Electrical - DC to DC Converters

Orion-TR 12/48-8A (380W) Isolated DC-DC ConverterRemote On/Off TerminalThe remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or for example the engine run/stop switch. All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.  High Temperature Protected The output current will reduce at high ambient temperatures.  IP43 Protection When installed with the screw terminals oriented downward.  Screw Terminals No special tools are needed for installation.  Input Fuse (not replaceable) On 12 V and 24 V input models only.  Adjustable Output Voltage Not intended for battery charging (consider using an Orion-Tr Smart for battery charging).Specifications: Input Voltage Range: 10-17 V Under Voltage Shut Down: 7 V Under Voltage Restart: 7.5 V Nominal Output Voltage: 48.2 V Output Voltage Adjust Range: 40-60 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 8 A Maximum Output Current (10 S) at Nominal Output Voltage minus 20%: 15 A Short Circuit Output Current: 25 A Cont. Output Power at 25 Degrees C: 430 W Cont. Output Power at 40 Degrees C: 380 W Efficiency: 89 % No Load Input Current (2): < 220 mA  Current Consumption: < 200uA when disabled via its remote port Galvanic Isolation: 200 VDC between input, output, and case Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C) Humidity: Max. 95 % non-condensing DC Connection: Screw terminals Maximum Cable Cross-Section: 16 mm² AWG6 Weight: 1.8 kg (4 lb) Dimensions (H x W x D): 130 x 186 x 80 mm (5.1 x 7.3 x 3.2 inch) Safety Standards: EN 60950 Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 12v Charger Output - Amps: 8a Charger Output Voltage: 48v Box Dimensions: 4"H x 6"W x 9"L WT: 3.5 lbs UPC: 8719076063650 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

30A Non-Isolated Step-Down 24VDC-12VDC ConverterThis high efficiency switch-mode step-down DC-DC converter converts an input voltage of 24 VDC nominal (range 20 VDC to 32 VDC) to a highly regulated output voltage of 12 VDC nominal (13.8 VDC) at 30 Amps. The SDC-30 DC-DC converter is non-isolated (no galvanic isolation between input and output) and meant for use in negative ground systems. Features include overload, over-heating, reverse polarity and over-voltage protection.Features: Advanced switchmode design Mount in almost any location Compact and light weight Reverse polarity protection High efficiency Cycle by cycle current limiting circuit Overvoltage protection Short circuit protection Specifications: Input: 20-32 VDC Output: 13.8 VDC Amps: 30 Amps Weight: 1.2 (lbs) Weight: 0.54 (kg) Dimensions: 6 x 3.5 x 1.9 (in) Dimensions: 15.2 x 8.9 x 4.8 (cm) Warranty: 2 Year Limited Applications: Earth moving equipment Heavy trucks Buses Marine vehicles CB radios 12 Volt lighting systems AM/FM sound systems WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

