Electrical - Terminals

22-18 Gauge - #8 Heat Shrink Spade Terminals - 25-PackAncor heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing. When heated, these connectors form a water tight seal and the ultimate vibration and strain relief.Features: Tinned for corrosion resistance Pure copper for maximum current flow Brazed seam for maximum strength UL listed and CSA recognized WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 22-18 AWG Type: Spade connectors Post Size: #8 Package Qty: 25 Heat Shrink: Yes Box Dimensions: 1"H x 3"W x 5"L WT: 0.05 lbs UPC: 091887316315 Quick Guide (pdf)

Read more less

DT & DTP Deutsch Cavity Plug - 16 & 12 Contact Size - White (100 Pack)Cavity plugs are used to seal cavity openings in Deutsch connectors (DTM, DT, DTP Series). Using cavity plugs is essential to prevent contaminants from entering connectors. Utilizing cavity plugs will guarantee that the connectors remain environmentally sealed. Properly sealed connectors offer durability, reliability, and longevity. How do you use Cavity Plugs? Simply insert one into an empty cavity on a Deutsch connector creating a watertight seal. They couldn't be easier to handle. These cavity plugs are field-serviceable and easy to install. Not sure which size is right for your project? Contact a Pacer expert today with any questions that you may have.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics: Hand-insertable cavity plugs Operating temperature ranges from -55°C to 125°C Specifications: Contact Size: 16 & 12 Connector Series: DT, DTP Package Size: 100 Brochure (pdf)

Read more less

DT & DTP Deutsch Cavity Plug - 16 & 12 Contact Size - White (25 Pack)Cavity plugs are used to seal cavity openings in Deutsch connectors (DTM, DT, DTP Series). Using cavity plugs is essential to prevent contaminants from entering connectors. Utilizing cavity plugs will guarantee that the connectors remain environmentally sealed. Properly sealed connectors offer durability, reliability, and longevity. How do you use Cavity Plugs? Simply insert one into an empty cavity on a Deutsch connector creating a watertight seal. They couldn't be easier to handle. These cavity plugs are field-serviceable and easy to install. Not sure which size is right for your project? Contact a Pacer expert today with any questions that you may have.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics: Hand-insertable cavity plugs Operating temperature ranges from -55°C to 125°C Specifications: Contact Size: 16 & 12 Connector Series: DT, DTP Package Size: 25 Brochure (pdf)

Read more less

DTP Deutsch Socket for 10 AWG Wire - Size 12 Contact (25 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability which are just a few of the reasons that the professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is the fact that they are simple to use and require little time for installation.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics:Hand-insertable contactsCompliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized Specifications: Cavity Style: Plug (socket) Connector Type: DTP Wire Size: 10 AWG Current Rating: 25 Package Size: 25 Contact Size: 12 Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

DTP Deutsch Socket for 10 AWG Wire - Size 12 Contact (10 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability which are just a few of the reasons that the professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is the fact that they are simple to use and require little time for installation.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics:Hand-insertable contactsCompliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized Specifications: Cavity Style: Plug (socket) Connector Type: DTP Wire Size: 10 AWG Current Rating: 25 Package Size: 10 Contact Size: 12 Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

DTP Deutsch Pin for 14-12 AWG Wire - Size 12 Contact (10 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability which are just a few of the reasons that the professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is the fact that they are simple to use and require little time for installation.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics:Hand-insertable contactsCompliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized  Specifications: Cavity Style: Receptacle (pin) Connector Type: DTP Wire Size: 14-12 AWG Current Rating: 25 Package Size: 10 Contact Size: 12 Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

DT Deutsch Pin for 14 AWG Wire - Size 16 Contact (100 Pack)Deutsch machined contacts are for use with almost the entire line of Deutsch connectors and are ideal for marine conditions. They are known for their reliability and durability which are just a few of the reasons that the professionals turn to these contacts for repeatable and reliable results. Another benefit of these contacts is the fact that they are simple to use and require little time for installation.Features: Easy to install Field serviceable Applications: Cable-to-cable applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics:Hand-insertable contactsCompliances: Ingress Protection (IP) Level: IP68 and IP6K9K RoHS UL Recognized Specifications: Cavity Style: Receptacle (pin) Connector Type: DT Wire Size: 14 AWG Current Rating: 13 Package Size: 100 Contact Size: 16 Operating Temperature: -55°C to 125°C

Read more less

DTP Deutsch Receptacle Repair Kit - 14-12 AWG (2 Position)DTP Series Deutsch Connectors are the solution for power application requirements. The DTP line was developed to handle the need for higher amperage, multi-pin economical connectors.  Each circuit is capable of continuous 25 amp service.  Deutsch solid contacts (14-12 AWG) are included in the packs. Contact a Pacer expert with any questions that you may have.Features: 14-12 AWG applications  25 Amp continuous power Specifications: Number of Cavities (Positions): 2 Contents: (1) 2 pos. receptacle, (1) 2 pos. wedge lock, (2) stamped and formed pins Brochure (pdf)

