Communication - Antennas

8' White VHF Antenna 6dB Heavy Stainless Steel Ferrule with 6M RG-8x Includes PL-259 Heavy Duty Offshore Antenna KS-43The KS-43 is the best-performing VHF antenna of the Scout range, specifically designed to guarantee long-range communication and endless duration for boaters who want more than a good VHF antenna. Collinear-phased, made with solid brass and copper elements, and extra heavy-duty fiberglass 1,5 mm thick.Moreover, the antenna is totally foam injected with the Scout 100% waterproof technique, making it perfectly sealed and with an outstanding resistance to harsh environments. Water, wind, ice, and high speed are good friends. The fiberglass whip is black painted, to make the antenna fit with the most modern boats.The antenna is supplied with 6m (20′) high-performance RG-8X cable with 97% copper braid coverage, which guarantees perfect shielding from external interferences. Stainless steel ferrule with standard 1″ x 14 threads to fit on every type of mount (stainless steel/chrome brass mounts are suggested).Features: High-performance 6 dB antenna Extra heavy-duty fiberglass whip Foam injected – 100% waterproof Specifications: Frequency: 156-162 MHz Impedance: 50 ohms Electrical length: 1/2 λ + 1/2 λ V.S.W.R.: < 1,5:1 Polarization: Vertical Gain: 6 dB Max power input: 50 W DC ground: Yes Whip material: Fiberglass Coaxial cable: 6 m (19.6′) RG-8X Mounting: 1″ x 14 thread Length: 2,4 m (8′) Weight: 0,86 kilo

Read more less

5' White VHF Antenna 3dB Lift & Lay Mount with 5M RG-58Premium quality, easy set up and quick lay down. The lift and lay mount makes it possible with an easy release. Indicated for fishing, trailering, coverage, and storage. The special paint with an anti-UV filter avoids the deterioration of the colouring and keeps the whip shining white.The vinyl plastic cap, navy blue, provides a quality, finished appearance to the antenna, and it’s extremely resistant to high temperatures. Now 100% WATERPROOF.Features: Lift and lay mount supplied with the antenna Anti–UV high gloss finish 100% WATERPROOF Antenna Base Lift and Lay inclusa con nell’antenna 5 m coaxial cable RG 58 CU MIL Specifications: Frequency: 156-162 MHz Impedance: 50 ohms Electrical length: 1/2 λ V.S.W.R.: < 1,5:1 Polarization: Vertical Gain: 3 dB Max power input: 50 W DC ground: Yes Whip material: Fiberglass Coaxial cable: 5 m (16′) RG 58 CU MIL Mounting: Lift and lay mount Length: 1,5 (5′) m Weight: 0,55 kilo

Read more less

3.3' Stainless VHF Whip Antenna 3dB with 5M RG-58 Coax KS23AScout has designed the KS-23A antenna specifically for small boats and RIBs, which require a light, flexible, resistant, and high-performance antenna. The KS-23A brings all these features together in only 90 cm in length.The electropolished stainless steel whip guarantees high flexibility and resistance; moreover, it can be easily removed by hand whenever needed. The design of the antenna is cool and smooth as needed for small boats and RIBs. Standard thread 1” x 14.Features: Electropolished stainless steel whip – removable Extra flexible 5 m coaxial cable RG-58 CU MIL Specifications: Frequency: 156-162 MHz Impedance: 50 ohms Electrical length: 1/2 λ V.S.W.R.: < 1,5:1 Polarization: Vertical Gain: 3 dB Max power input: 50 W DC ground: Yes Whip material: Stainless steel Coaxial cable: 5 m RG-58 CU MIL Mounting: 1″ x 14 thread Length: 0,9 m (3′) Weight: 0,23 kilo

Read more less

8' Black VHF Antenna 6dB Stainless Steel Ferrule with 5M RG-58 Coax Includes PL-259 KS-42Scout celebrates the 30th anniversary with the collection of antennas Black Edition. These design antennas fit perfectly with black boats, grey boats, and with metal/aluminum finishings.The KS-42 Black Edition is built with a heavy-duty 1,5 mm thick fiberglass whip that gets fully foam injected with the special Scout 100% waterproof technique. Standard thread 1” x 14, chrome brass ferrule. The antenna is supplied with 5m RG-58 MIL cable and 1 PL-259 connector to complete the installation on board. Suggested for medium and large-sized boats.Features: Black Edition Foam injected – 100% WATERPROOF – IP69 5 m coaxial cable RG-58 CU MIL Specifications: Frequency: 156-162 MHz Impedance: 50 ohms Electrical length: 1/2 λ V.S.W.R.: < 1,5:1 Polarization: Vertical Gain: 6 dB Max power input: 50 W DC ground: Yes Whip material: Fiberglass Coaxial cable: 5 m (16′) RG-58 CU MIL Mounting: 1″ x 14 thread Length: 2,4 m (8′) Weight: 0,86 kilo