Orion-TR Smart 12/12-30A (360W) Isolated DC-DC Charger or Power SupplyThe Orion-Tr Smart isolated DC-DC charger serves as a DC-DC battery charger or a power supply (also designed for use as a constant voltage source), offering a wide input and output voltage range. This is especially significant in the case of vehicles with a Euro 5 or Euro 6 smart alternator, which often supplies too low charging voltage even when the engine is running or when extended cable lengths, as is often the case in boats and RVs, lead to voltage drops. In such scenarios, precise and controlled charging is imperative to fully charge the service battery while protecting the starter/input battery from discharge.Bluetooth Smart Enabled Any Bluetooth-enabled smartphone, tablet, or other device can be used to monitor, change settings, and update the charger when new software features become available Instant Readout: The VictronConnect App can display key data, including warnings and alarms, on the device list page without the need to connect to the product Fully programmable Battery charge algorithm (configurable) or fixed output.  Smart Alternator Compatibility: engine running detection mechanism Adaptive 3-Stage Charge Algorithm: Bulk – Absorption – Float For lead-acid batteries, it is important that during shallow discharges the absorption time is kept short to prevent overcharging of the battery. After a deep discharge, the absorption time is automatically increased to make sure that the battery is completely recharged For lithium batteries, the absorption time is fixed; the default is 2 hours Alternatively, a fixed output voltage can be chosen Suitable for Use in Vehicles with a Smart Alternator (Euro 5 and Euro 6 Engines)The built-in engine shutdown detection will stop the converter when the engine is not running. This prevents unwanted discharge of the starter battery (see manual for details).Remote On/OffA remote on/off switch or relay contact can be connected to a two-pole connector. Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two-pole connector can be switched to battery minus (or the chassis of a vehicle, for example).All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.High Temperature ProtectedThe output current will reduce at high ambient temperatures.IP43 ProtectionWhen installed with the screw terminals oriented downward.Screw TerminalsNo special tools are needed for installation. Input fuse (not replaceable) *Input fuse (not replaceable) Specifications: Input Voltage Range: 10-17 V Under Voltage Shut Down: 7 V Under Voltage Restart: 7.5 V Nominal Output Voltage: 12.2 V Output Voltage Adjust Range: 10-15 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 30 A Maximum Output Current (10 S) at Nominal Output Voltage minus 20%: 40 A Short Circuit Output Current: 60 A Cont. Output Power at 25 Degrees C: 430 W Cont. Output Power at 40 Degrees C: 360 W Efficiency: 87 % No Load Input Current (2): < 80 mA  Standby Current: Less than 1A Can Be Used as Power Supply: Yes, output voltage can be set with Bluetooth  Galvanic Isolation: 200 VDC between input, output, and case  Operating Temperature Range -20 to +55 °C (derate 3 % per °C above 40 °C)  Humidity: Max. 95 % non-condensing  DC Connection: Screw terminals  Maximum Cable Cross-Section: 16 mm²  AWG6  Weight: 1,8 kg (3 lb)  Dimensions (H x W x D):130 x 186 x 70 mm  (5.1 x 7.3 x 2.8 inch)  Protection Category IP43 (electronic components), IP22 (connection area)  Safety Standards: EN 60950 Emission/Immunity Standards: EN 61000-6-3, EN 55014-1 / EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Output - Amps: 30a Charger Input - Voltage: 12v Portable: No Charging Banks: 1 Charger Output Voltage: 12v Box Dimensions: 4"H x 6"W x 9"L WT: 4.45 lbs UPC: 8719076047698 Quick Guide (pdf)

Read more less

12A Non-Isolated Step-Down 24VDC-12VDC Converter - Heavy Duty ApplicationsThis high efficiency switch-mode step-down DC-DC converter converts an input voltage of 24 VDC nominal (range 20 VDC to 35 VDC) to a highly regulated output voltage of 12 VDC nominal (13.8 VDC) at 12 Amps. The SDC-15 DC-DC converter is non-isolated (no galvanic isolation between input and output) and meant for use in negative ground systems. Features include overvoltage/short-circuit protection, temperature compensated current limit, output-side overvoltage protection, input-side overvoltage/ transient protection and input-side reverse polarity protection. The SDC-15 DC-DC converter is designed for heavy duty applications.Features: Advanced switchmode design Mount in almost any location Compact and light weight Reverse polarity protection High efficiency Cycle by cycle current limiting circuit Overvoltage protection Short circuit protection Specifications: Input: 20-35 VDC Output: 13.8 VDC Amps: 12 Amps Weight: 2 (lbs) Weight: 0.9 (kg) Dimensions: 7.75 x 5 x 2.5 (in) Dimensions: 19.7 x 12.7 x 6.4 (cm) Warranty: 2 Year Limited Applications: Earth moving equipment Heavy trucks Buses Marine vehicles CB radios 12 Volt lighting systems AM/FM sound systems WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

