Sailing - Blocks

40mm Double Sheave Fishing BlockLow-friction Carbo Air blocks are lightweight, strong, and reliable. These compact blocks have very high working loads and smooth operation to simplify the positioning and retrieval of teaser lines. Specifications: Sheave Ø (mm): 40 mm Sheave Ø (in): 1-9/16 in Maximum line Ø (mm): 10 mm Maximum line Ø (in): 3/8 in Maximum working load (kg): 220 kg Maximum working load (lb): 485 lbs

Read more less

29mm Single Bullet Block with BecketLow-friction Bullet blocks lead control lines aft. They are compact and lightweight, with fast trim and release under high or low loads. A range of styles lets these blocks adapt to almost all control line applications. Features: Sheave: 29mm (1-1/8") Maximum Line: 8mm (5/16") Maximum Working Load: 136kg (300lb)

Read more less

60mm Single Element Block Mastbase with SwivelElement blocks introduce sideplates that combine forged aluminum and compound curves for strength. They are simultaneously contemporary and very robust. Element’s design pairs the minimum amount of metal required to protect the sheave with a proven journal bearing. So size for size, Element is priced significantly lower, than our previously least expensive blocks.Sideplates are hardcoat-anodized to resist corrosion. A tough composite bearing sheave resists corrosion for a long service life.Specifications: Sheave: 60mm (2-3/8" Max Line: 14mm (9/16") Max Working Load: 1100kg (2425lbs)

Read more less

57mm Carbo Single Ratchet Block with SwivelCarbo Ratchets allow sailors to hand-hold loaded lines and offer balance between holding power and controlled easing.Features: On/off switch operates from both sides Standard grip: medium/light air; 10:1 holding power Sheave Ø (mm): 57 mm Sheave Ø (in): 2-1/4 in Maximum line Ø (mm): 10 mm Maximum line Ø (in): 3/8 in Maximum working load (kg): 227 kg Maximum working load (lb): 500 lb

Read more less

40mm Carbo Single Ratchet Block with SwivelCarbo Ratchets allow sailors to hand-hold loaded lines and offer balance between holding power and controlled easing. 2608, 2609, and 2614 have on/off switches. Features: Sheave Ø (mm): 40 mm Sheave Ø (in): 1-9/16 in Maximum line Ø (mm): 10 mm Maximum line Ø (in): 3/8 in Maximum working load (kg): 136 kg Maximum working load (lb): 300 lb

Read more less

75mm Carbo Air Block with SwivelLow-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken Black Magic block line, these small, compact blocks have very high working loads for safe, easy trimming.Specifications: Sheave: 75mm / 2-15/16in Length: 137mm / 5-3/8in Weight: 195g / 6.9oz Shackle pin: 6mm / 1/4in Maximum line: 14mm / 9/16in Maximum working load: 550kg / 1213lb Breaking load: 1650kg / 3638lb

Read more less

16mm Triple Block with BecketThe 16 mm is Harken’s smallest block. It is perfect for small synthetic control lines found on high-tech dinghies. The patented bearing system uses stainless steel balls in a captive grooved race.Specifications: Sheave: 16mm / 5/8in. Length: 57mm / 2-1/4in. Weight: 43g / 1.5oz Maximum line: 5mm / 7/32in Maximum working load: 318kg/ 700lb Breaking load: 544kg / 1200lb

Read more less

45mm Single Element Block with Swivel & BecketElement blocks introduce sideplates that combine forged aluminum and compound curves for strength. They are simultaneously contemporary and very robust. Element’s design pairs the minimum amount of metal required to protect the sheave with a proven journal bearing. So size for size, Element is priced significantly lower, than our previously least expensive blocks.Sideplates are hardcoat-anodized to resist corrosion. A tough composite bearing sheave resists corrosion for a long service life.Specifications: Sheave: 45mm / 1-3/4in Length: 121mm / 4-3/4in Weight: 115g / 4oz Shackle pin: 6mm / 1/4in Maximum line: 12mm / 1/2in Maximum working load: 700kg / 1543lb Breaking load: 1400kg / 3086lb

Read more less

40mm Carbo Air Block with Cam Cleat & BecketLow-friction Carbo Air blocks are lightweight, strong, reliable—and affordable. Companions to the popular Harken Black Magic block line, these small, compact blocks have very high working loads for safe, easy trimming.Specifications: Sheave Ø (mm)40 mm Sheave Ø (in)1 9/16 in Maximum line Ø (mm)6 mm Maximum line Ø (in)1/4 in Maximum working load (kg)136 kg Maximum working load (lb)300 lb

Read more less

22mm Micro Block with BecketLow-friction Micro blocks are compact and lightweight. Specifications: Sheave: 22mm / 7/8in. Length: 51mm / 2in. Weight: 21g / .75oz. Maximum line: 6mm / 1/4in. Maximum working load: 91kg / 200lb Breaking load: 544kg/ 1200 lb

Read more less

22mm Fiddle Micro Block with V-JamLow-friction Micro blocks are compact and lightweight. They are ideal for sailboards, smaller dinghies, and lightly loaded control lines on boats of all sizes.Specifications: Sheave: 22mm / 7/8in. Length: 89mm / 3-1/2in. Weight: 57g / 2oz. Shackle pin: 5mm/ 3/16in Maximum line: 6mm / 1/4in. Maximum working load: 159kg / 350lb Breaking load: 544kg/ 1200 lb

Read more less

22mm Micro Block with SwivelLow-friction Micro blocks are compact and lightweight. They are ideal for sailboards, smaller dinghies, and lightly loaded control lines on boats of all sizes.Specifications: Sheave: 22mm / 7/8in. Length: 60mm / 2-3/8in. Weight: 28g / 1oz. Shackle pin: 4mm / 5/32in, Maximum line: 6mm / 1/4in. Maximum working load: 91kg / 200lb Breaking load: 544kg/ 1200 lb

Read more less
