Communication - Antennas

Shakespeare Style 5250 Skinny Mini3 ft. (0.91 M) VHF Marine Band 3dBEnd-fed 1/2-wave stainless steel whipThis compact, lightweight antenna is ideal for vessels where space is limited - bass boats and fishing vessels, for example. Its chrome plated brass canister minimizes de-tuning. Cable and PL-259 connector included. Stainless steel whip Sealed, tin-plated copper wire coil Requires mount with center hole for passage of the supplied 15' RG-58 cable. One section Specifications: Antenna Band: VHF Color: Stainless Construction: Stainless Steel Ferrule Type: Stainless Steel Length (Inches): 36" Box Dimensions: 3"H x 3"W x 39"L WT: 2 lbs UPC: 719441100797 Quick Guide (pdf)

Read more less

Galaxy 5420-XT 4' AM/FM Antenna4' AM/FM Entertainment BandBring in those stations! This Little Giant is in charge of the entertainment. Its sturdy construction and outstanding performance make it an excellent choice for T-tops, Hard-tops and other elevated mounting positions. Extra rigid, extra tough.Features: Copper elements Stainless steel ferrule with standard 1"-14 thread Includes 12' RG-62 cable with Motorola type plug installed Suggested mount: Shakespeare Style 4187 Ratchet Mount One section Shakespeare Limited Warranty: 5 years Specifications:Antenna Length: 4ft. Specifications: Antenna Band: AM/FM Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 3"H x 3"W x 55"L WT: 2.4 lbs UPC: 719441400132 Quick Guide (pdf)

Read more less

End-fed, center loaded stainless steel whipHead for the regatta! This super light-weight black VHF marine antenna is specifically built for sailboat racers. It won't add much weight, while delivering the performance you need. Its 15" center-loaded design delivers Unity Gain, and it comes with a black L-bracelet for mounting atop your mast. Its connector is gold-plated too. Small and extra light-weight Stainless steel whip Black L-bracket included for mast mounting One section Band: VHF marine band Max Input Power: 25 watts Color/finish: Black Specifications: Antenna Band: VHF Color: Black Construction: Stainless Steel Length (Inches): 15" Box Dimensions: 3"H x 5"W x 16"L WT: 0.35 lbs UPC: 719441190071

Read more less

5101 8’ Classic VHF Antenna with 15' RG-58 Cable - White - Reduced Length VersionEND-FED WITH MATCHING STUBA standard of excellence in an economical antenna! Shakespeare brings you the best of the high-end features in an 8' antenna with a brass element and a smooth, high-gloss, polyurethane finish that won't turn yellow in the sun. This antenna delivers not only performance, but superb value.Features: Brass and copper elements Chrome-plated brass ferrule with standard 1"-14 thread Includes 15' RG-58 cable and a PL-259 connector Suggested mount: Shakespeare Style 4187 Ratchet Mount, or use a Shakespeare Style 410-R Mounting Kit plus a Style 4008 Extension Mast to form a 16' antenna system One section Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency:    VHF Marine Band Bandwidth:    (within 2.01 SWR): 5 MHz SWR:    1.5:1 at 156.8 MHz Impedance:    (Ohms): 50 Gain:    6 dB Max. Input (Watts):    50 DC Ground:    YES - however, the antenna will read "open circuit" when tested with an ohmmeter. Termination:    15' RG-58 cable Height (feet):    8' Polarization:    Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 96" Box Dimensions: 2"H x 2"W x 95"L WT: 3.65 lbs UPC: 719441100490 Quick Guide (pdf)