Magic 12/12-20 DC ConverterFor The Toughest TasksThe Mac and Magic DC-DC converters are designed for the toughest conditions for professional, semi-professional and recreational purposes. Even under the most extreme conditions, these DC-DC converters operate faultlessly, giving you round-the-clock output when necessary. The sustainability and technologies that underpin the Mastervolt concept have long been proven in practice. With an MTBF of 280,000 hours at full capacity and 24/7 use, the DC-DC converters are ideal for the toughest tasks and any situation that requires a reliable power supply. Making The Best Even BetterThe reliability and long lifespan of Mastervolt’s DC-DC converters have been established beyond doubt over the past 20 years. While the Mastervolt products have evolved with the latest technological developments, the dimensions and connections have remained the same. As a result it is exceptionally easy to replace one unit with another with only negligible downtime. Mastervolt Green by HeartAs part of our constant search for eco-friendly and long-lasting solutions, Mastervolt has developed the Green by Heart program. Its impact on the Mac & Magic DC-DC converters include: An exceptionally effective use of the consumed input current (cos phi) > 0.98! Faster charging of batteries, even with when the input current is limited Use of top quality components with a long lifespan Savings in weight and space Fewer installation materials MasterBus CompatibleFor the DC-DC converters you can use the MasterBus Serial Interface. All you need is a single cable with one connection. Your benefits: Fast and easy installation, plus centralized monitoring, configuration and operation of your system with a MasterView panel.Programmable via Desktop or Laptop/PCRemote control the Mac or Magic via your laptop or PC or configure your personal preferences. The device has a communication port and easy installation with a PC-Link and MasterAdjust software.Energy-Saving Dimmer FunctionMany standard light dimmers convert part of the energy to heat and also lose unnecessary energy. The Mastervolt Magic converters regulate the power supply efficiently and without excessive heat build-up, up to 580 watts for optimal safety (multiple Magic converters can be used for multiple lamps).Parallel OperationIf you have many/heavy power-consuming devices onboard, the parallel use of several units allows capacities of 40, 60 or more Amps. Advanced high-frequency technology with modern microprocessors ensures minimum power loss when switching from 24 to 12 V and vice versa. Powerful Selling Points: Reliable and very stable DC supply For 12 and 24 V battery systems Parallel switching of multiple units for capacities of 40, 60 or more Amps Battery charger and dimmer function Adjustable output voltage Voltage stabilization for a longer lifespan of halogen lights, etc Corrosion-proof aluminium casing Shock-proof Temperature-powered fan for cooling Generates limited heat, so installable almost anywhere Fully MasterBus compatible with a MasterBus Serial Interface Specifications: Nominal output voltage: 13.6V Output voltage (adjustable with MasterAdjust): 10-15V Output voltage dimmer (adjustable with MasterAdjust): 4-13V Output voltage stabilization: 2% at extremes of temperatures, load and input Output voltage ripple (peak peak): max. 1% Max. output power: 300W Nominal output power: 300W Max. output current: 20A Output charge current (3-step mode): 16 A Nominal input voltage: 12V Input voltage range: 11-16V Input voltage range (3-step charge mode): 12-16V Lower input set point (adjustable with MasterAdjust): 10V Delay lower input set point (adjustable with MasterAdjust): 30 sec. Galvanic isolation: yes Voltage limited: yes Efficiency: > 90% at nom. input voltage, full load; peak 92 % Dimmer function: yes, by external momentary switch via fast-on connection, to be activated by DIP switch setting Alarm contact: yes (fast-on connector) Dimensions, HxWxD: 227 x 154 x 81mm / 8.9" x 6.1" x 3.2" Weight: 1.8kg / 4.0lb Approvals: CE 3-Step charge option: yes (DIP switch settings) DC consumption: < 115 mA Connections: screw terminals (max. wire size 16 mm² / AWG5) Temperature range (ambient temp.): -25 °C to 80 °C, derating > 40 °C -13 °F to 176 °F Sound level: < 48 dBA at 1M Protection degree: IP21 Protections: against over load & over temperature Cooling: maintenance free vario fans MasterBus compatible: yes, in combination with a MasterBus Serial Interface WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Orion-TR 12/12-9A (110W) Isolated DC-DC ConverterRemote On/Off TerminalThe remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or for example the engine run/stop switch. All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.  High Temperature Protected The output current will reduce at high ambient temperatures.  IP43 Protection When installed with the screw terminals oriented downward.  Screw Terminals No special tools are needed for installation.  Input Fuse (not replaceable) On 12 V and 24 V input models only.  Adjustable Output Voltage Not intended for battery charging (consider using an Orion-Tr Smart for battery charging).Specifications: Input Voltage Range: 8-17 V Under Voltage Shut Down: 7 V Under Voltage Restart: 7.5 V Nominal Output Voltage: 12.2 V Output Voltage Adjust Range: 10-15 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 9 A Maximum Output Current (10 S) at Nominal Output Voltage: 12.5 A Short Circuit Output Current: 32 A Cont. Output Power at 25 Degrees C: 110 W Cont. Output Power at 40 Degrees C: 85 W Efficiency: 87 % No Load Input Current (2): < 50 mA  Current Consumption: < 200uA when disabled via its remote port Galvanic Isolation: 200 VDC between input, output, and case Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C) Humidity: Max. 95 % non-condensing DC Connection: Screw terminals Maximum Cable Cross-Section: 6 mm² AWG10 Weight: .42 kg (1 lb) Dimensions (H x W x D): 100 x 113 x 47 mm (4.0 x 4.5 x 1.9 inch) Safety Standards: EN 60950 Immunity Standards: EN 61000-6-3, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 12v Charger Output - Amps: 9a Charger Output Voltage: 12v Box Dimensions: 3"H x 6"W x 9"L WT: 1.05 lbs UPC: 8719076016878 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

