns on when water level rises and shuts off when water is removed No float switch required 1100 GPH/4164 LPH Anti-fouling impeller Submersible Ignition protected Includes back flow preventer 3-year warranty Specifications: Type: Electric Gallons Per Hour: 1100 GPH Operation: Automatic Volts: 12v Box Dimensions: 4"H x 7"W x 9"L WT: 1.3 lbs UPC: 042237106216

Read more less

Ultima Bilge PumpUltimaBilge Pumps are the latest addition to the Johnson Pump brand lineup. Integration of the Ultima "field effect" sensing technology into the bilge pump body creates a sleek, reliable and compact unit with integrated switch ready to install and run for years and years of unerring service. Available in 600-800-1000-1250 GPH versions. Voltage 12 V DC. For UltimaBilge 600 GPH-1000 GPH, we have easy-to-install Dura-Port discharge ports to eliminate stress cracking caused by over-tightened hose clamps. The pumps are delivered including both a straight and a 90 degree smooth elbow Dura-Port. For UltimaBilge 1250GPH we include threaded 1.1/4" & 1.1/8" discharge port. All version are delivered with a removable check valve.The Ultima Bilge pumps may be manually operated via the Johnson Pump bilge control panel.CE-ApprovedFeatures: Compact, all-in-one unit Integrated Ultima Switch sensing right into the pump body No Mercury Removable clip on basket design Removable impeller cover allows for easy clean out 3-wire device can be run in auto or manual override mode No tools needed for maintenance Extremely energy efficient Water-cooled motor for long service intervals Pump Body: ABS Shaft Seal: Lip Seal Shaft: Stainless steel (SS2343) Voltage: 12 V DC Capacity 3 ft (0.9 m) head (13.6 V): 51 l/min - 800 GPH Capacity straight (13.6 V): 79 l/min - 1250 GPH Amperage: 3 A Fuse Size: 5 A Connection: 1-1/8" and 1-1/4" Length:142 mm - 6" Width:82 mm - 3.2" Height:117 mm - 4.6" Weight:0.66 kg - 23.3 oz. Specifications: Gallons Per Hour: 1250 GPH Operation: Automatic Outlet Size: 1-1/4" or 1-1/8" Volts: 12v Type: Electric Box Dimensions: 4"H x 8"W x 9"L WT: 1.5 lbs UPC: 729321472616 Owner's Manual (pdf)

Read more less

High Flow Submersible Electric Galley Pump - 12VWhale electric galley pump range includes models with the very latest electronic technology. All pumps are manufactured from only highest quality inhouse molded parts and robust motors.Whale has developed the pump designs based on more than 60 years of expertise. Today Whale has used that experience to develop the most compact, quiet, lightweight high performance electric galley pumps.Features: Simple and compact High flow submersible Ideal for up to 2/3 mixer outlets 15.8 liters per minute maximum flow rate 3.8 Amps power consumption 12V Specifications: Type: Electric Volts: 12v Box Dimensions: 2"H x 8"W x 10"L WT: 0.5 lbs UPC: 766478942173

Read more less

Sahara MK2 S800 Bilge Pump 800 GPH - 24V - AutomaticEngineered for extended service life, these pumps feature a cool-running design and quality components, including permanent magnet motors, stainless steel shafts, and steel-reinforced seals.Features: Sahara Mk2 is the only automatic bilge pump that eliminates air-locks  Patented X-Air™ Impeller ejects trapped air in the pump and pipework. Sahara Mk2 is the easiest automatic bilge pump to install and service  External mounting feet and integrated outlet reduces time and effort. Universal mounting pattern makes replacement simple. Service pump cartridge from hard-to-reach areas using only one hand. Sahara Mk2 is the most reliable automatic bilge pump in freshwater and saltwater applications  Attwood’s SteadySwitch™ reduces cycling and extends the life of the pump. 40% better protection against water ingress and electrolysis - vs. MK1. 2X better protection against water ingress and electrolysis - than the leading competition. Universal mounting patterns make it backwards compatible with the most popular bilge pumps on the market. Specifications: Volts: 24v Type: Pumps/Drives Outlet Size: 3/4" or 1" Operation: Automatic Gallons Per Hour: 800 GPH Box Dimensions: 2"H x 4"W x 8"L WT: 1.5 lbs UPC: 022697023476 Owner's Manual (pdf)Brochure (pdf)

