Electrical

DS30-P-BLK Vertical Cable Seal - Black *3-PackScanstrut premium IP68 waterproof cable seal provides easy-fit cable routing that cuts down your installation time and is the only guaranteed and proven watertight installation for your antenna and navlight cables. Features: Watertight installation - 100% waterproof with an IP68 rating Easy and reliable installation - each unit is supplied with both pre-drilled and blank inner seals to make your installation as easy as possible.  No Need to Remove Cable Connectors - split-seal option does not require connector removal during installation.  Multi-Functional Dome Shape - the aesthetic dome-shaped profile provides a stronger, impact-resistant design and the outer dome provides an additional water shield. Technical Specifications: Fits cable size (diameter) - .35" to .55" (9 - 14 mm)   Fits connector size up to 1.18" (30 mm) in diameter  Height - .81" (20.5 mm) Color - Black Orientation - Vertical Material - ASA Plastic In the Box: Cable seal Mounting hardware Installation manual  *Sold as a Three (3) Pack Specifications: Type: Deck Seal Box Dimensions: 2"H x 4"W x 9"L WT: 1.05 lbs Quick Guide (pdf)Brochure (pdf)

Read more less

Galvonic Isolator VDI-32A 32A Max Waterproof (Potted)The galvanic isolator prevents electrolytic corrosion. It blocks low voltage DC currents that enter your boat via the shore power earth wire. These currents can cause corrosion to the boat’s underwater metals, like the hull, propeller, shaft and so on.The galvanic isolator consists internally of two diodes which are connected in anti-parallel fashion. When they are connected in this way, the diodes allow current in both directions but only above a certain threshold voltage. The voltage at which diodes conduct is about 1.4 Vdc.The isolator is installed directly behind your boat's 120V - 230V connection. The forward voltage from the galvanic isolator is higher than the potential difference between metals. As a result, this voltage will not allow conduction and as such, the galvanic isolator will prevent any electrolytic current. However, if there is a (higher) error voltage in the AC circuit, the diodes will allow current through and the residual-current device will break the circuit.Terminal posts are 6mm (1.4")This item is not ABYC A-28 approvedPlease contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

DS30-P-BLK Vertical Cable Seal - BlackScanstrut premium IP68 waterproof cable seal provides easy fit cable routing that cuts down your installation time and is the only guaranteed and proven watertight installation for your antenna and navlight cables. Features: Watertight installation - 100% waterproof with an IP68 rating Easy and reliable installation - each unit supplied with both pre-drilled and blank inner seals to make your installation as easy as possible.  No Need to Remove Cable Connectors - split-seal option does not require connector removal during install.  Multi-Functional Dome Shape - the aesthetic dome-shaped profile provides a stronger, impact-resistant design and outer dome provides additional water shield. Technical Specifications: Fits cable size (diameter) - .35" to .55" (9 - 14 mm)   Fits connector size up to 1.18" (30 mm) in diameter  Height - .81" (20.5 mm) Color - Black Orientation - Vertical Material - ASA Plastic In the Box: Cable seal Mounting hardware Installation manual  *Sold as an Individual Specifications: Type: Deck Seal Box Dimensions: 2"H x 4"W x 9"L WT: 0.35 lbs UPC: 5060114797376 Quick Guide (pdf)Brochure (pdf)