100W Fully Isolated DC-DC Converter - 8A - 30-60V Input - 12.5V OutputIDC-100 series is a complete line of high efficiency 100 Watt isolated DC-DC converters suitable for applications requiring galvanic isolation between the input and the output. IDC-100C-12 isolated DC-DC converter provides a highly regulated output DC voltage of 12.5 Volts for an input DC voltage range of 30-60 Volts and rated output current of 8 Amps (at 60 Volts input). Features of this isolated DC-DC converter include compact housing, fold-back current limiting and protection against short circuit, overheating, overvoltage and reverse polarity connection. The unit comes with 1/4” push-on flat blade “quick disconnect” connectors. IDC-100C-12 isolated DC-DC converter is EMI/EMC compliant and conforms to European standards EN50081-1 (for EMI) and EN50082-1 (for EMC).Features: Fully Isolated Short Circuit Protected Current Limited 2 Year Warranty CE Approved Specifications: Input: 30-60 VDC Output: 12.5 VDC Amps: 8 Amps Weight: 1.2 (lbs) Weight: 0.54 (kg) Dimensions: 6 x 3.5 x 1.9 (in) Dimensions: 15.2 x 8.9 x 4.8 (cm) Safety: CE Warranty: 2 Year Limited Applications: Earth moving equipment Heavy trucks Buses Marine vehicles CB radios 12 Volt lighting systems AM/FM sound systems WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

Step-Up DC-DC Converter - 7A - 9-18V Input - 24V OutputFeatures: Step up from 12VDC to 24VDC at 7 Amps DC Switch Mode design CE approved High Efficiency Over-current protection Over-voltage, Reverse Polarity protection 6.3 mm push-on flat pin connectors Specifications: Input: 9-18 VDC Output: 24 VDC Amps: 7 Amps Weight: 0.8 (lbs) Weight: 0.36 (kg) Dimensions: 5 x 3.5 x 2 (in) Dimensions: 12.7 x 8.9 x 5.1 (cm) Safety: CE Warranty: 2 Year Limited Applications: Industrial Commercial OEM Recreational Marine WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