Read more less

4' VHF/AIS White Antenna with 15' CableThe 594-MW is one antenna designed for the best performance on VHF and AIS signals. To ensure the most incredible AIS and VHF range, Digital Antenna’s new 4.5dB gain AIS/VHF antenna features a less than 1:5:1 SWR on both the VHF (156MHz) and AIS (162MHz) frequencies.Digital VHF radio-based transponder systems need antennas designed for digital signals. Digital Antenna is the only manufacturer to design all antennas to maintain and maximize digital signals for the best transmit and receive range.Ideal for use on any size commercial or recreational vessel. Perfect for use with combined VHF/AIS radios. Factory-installed mini-UHF connector (less than 3/8” OD) and included PL259 adapter make a quick and secure connection to the radio. (no soldering needed).Features: Designed for Digital AIS/VHF signals 4.5dBi Omni-directional gain Rugged fiberglass rod with UV stable finish Secure soldered connections 316 stainless steel base 1”x14 female threaded base 15’ premium low-loss RG-8X cable Factory-installed mini-UHF connector 5-year warranty Specifications: Radiation: Pattern Omni-Directional Gain: 4.5dBi Bandwidth: VSWR: < 1.5:1 = 1 56-162.5 MHz (6.5MHz) Cable: 15’ Digital Antenna exclusive low loss RG-8X Impedance: 50 ohms Max Input Power: 50 watts Exterior Finish: White polyurethane high gloss UV stable Dimensions: 4’ length x 1” OD taper Weight: 1.7 lbs RF Connector: Mini-UHF female with included PL259 adapter Installation: 1”x14tpi female threaded base Elements: Brass - Hand soldered Polarization: Vertical Wind Rating: >160KPH Operating Temp: 30º F to +175º F Warranty: 5 Years Compliance: Automatic Identification System (AIS) Use with all AIS class A and B transceivers, AIS transponders, Smart AIS transponders, AIS receivers, auxiliary civil services, multi-use radio service (MURS), 2-way land mobile, VHF marine radio, narrow band FM, VHF SATCOM, Automatic Identification System (AIS), and NOAA Weather Stations.Applications:  Commercial Recreational Government vessels where AIS is required Specifications: Color: White Length (Inches): 48" Box Dimensions: 2"H x 2"W x 50"L WT: 2.5 lbs UPC: 839494001923

Read more less

829-VW-S 8' VHF Antenna - White6dB GainDigital Antenna's ultimate, award-winning 8' VHF antennas combine 6 dB gain, ruggedness and a pristine finish to give you the most superior antenna available. Even in the harshest conditions, these antennas will maintain their beautiful glossy finish for years. Built to withstand high speeds, these antennas are ideal for radar arches and T-tops on speedboats, yachts and commercial vessels.All of our antennas are made in the USA, assembled, tested and tuned by hand for maximum performance, quality and durability.All 8' VHF Antennas Feature: Powerful brass radiators Soldered connections Power directing ferrite choke bead High gloss urethane finish 316 stainless steel ferrule 6dB gain 800 Series: Mount: Stainless steel double female ferrule for mounting 114 threaded base Connector: Highest quality female SO-239 (UHF) Cable: Not included use our VHF/AIS cables and two DA645 connectors This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 94" Box Dimensions: 3"H x 3"W x 95"L WT: 5.5 lbs UPC: 839494004665 Owner's Manual (pdf)Brochure (pdf)

Read more less

VHF Antenna4.5dB GainVoted the best 4' VHF antenna by PowerBoat Reports, Digital Antennas 4' VHF antennas are ideal for use on T-tops, speedboats and sailboats. With 4.5dB gain and award-winning quality construction, these powerful and compact antennas deliver high performance that will last for years.Customers and installers love the 500 GOLD Series easy installation connector system. The gold factory-attached mini-UHF female connector with PL-259 (UHF) adapter makes connecting to the radio easy, eliminating the need to solder connectors.All of our antennas are made in the USA, assembled, tested and tuned by hand for maximum performance, quality and durability.4' VHF Antennas Feature: Powerful brass radiators Soldered connections Power directing ferrite choke bead High gloss urethane finish 316 stainless steel ferrule 4dB gain 500 GOLD Series: Mount: Standard 1"14 threaded base Connector: Gold factory-attached mini-UHF female with mini-UHF male to UHF male (PL259) adapter Cable: Includes 15 of our low-loss, tinned braid, foil shielded, UV stable RG-8X marine cable This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Antenna Band: VHF Color: Black Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 2"H x 2"W x 50"L WT: 3.3 lbs UPC: 839494001190 Quick Guide (pdf)

Read more less

4' AM/FM AntennasStereoWhen onboard entertainment is your passion, Digital Antennas AM/FM antennas deliver unbeatable reception and clarity. For the most eye-catching aesthetics, our 4 AM/FM antennas are designed to match our 4 VHF, AIS and cellular antennas.All of our antennas are made in the USA, assembled, tested and tuned by hand for maximum performance, quality and durability.All 4' AM/FM Antennas Feature: Soldered connections High gloss urethane finish 316 stainless steel ferrule 500 GOLD Series: Mount: Standard 114 threaded base Connector: Unattached Motorola type plug Cable: Includes 15 of our low-loss, tinned braid, foil shielded, UV stable RG-8X marine cable This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Antenna Band: AM/FM Color: Black Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 2"H x 2"W x 50"L WT: 2.95 lbs UPC: 839494001077 Quick Guide (pdf)

