Communication - Antennas

Classic Style 5104 4' (1.2m) VHF Marine Band 3dBEnd-Fed with Matching StubFour-foot, 3dB antenna with a great selection of high-end features. Brass and copper elements for performance, plus a smooth, high-gloss, polyurethane finish that won?t turn yellow in the sun. Superb value, and excellent performance in a great looking antenna. Brass and copper elements Chrome-plated brass ferrule with standard 1in-14 thread Includes 15ft RG-58 cable, which can be cut to size, and a PL-259 connector Suggested mount: Style 4187 or 5187 Ratchet Mount (each sold separately) Smooth, durable, high gloss finish One section Classic 5104 SpecificationsBand: VHF Marine BandAntenna Gain: 3dBMax. Input Power: 50WSWR: nominally 1.5:1 at 156.8 MHzBandwidth: 5 MHz within 2.0:1 VSWRFerrule: Chrome-plated brassCoax Supplied: 15 ft of RG-58Connector Supplied: PL-259, not installedColor/finish: WhitePolarity: VerticalImpedance: 50 OhmsShakespeare Limited Warranty: 2 years Specifications: Antenna Band: VHF Color: White Ferrule Type: Chrome Plated Length (Inches): 48" Box Dimensions: 3"H x 3"W x 55"L WT: 2.1 lbs UPC: 719441100896 Quick Guide (pdf)

Read more less

Galaxy Style 5228-1, 1 ft Heavy-Duty Extension MastOne foot length. Constructed of high-quality Shakespeare white fiberglass, and finished to match Galaxy antennas. This 1 " diameter extension mast can be used to increase height of an antenna and thus improve effective range, or to boost placement of an antenna above on-board obstructions. For light to moderate applications. Excellent for use with GPS or TV antennas to clear on-board obstructions. Stainless steel upper and lower ferrules with standard 1in-14 thread Mount: Shakespeare Style 409-R or 410-R Mounting Kit (sold seperately) One section, actual length 12" Use an upper support bracket (sold seperately) if the length of antenna and mast total more than eight feet.Color: Galaxy White Specifications: Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 12" Box Dimensions: 2"H x 2"W x 18"L WT: 1.1 lbs UPC: 719441200145 Quick Guide (pdf)

Read more less

Shakespeare Style 5206-N VHF Marine - Reduced Length Version8' LENGTH 6dBEND-FED WITH MATCHING STUBSame as the Style 5206-C, but the 5206-N has a nylon ferrule.An economical and lightweight, self-supporting antenna for good communications where range is not the predominant factor. Quality copper cable elements for good range and efficiency Nylon ferrule with standard 1"-14 thread Includes 15' RG-58 cable and a PL-259 connector Suggested mount: Shakespeare Style 495 Lift-n-Lay Mount or Style 4186 Ratchet Mount Twin to: Shakespeare Styles 5205 and 5207 CB Marine antennas One section Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency: VHF Marine band Bandwidth: 3 MHz SWR: 1.5:1 @156.8 MHz Impedance: (Ohms): 50 Gain: 6 dB Max Input (Watts): 50 DC Ground: NO - the antenna will read "open circuit" when checked with an ohm meter or continuity tester. Termination: RG-58 Height (feet): 8 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Nylon Length (Inches): 96" Box Dimensions: 3"H x 3"W x 95"L WT: 2.4 lbs UPC: 719441100186 Quick Guide (pdf)

Read more less

MRANT10 AM/FM Dipole AntennaDipole hide-away soft wire antenna that is designed for the marine environment.  Universal wire antenna plugs right in to your factory or aftermarket stereo. Features: AM/FM antenna Works with any stereo Cable length - 45" *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Length (Inches): 45" Construction: Plastic Color: Black Antenna Band: AM/FM Type: Antennas Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 791489310420

