Electrical - Battery Management

7700 Includes ML-Series Remote Control Contura Switch 2145 Manual control switch provides an added level of safety allowing control with or without power, and offering "Locked Off" capability for servicing 500 Ampere continuous rating for engine, inverter, house loads, and emergency battery combine Magnetic latching draws no current in "ON" or "OFF" state, only draws current when changing state of switch Silver alloy contacts provides high reliability for switching live loads 3/8" -16 tin-plated copper studs for maximum conductivity and corrosion resistance 7/8" (22mm) stud length accepts multiple cable terminals Label recesses for circuit identification WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

7700100 ML Solenoid 12V 500A with Manual Control & Deutsch Connector500 Amp magnetic latching switch provides high amperage switching under load, manually or from remote locations.Features: Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing LED output to remotely indicate switch state - requires optional LED 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance 7/8" (22 mm) stud length accepts multiple cable terminals Label recesses for circuit identification Silver alloy contacts provide high reliability for switching live loads Specifications: Control Circuit Connection: Deutsch DTM Nominal Voltage: 12VDC Coil Function: Bi-Stable Mounting: #10 Amperage Operating Current Continous: 0mA Terminal Stud Torque: 140 in-lb (15.82 Nm) Continuous Rating: 500A Intermittent Rating: 700A (5 min) Cranking Rating 30 Seconds: 1450A DC Cable Size to Meet Ratings: 2x (4/0) Live Current Switching: 300A@12VDC Master Control Switch Capability: No Mechanical Endurance: 100,000 Cycles Terminal Ring Diameter Clearance: 1.18" (29.97 mm) Terminal Stud Length: 0.875" (22.23 mm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 1.75lb (0.79 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

SmartSolar MPPT 150/45 Solar Charge ControllerA solar charger gathers energy from your solar panels, and stores it in your batteries.  Using the latest, fastest technology, SmartSolar maximizes this energy harvest, driving it intelligently to achieve full charge in the shortest possible time.  SmartSolar maintains battery health, extending its life.The SmartSolar charge controller will even recharge a severely depleted battery.  It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulfated or otherwise damaged.Features: MPPT - Ultra Fast Maximum Power Point Tracking - By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage.  The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing. Remote Monitoring and Control - Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in Bluetooth by pairing it with your smartphone or another device via VictronConnect. Advanced Maximum Power Point Detection in case of partial shading conditions.  Outstanding conversion efficiency.  Natural convection cooling.  Automatic battery voltage recognition.  Flexible charge algorithm.  Over-temperature protection and power derating when the temperature is high.  Technical Specifications: Dimensions (L x W x H) - 7.3" x  5.2" x  2.8" (186 x 132 x 71mm)  Battery Voltage - 12/24/36/48V  Rated Charge Current - 45A Max. PV Short Circuit Current - 50A Maximum Efficiency - 98% Data Communication Port - VE. Direct In the Box: 150/45 Solar Charge Controller Instruction Manual  *Sold as an IndividualPlease contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Orion-TR Smart 12/12-18A (220W) Isolated DC-DC Charger or Power SupplyThe Orion-Tr Smart isolated DC-DC charger serves as a DC-DC battery charger or a power supply (also designed for use as a constant voltage source), offering a wide input and output voltage range. This is especially significant in the case of vehicles with a Euro 5 or Euro 6 smart alternator, which often supplies too low charging voltage even when the engine is running or when extended cable lengths, as is often the case in boats and RVs, lead to voltage drops. In such scenarios, precise and controlled charging is imperative to fully charge the service battery while protecting the starter/input battery from discharge.Bluetooth Smart Enabled Any Bluetooth-enabled smartphone, tablet, or other device can be used to monitor, change settings, and update the charger when new software features become available Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the device list page without the need to connect to the product Fully programmable Battery charge algorithm (configurable) or fixed output.  Smart Alternator Compatibility: engine running detection mechanism Adaptive 3-Stage Charge Algorithm: Bulk – Absorption – Float For lead-acid batteries, it is important that during shallow discharges the absorption time is kept short to prevent overcharging of the battery. After a deep discharge, the absorption time is automatically increased to make sure that the battery is completely recharged For lithium batteries, the absorption time is fixed; the default is 2 hours Alternatively, a fixed output voltage can be chosen Suitable for Use in Vehicles with a Smart Alternator (Euro 5 and Euro 6 Engines)The built-in engine shutdown detection will stop the converter when the engine is not running. This prevents unwanted discharge of the starter battery (see manual for details).Remote On/OffA remote on/off switch or relay contact can be connected to a two-pole connector. Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two-pole connector can be switched to battery minus (or the chassis of a vehicle, for example).All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.High Temperature ProtectedThe output current will reduce at high ambient temperatures.IP43 ProtectionWhen installed with the screw terminals oriented downward.Screw TerminalsNo special tools are needed for installation. Input fuse (not replaceable) *Input fuse (not replaceable) Specifications: Input Voltage Range: 8-17 V Under Voltage Shut Down: 7 V Under Voltage Restart: 7.5 V Nominal Output Voltage: 12.2 V Output Voltage Adjust Range: 10-15 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 18 A Maximum Output Current (10 S) at Nominal Output Voltage minus 20%: 25 A Short Circuit Output Current: 40 A Cont. Output Power at 25 Degrees C: 280 W Cont. Output Power at 40 Degrees C: 220 W Efficiency: 87 % No Load Input Current (2): < 80 mA  Standby Current: Less than 1A Can Be Used as Power Supply: Yes, output voltage can be set with Bluetooth  Galvanic Isolation: 200 VDC between input, output, and case  Operating Temperature Range -20 to +55 °C (derate 3 % per °C above 40 °C)  Humidity: Max. 95 % non-condensing  DC Connection: Screw terminals  Maximum Cable Cross-Section: 16 mm²  AWG6  Weight: 1,8 kg (3 lb)  Dimensions (H x W x D):130 x 186 x 70 mm  (5.1 x 7.3 x 2.8 inch)  Protection Category IP43 (electronic components), IP22 (connection area)  Safety Standards: EN 60950 Emission/Immunity Standards: EN 61000-6-3, EN 55014-1 / EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Portable: No Charging Banks: 1 Charger Output Voltage: 12v Charger Output - Amps: 18a Charger Input - Voltage: 12v Box Dimensions: 4"H x 6"W x 9"L WT: 2.95 lbs UPC: 8719076046066 Quick Guide (pdf)Brochure (pdf)