Read more less

AIS Antennas4' Length, 4.5dB GainIn conjunction with the USCG Automatic Identification System (AIS) requirements for commercial vessels, Digital Antenna created a series of 4 AIS antennas that meet the exacting AIS frequency requirements. Designed with a low 1.5:1.0 SWR ratio from 159-162 MHz, Digital Antennas 4.5 dB gain AIS antennas offer unsurpassed durability and performance compatible with all AIS transponders.Customers and installers love the 500 GOLD Series easy installation connector system. The gold factory-attached mini-UHF female connector with PL-259 (UHF) adapter makes connecting to the AIS transponder easy, eliminating the need to solder connectors.All of our antennas are made in the USA, assembled, tested and tuned by hand for maximum performance, quality and durability.All 4' AIS Antennas Feature: Powerful brass radiators Soldered connections Power directing ferrite choke bead High gloss urethane finish 316 stainless steel ferrule 4.5dB gain 500 GOLD Series Mount: Standard 114 threaded base Connector: Gold factory-attached mini-UHF female with mini-UHF male to UHF male (PL259) adapter Cable: Includes 25 of our low-loss, tinned braid, foil shielded, UV stable RG-8X marine cable This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Antenna Band: AIS Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 3"H x 3"W x 50"L WT: 3.2 lbs UPC: 839494001619 Quick Guide (pdf)

Read more less

Shakespeare Squatty Body®Style 5215-AIS 3' (0.9m) VHF Marine Band 3dBEnd-fed 1/2-wave stainless steel whipSailboat owners will love this version of their longtime favorite, our Style 5215. Its the same light weight, low-profile, stainless steel antenna, specially designed for masthead mounting and built with extra bandwidth for all popular AIS transceivers. Sealed, tin-plated copper wire coil Designed specifically for AIS transceivers SO-239 connector Stainless steel L-shaped bracket supplied for mounting One section For AIS applications Best applications include: SailboatsShakespeare 5215-AIS Squatty Body® Specifications Band: VHF Marine Band Antenna Gain: 3dB Max. Input Power: 50 watts SWR: nominally 1.5:1 at 162 MHz Bandwidth: 7 MHz within 2.0:1 VSWR Ferrule: L-bracket and retaining nut, SO-239 connector Polarity: Vertical Impedance: 50 Ohms DC Ground: No DC Ground - The antenna will read open on continuity test. Shakespeare Limited Warranty: 2 years Specifications: Antenna Band: AIS Length (Inches): 36" Box Dimensions: 2"H x 2"W x 40"L WT: 2 lbs UPC: 719441100810 Quick Guide (pdf)

Read more less

Low-profile end-fed 1/2 wave with standard duty whipThis legacy style is coming back due to customer request. A convenient press-and-twist bayonet fitting makes attaching or removing its stainless steel whip quick and easy. The bayonet has been re-designed and improved for extra convenience. Stainless steel whip (36 in) Whip is user replaceable L-shaped bracket included for mounting One Section Best applications include: bass boats and center console fishing boats; for small to medium and similar types of vessels. Specifications: Construction: Stainless Steel Antenna Band: VHF Length (Inches): 36" Box Dimensions: 2"H x 3"W x 40"L WT: 1.6 lbs UPC: 719441100759 Quick Guide (pdf)

Read more less

VHF 8' QuickConnect™ 6dB for QCM Series MountsQuickConnect™ antennas stem from the popularity of the quick connecting feature on Shakespeare's high-end Phase III® marine antennas, the QuickConnect™ product line brings you the ease of connecting and disconnecting your marine antenna in a more affordable line-up.Features: QuickConnect™ System - Screw or unscrew the antenna to disconnect or connect Splash Protection Cap - Protects the connector on the mount when the antenna is disconnected Centerpin® PL-259 Connector - An easy crimp-on connector Base connector included for use with QuickConnect™ mounts only Single Section antennas with VSWR of <1.5:1 at 156.8 MHz Maximum input power of 50W The bandwidth of 5 MHz within 2.0:1 VSWR Does not contain a built-in DC ground connection Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Length (Inches): 96" Box Dimensions: 3"H x 3"W x 95"L WT: 3.75 lbs UPC: 719441173111
