Uflex UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft [UP28R]

Description

UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft

Features:

  • Available in four different displacement sizes
  • Compact design
  • Ball bearing piston race
  • Built-in lock valve for positive rudder lock
  • Integral relief valve for over-pressure protection
  • 3/4” tapered stainless steel shaft
  • Easily accessible lock valve and shaft seal for replacement
  • Cast iron cylinder rotor for greater durability and longer life
  • 1/4" NPT fitting for 3/8" tube
  • Includes 90° adjustable fittings for 3/8” tube and white bezel
  • UP45R pump is ideal for double cylinder outboard applications
  • UP45 pump is available also for inboard application
  • X68 (optional) - 40894Z Chrome bezel
  • KITF (optional) - 39664Y Remote fill adapter

Specifications:

  • Mounting: Retro-cruscotto
  • Displacement/Revolution: 28 cc-1.7 cu in
  • # of Pistons: 5
  • Relief Valve Setting: 70 Bar - 1000 PSI
  • Maximum Wheel Diameter: 710mm - 28"
  • Weight: 5kg - 11 lbs.
Product form

UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel ShaftFeatures: Available in four different displacement sizes Compact design Ball... Read more

SKU: CWR-75560
Barcode: 702755024811

3 in stock

$1,010.16$665.50

    • Price Match Guarantee
    • Free Shipping on orders over $200
    • Secure Checkout

      Description

      UP28R Rear Mount Helm 1.7 cu. 3/4" Tapered Stainless Steel Shaft

      Features:

      • Available in four different displacement sizes
      • Compact design
      • Ball bearing piston race
      • Built-in lock valve for positive rudder lock
      • Integral relief valve for over-pressure protection
      • 3/4” tapered stainless steel shaft
      • Easily accessible lock valve and shaft seal for replacement
      • Cast iron cylinder rotor for greater durability and longer life
      • 1/4" NPT fitting for 3/8" tube
      • Includes 90° adjustable fittings for 3/8” tube and white bezel
      • UP45R pump is ideal for double cylinder outboard applications
      • UP45 pump is available also for inboard application
      • X68 (optional) - 40894Z Chrome bezel
      • KITF (optional) - 39664Y Remote fill adapter

      Specifications:

      • Mounting: Retro-cruscotto
      • Displacement/Revolution: 28 cc-1.7 cu in
      • # of Pistons: 5
      • Relief Valve Setting: 70 Bar - 1000 PSI
      • Maximum Wheel Diameter: 710mm - 28"
      • Weight: 5kg - 11 lbs.
