Shakespeare 5250-AIS Skinny Mini3ft. VHF Marine Band 3dBEnd-fed 1/2-wave stainless steel whipDesigned to meet the broader bandwidth requirements of all popular AIS transceivers, this antenna mounts with ease. Its compact size will be welcome aboard any vessel. Chrome plated brass canister minimizes de-tuning. Built for AIS transceivers Sealed, tin-plated copper wire coil Stainless steel whip (36") Requires mount with center hole for passage of the supplied 15' RG-58 cable. One section PL-259 connector included Specifications: Antenna Band: VHF Color: Stainless Construction: Stainless Steel Length (Inches): 36" Box Dimensions: 3"H x 3"W x 40"L WT: 2 lbs UPC: 719441100803 Quick Guide (pdf)

Read more less

Shakespeare Style 43513' COMBINATION AM/FMThis 3' combination antenna features Shakespeare's exclusive distributive load for super signal pulling power. The coil is permanently sealed in Shakespeare's white fiberglass.The Style 4351 has a 1"-14 thread nylon ferrule for use with standard marine mounts. Includes 10' RG-62 coax with Motorola plug installed One section, 39" overall length Nylon ferrule with standard 1in-14 thread Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency: 550-1600 KHz, 88-108 MHz Impedance: (Ohms): 93 Termination: 10' RG-62 cable, Motorola Plug Height (feet): 3 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: AM/FM Color: White Construction: Fiberglass Ferrule Type: Nylon Length (Inches): 39" Box Dimensions: 3"H x 3"W x 44"L WT: 1.4 lbs UPC: 719441400026 Quick Guide (pdf)

Read more less

Shakespeare Style 5215-C-X SQUATTY BODY® VHF Marine36" LENGTH, 3dBEND-FED 1/2-WAVE STAINLESS STEEL WHIPSame as the Style 5215 but comes with 60' RG-8/X low-loss cable and PL-259 connectors.A favorite with Sailboat owners, this lightweight, low profile, stainless steel antenna is specially designed for masthead mounting. Hermetically sealed, tin-plated copper wire coil Stainless steel body and whip SO-239 connector Includes 60' RG-8/X low-loss cable and PL-259 connectors. Mount: Stainless steel "L" bracket supplied, for mast mounting One section Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency: VHF Marine band Bandwidth: 7 MHz SWR: 1.5:1 @ 156.8 MHz Impedance: (Ohms): 50 Gain: 3 dB Max Input (Watts): 50 DC Ground: NO Termination: 60' RG-8X cable Height (feet): 3' Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: Stainless Construction: Stainless Steel Length (Inches): 36" Box Dimensions: 4"H x 4"W x 44"L WT: 4.2 lbs UPC: 719441100155 Quick Guide (pdf)

Read more less

Cellular/Wi-Fi World Band Galaxy AntennaThe Galaxy 5239 antenna is Shakespeare's smallest Galaxy antenna, but don't let the size fool you. This World-band antenna provides coverage for 2G/3G/4G and WLAN systems for Cellular, PCS, AWS and LTE frequencies, as well as 802.11n Wi-Fi. This compact, feature rich antenna is at home on virtually any watercraft, and is fitted with a stainless steel ferrule and N-connector that are compatible with nearly all Shakespeare 1in -14 threaded mounts.Features: Full Band (698 - 2700 MHz) Broadband 2G/3G/4G and WLAN systems Wi-Fi 802.11n compatible Designed for marine use Omni-directional antenna 3-4 dB Gain. Easy to install Includes FME Cables Specifications: Frequency: 698-960/1700-2700 MHz Input Impedence: 50 ohm Antenna Gain: 2-3dB @ 698-960/3-4dB @ 1700-2700 MHz VSWR: ≤ 1.8 Power Rating (W): 10 Polarization Type: Vertical Radiation: Omni-Directional Maximum Power (W): 100 Connector Type: N-female Dimension: 9.25" H x 2.625" D Color: White Operating Temperature (F): -22 to +176 Mounting: 1" x 14 Thread Mount Ground Plane: Internal Material: Fiberglass Specifications: Length (Inches): 9.25" Construction: Fiberglass Color: White Box Dimensions: 5"H x 5"W x 11"L WT: 1.8 lbs UPC: 719441900960