Read more less

Charge Mate Pro 90Current limited electronic charge relay with high efficiency and reverse current protectionA secondary battery onboard requires a dedicated charging solution. The Charge Mate Pro makes it possible to distribute the charger or alternator current effectively between two battery banks such as a starter and a service battery. The Charge Mate Pro connects both batteries during charging and keeps them isolated when discharging. This significantly reduces the risk of a flat starter battery for example.The Charge Mate Pro offers an additional advantage over mechanical charge relays, by limiting the charge current to the second battery. The primary battery, like a starter battery, is therefore charged with priority. The return current is automatically blocked even when the secondary battery has a higher voltage. An emergency start function is possible by connecting an optional bypass switch to the ChargeMaster Pro.A marine application example is the connection of a bow thruster battery to a service battery. The Charge Mate Pro ensures that the service battery is always charged with priority. The blocking of the return current from the bow thruster battery guarantees that the bow battery remains charged while the current limiting also prevents power dips of the onboard electrical network.The Charge Mate Pro series consists of a 40 Amp and a 90 Amp version, both suitable for charger or alternator applications. The Charge Mate Pro 90 ensures a higher charge current for example when charging Lithium-Ion batteries. It is also perfectly suitable for large automotive alternators up to 180 A and can be used in parallel operation with a 225 Amp alternator to fulfill even higher continuous power demands of your equipment on board.Charge Mate Pro: for controlled charging from a single source.Applications:Leisure and professional marine and mobile applications. An effective solution for high power demand onboard and/or the need for prioritized or current limited charging.Features: Charges two battery banks from a single source. Electronic charge coupling with very low voltage drop. Makes effective dual charging possible. Suitable for all battery types, including Lithium-Ion. Charge current secondary battery limited to 40 or 90 A. High system reliability by prioritizing charging of the main battery. Unidirectional which blocks return current under all circumstances. Prevents power dips in the onboard electrical network. Suitable for all kinds of chargers and alternators. Monitoring with LED status indication. IP65 electronics in a corrosion-resistant casing with aluminum heat sinks. Fast and easy installation. General Specifications: Monitoring: LED (warnings and status indication) Output current: limited to 90 A; > 25 °C derating power Number of battery outlets: 2 Input voltage range: 9-32 V Parallel configuration: Yes Battery voltage: Automatic 12/24 V detection Remote switch functions: On, off, auto, start to assist Dimensions, hxwxd: 157 x 140 x 80 mm/6.2 x 5.5 x 3.1 inch Weight: 0.88 kg/1.9 lb Compliance: CE Technical Specifications: Connection possibilities: 3 x faston connectors (switch, ground, and status) • switch: for an optional single-pole ON-OFF-ON switch for remote operation • status: for an optional LED indicator Power consumption: Switch open: < 1 mA at 12/24 V DC Battery types: All types (Lithium-Ion protection via Multipurpose Contact Output, product code 77030500) Switch on voltage: 13.5 V (12 V) / 27 V (24 V) Switch on delay: 5 sec Switch off voltage: 12.75 V (12 V) / 25.5 V (24 V) Switch off delay: 2.5 sec Relay: Electronically (MOSFETs with a low voltage drop of max 0.2 V) Temperature range (ambient temp.): -40 °C to 60 °C/-40 °F to 140 °F Protection degree: IP65 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

