Snatch Block with Snap Shackle - Max Rope Size 12mm (15/32")Features: Free rotation thanks to snap shackle Very strong closing system Easy opening by simply pulling on the plunger pin Shock and scratch-resistant thanks to the elastomer molded cheeks Applications: Changing sheets Spinnaker sheet deflector blocks Materials:  HR 17.4 PH forged stainless steel arm  Elastomer molded cheeks Composite sheave Specifications: Rope size: (inch) 15/32" / (mm) 12 Length: (inch) 5 45/64" / (mm) 145 Width: (inch) 2 21/64" / (mm) 59 Thickness: (inch) 1 11/16" / (mm) 43 Working Load: (lb) 1580 / (kg) 720 Breaking Load: (lb) 2860 / (kg) 1300 Weight: (lb) 0.56 / (g) 254 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Snatch Block with Snap Shackle - Max Rope Size 18mm (23/32")Features: Free rotation thanks to snap shackle Very strong closing system Easy opening by simply pulling on the plunger pin Shock and scratch-resistant thanks to the elastomer molded cheeks Applications: Changing sheets Spinnaker sheet deflector blocks Materials:  HR 17.4 PH forged stainless steel arm  Elastomer molded cheeks Composite sheave Specifications: Rope size: (inch) 23/32" / (mm) 18 Length: (inch) 6 7/64" / (mm) 155 Width: (inch) 2 21/64" / (mm) 59 Thickness: (inch) 1 59/64" / (mm) 49 Working Load: (lb) 2640 / (kg) 1200 Breaking Load: (lb) 5510 / (kg) 2500 Weight: (lb) 0.913 / (g) 414 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Soft Snatch Block - 10mm Rope SizeAvailable in 4 models, the collection of soft snatch blocks will quickly become an essential piece of kit: flying sail furling, Furler terminals, rigging deviation, and barber-haulers.Made from anodized aluminum, these are both lightweight and robust. The Dyneema loop ensures easy installation. They are easy to open and close too, thanks to the Velcro strip.Applications: Terminals for flying sail furlers 2/1 mainsail halyard Rigging deviation Barber-hauler Specifications: Materials -Anodized aluminium - Dyneema loop  Rope size -10mm Loop diameter - 5mm Working load (lb) 4400 Breaking load (lb) 8810 Weight (lb) 0.218 Dimensions: A (inch) 25/64" B (inch) 2 21/64" C (inch) 1 39/64" D diameter (inch) 13/64"

Read more less

Soft Snatch Block - 12mm Rope SizeAvailable in 4 models, the collection of soft snatch blocks will quickly become an essential piece of kit: flying sail furling, Furler terminals, rigging deviation, and barber-haulers.Made from anodized aluminum, these are both lightweight and robust. The Dyneema loop ensures easy installation. They are easy to open and close too, thanks to the Velcro strip.Applications: Terminals for flying sail furlers 2/1 mainsail halyard Rigging deviation Barber-hauler Specifications: Materials -Anodized aluminum - Dyneema loop  Rope size -12mm Loop diameter - 6mm Working load (lb) 6610 Breaking load (lb) 13220 Weight (lb) 0.311 Dimensions: A (inch) 15/32" B (inch) 2 33/64" C (inch) 1 13/16" D diameter (inch) 15/64"

Read more less

Soft Snatch Block - 16mm Rope SizeAvailable in 4 models, the collection of soft snatch blocks will quickly become an essential piece of kit: flying sail furling, Furler terminals, rigging deviation, and barber-haulers.Made from anodized aluminum, these are both lightweight and robust. The Dyneema loop ensures easy installation. They are easy to open and close too, thanks to the Velcro strip.Applications: Terminals for flying sail furlers 2/1 mainsail halyard Rigging deviation Barber-hauler Specifications: Materials -Anodized aluminum - Dyneema loop  Rope size -16mm Loop diameter - 8mm Working load (lb) 9920 Breaking load (lb) 19840 Weight (lb) 0.549 Dimensions: A (inch) 5/8" B (inch) 3 7/64" C (inch) 2 11/64" D diameter (inch) 5/16"