Read more less

Mac Plus 12/48-15Boost Your Service BatteryToo often, service batteries don’t get the charge they need. This is a problem made worse by smart alternators and start/stop systems, which result in slow and insufficient charges. The Mac Plus 48V and 36V solve that problem. With brand-new bi-directional technology, the Mac Plus can use each side as an input or output, delivering a reliable and consistent charge to both service and starter batteries.Proven Mastervolt QualityThe Mac Plus uses the proven Mastervolt 3-step+ charge algorithm, delivering a quick and easy charge, even to completely flat batteries. By knowing when the engine is running and providing charge, you can also be sure that the Mac Plus will never drain your starter battery.A robust design holds up in even the harshest conditions, with battery temperature-optimized charging and high-quality aluminum housing to ensure superior protection against dust and water ingress. The power-efficient design also allows the Mac Plus to operate silently and without a fan.Total Power FlexibilityWith a wide DC input range, the Mac Plus allows all DC sources and can charge two batteries from a single alternator or charger. It supports a full range of chemistries and battery types, including lithium. It also functions seamlessly with modern alternators such as Euro 5 and 6, ensuring proper charging by providing constant power, even when the alternator is inactive.Parallel configuration of up to ten units will provide over 100 amperes. And advanced high-frequency technology with modern microprocessors ensures minimal power loss when switching from 36/48V to 12/24V and vice versa.Analog voltage sense ports are also available to compensate for voltage drops and maintain proper charging.Superior Monitoring & ControlCompatibility with CZone®, NMEA 2000®, and MasterBus delivers truly superior monitoring and control and ensures Mac Plus integrates easily into complete systems. Achieve the best performance possible via various controllers and high-quality MOSFETs. And configure the Mac Plus with ease via MasterAdjust, the CZone configuration tool, or even via the on-board DIP switches.Features: Bi-directional technology Get either 48V or 36V power from a single unit Fast and safe charging, even during short trips Fanless design for silent operation Suitable for flooded, Gel, AGM, and Li-Ion batteries (incl. LiFePO4) Even charges fully depleted batteries Engine run detection protects the starter battery Adjustable current limits to meet Euro 5/6 requirements Voltage stabilization protects sensitive equipment, lights, and loads Parallel operation to obtain charging capacities well over 100 Amps MasterBus, CZone, and NMEA 2000 compatible, with intelligent system monitoring and automation Temperature compensation and voltage sense for an optimal charging result E-Mark/R10 certification for mobile applications Power supply mode offers stable power for sensitive loads Heavy-duty connections for easy installation and quick setup via DIP switches General Specifications: Battery Voltage Sense: Yes Status indicator: Yes, 3 color double LED Communication protocol: MasterBus, CZone & NMEA 2000 Output voltage: 30-60 V DC Nominal output voltage: 36/48 V Output voltage stabilization: 2 % at extremes of temps, load, and input Output voltage ripple (peak-peak): Max. 1 % Max. output power: 900 W Max. output current: 15 A Nominal input voltage: 12 V DC Input voltage range: 8-16 V Max. input current: 60 A Galvanic isolation: No Efficiency: > 95 % (at nom. input voltage, full load); 97 % peak Parallel configuration: Yes, up to 4 Alarm contact: Yes, through MasterBus, CZone, DIP Switch, or remote switch Engine run signal input: Yes (active high/active low) DIP switches: Yes, for basic setup Dimensions, hxwxd: 255x165x66 mm, 10.0 x 6.5 x 2.6 inch Weight: 2 kg, 4.4 lb Compliance: CE, E-Mark, SAE J1171, ISO 8846 ignition protected, ABYC & UKCA Technical Specifications: Battery types: Gel, AGM, Lithium Ion, user-defined Power consumption: < 5 mA, < 10 mA in CZone, < 1 mA in MasterBus Temperature range (ambient temp.): - 25 °C to 60 °C; derating > 40 °C/104 °F Cooling: Natural cooling Protection degree: IP23 Protections: Overload, over-temperature, DC short circuit, reversed polarity (fuse) Specifications: Charger Input - Voltage: 12v Charger Output - Amps: 15a Charger Output Voltage: 36/48V Box Dimensions: 4"H x 9"W x 15"L WT: 5.6 lbs UPC: 816882023446 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

ChargeMaster Plus 12/50-3 Battery ChargerMake the most of your batteries with the ChargeMaster series, plugging in and charging anywhere in the world. Mastervolt’s ChargeMaster guarantees fast and complete charging of your batteries no matter where you are. Thanks to Mastervolt’s innovative 3-step+ charging process, batteries also perform better and last longer.All ChargeMasters can be easily connected to a MasterBus network with only one cable and one connection (with the exception of the ChargeMaster 12/10, ChargeMaster 12/15-2, and ChargeMaster 24/6). What’s more, you have the option for central, local, or remote monitoring, configuration, and control of your system.Clear DisplayA clearly lit display on the ChargeMaster provides all essential information: charge current, charge voltage, charge phase, and battery content measurement and/or battery condition measurement as a percentage of available Ah capacity. The display also provides an indication of MasterBus communication. Three buttons adjacent to the read-out panel allow for easy operating of the entire system. The ChargeMaster is available in various models to guarantee you the ideal battery charger for any situation and demand.Features: For recreational and semi-professional use. Suitable for any type of battery, including Lithium-Ion batteries. 3-Step+ charging technology for fast and complete charging also charges depleted batteries. Memory function prevents overcharging in case of unreliable mains. Safe and complete charging due to standard safety features. Charging capacity up to 1000 Ah battery banks. Easy to connect and quick to install. Can charge multiple battery banks simultaneously. Built-in system functionality (MasterBus) in combination with other Mastervolt products. Clear control panel (with the exception of the ChargeMaster 12/10, ChargeMaster 12/15-2, and ChargeMaster 24/6). Supplies your system without a battery. Charging your batteries with every voltageThe Mastervolt ChargeMaster supplies a maximum capacity wherever you are via auto-ranging. Auto-ranging ensures perfect fully automatic operation anywhere in the world, regardless of the available mains voltage (90-265 V AC, 50 or 60 Hz). The 3-step+ charging technology guarantees fast and complete charging, while the cos phi 1-regulation gets the most out of limited generator capacity.Robust Connections Solid metal-to-metal connectors equipped with strain relief prevent corrosion and overheating.Charging multiple battery banksThe ChargeMaster series has three equal charge outputs. Those of the smaller ChargeMaster models are pre-installed with two meters of cable for a plug & play solution, while the heavier models have one full output (for example for your service battery) and two outputs of 10 A, ideal for your starter batteries.DC Power SupplyEven if the batteries are not connected, Mastervolt ChargeMaster battery chargers can provide a constant DC output allowing you to turn on lights or keep the fridge cold.Specifications: Nominal output voltage: 12V Total charge current: 50 A at 14.4 V Number of battery outlets: 3 Charge current second output: 50 A Charge current third output: 50 A Battery bank size: 100-500 Ah Nominal input voltage: 120/230 V (90-265 V), 50/60 Hz AC connection: Connector strips Power supply mode: Yes Galvanic isolation: Yes Display/read-out: LED display Fastening: Mounting bracket (included) or 4x screw Specifications: Charger Input - Voltage: 120/230v Charger Output - Amps: 50a Charger Output Voltage: 12v Charging Banks: 3 Portable: No Box Dimensions: 6"H x 12"W x 15"L WT: 9.2 lbs UPC: 816882022883 Owner's Manual (pdf)

