SmartSolar MPPT Charge Controller - 100V - 50AMPFeatures: Bluetooth Smart built-in The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.  VE.Direct For a wired data connection to a Color Control GX, other GX products, PC or other devices  Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Load output Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage (48V model: interface with a relay). Alternatively, an intelligent battery management algorithm can be chosen: see Battery Life. The load output is short circuit proof.  Battery Life: intelligent battery management When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a ‘partially charged’ state and the ‘end of discharge’ state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months. The Battery Life algorithm will monitor the state of charge of the battery and, if needed, day by day slightly increase the load disconnect level (i.e. disconnect the load earlier) until the harvested solar energy is sufficient to recharge the battery to nearly the full 100%. From that point onwards, the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week.  Programmable battery charge algorithm See the software section on our website for details  Day/night timing and light dimming option See the software section on our website for details  Internal temperature sensor Compensates absorption and float charge voltage for temperature.  Optional external battery voltage and temperature sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 18-100v Charger Output - Amps: 50a Charger Output Voltage: 12v/24v Charging Banks: 1 Portable: No Box Dimensions: 4"H x 6"W x 8"L WT: 3.95 lbs UPC: 8719076040194 Quick Guide (pdf)Brochure (pdf)

Read more less

Original Equipment Quality Replacement Solenoid for BRP-OMC & Evinrude E-TECReplacement solenoid that will fit BRP-OMC, EVINRUDE E-TEC, 2010-UP 15 HP-300 HP.Replaces:BRP-OMC 587020*ARCO Assurance 12-month part and labor warranty protectionThis product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

5022 Panel Mount AGC/MDL Fuse Holder Replacement CapReplaces cap for 5021 Specifications: Fuse Type: AGC/MDL Type: Fuse Holders Box Dimensions: 1"H x 2"W x 4"L WT: 0.05 lbs UPC: 632085050221

Read more less

M2 OLED Tank MonitorThe M2 Organic LED Digital Monitor measures essential electrical system parameters with adjustable alarms and an auto-dimming display. The M2 Monitors include a MOSFET External Circuit Relay (ECR) which can be used to control external circuits based on any value measured by the M2.Features: Auto-dimming, bright Organic LED display is easy to read 80dB alarm on all models Isolated 500mA MOSFET relay Includes external DC Shunt or AC Current Transformer when required Intuitive tank level monitoring Monitor up to 4 tanks Auto calibration for unique tank shapes Compatible with common sending units Specifications: Meter: Tank Function: Monitors tank volume in up to 4 tanks Resolution: 1% Display Size: 55mm x 28mm Input Voltage: 7-70V DC - Variable with voltage, display intensity, and sleep mode Range: 0.3W-1.0W Tank Alarms: 80dB Tank Shapes: Custom shapes, auto calibration Weight: 0.25lb (0.11 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

1810Features: Accurate - used with the Vessel Systems Monitor VSM 422 PN 1800 - can be precisely calibrated for each tank* Reliable - SSI Technologies, Inc. Fluid-Trac® is non-contacting eliminating any mechanical moving parts that can wear and cause intermittent or complete signal loss Digital filtering - Eliminates errors due to liquids sloshing in mobile tanks * Calibrated for use with Blue Sea Systems Vessel Systems Monitor VSM 422 only WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

MK 315D On-Board ChargerON-BOARD MARINE BATTERY CHARGERS.Reengineered with a microprocessor-based design, our all-new digital on-boardchargers protect your battery, charge faster, and help you stay on the water longer.DIGITALLY CONTROLLED. We set out to build a smarter charger, and the result is the ingenious microprocessor-based design of our new on-boardunits. By monitoring factors like temperature and state of charge, they deliver a faster, more regulated precise charge so you can stay on the water longer, without worrying about your batteries.PROTECTS BATTERIES.Our new on-board chargers feature Multi-Stage Charging and Automatic Temperature Compensation for more precise charges that won't damage your battery. And its automatic shut-off feature extends battery life by shutting down when charging is complete. So your battery and your day on the water will always last longer.TWO TIMES FASTER CHARGING.In high temperatures, our new on-board chargers juice up your batteries up to twice as fast. Thanks to a digital design that monitors everything from temperature to state of charge, our new on-boards get the job done.ENHANCED STATUS CODES.Comprehensive readings on our new chargers inform you of the charge stage, maintenance mode status, any error notifications and full charge. Waterproof, shock- and vibration-resistant aluminum construction Saltwater tested and fully corrosion-resistant Short circuit, reverse polarity, arc and ignition protected For use with 12V/6 cell batteries that are flooded/wet cell,maintenance free or starved electrolyte (AGM) only FCC compliant UL listed to marine standard 1236 Length - 12-1/2" Width - 7-1/2" Height - 4" Weight - 14lbs WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Charger Output - Amps: 15a Charging Banks: 3 Portable: No Charger Input - Voltage: 120v Charger Output Voltage: 12/24/36v Box Dimensions: 7"H x 8"W x 16"L WT: 15.6 lbs UPC: 029402034796 Owner's Manual (pdf)Brochure (pdf)