Read more less

Softlink 3.0 Soft Shackle - 3mm Diameter - 1/8" - 70mm Length - 2-3/4"Features:  SoftLink is a soft shackle developed by Wichard for recreational sailors looking for performance and ease of use For the same strength, SoftLink is 4 or 5 times lighter than a 316L stainless steel shackle No knowledge of ropework required Replaces shackles and snap hooks Easy to fit and easy to open Remarkably light and strong Re-usable 3 sizes available  Applications: Fastenings Replaces shackles and snap hooks Specifications: Materials: 316L stainless steel grade Dyneema SK78Dimensions: Loop diameter: (inch) 1/8" / (mm) 3  Loop length: (inch) 2 3/4" / (mm) 70  Working load: (lb) 3300 / (kg) 1500  Breaking load: (lb) 4400 / (kg) 2000  Weight: (lb) 0.026 / (g) 12  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Softlink 4.0 Soft Shackle - 4mm Diameter - 5/32" - 80mm Length - 3-5/32"Features:  SoftLink is a soft shackle developed by Wichard for recreational sailors looking for performance and ease of use. For the same strength, SoftLink is 4 or 5 times lighter than a 316L stainless steel shackle. No knowledge of ropework required Replaces shackles and snap hooks Easy to fit and easy to open Remarkably light and strong Re-usable 3 sizes available Applications: Fastenings Replaces shackles and snap hooks  Specifications: Materials: 316L stainless steel grade Dyneema SK78Dimensions: Loop diameter: (inch) 5/32" / (mm) 4  Loop length: (inch) 3 5/32" / (mm) 80  Working load: (lb) 5070 / (kg) 2300  Breaking load: (lb) 6610 / (kg) 3000  Weight: (lb) 0.051 / (g) 23  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

5.0 Soft Shackle - 5mm Diameter - 13/64" - 90mm Length - 3 35/64"Features:  SoftLink is a soft shackle developed by Wichard for recreational sailors looking for performance and ease of use. For the same strength, SoftLink is 4 or 5 times lighter than a 316L stainless steel shackle. No knowledge of ropework required Replaces shackles and snap hooks Easy to fit and easy to open Remarkably light and strong Re-usable 3 sizes available  Applications: Fastenings Replaces shackles and snap hooks Specifications: Materials: 316L stainless steel grade Dyneema SK78Dimensions: Loop diameter: (inch) 13/64" / (mm) 5  Loop length: (inch) 3 35/64" / (mm) 90  Working load: (lb) 8370 / (kg) 3800  Breaking load: (lb) 11020 / (kg) 5000  Weight: (lb) 0.104 / (g) 47  Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Stainless Steel Single Block - 25mm Sheave Diameter for 25mm Stanchion PivotingA single block intended for use on a dinghy. The block is light, reliable, and has good performance.Applications:For stanchion applications - furling system lineSpecifications: Materials Composite sheave and 316L stainless steel grade cheeks Rope size: (inch) 5/16"-25/64" / (mm) 8-10 Length: (inch) 3 47/64" / (mm) 95 Width: (inch) 2 3/32" / (mm) 53 Thickness: (inch) 53/64" / (mm) 21 Sheave Diameter: (inch) 63/64" / (mm) 25 Working load: (lb) 610 / (mm) 280 Breaking load: (lb) 880 / (mm) 400 Weight: (lb) 0.154 / (g) 70 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Symmetric Carbin Hook - 120mm Length - 15/32"Features: Grade 316L stainless steel carbine hooks Symmetrical shape With eye to attach a webbing or a splicing Applications:For fastening applications Specifications: Materials: 316L stainless steel grade Working load: (lb) 2990 / (kg) 1360  WLL: (lb) 1580 / (kg) 720  Breaking load: (lb) 7930 / (kg) 3600  Weight: (lb) 0.505 / (g) 229  Dimensions: A: (inch) 53/64" / (mm) 21 B: (inch) 5/8" / (mm) 16 D diameter: (inch) 15/32" / (mm) 12 Length: (inch) 4 23/32" / (mm) 120 Caption: Working Load (WL): For nautical applications Working Load Limit (WLL): For industrial applications only. The safety factor is 5 times the breaking load. WLL = Breaking load / 5 *Sold as an Individual Quick Guide (pdf)

Read more less

Symmetric Carbin Hook Without Eye - Length 120mm - 15/32"Features: Grade 316L stainless steel carbine hooks Symmetrical shape without eye                                           Applications:For fastening applicationsSpecifications: Materials 316L stainless steel grade Length (inch) 4-23/32" Working load (lb) 2990 WLL (lb) 1670 Breaking load (lb) 8370 Weight (lb) 0.441 Dimensions (see 2nd image): A (inch) 53/64" B (inch) 5/8" D diameter (inch) 15/32"

Read more less

Symmetric Carbine Hook - Length 100mm - 13/32"Features: Grade 316L stainless steel carbine hooks Symmetrical shape With eye to attach a webbing or a splicing Applications:For fastening applications Specifications: Materials 316L stainless steel grade Length (inch) 3-15/16" Working load (lb) 2640 WLL (lb) 1100 Breaking load (lb) 5510 Weight (lb) 0.291 Dimensions (see 2nd image): A (inch) 19/32" B (inch) 33/64" D diameter (inch) 25/64"