Read more less

Shakespeare Style 396-1-AIS VHF Marine AIS4' LENGTH 3dB4' MAST MOUNT AIS ANTENNAThe 396-1-AIS has been specially designed to meet the broader bandwidth requirements of all popular AIS transceivers. Commercial-grade construction with a mast mounting sleeve. Brass and copper elements SO-239 connector at the base Suggested Mount: U-Bolts included. Can be strapped to a larger mast using steel banding (not supplied) One section Coax cable sold separately Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency: VHF Marine Band Bandwidth within 2.0:1 SWR: 6.0 MHz SWR: 1.5:1 at 156.8 MHz Gain: 3dB Impedance (Ohms): 50 Gain: 3dB Max. Input (Watts): 100 DC Ground: no (will read open-circuit with ohmeter test) Termination: SO-239 at bottom of antenna Height (feet): 4 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Length (Inches): 48" Box Dimensions: 3"H x 3"W x 55"L WT: 3 lbs UPC: 719441170585 Quick Guide (pdf)

Read more less

5400-XT Galaxy 4' VHF Antenna - 3dB GainThe compact Galaxy® 5400-XT is an outstanding, general purpose 4' antenna of heavy duty construction for general purpose communications. Its at home on T-tops, hard-tops, and other positions aloft, where its small size can deliver maximum range.Features: Center-fed 1/2 wave coaxial sleeve Brass and copper elements for maximum range Stainless steel ferrule with standard 1"-14 thread Includes 20' RG-8/X cable and a PL-259 connector Suggested mount: Shakespeare Style 4187 Ratchet Mount One section Shakespeare Limited Warranty: 5 years Includes FME Cables Technical Specifications: Frequency: VHF Marine Band Bandwidth: 5 MHz within 2.0:1 VSWR SWR: Nominally 1.5:1 at 156.8 MHz Gain: 3 dB Max Input (Watts): 50 watts Height (feet): 4 Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 3"H x 3"W x 52"L WT: 2.5 lbs UPC: 719441100605 Quick Guide (pdf)

Read more less

Shakespeare Style 393 SSB23' LENGTHWHIP ANTENNA WITH CONDUCTORS RUNNING FULL-LENGTH (NO LOADING COIL)The Style 393 antenna is electrically the same as the industry standard Style 390, For use in calm to moderate seas. Chrome-plated brass ferrules, bottom ferrule has 1"-14 thread Side feed termination band Suggested mount: Shakespeare Style 409-R or 410-R Mounting Kit for deck or side mounting Three sections: Base 92"; Center 92"; Tip 92" Shakespeare Limited Warranty: 2 years Technical Specifications: Frequency: 2-30 MHz HF band with tuner Bandwidth: Resonant frequency 10.8 MHz SWR: N/A Impedance: (Ohms): N/A Gain: N/A Max Input (Watts): 1000 DC Ground: N/A Termination: Side Termination Height (feet): 23 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: SSB Color: White Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 144" Box Dimensions: 3"H x 3"W x 96"L WT: 5.2 lbs UPC: 719441600075 Quick Guide (pdf)

Read more less

Style 396-1 VHF 3dBCenter-fed 1/2-wave coaxial sleeveOutstanding, basic 3dB antenna designed to reduce signal fading in rough seas. This is probably the most widely used antenna on Coast Guard vessels. Brass and copper elements Chrome-plated brass ferrule with standard 1-14 thread Includes 15' RG-58 cable and a PL-259 connector Suggested mount: Style 4187 Ratchet Mount One section Technical Specifications: Frequency: VHF Marine band Bandwidth: (within 2.0:1 SWR): 5 MHz SWR: 1.5:1 at 156.8 MHz Impedance (Ohms): 50 Gain: 3 dB Max Input (Watts): 50 DC Ground: NO Termination: 15' RG-58 cable Height (feet): 5 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 60" Box Dimensions: 3"H x 3"W x 63"L WT: 2.9 lbs UPC: 719441100018 Quick Guide (pdf)