Read more less

Tsunami MK2 Manual Bilge Pump - T800 - 800 GPH & 24VThe Tsunami Mk2 is the only manual bilge pump that eliminates airlocks. This is done by the Patented X-Air™ Impeller, which ejects trapped air in the pump and pipework. Also, the Tsunami Mk2 is the most reliable manual bilge pump in freshwater applications, considering it has 40% better protection against water ingress and electrolysis vs. the Mk1 pump.Easy Installation & Service  GPH (Gallons Per Hour): 800 90° rotatable elbow outlet allows users to install the pump anywhere in a full 360° orientation Backward compatible hole pattern and motor cartridges of Tsunami Mk1 bilge and aerator pumps External mounting feet and integrated outlet reduces time and effort Service pump cartridges from hard-to-reach areas using only one hand Specifications: Rated Volts DC: 24V Fuse Size: 2 Amp Wire Length: (inch) 29" / (mm) 735 Hose Diameter: (inch) 3/4" and 1" *Must be used with appropriate Tsunami outlet Specifications: Gallons Per Hour: 800 GPH Operation: Non-Automatic Outlet Size: 3/4" or 1" Type: Pumps/Drives Volts: 24v Box Dimensions: 4"H x 5"W x 7"L WT: 1.2 lbs UPC: 022697024121 Quick Guide (pdf)

Read more less

Quad Pump - 12VDCBILGE-B-DRY is the world’s only Smart Device enabled Dry Bilge System on the market!Enjoy simple installation and customized scheduling control at your fingertips with our Mobile App for Apple or Android devices. Due to size and placement, traditional bilge pumps cannot remove the last few inches of excess water accumulating in your bilge. With BILGE-B-DRY, you can finally eliminate cabin odors, reduce mold or corrosion, and protect your electrical wiring by removing every drop of water from your bilge. Your cabin will be odor-free, and your bilge will be the driest and cleanest at the marina!Why choose BILGE-B-DRY? Take advantage of: The world’s ONLY Smart Device enabled Dry Bilge System on the market with customizable operation!  An efficient, reliable method to remove excess bilge water on all boats, including stepped-hull boats where water sits forward of the “step. Use BILGE-B-DRY after washdown, heavy rain or sea spray accumulation, rough seas, untreated leaks, etc.  Heavy-duty pump enclosure with improved durability, enhanced pump efficiency, and streamlined internal plumbing. A choice of four pump configurations in 12vdc or 24vdc for optimal water removal. The pump diaphragm design can run dry for extended periods without damage. A compact pump design for easy installation in tight or awkward spaces in any orientation (horizontal or vertical). Customized pump scheduling with the free Mobile App for Apple and Android devices.  Quick disconnect wiring harness with optional connection to a helm or float switch.  An environmentally friendly low-profile bilge water pickup design with a replaceable filter system.  Configured to automatically cycle for 2 minutes every 6 hours if you decline Smart Device connectivity. BILGE-B-DRY connects to your Smart Device (if desired) through the free Mobile App on the APPLE & GOOGLE PLAY stores. Customizable operation is at your fingertips with two options:  Run the “TIMER” option up to 20 minutes after boating in heavy seas or upon washdown.  Choose the “SCHEDULE” option for five customizable run times during the day, up to 20 minutes. This is a great option if you will be away from your boat for a few weeks.  Example:  With your Smart Device, schedule your BILGE-B-DRY to run at 9:00 AM for three minutes and again at 3:00 PM for two minutes. The schedules will run daily until canceled. If at 8:00 PM you still see water in your bilge, run the on-demand Timer for up to 20 minutes to remove the remaining water. BBD Quad Pump 12VDC:Four motors/diaphragm pumps20 feet of input tubing provided (for pickup)6 feet of output tubing provided (for discharge)Input tubing diameter (PVC or PU) - 1/4” OD Output tubing diameter (PVC or PU) - 3/8” ODIncluded with your BILGE-B-DRY purchase are low-profile bilge water pickups. Our uniquely designed low-profile bilge water pickup (bracket sold separately) with a replaceable filter helps reduce the harmful overboard discharge of heavy metals, solids, and petroleum. Place the pickups wherever you wish to remove water, such as the lowest part of your bilge, A/C evaporator, or hard-to-reach compartments. Twenty small holes along the bottom of the pickup provide a debris barrier. The pickup’s integrated filter contains a proprietary blend of materials to prevent damage to the BILGE-B-DRY pump and to reduce oil discharge, which, unlike other dry bilge systems, eliminates the need for a secondary filter.For optimum performance of your BILGE-B-DRY unit, replace the low-profile bilge water pickups when the flow rate has decreased. You can choose to replace the filter material or replace the entire pickup. BILGE-B-DRY orders DO NOT INCLUDE the stainless hold-down bracket or inline fuse!Specifications: Meets ISO 8846 standards, Section 5, Protection against ignition of surrounding flammable gases. Power Required:  12 VDC (8 – 14 VDC)  Max current: 1.4 amps (12 VDC)  Idle Current: 0.05 amps (12 VDC)  Pump:  Maximum flow: 1.0 GPM  Pump head: 10 feet  Pump suction: 5 (vertical) feet  Diaphragm design, able to run dry for extended periods without damage  Life expectancy >1000 hours  Control board:  Wireless Connectivity  Life expectancy: 100,000 cycles  Working temperature: - 40 85 °C  Wi-Fi & RF Grant FCC Rule Part 15C  Dimensions (in):  Enclosure: 4.1 H x 6.8 W x 7 L  Rectangular Pickup: 0.98 H x 2.4 W x 3.9 L Dimensions (mm):  Enclosure: 76 H x 172 W x 177 L  Rectangular Pickup: 25 H x 60 W x 100 L Weight 2.4 LB (not including tubing, pickup, or accessories)  Tubing:  Input tubing: 1/4" Outer Diameter  Output tubing: 3/8" Outer Diameter  Use Polyvinyl chloride (PVC) or Polyurethane (PU) tubing  Hardness Shore A 80 or higher