7611 DC BatteryLink™ Automatic Charging Relay - 120 Amp w/Auxiliary Battery ChargingFeatures: 120 Amp continuous rating 12/24V DC auto ranging voltage input Senses charging on two battery banks Side and bottom knockouts for cable connections Clip-on cover insulates terminal connections 7/8" (22 mm) stud length to accept multiple cable terminals Integrated LED indicates ACR status 1/4" x .032" male quick connect terminals for ground and optional features Specifications: Intermittent Rating: 5 min.: 210 Amps Continuous Rating: 120 Amps Nominal Voltage: 12/24 Volts DC WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Continuous Amperage: 120a Box Dimensions: 4"H x 7"W x 9"L WT: 1.25 lbs UPC: 632085076115 Owner's Manual (pdf)

Read more less

Mini Battery Switch Key with Removable Knob - 32V & 300AThese Mini Battery Switches feature a removable knob for extra security. To remove, simply twist the cap to the OUT position and pull. Mini footprint makes it ideal for close quarters. The 422730-1 is rated at 300A continuous and 1000A cranking amps. Installation is as easy as drilling a 2-1/16" hole for the 422730-1, inserting the socket body, tightening the locking nut, and connecting the wires. Features:  3 Switch positions: On, off, and out Constructed of machined brass and injection molded nylon Specifications: Switch Face Width: (inch) 2-1/16" Volts: 32 Amps: 300 Stud Diameter: (inch) 5/16" WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Continuous Amperage: 300 Positions: 3 Box Dimensions: 3"H x 4"W x 7"L WT: 0.4 lbs UPC: 035514432887

Read more less

ProTechOne - 4 AMP - AC InletProMariner's ProTechOne Fully Automatic Onboard Battery Charger and Maintainer utilizes the latest in microprocessor and software control charging and energy-saving auto maintain technology. Safe for short and long-term storage with multi-stage charging, conditioning, and auto maintaining proved to maximize battery performance and life. Designed for weatherproof applications and years of trouble-free use, ProTechOne boasts a gasket molded case design for outdoor use with commercial-grade jacketed AC and DC cables for maximum cable protection and durability. ProTechOne incorporates a push-to-test battery status monitor showing remaining battery power, in addition to fault detection of battery connections, reverse polarity, or battery too low to charge. In the event of a fault, both the Charging and Auto maintain LEDs will remain off. An angled easy-to-view LED dashboard provides the quick status of AC Power, Charge Mode, and Auto Maintain (Energy Saver) mode, which controls the charging output as needed to maintain a fully charged battery, lowering AC consumption and reducing operating cost.Features: All-digital charging technology with fully-automatic multi-stage digital charging Dedicated battery charging, sensing, and control Push-to-test battery monitor LED fuel gauge status Waterproof DC safety fuse for maximum DC wire protection Ignition protected and FCC Class A for quiet operation and non-radio interference

Read more less

Battery Box Strap & Brackets - 38" Battery Box Strap & Brackets includes a woven polypropylene strap, injection molded nylon buckle, two brackets, and four #8 FH fasteners. WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

BI-100 Battery IntegratorCharging multiple battery banks without the use of diode isolators dictates that the batteries be connected or “integrated” only whenever a charge voltage is present so that they may be charged simultaneously, then disconnected or “isolated” when the charge voltage is no longer present to allow for selective discharge and avoid having the secondary or standby battery drain into the primary battery.Battery integrators perform this function automatically, acting as a “smart” switch to connect independent battery banks only when a charging voltage is present. Otherwise, they are isolated, and discharge between banks is prevented.The Battery Integrator causes no voltage drop in the charging system, while the multiple batteries are charged as a single bank whenever a charging source of approximately 13.2 VDC or 26.4 VDC or greater is present (depending on the model).When the alternator or charger is off or a large load causes the voltage to drop below the disconnect point, the unit breaks the common tie between the banks. This allows selective battery discharge and prevents the “dumping” of a higher-charged bank into a lower-charged bank. The unit may also be remotely activated to connect other batteries through the key starter or a manual switch to provide an added “boost” from the secondary battery whenever the starter is engaged and the unit senses there is sufficient voltage in that battery to provide an assist.Features: Enables charging of two separate banks without voltage drop yet maintains 100% isolation at all other times. For systems of three banks or more, an additional unit must be installed for each additional bank Heavy-duty silver-plated contactor, continuous duty rated to 100 Amps or 200 Amps depending on model Voltage sense circuits, epoxy-encapsulated, and heavy-duty continuous-rated solenoids are all designed for use in marine environments 12 volt, 100 amp model has an ignition protection rating Has ignition protection rating Easy three-wire hookup for two bank systems (BATT +, BATT +, GROUND) Terminal for optional wiring of a remote light indicating when battery banks are integrated Optional internal connections can be wired through the key starter or manual override switch, tying battery banks together for an extra boost during engine start Specifications: Terminals: Battery Connections: 5/16 in. copper alloy stud Approvals: CE Marked Dimensions (H x W x D): 100 Amp Models: 3 x 3.25 x 2.5 inches Weight: 1 lb. Operating Temperature: Control: -40 to +85 degrees C and Solenoid: -28 to +48 degrees C Voltage: 12 VDC Battery Integration Point: 13.2 VDC     Battery Disconnect Point: 12.8 VDC Max. Continuous Current: 100 Amps     Peak Maximum Current: 400 Amps