Mac Plus 24/24-30 + CZoneBoost the Service BatteryToo often, service batteries don’t get the charge they need. This is a problem made worse by smart alternators and start/stop systems, which result in slow and insufficient charges. The Mac Plus DC-DC charger solves this problem, providing a quick, safe, and consistent charge to the service battery. And, by knowing when the engine is running and providing charge, users can be sure that the Mac Plus will never drain a starter battery.Proven Mastervolt QualityUsers get peace of mind knowing that they have the best on board. Using the proven Mastervolt 3-step+ charge algorithm, the Mac Plus delivers a quick and easy charge, even for completely flat batteries.A robust design holds up in even the harshest conditions, with battery temperature-optimized charging and a high-quality aluminum housing to ensure superior protection against dust and water ingress. The power-efficient design also allows the Mac Plus to operate silently and without a fan.Total Power FlexibilityWith a wide DC input range, the Mac Plus allows for all DC sources and can charge two batteries from a single alternator or charger. It supports a full range of chemistries and battery types, including lithium. It also functions seamlessly with modern alternators such as Euro 5 and 6, ensuring proper charging by providing constant power, even when the alternator is inactive.Parallel configuration of up to ten units will provide over 100 amperes. Advanced high-frequency technology with modern microprocessors ensures minimal power loss when switching from 12V to 24V and vice versa.Analog voltage sense ports are also available to compensate for voltage drops and maintain proper charging.Superior Monitoring & ControlCompatibility with CZone®, NMEA 2000®, and MasterBus delivers truly superior monitoring and control and ensures Mac Plus integrates easily into complete systems. Achieve the best performance possible via various controllers and high-quality MOSFETs. And configure the Mac Plus with ease via MasterAdjust, the CZone configuration tool, or even via the on-board DIP switches.Features: Fast and safe charging, even during short trips Fanless design for silent operation Suitable for flooded, Gel, AGM, and Li-Ion batteries (incl. LiFePO4) Even charges fully depleted batteries Engine run detection protects the starter battery Adjustable current limits to meet Euro 5/6 requirements Voltage stabilization protects sensitive equipment, lights, and loads Parallel operation to obtain charging capacities well over 100 Amps MasterBus, CZone, and NMEA 2000 are compatible for intelligent system monitoring and automation Temperature compensation and voltage sense for an optimal charging result E-Mark/R10 certification for mobile applications Power supply mode offers stable power for sensitive loads Heavy-duty connections for easy installation and quick setup via DIP switches Specifications: Battery Temperature Sensor: Yes, included Battery Voltage Sense: Yes  General Specifications: Status Indicator: Yes, 3-color LED Communication Protocol: MasterBus, CZone & NMEA 2000 Output Voltage: 20-30 V Nominal Output Voltage: 24 V Output Voltage Stabilization: 2 % at extremes of temperatures, load, and input Output Voltage Ripple (peak-peak): Max. 1 % Max. Output Power: 850 W Nominal Output Power: 810 W Max. Output Current: 30 A Output Charge Current (3-step mode): 30 A Nominal Input Voltage: 24 V Input Voltage Range: 19-30 V Max. Input Current: 30 A Galvanic Isolation: No Voltage Limited: Yes Efficiency: > 95 % (at nom. input voltage, full load); peak 97 Parallel Configuration: Yes Alarm Contact: Yes, through MasterBus MasterBus Powering: No Engine Run Signal Input: Yes (active high/active low) DIP Switches: Yes, for basic setup Dimensions, H x W x D: 255 x 165 x 66 mm (10.0 x 6.5 x 2.6 inch) Weight: 2 kg (4.4 lb) Compliance: CE, E-Mark, SAE J1171 & ISO 8846 Ignition Protected  Technical Specifications: No-load Consumption: < 2 mA Charge Characteristic: 3-traps+ Battery Types: Flooded, Gel, AGM, spiral, Lithium Ion, traction, user-defined 3-Step Charge Option: Yes (DIP switch settings) DC Consumption: < 5 mA Connections: 3 x M8 terminal for cable diameters of 10-50 mm², (positive input, positive output, joint negative connection) 8-pole screw connection for cable diameters of 0.75-1.5 mm² (remote on/off, temperature sensor, voltage measurement Temperature Range (ambient temp.): -25 degrees C to 60 degrees C; derating > 40 Cooling: Natural cooling Protections: Overload, over temperature, DC short circuit, reversed polarity (fuse) MasterBus Compatible: Yes Specifications: Charger Input - Voltage: 24v Charger Output - Amps: 30a Charger Output Voltage: 20-30v Box Dimensions: 4"H x 9"W x 15"L WT: 5.65 lbs UPC: 816882023521 Owner's Manual (pdf)

