Symmetric Carbine Hook - Length 60mm - 1/4"Features: Grade 316L stainless steel carbine hooks Symmetrical shape With eye to attach a webbing or a splicing Applications:For fastening applications Specifications: Materials 316L stainless steel grade Length (inch) 2-23/64" Working load (lb) 790 WLL (lb) 260 Breaking load (lb) 1320 Weight (lb) 0.066 Dimensions (see 2nd image): A (inch) 25/64" B (inch) 9/32" D diameter (inch) 15/64"

Read more less

Symmetric Carbine Hook Without Eye - Length 100mm - 13/32"Features: Grade 316L stainless steel carbine hooks Symmetrical shape without eye                                           Applications:For fastening applicationsSpecifications: Materials 316L stainless steel grade Length (inch) 3-15/16" Working load (lb) 2640 WLL (lb) 1100 Breaking load (lb) 5510 Weight (lb) 0.273 Dimensions (see 2nd image): A (inch) 19/32" B (inch) 35/64" D diameter (inch) 25/64"

Read more less

Symmetric Carbine Hook Without Eye - Length 60mm - 1/4"Features: Grade 316L stainless steel carbine hooks Symmetrical shape without eye                                           Applications:For fastening applicationsSpecifications: Materials 316L stainless steel grade Length (inch) 2-23/64" Working load (lb) 790 WLL (lb) 260 Breaking load (lb) 1320 Weight (lb) 0.062 Dimensions (see 2nd image): A (inch) 25/64" B (inch) 5/16" D diameter (inch) 15/64"

Read more less

Symmetric Carbine Hook Without Eye - Length 80mm - 5/16"Features: Grade 316L stainless steel carbine hooks Symmetrical shape without eye                                           Applications:For fastening applicationsSpecifications: Materials 316L stainless steel grade Length (inch) 3-5/32" Working load (lb) 1940 WLL (lb) 700 Breaking load (lb) 3520 Weight (lb) 0.137 Dimensions (see 2nd image): A (inch) 33/64" B (inch) 33/64" D diameter (inch) 5/16"

Read more less

Thimble Shackle - Allen Head Pin - 8mm Diameter - 5/16"Features: Thimble shackle with allen head pin forged in grade 316L stainless steel Allows to spliced a rope without adding and additional thimble With the captive pin, no risk to lose the pin Outstanding working and breaking loads Applications: Mainsheet halyards Max rope size: 12 mm Specifications: Materials: 316 stainless steel grade Working load: (lb) 2200 / (kg) 1000  Breaking load: (lb) 6610 / (kg) 3000  Weight: (lb) 0.168 / (g) 76  Dimensions: A: (inch) 1 39/64" / (mm) 41  B: (inch) 5/8" / (mm) 16  C: (inch) 5/16" / (mm) 8  D: (inch) 5/8" / (mm) 16  D diameter: (inch) 5/16" / (mm) 8  E: (inch) 9/32" / (mm) 7  F: (inch) 2 63/64" / (mm) 76  G: (inch) 1 19/64" / (mm) 33  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Thimble Shackle - Captive Pin - Diameter 10mm - 13/32"Features: Thimble shackle with captive pin forged in grade 316L stainless steel Allows to spliced a rope without adding an additional thimble With the captive pin, no risk to lose the pin Outstanding working and breaking loads Applications: Mainsheet halyards Max rope size: 16 mm Specifications: Materials 316 stainless steel grade Working load (lb) 3350 Breaking load (lb) 11020 Weight (lb) 0.322 Dimensions (see 2nd image): A (inch) 2-1/64" B (inch) 25/32" C (inch) 25/64" D (inch) 25/32" D diameter (inch) 25/64" E (inch) 23/64" F (inch) 3-47/64" G (inch) 2-1/8"

Read more less

Thimble Shackle - Captive Pin - Diameter 8mm - 5/16"Features: Thimble shackle with captive pin forged in grade 316L stainless steel Allows to spliced a rope without adding an additional thimble With the captive pin, no risk to lose the pin Outstanding working and breaking loads Applications: Mainsheet halyards Max rope size: 12mm Specifications: Materials 316 stainless steel grade Working load (lb) 2200 Breaking load (lb) 6610 Weight (lb) 0.172 Dimensions (see 2nd image): A (inch) 1-39/64" B (inch) 5/8" C (inch) 5/16" D (inch) 5/8" D diameter (inch) 5/16" E (inch) 9/32" F (inch) 2-63/64" G (inch) 1-21/32"

Read more less

Thimble Shackle Allen Head Pin - 10mm Diameter - 13/32"Features: Thimble shackle with allen head pin forged in grade 316L stainless steel Allows a rope to be spliced without adding and additional thimble With the captive pin, no risk to lose the pin Outstanding working and breaking loads Applications: Mainsheet halyards Max rope size: 16 mm Specifications: Materials: 316 stainless steel grade Working load: (lb) 3350 / (kg) 1520 Breaking load: (lb) 11020 / (kg) 5000 Weight: (lb) 0.313 / (g) 142 Dimensions: A: (inch) 2 1/64" / (mm) 51 B: (inch) 25/32" / (mm) 20 C: (inch) 25/64" / (mm) 10 D: (inch) 25/32" / (mm) 20 D diameter: (inch) 25/64" / (mm) 10 E: (inch) 5/16" / (mm) 8 F: (inch) 3 25/32" / (mm) 96 G: (inch) 1 39/64" / (mm) 41 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

U-Bolt Pad Eye - 10mm Diameter - 25/64" - 110mm Length - 4-21/64"Features: Entirely drop forged product with high-quality stainless steel Outstanding working and breaking loads For any fastening applications (shrouds, lifelines, blocks...) Delivered with bolts and counter-plate Max tightening torque: 36 Nm Applications:Various fastening applications: shrouds, lifelines, blocks…Specifications: Materials: 316L stainless steel grade Working load: (lb) 7930 / (kg) 3600  Breaking load: (lb) 15430 / (kg) 7000  Weight: (lb) 0.489 / (g) 222  Dimensions: A: (inch) 1 37/64" / (mm) 40  B: (inch) 1 17/64" / (mm) 32  C: (inch) 2 9/16" / (mm) 65  D diameter: (inch) 25/64" / (mm) 10  Length: (inch) 4 21/64" / (mm) 110  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

U-Bolt Pad Eye - 12mm Diameter - 15/32" - 110mm Length - 4-21/64"Features: Fully drop forged product with high-quality stainless steel Outstanding working and breaking loads For any kind of fastening applications (shrouds, lifelines, blocks...) Delivered with bolts and counter-plate Max tightening torque: 60 Nm Applications:Various fastening applications: shrouds, lifelines, blocks…Specifications: Materials: 316L stainless steel grade Working load: (lb) 14100 / (kg) 6400  Breaking load: (lb) 22040 / (kg) 10000  Weight: (lb) 0.703 / (g) 319  Dimensions: A: (inch) 1 47/64" / (mm) 44  B: (inch) 1 11/32" / (mm) 34  C: (inch) 1 31/32" / (mm) 50  D diameter: (inch) 15/32" / (mm) 12  Length: (inch) 4 21/64" / (mm) 110  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)