Read more less

AM/FM Top Mount Pull-Up Antenna Want to replace that broken antenna? This antenna offers a convenient solution for bringing crisp, static-free AM/FM reception to your stereo.Features: AM/FM/ Top Mount Pull-Up Antenna  5 section collapsible Antenna  39" Mast length  48" Cable length Adjustable 35" angle  Locking application - key included Removable rubber cap for locking or unlocking application (Key provided) *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Antennas Antenna Band: AM/FM Color: Black Length (Inches): 39" Box Dimensions: 2"H x 4"W x 12"L WT: 0.45 lbs UPC: 681787012945

Read more less

AM/FM Soft Wire Antenna Superior sound performance will be delivered to you via the ANT1B AM/FM Stereo Antenna. This unit's small size and unique soft wire design will make it the perfect option aboard any boat. Achieve excellent sound quality with the ANT1B antenna! Features: 30" in length Soft wire design Works with any stereo *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Antennas Antenna Band: AM/FM Color: White Length (Inches): 30" Box Dimensions: 1"H x 4"W x 4"L WT: 0.05 lbs UPC: 681787018329

Read more less

DTV100 Marine HDTV/FM AntennaThe DTV100 HD TV antenna from Digital Yacht allows you to access free digital TV services on board. With a super sensitive design and hi gain amplifier, it sucks in even the weakest of signals. It's omni-directional too so there's no complicated aligning plus it will also provide a feed for a FM stereo radio.The DTV100 is a high performance, omni-directional TV antenna providing a great signal for on board HD TV systems. Start taking advantage of free HD digital TV entertainment today.Digital terrestrial TV (even in HD) can now be received while afloat with a new TV antenna from Digital Yacht. Called the DTV100, it features a highly sensitive omni-directional design and hi gain (-7 to 29dB amplifier) to pick up even the weakest of signals. It can also feed a FM stereo. Start enjoying a few home luxuries on board today.The slick DTV100 TV antenna picks up national free to view HD TV signals and allows a range of popular channels to be viewed on board thanks to its sensitive omni-directional design.Features: Very high performance omni-directional marine TV antenna Global reception capability of latest DVB/HDTV signals TV and FM radio outlet Below deck mounted amplifier with -7dB to +29dB gain Pole or standard 1" adapter mounting capability Supplied with 10m coax Optional dual TV outlet amplifier Just 280mm diameter Exceptional performance for an omni-directional TV antenna Designed for Easy Installation & Performance: Waterproof to IP68 and ultra tough UV resistant ABS casing Antenna supports vertical and horizontal polarization plus FM radio Adapters for antenna supplied to fit standard pole or 1" threaded mounts from 3rd parties Single RG6 coax feed to below deck amplifier Below deck amplifier and splitter provides -7 to 29dB gain adjustment. 12/24V Optional amplifier provides 2nd TV output for multi cabin installation Specifications: Antenna Band: TV Color: White Box Dimensions: 10"H x 12"W x 13"L WT: 4 lbs UPC: 081159830427 Brochure (pdf)

Read more less

532-VW-RS 16' White VHF f/RUPP Mounts10dB Gain** Designed to be used with RUPP Antenna Mounts **A favorite of marine professions, our largest VHF antennas offer the power and durability to achieve maximum range and extended performance, even in the roughest seas. A powerful gain of 10dB and solid construction make Digital Antenna's 16' VHF antennas the ideal choice for critical communication onboard large yachts, commercial vessels and base stations.Customers and installers love the 500 GOLD Series' easy installation connector system. The gold factory-attached mini-UHF female connector with PL-259 (UHF) adapter makes connecting to the radio easy, eliminating the need to solder connectors.All of our antennas are made in the USA, assembled, tested and tuned by hand for maximum performance, quality and durability. UPS shippable.16' VHF antennas require a side support 3' to 4' from the base of the antennaFeatures: Pre-installed RUPP collar Powerful brass radiators Soldered connections Power directing ferrite choke bead High gloss urethane finish 316 stainless steel ferrule 10dB gain Cable: Includes 20’ of our low-loss, tinned braid, foil shielded, UV stable RG-8X marine cable Mount: Standard 1"–14 threaded base (RUPP support arm required) Connector: Gold factory-attached mini-UHF female with mini-UHF male to UHF male (PL259) adapter This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 190" Box Dimensions: 4"H x 4"W x 95"L WT: 13.6 lbs UPC: 839494004696 Brochure (pdf)