Read more less

528-VW 4' VHF Antenna with 15' Cable - WhiteVoted the best 4' VHF antenna by PowerBoat Reports, Digital Antennas 4' VHF antennas are ideal for use on T-tops, speedboats and sailboats. With 4.5dB gain and award-winning quality construction, these powerful and compact antennas deliver high performance that will last for years.Customers and installers love the 500 GOLD Series easy installation connector system. The gold factory-attached mini-UHF female connector with PL-259 (UHF) adapter makes connecting to the radio easy, eliminating the need to solder connectors.All of Digital's antennas are made in the USA, assembled, tested and tuned by hand for maximum performance, quality and durability.Features: Powerful brass radiators Soldered connections Power directing ferrite choke bead High gloss urethane finish 316 stainless steel ferrule 4.5dB gain 500 GOLD Series: Mount: Standard 1"14 threaded base Connector: Gold factory-attached mini-UHF female with mini-UHF male to UHF male (PL259) adapter Cable: Includes 15' of Digital's low-loss, tinned braid, foil shielded, UV stable RG-8X marine cable This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 3"H x 3"W x 50"L WT: 3.1 lbs UPC: 839494000568 Quick Guide (pdf)

Read more less

Style 399-1M VHF 6dBCollinear Phased 5/8-wave with two coaxial chokes to suppress cable radiationThe Style 399-1M is the same as the 399-1, but it has a special sleeve for mast mounting. A professional quality antenna in a compact package. This extra-duty antenna combines strength and performance for use where you really need the efficiency of a large antenna, but don't have room for one. Brass and copper elements Chrome-plated brass ferrule with standard 1"-14 thread Aluminum sleeve for mast mounting Suggested mount: 1-1/4" U-bolts are supplied. The 399-1M can be strapped to a larger mast using steel banding (not supplied) Two sections: Base 75"; Tip 39" UPS shippable Technical Specifications: Frequency: VHF Marine band Bandwidth: (within 2.0:1 SWR): 5MHz SWR: 1.5:1 at 156.8 MHz Impedance: (ohms): 50 Gain: 6 dB Max Input (Watts): 100 DC Ground: YES Termination: SO - 239 Height (feet): 9.5 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 114" Box Dimensions: 5"H x 5"W x 88"L WT: 5.2 lbs UPC: 719441100032 Quick Guide (pdf)

Read more less

MRANT12 AM/FM Rubber Antenna - WhiteAdd or replace your AM/FM antenna with an unbreakable 12" rubber antenna from Boss Audio.Features: AM/FM Antenna Rubber-ducky type that cannot be broken Bulkhead style hardware with screw on nut Includes 56" cable 1/2" Cutout dimension  *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Construction: Vinyl Rubber Color: White Type: Antennas Length (Inches): 12" Antenna Band: AM/FM Box Dimensions: 1"H x 3"W x 20"L WT: 0.4 lbs UPC: 791489117609

Read more less

5101 8’ Classic VHF Antenna with 15' RG-58 Cable - BlackA standard of excellence in an economical antenna! Shakespeare brings you the best of the high-end features in an 8' antenna with a brass element and a smooth, high gloss, polyurethane finish that won't turn yellow in the sun. This antenna delivers not only performance but superb value.Features: Brass and copper elements Chrome-plated brass ferrule with standard 1"-14 thread Includes 15' RG-58 cable and a PL-259 connector Suggested mount: Shakespeare Style 4187 Ratchet Mount, or use a Shakespeare Style 410-R Mounting Kit plus a Style 4008 Extension Mast to form a 16' antenna system One section Shakespeare Limited Warranty: 2 years Specifications: Frequency: VHF Marine Band Bandwidth: (within 2.0 1 SWR): 5 MHz SWR: 1.5:1 at 156.8 MHz Impedance (Ohms): 50 Gain: 6 dB Max. Input (Watts): 50 DC Ground: YES - however, the antenna will read "open circuit" when tested with ohmeter. Termination: 15' RG-58 cable Height (feet): 8' Polarization: Vertical Radiation pattern: Omni - directional Specifications: Antenna Band: VHF Color: Black Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 96" Box Dimensions: 2"H x 2"W x 95"L WT: 3.9 lbs UPC: 719441101107

Read more less

AM/FM 8' 5235-XT GalaxyThis antenna reaches out to pick up those AM/FM signals from afar. Its 8ft length offers the extra reach, while matching Shakespeare's other Galaxy 8ft antennas.Features: 8ft AM/FM Entertainment Band Copper elements for maximum range Stainless steel ferrule with standard 1in-14 thread Includes 20ft RG-62 cable with Motorola type plug installed One section Specifications: Antenna Length: 8ft. Suggested mount: Shakespeare Style 4187 or Style 5187 Ratchet Mount (each sold separately) Frequency: AM, FM, and FM-stereo Twin to: Galaxy 8ft antennas Band: AM-FM Ferrule: Stainless steel Coax Supplied: 20 ft of RG-62 Connector Supplied: Motorola type, installed Color/finish: Galaxy White Polarity: Vertical Impedance: 93 Ohms Includes: FME Cables Specifications: Length (Inches): 96" Ferrule Type: Stainless Steel Construction: Fiberglass Color: White Antenna Band: AM/FM Box Dimensions: 2"H x 2"W x 95"L WT: 4.1 lbs UPC: 719441400156 Quick Guide (pdf)