Read more less

DTP Deutsch Receptacle Repair Kit - 14-12 AWG (4 Position)DTP Series Deutsch Connectors are the solution for power application requirements. The DTP line was developed to handle the need for higher amperage, multi-pin economical connectors.  Each circuit is capable of continuous 25 amp service.  Deutsch solid contacts (14-12 AWG) are included in the packs. Contact a Pacer expert with any questions that you may have.Features: 14-12 AWG applications  25 Amp continuous power Specifications: Number of Cavities (Positions): 4 Contents: (1) 4 pos. receptacle, (1) 4 pos. wedge lock, (4) stamped and formed pins Brochure (pdf)

Read more less

DTP Deutsch Plug Repair Kit - 14-12 AWG (2 Position)DTP Series Deutsch Connectors are the solution for power application requirements. The DTP line was developed to handle the need for higher amperage, multi-pin economical connectors.  Each circuit is capable of continuous 25 amp service.  Deutsch solid contacts (14-12 AWG) are included in the packs. Contact a Pacer expert with any questions that you may have.Features: 14-12 AWG applications  25 Amp continuous power Specifications: Number of Cavities (Positions): 2 Contents: (1) 2 pos. plug, (1) 2 pos. wedge lock, (3) stamped and formed contacts Brochure (pdf)

Read more less

Step-Down Butt Splices with Blue Heat Shrink - 22-18 AWG to 16-14 AWG - 100 PackIn an electrical system, there may be times when connecting one wire to multiple wires is needed. Alternatively, there may be times when connecting two different gauge wires is needed. In situations like this, users would use step-down butt splices with colored heat shrink.Heat-shrink butt splices protect against the elements in the most challenging of environments. They offer the best moisture protection available. These step-down heat-shrink butt splices have an adhesive liner. This liner provides a durable, rugged, environmentally sealed connection for wires between 18 AWG - and 14 AWG. It protects from physical abuse and abrasion, water, salt, and other corrosive compounds. Step-down butt splices join two wires to one. The colored dash on the tubing indicates the wire size for the connector, and this blue one indicates 16-14 AWG. Step-down heat-shrink butt splices are used to connect different gauge wires. They are also used to connect multiple wires of the same size. So, users could connect a 10 AWG wire to a 12 AWG wire or connect a 12 AWG wire to two 12 AWG wires. The first step is to properly strip the wires to the correct length. If users look inside the butt splice, an indentation where the wires should butt up against can be seen. Also, be careful to make sure that the butt splice and the wire insulation are touching. If not, users run the risk of weakening the connection.Next, the stripped wire is inserted into one side of the butt splice and crimped with the proper tool. This crimp bends the connector around the wire. This crimp creates a solid connection. On the other side, two wires are added. After crimping, perform the tug test to make sure the wires don't pull out. Once the wire has passed the test, apply heat to the heat shrink, working outward. Be careful not to burn the butt splice or the wire insulation. Now a durable, environmentally protected connection is created. Remember, butt splices are useful for their rapid installation and durability. Other methods of connection may not offer the same level of protection.Features: Protects terminations from water, condensation, salt spray, and corrosion Added vibration protection in rugged environments Provides strain relief Compliances: UL CSA RoHS Technical Specifications: Shrink Ratio: Approx. 3:1 at 135 degrees C Operating Temperature: -55 degrees C - 125 degrees C Vol. Resistivity: 1015 Ohm-cm3 Dielectric Strength: 900V/mil Voltage Rating: 600V Guage (AWG): 22-18 AWG to 16-14 AWG Max. Wire Insulation Outer Diameter: 0.21 in. Heat Shrink Color: Blue *Sold as a pack of 100 Brochure (pdf)

Read more less

DT Deutsch Plug Repair Kit - 14-18 AWG (12 Position)Pacer's DT repair kits use the larger size 16 contacts (Deutsch Pin P/N 0460-215-16141, Socket P/N 0462-209-16141) for applications using 14 AWG wires. However, DT series connectors are designed for 20-14 wire gauge applications. The DT series offers electrical designers the ability to use multiple sizes of 16 contacts (20-14 AWG) each with a 13-amp continuous capacity, within a single shell. Pacer also sells these other components for use in a wider range of applications.Features: Packs include all parts needed to assemble a connector One to two extra terminals Cavity plugs to seal open circuits Applications: Wire-to-wire applications Enclosed connectors offer field-proven reliability and rugged quality Compliances: Ingress Protection (IP) Level: IP68 and IP6K9K EU RoHS/ELV Standard UL-94 Recognized Characteristics: Wedge locks ensure contact alignment and retention Redundant Silicone Seals Hand-insertable and removable contacts Technical Specifications: Number of Cavities: 12 Housing: Rectangular receptacle, plastic reinforced with glass fiber Contact Size: 16 (13 amp) Wire Size: 14 AWG Holds Pin/Socket: Sockets Operating Temperature: -55°C to 125°C Contents:  (1) 12 pos. plug (1) 12 pos. wedge lock (14) sockets (6) cavity plugs Quick Guide (pdf)

Read more less