Read more less

DC Master 24V to 12V Converter - 12A w/IsolatorPower you can rely onThe required voltage for DC current can vary. Some equipment requires 24 V, while onboard equipment usually requires 12 V. For custom DC current, Mastervolt offers a series of compact and made to measure DC-DC converters for both 12 V and 24 V battery systems that offer stable power with the right current for any connected consumer. There is a wide range of DC Master converters available, including insulated and non-insulated models.Benefits Recreational and semi-professional use. Easy to install using included mounting bracket, screws and fasteners. Smart electronics mean no unnecessary heat generation. Continuous output. Insulated and non-insulated models available. Two minutes of extra power for short power boosts. Excellent price/performance ratio. Intelligent DC-DC convertersA large benefit of the DC Master models is their two minutes of extra capacity; ideal if you need a short power boost.Complete package DC MasterAll DC Master converters are delivered with mounting bracket, screws and fasteners.WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

DC Master 24V to 12V Converter - 12 AmpAlways on course with Mastervolt. Mastervolt ensures you an electrical system with no weak links and a dependable and silent power supply. Whether for recreational or professional purposes, with Mastervolt you always have power you can rely on... The power to be independent.DC Master DC-DC convertersThe required voltage for DC current can vary. Some equipment requires 24 V, while onboard equipment usually requires 12 V. For custom DC current, Mastervolt offers a series of compact and made to measure DC-DC converters for both 12 V and 24 V battery systems that offer stable power with the right current for any connected consumer.Features: Recreational and semi-professional use Easy to install using included mounting bracket, screws and fasteners Smart electronics mean no unnecessary heat generation Continuous output Two minutes of extra power for short power boosts Excellent price/performance ratio General Specifications Nominal output voltage: 13.6 V Max. output power: 245 W Nominal output power: 164 W Max. output current (for 2 min. intervals): 18 A Continuous output current: 12 A Nominal input voltage: 24 V Input voltage range (max.): 20-32 V DC (35 V) Galvanic isolation: no Stabilised: yes Dimensions, hxwxd: 127 x 87 x 50 mm 5.0 x 3.4 x 2.0 inch Weight: 0.405 kg 0.9 lb Compliance: CE Technical Specifications DC consumption: < 15 mA Connections: fast-on Temperature range (ambient temp.): -25 °C to 80 °C, derating > 30 Cooling: natural cooling Protection degree: IP53 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Charger Input - Voltage: 24v Charger Output - Amps: 12a Charger Output Voltage: 12v Box Dimensions: 2"H x 4"W x 6"L WT: 0.95 lbs UPC: 852968002806 Owner's Manual (pdf)Brochure (pdf)

Read more less

Orion-TR 48/24-16A (380W) Isolated DC-DC ConverterIsolated Model - separate in and out (-) leads Remote On/Off TerminalThe remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or for example the engine run/stop switch. All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.  High Temperature Protected The output current will reduce at high ambient temperatures.  IP43 Protection When installed with the screw terminals oriented downward.  Screw Terminals No special tools are needed for installation.  Input Fuse (not replaceable) On 12 V and 24 V input models only.  Adjustable Output Voltage Not intended for battery charging (consider using an Orion-Tr Smart for battery charging).Specifications: Input Voltage Range: 40-70 V Under Voltage Shut Down: 28 V Under Voltage Restart: 30 V Nominal Output Voltage: 24.2 V Output Voltage Adjust Range: 20-30 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 16 A Maximum Output Current (10 S) at Nominal Output Voltage: 25 A Short Circuit Output Current: 40 A Cont. Output Power at 25 Degrees C: 430 W Cont. Output Power at 40 Degrees C: 380 W Efficiency: 89 % No Load Input Current (2): < 80 mA  Galvanic Isolation: 200 VDC between input, output, and case Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C) Humidity: Max. 95 % non-condensing DC Connection: Screw terminals Maximum Cable Cross-Section: 16 mm² AWG6 Weight: 1.6 kg (3.5 lb) Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch) Safety Standards: EN 60950 Emission Standard: EN 61000-6-3, EN 55014-1 Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 48v Charger Output - Amps: 16a Charger Output Voltage: 24v Box Dimensions: 4"H x 6"W x 9"L WT: 3.45 lbs UPC: 8719076038887 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less