Read more less

5401-XT Galaxy 4' Antenna - 3dB GainThis antenna is the same as the Style 5400-XT, but in an exclusive black Galaxy finish. It's an outstanding, 4' antenna of heavy-duty construction for general purpose communications. Its at home on T-tops, hard-tops and other positions aloft, where its small size can deliver maximum range.Features: Center-fed 1/2 wave coaxial sleeve Brass and copper elements for maximum range Stainless steel ferrule with standard 1"-14 thread Includes 20' RG-8/X cable and a PL-259 connector Suggested mount: Shakespeare Style 4187 Ratchet Mount One section Shakespeare Limited Warranty: 5 years Includes FME Cables Technical Specifications: Frequency: VHF Marine Band Bandwidth: 5 MHz within 2.0:1 VSWR SWR: Nominally 1.5:1 at 156.8 MHz Gain: 3 dB Max Input (Watts): 50 watts Height (feet): 4 Specifications: Antenna Band: VHF Color: Black Construction: Fiberglass Ferrule Type: Stainless Steel Length (Inches): 48" Box Dimensions: 3"H x 3"W x 55"L WT: 3.1 lbs UPC: 719441100612 Quick Guide (pdf)

Read more less

Style 396-1 VHF 3dBCenter-fed 1/2-wave coaxial sleeveOutstanding, basic 3dB antenna designed to reduce signal fading in rough seas. This is probably the most widely used antenna on Coast Guard vessels. Brass and copper elements Chrome-plated brass ferrule with standard 1-14 thread Includes 15' RG-58 cable and a PL-259 connector Suggested mount: Style 4187 Ratchet Mount One section Technical Specifications: Frequency: VHF Marine band Bandwidth: (within 2.0:1 SWR): 5 MHz SWR: 1.5:1 at 156.8 MHz Impedance (Ohms): 50 Gain: 3 dB Max Input (Watts): 50 DC Ground: NO Termination: 15' RG-58 cable Height (feet): 5 Polarization: Vertical Radiation pattern: Omni-directional Specifications: Antenna Band: VHF Color: White Construction: Fiberglass Ferrule Type: Chrome Plated Length (Inches): 60" Box Dimensions: 3"H x 3"W x 63"L WT: 2.9 lbs UPC: 719441100018 Quick Guide (pdf)

Read more less

8' Wide Band Antenna with 20' CableUtilizing technology designed for military and commercial applications, Digital Antenna delivers our new, highly advanced 8' Wide Band VHF Antennas to the marine industry. These antennas provide tactical maritime users with a high-performance solution for broadband VHF communications.Featuring a tremendous bandwidth of 134 to 176 MHz, a nominal 6dB gain, and the ability to withstand continuous RF power up to 150 watts, the new antennas facilitate high-quality communications across a normally hard-to-cover band. An exclusive patent-pending electrical design with an internal ground plane allows the antenna to maintain a low radiation pattern, resulting in exceptional communication capability over a wide bandwidth.Designed to meet the military’s rigorous MIL-STD-810 environmental engineering testing, as well as typical marine standards for high seas applications, the 992-MW and 992-MB antennas, are built to endure environmentally harsh conditions. They are designed for use with a multitude of services including auxiliary civil services, 2-meter amateur radio band, VHF business band, multi-use radio service (MURS), 2-way land mobile, VHF marine radio, narrowband FM, VHF SATCOM, Automatic Identification System (AIS) and NOAA weather stations.Digital Antenna’s quality components include a rugged hard-coated anodized finish over an aircraft-grade aluminum ferrule, soldered brass radiating elements, power directing ferrite choke bead, and high-gloss UV stable coating. Manufactured in the USA by skilled craftsmen, our antennas are hand tested and tuned to assure the highest possible performance, quality, and durability. Lifetime limited warranty.Features: Broadband 134-176 MHz Withstands continuous RF power up to 150 watts Aircraft-grade aluminum ferrule Completely sealed High performance 6dB gain Sleek mono-color design Lifetime limited warranty Mount: Standard 1”–14 threaded base Connector: Gold factory-attached mini-UHF female with mini-UHF male to UHF male (PL259) adapter Cable: Includes 20’ exclusive low-loss, tinned braid, foil shielded, UV stable DA195 Ultra-Flex marine cable Specifications: Length (Inches): 94" Box Dimensions: 3"H x 3"W x 95"L WT: 2.5 lbs UPC: 839494004726 Brochure (pdf)

Read more less