Read more less

SeaWatch® 15" Marine TV Antenna - 12VDC - 110VACThe SeaWatch® series of TV antennas are omni-directional over-the-air digital HDTV solutions that bring sleek lines and 360 degrees high-performance coverage to your watercraft. Designed to accept common 1in-14 threaded mounts, the antennas are well suited to fit virtually any application. Everything needed to connect the antenna to your converter or television is in the box. When paired with an optional 2-way band separator between the antenna and the amplifier, these antennas can also receive AM/FM radio signals. A full line of mounts and extension masts are available to fine-tune the installation.The 3015 antenna is designed for the mobile lifestyle and can be used on marine vessels, RVs, pop-up campers and more! Watch your favorite sports, sitcoms, reality TV, crime dramas, local news, weather, kids programming and more for FREE and in 1080 HD!Features: Low noise amplifier Omni-directional Recieves ALL local HD broadcast signals AC, DC and USB power adapter Best suited for areas up to 40 Miles from Broadcast Towers Specifications: Frequency Range: VHF:47-230MHz;UHF: 470-862MHz Receiving Range: FM/VHF/UHF Gain: 30dB Noise Figure: 3db Max. output lever: 110dBuV Impedance: 75ohms Connector: F-connectors Power Supply: DC 12V, AC 110v Dimensions: 15" x 3" Package Includes: 3015 Panel TV Antenna 20' RG-59 Coax Cable/F-Connectors USB/AC/DC Power Cords Specifications: Length (Inches): 15" Color: White Antenna Band: TV Box Dimensions: 6"H x 16"W x 16"L WT: 5.4 lbs UPC: 719441140533 Brochure (pdf)

Read more less

Shakespeare Style 393 SSB23' LENGTHWHIP ANTENNA WITH CONDUCTORS RUNNING FULL-LENGTH (NO LOADING COIL)The Style 393 antenna is electrically the same as the industry standard Style 390, For use in calm to moderate seas. Chrome-plated brass ferrules, bottom ferrule has 1"-14 thread Side feed termination band Suggested mount: Shakespeare Style 409-R or 410-R Mounting Kit for deck or side mounting Three sections: Base 92"; Center 92"; Tip 92" Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency: 2-30 MHz HF band with tuner Bandwidth: Resonant frequency 10.8 MHz SWR: N/A Impedance: (Ohms): N/A Gain: N/A Max Input (Watts): 1000 DC Ground: N/A Termination: Side Termination Height (feet): 23 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: SSB Color: White Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 144" Box Dimensions: 3"H x 3"W x 96"L WT: 5.2 lbs UPC: 719441600075 Quick Guide (pdf)

Read more less

6500-WB 4FT Broad Band VHF Antenna 3dBBuilt for maximum performance, this 4’ broad band antenna is designed to endure the harsh environment and communication requirements in commercial, law enforcement and disaster management applications. Whether you install it on a vessel, base station, or a stationary platform, this antenna provides a host of mounting options to fit your need. No tuning or ground plane required. Cable not included.Features: Stainless steel mounting bracket: corrosion resistant even in marine environments. Patent pending mount design: install the U-bolts without removing hardware – no more lost hardware Detachable antenna: handle mounting bracket easily without the weight of the antenna. Mount it on a large variety of Shakespeare® mounts with a 1”-14 thread* IP67**, high wind rating, wide temperature range, and PU Coating: built to last in rain, sun, ice, dust, water splashes and even corrosive marine environments *Requires a Shakespeare 4006 double female ferrule (not included).**When installed as instructed. Specifications: Length (Inches): 48" Color: White Antenna Band: Broadband Box Dimensions: 2"H x 5"W x 52"L WT: 4 lbs UPC: 719441173081

Read more less

MA800 GPS Antenna for AIS TranspondersThe MA800 passive GPS Antenna for AIS transponder (P/No. X500.391) is compatible with all current Digital Yacht AIS Transponders (AIT2000/2500/3000/5000/CLA1000/CLA2000). It is therefore an ideal replacement antenna for many makes of GPS receivers and chart plotters.  You can also use it with the discontinued AIT250 and AIT1000. However, the physical size and shape are different from the original antenna.The base can be removed for puck mounting or with the base fitted, it can be attached to any 1” mounting accessory (available separately) for pole, deck, bracket, and rail mounting.It ships with a 33' cable terminated with a slim FME connector and FME-TNC adaptor.Specifications: Bolt holes: 5/16" diameter, 3" x 1-1/2" on center Special cable slot thus eliminating removal of most factory-installed connectors Standard 1 in-14 thread (male) Stainless steel Heavy-duty construction Specifications: Antenna Band: AIS Color: White Type: Antennas Box Dimensions: 2"H x 8"W x 9"L WT: 1.2 lbs UPC: 081159830373