Read more less

7443 UL-489 Circuit Breaker - 20A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 20A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 20a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074432

Read more less

Water Resistant Contura Switch - OFF-(ON) - GreyFeatures: Vibration, shock, thermoshock, moisture, and salt spray resistant Specially manufactured for mounting in Blue Sea Systems' water-resistant panels Ignition Protected - Safe for installation aboard gasoline-powered boats Meets UL1500 and ISO8846 ignition protection requirements WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Grey Throw/Pole: SPST Action: On/Off Box Dimensions: 1"H x 2"W x 4"L WT: 0.3 lbs UPC: 632085082314

Read more less

8232 Water Resistant Contura III Switch - ON-OFF-ON - GreyFeatures: Vibration, shock, thermoshock, moisture, and salt spray resistant Specially manufactured for mounting in Blue Sea Systems' water-resistant panels Ignition Protected - Safe for installation aboard gasoline-powered boats Meets UL1500 and ISO8846 ignition protection requirements WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Grey Throw/Pole: SPDT Action: On/Off/On Box Dimensions: 1"H x 3"W x 4"L WT: 0.41 lbs UPC: 632085082321

Read more less

Push Button Reset Only Screw Terminal Circuit Breaker - 7 AmpsFeatures: Branch circuit breakers (can also be used for 24-hour circuit protection) Quick connect terminal style circuit breakers are incorporated into Blue Sea Systems WeatherDeck Waterproof Circuit Breaker Panels, Dual Battery Bank Main Distribution Panels, and 360 Distribution Panels Compact design enables high density circuit protection configurations Push-to-reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasoline powered boats Optional Push Button Waterproof Boot protects circuit breaker in wet environments, replaces dress nut mounting on circuit breakers and resists discoloration and cracking Specifications: Amperage: 7A Maximum Voltage: 32V DC Mounting: Panel Mount 3/8-27 UNS Circuit Breaker Type: Thermal trip, manual push-button reset only Terminal Type: #8 Screw Interrupt Capacity: 3000A @ 14.7V / 2500A @ 28V Minimum Operating Temperature: -10° C Maximum Operating Temperature: t60° C Screw Terminal Torque: 6 in-lb (0.68 Nm) Weight: 0.09lb (0.04 kg)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 7a Box Dimensions: 1"H x 3"W x 5"L WT: 0.1 lbs UPC: 632085021313

Read more less

Horizontal Battery Distribution Cluster f/Single Engine w/Two Battery BanksThe 716-H-140A-DVSR is an ideal replacement for a battery selector switch. Just remove the selector switch and connect the existing wires to a 716 cluster, no extra wires are required for a fully automatic battery management system. To be used in a single outboard dual battery bank system or in a single alternator inboard engine dual battery bank system. No more flat start batteries Electronics protection from harmful engine start spikes The 716 cluster is for use on charging systems up to 150A The 716 cluster replaces battery isolator systems Two battery banks WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

7235 A-Series Double Pole Toggle - 15AMP - WhitePoles: 2Color: WhiteAmperage: 15AMPFeatures: Meets American Boat and Yacht Council (ABYC) standards UL 1077 recognized, TUV certified, CE marked for Europe and CSA certified for Canada The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Used as AC Main circuit protection "Trip Free" design cannot ben held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 15a Box Dimensions: 2"H x 3"W x 5"L WT: 0.3 lbs UPC: 632085072353

Read more less

5031ST Blade Fuse Block w/out Cover - 12 Circuit w/ Negative Bus Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit Accepts ATO and ATC fast acting blade fuses WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ATO/ATC Type: Fuse Blocks Box Dimensions: 2"H x 4"W x 10"L WT: 0.7 lbs UPC: 632085050313 Owner's Manual (pdf)

Read more less