Read more less

Grey IC Waste Pump 12VUnique Intelligent Control means Gulley IC Kit is all you need to manage waste from multiple drains through one pumpElectrical signals are sent from the Two Way Manifold IC only when grey waste water needs to be pumped outComplete prewired grey waste system that handles waste from multiple drains using the high capacity Gulper IC pump.Features and Benefits Senses waste level through wall - not in contact with water Quiet drainage Removes the need to install a bulky grey waste tank Service free - No moving parts to clog or burn Fully potted circuitry - protected against water ingress WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Waste Pumps Gallons Per Minute: 5 GPM Inlet Size: 3/4" or 1" Operation: Automatic Outlet Size: 3/4" or 1" Volts: 12v Operation Method: Automatic Box Dimensions: 6"H x 8"W x 12"L WT: 5.4 lbs UPC: 766478945716

Read more less

Bilge Pump Heavy Duty 2250 GPH - 12VSubmersible heavy duty bilge pump 12V with pump capacity 140 L/min (2250 GPH) and 120 L/min (1900 GPH) at 1m head. Stainless steel shaft, double ball bearings, mechanical seal, tough thermoplastic ABS housing and a robust long-life motor design.Universal base plate with strainer and pin (for “T-slot”) to attach a level switch for automatic operation. Including check valve, 32mm (1,25″) and 38mm (1,5″) ports. Features: Heavy Duty Submersible For pleasure or commercial boats above 12m (36 Ft) length  Interchangeable with Rule 2000, Johnson Pump 22004/32-2200-01 Specifications: Weight: 0.9 kg/1 lb Dimensions: 150/6L x 170/6.7H x 130/5W mm/in  Fuse: 8A  *CE marked 94/25/ECC, ISO8846 Small Craft, Electromagnetic compatibility 89/336/EEC, EN51014 1993/radio disturbance Specifications: Type: Electric Gallons Per Hour: 2250 GPH Gallons Per Minute: 37 GPM Operation: Non-Automatic Outlet Size: 1-1/4" or 1-1/2" Volts: 12v Box Dimensions: 6"H x 7"W x 8"L WT: 4.45 lbs UPC: 7340176600127