Read more less

AM/FM Flexible AntennaThis side or top mount 14" AM/FM antenna features a 60" cable and can adjust to a 90 degree angle.Features: AM/FM Antenna Top or side Mount Cable length- 60" 90 degree adjustable angle *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Antennas Antenna Band: AM/FM Color: Black Construction: Vinyl Rubber Length (Inches): 14" Box Dimensions: 1"H x 3"W x 19"L WT: 0.5 lbs UPC: 681787011122

Read more less

GV30 Combo GPS & AIS AntennaA Class B AIS transponder requires a dedicated GPS antenna (all Class B units must have their own internal GPS and can't use an external feed for regulatory purposes) as well as a VHF antenna or suitable VHF-AIS antenna splitter. The GV30 is a combination VHF/AIS and GPS antenna with twin coax feeds (10m). It is fitted with a standard 1" threaded base so will mount onto a variety of deck, pole and rail attachments available from many 3rd party suppliers.The 10m coax cables are terminated with a FME mini connectors which makes running the cable easy, as the connector is barely larger than the 5mm cable. We then supply suitable adaptors for the TNC and BNC connectors on our AIT2000.The GV30 is just 190mm high and 75mm in diameter. Despite its compact dimensions, it offers very good performance as it is specifically tuned to 162MHz (AIS frequency). The GV30 is also available with the AIT2000 as a bundle.Features: Combination AIS/VHF and GPS antenna Specifically tuned to 162MHz High gain GPS element Supplied with 2 x 10m cable tails fitted with mini connectors for easy cable installation Standard 1" threaded base for compatibility with a variety of 3rd party mounts Supplied with TNC (GPS) and BNC (AIS) adaptors Under 200mm high for low profile installation

Read more less

Dorsal Antenna White Low Profile 26' RGB Cable with PL-259The Shakespeare Dorsal Antenna is designed specifically for greater effectiveness in short-range applications. The fin-shaped design removes the chance of the antenna getting snagged while the high-impact ABS body ensures a longer life within harsh environments.Features: Low-profile fin-shaped antenna Suitable for up to 10 miles range Supplied with 8m cable and plug as standard Fully water sealed with rubber gasket included Specifications: Frequency Band: 156 - 162 Size: 100 x 60 x 65mm Mounting: M14x1 Thread base  Cable/Connector: 8m RG58 / PL-259 Plug Owner's Manual (pdf)

Read more less

VHF 8' 6225-R Phase III Antenna - No CableReduced Length Version Embark upon your next voyage with the most technologically advanced antenna we've ever created...Construction Goes High-TechPhase III antennas embody the ultimate in antenna design, construction and performance. We intend them for discerning, tech-conscious boaters who won't settle for less than the best, most versatile and most attractive antennas. For highest electrical efficiency, performance, and longevity, Phase III VHF and Cellular antennas start with silver-plated elements. They also feature Shakespeare's unique low-angle radiation that puts your signal where it matters most. All of our extra heavy-duty Phase III radomes are completely foam-filled. This sophisticated technique, which is no easy feat to manufacture, isolates the radiators from vibration and moisture for long, dependable service. Antenna mounting has also been designed for more versatility. Phase III's newly engineered ferrules accommodate a variety of installation possibilities, including standard 1" - 14 thread mounts, and strapping or clamping to a mast. Collinear-phased 5/8-wave elementsBuilt for performance and durability, this flagship Phase III antenna won't mind high speeds and high winds. Its great looks will be welcome on your boat, and so will its reliability.Features Silver-plated outer conductor, copper inner conductor Stainless steel mounting sleeve The connection is an SO239 which uses a standard PL259 connector Suggested mount: Shakespeare Style 4187-HD Ratchet Mount Max Power Input: 150 Watts SWR: Less than 1.5:1 at 156.8 MHz Bandwidth: 3 MHz within 2.0:1 VSWR Frequency: VHF Marine Band DC Grounding: Yes Warranty: 8 Years Specifications: Length (Inches): 96" Ferrule Type: Stainless Steel Construction: Fiberglass Color: White Antenna Band: VHF Box Dimensions: 3"H x 3"W x 95"L WT: 7.8 lbs UPC: 719441200640 Quick Guide (pdf)