Read more less

15A to 50A 125/250V Pigtail AdapterAllows connection of 50A 125/250V inlets to 15A 125V cords.Features: LED Power Indicator Ergonomic design for easier gripping Fully molded with a sealing collar for use in wet locations 15A 125V output, for use with 120V devices WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Pigtail Adapter Box Dimensions: 3"H x 7"W x 12"L WT: 2 lbs UPC: 093344062131

Read more less

Flip Pro Multi - Dual USB-C & 12V Power SocketCombining the features of the high-power Flip Pro Max and 12V Power Sockets into a beautiful multi-power solution.When not in use, the spring-loaded caps remain tightly closed, protecting the ports from the elements.Universal: Universal fit for any USB-C connectors Fast charge (60W max) up to 2 devices at a time Marine Ready: IPX4 waterproof with the cover closed UV resistant 316 stainless steel hinge and spring Electrical Information: 120 -150W max power (12V system only) Input voltage: 10-30V DC (12/24V System) Input current Max: 6A (10A fuse recommended) Key Information: To maximize charge performance, use the cable supplied with your tablet, phone, etc. (C to C, or C-lightning) Phones charge at the same speed on either a 12 or 24V system, but a 24V system must be used to get the full 60W output suitable for laptops Quick Guide (pdf)

Read more less

LED Battery TesterSpecifically for all 12 Volt DC batteries.

Read more less

Green 8 AWG Primary Wire - 100'Pacer's marine wire is designed to handle the harshest marine environments.  It is manufactured to meet and exceed the most stringent specifications.  This 8 AWG marine wire is constructed in the USA to achieve the highest level of quality. Built from Type III class K tinned copper, this wire offers excellent flexibility.  The tinned copper also resists corrosion adding to the life of the wire.  What about the insulation?  After the copper is tinned it is then insulated with a durable and flexible PVC jacket.  The jacket makes this 8 AWG marine wire resistant to alkali, abrasion, acid, gas, oil, flame, and moisture.  What standards and compliances does this wire meet?  Pacer's marine wire exceeds the requirements and standards of UL, ABYC, and NMMA. Features: Built for durability, flexibility, and longevity in the harshest marine environments  So flexible that you can tie it into a knot without compromising any of its qualities  Proprietary insulation ensures the highest level of protection available  Ease of installation and the longevity of its design have helped solidify this marine wire as the choice of boating professionals Compliances: UL Standard - 1426 BC-5W2 U.S.C.G - 33 CFR part 183  ABYC - E-11.14  Technical Specifications: Conductor - Type III annealed finely stranded tinned copper ASTM B172 Class K Insulation -20 °C to 105 °C flexible, color-coded PVC Voltage Rating - 600-V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture *Sold as an Individual Specifications: Color: Green Gauge: 8 AWG Length (Feet): 100' Box Dimensions: 5"H x 7"W x 7"L WT: 8.25 lbs UPC: 840248203302 Brochure (pdf)

Read more less

12V Battery ConnectorThis easy-to-use battery connector is part of a system that provides the ability to quickly and easily hook up 12V marine batteries in boats, lawn tractors, ATVs, or other equipment 12V systems in seconds with just a quick snap.Self-cleaning marine grade connectors last for years of service. This device allows endless multiple uses for a battery in the outdoors. Quickly hook up a battery for use in Boats, ATVs, RVs, Ice Houses, Agricultural Equipment, or anywhere you want to share a battery.With an easy and quick snap, this system allows the use of any of your batteries and or equipment, anywhere at any time. The uses are endless. No more wasted time chasing tools, fighting corrosion, or dead batteries.Compatible With:The 12 Volt Easy Battery Connector can be used to hook multiple 12V batteries up in parallel for extended usage or backup systems on boats, RVs, Ice Houses, trap machines, and much more.Once installed, no tools are needed for the removal, replacement, or storage of expensive marine batteries. Using the Connect-Ease series of products allows connecting any 12V marine battery with any equipment or device at any time, any place, easily and quickly, by simply snapping the connectors together.Features: 6 Gauge marine grade battery connection with 3/8 inch terminals. Plug & Play connections Lithium Compatible. Suitable for use t-40° to 221° UL1977 120 Amp Rating. Lithium Compatible Specifications: One-year Warranty - Fresh & Salt Water Approved Made In the USA -  Patent Pending

Read more less

12V DC 4 PositionFeatures: 4 to 32 branch circuits with installed 15 Ampere circuit breakers Available with voltmeters, ammeters, and digital multimeters Includes 4205-Square Format Label Set Specifications: Positions:t4 Nominal Voltage:t12V DC Maximum Amperage*:t100A Height:t4.75" (120.65mm) Width:t4.88" (123.95mm) Depth:t3.00" (76.2mm) Weight:t1.35lb (0.61kg) * Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.Includes:(4) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4205 - Basic DC Label Kit - 30 Black Square Labels [LABEL]WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: DC Box Dimensions: 6"H x 7"W x 9"L WT: 1.5 lbs UPC: 632085012168 Quick Guide (pdf)Owner's Manual (pdf)

Read more less