Read more less

BM100 Battery Monitoring SolutionThe BM100 is a complete system comprising SmartShunt and the veKonvert NMEA 2000 interface. It is part of Digital Yacht’s iSeaSense range of NMEA 2000 boat instruments. With this solution, your multi-function display becomes a sophisticated battery and energy management system.FeaturesDigital Yacht’s BM100 battery monitoring system allows highly accurate DC voltage, current, and capacity measurements, enabling reliable monitoring of your boat’s battery and electrical system.Core to the system is the SmartShunt. It measures battery voltage and current. Based on these measurements, it intelligently calculates the battery’s state of charge and the time to depletion for the remaining charge. It also keeps track of historical data, such as the deepest discharge and average discharge current, as well as the number of charge and discharge cycles. The smart shunt can also monitor the voltage of a 2nd battery, typically dedicated to engine starting.The product is a collaboration between Victron Energy and Digital Yacht. The system utilizes Victron’s proprietary VE.Direct data connectivity as a source for the NMEA 2000 data.The BM100 is part of a wider group of products now introduced by Digital Yacht that bring NMEA 2000 connectivity to Victron systems using the VE.Direct interface.Victron solar panel controllers (MPPTs) and battery monitors can now also interconnect to NMEA 2000 via the veKonvert interface.Monitoring the battery with the BM100 will give important feedback to the user so that remedial measures can be taken when necessary. Doing this will extend battery life. There’s also an optional battery temperature sensor available.The BM100 can also integrate with Digital Yacht’s other NMEA 2000 and wireless instruments, which offer hybrid NMEA 2000 and wireless display options.NMEA 2000 InterfaceThe system features an NMEA 2000 interface, so your navigation multi-function display or plotter can display all key parameters. Modern MFDs from leading manufacturers such as Garmin, Raymarine, Furuno, and Navico allow electrical battery data to be displayed via their NMEA 2000 interface. Alarms and alerts for low capacity and voltage can also be enabled.Bluetooth InterfaceThe BM100 also has a standalone wireless Bluetooth interface, so your mobile phone or iPad can connect and display current, voltage, capacity, additional historical data, state of charge information, and time to go based on remaining battery capacity.Specifications: BM100 solution comes as a complete package with SmartShunt and the veKonvert NMEA 2000 interface Bluetooth interface for setup and detailed analysis, including charge/discharge cycles, state of charge, remaining capacity, and historical data Use your phone/tablet and your NMEA 2000 devices for battery monitoring and management 500A SmartShunt included for the main battery system Monitor the voltage of a separate (eg starter) battery Universal NMEA 2000 gateway for Victron’s popular range of smart battery monitors/SmartShunt using the VE.Direct interface (see compatibility list in the FAQ tab) Enables electrical and battery monitoring and management on compatible multi-function displays (Raymarine, Garmin, Navico, Furuno, etc) Provides battery voltage, charge/discharge current, state of charge, and time to depletion based on a sophisticated algorithm Easy installation, plug ‘n play connectivity, and self-powering from the NMEA 2000 bus Supports alerts generated by the SmartShunt Supports multiple SmartShunts for multi-battery systems Also compatible with other VE.Direct products such as solar MPPT controllers Vekonvert Is Compatible with the Following Victron Products:BMV -700, BMV -702, BMV -700H, BMV-712 Smart, BMV-710H Smart, BMV-712 Smart Rev2, SmartShunt 500A/50mV, SmartShunt 1000A/50mV, SmartShunt 2000A/50mV, and All MPPT Charge ControllersNOTE: veKonvert is not compatible with Victron Chargers and Inverters. It should also not be plugged into the VE.Direct interfaces of any Victron "Consumers" such as Multiplus, Quattro, Cerbo, etc.

Read more less

CYRIX-LI-CHARGE 12/24-120A Intelligent Charge Relay Cyrix LI ChargeThe Cyrix Battery Combiner is a microprocessor-controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged) and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is that there is virtually no voltage loss so that the output voltage of alternators or battery chargers does not need to be increased.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less
