Electrical

9011Switch, AC 120VAC Amperes 65 Positions 2+OFF Poles 2 Switches 2 - 120 or 230 Volt AC sources Compact solution when circuit protection is provided elsewhere Allows connecting one of two different AC sources to one circuit Mounts in panels up to 0.16" (4.00mm) thick Heavy duty industrial rated switch Intuitive function - One hand operation UL listed 600 Volt AC max WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Box Dimensions: 4"H x 6"W x 7"L WT: 1 lbs UPC: 632085090111 Owner's Manual (pdf)

Read more less

7610120 Amp SI-Series Automatic Charging Relay Allows temporary isolation of house loads from engine circuit during engine cranking to protect sensitive electronics Automatically combines battery banks during the charging cycle and isolates under discharge 12/24 Volt auto ranging voltage input Waterproof rated IP67 - temporary immersion for 30 minutes Ignition protected - safe for installation aboard gasoline powered boats Remote LED output indicates relay state away from ACR LED light indicates when batteries are combined LED blinks in undervoltage lockout and starting lockout Supports high-output alternators up to 120 Amperes Included with the ADD A BATTERY Dual Circuit System Automatically combines battery banks during the charging cycle and isolates under discharge Ignition protected - safe for installation aboard gasoline-powered boats Activates from any charging source - alternators, battery chargers, or solar panels Hermetically sealed contacts / vaporproof Side and bottom knockouts for power cable connections Clip-on cover protects and insulates terminal connections Tin-plated copper studs for maximum corrosion resistance 7/8" (22.22mm) stud length to accept multiple cable terminals 1/4" x 0.031" male quick connect terminals for ground and remote LED and starting interrupt WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Circuit Breaker Panel PlugBlack plug fits standard toggle circuit breaker holeWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Water Resistant Contura Switch - (ON)-OFF-(ON) - GreyFeatures: Vibration, shock, thermoshock, moisture, and salt spray resistant Specially manufactured for mounting in Blue Sea Systems' water-resistant panels Ignition Protected - Safe for installation aboard gasoline-powered boats Meets UL1500 and ISO8846 ignition protection requirements WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Grey Throw/Pole: DPDT Action: (ON)-OFF-(ON) Box Dimensions: 2"H x 3"W x 4"L WT: 0.09 lbs UPC: 632085082222

Read more less

187 - Series Thermal Circuit Breakers - Panel Mount30 Amp Circuit BreakerPN:  7036Features: Combines switching and circuit protection into a single device All components meet SAE J1171 external ignition protection requirements Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Self-trimming case eliminates the need for mounting panels or trim bezels Round case permits easy installation with standard sized hole saw Large clearance around terminal studs accept heavy gauge wire lugs Robust 5/16 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - safe for installation aboard gasoline powered boats Specifications   Circuit Breaker Class: Type III - Switchable / Manual Reset - Trip Free Type: Thermally Responsive Bi-Metal Blade Case Material: Thermoset Polyester Voltage Rating: 48 Volts DC Maximum Interrupt Rating: 5,000 Amperes @12 Volts DC   3,000 Amperes @24 Volts DC   1,500 Amperes @42 Volts DC Operating Temperature Range: -25C° to +82C° WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 2"H x 5"W x 8"L WT: 0.45 lbs UPC: 632085070366

Read more less

7054Push Button Thermal with Quick Connect Terminals10A Ideal for 24-hour circuit protection Incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels Push to reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasonline powered boats With male quick connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 10a Box Dimensions: 1"H x 3"W x 4"L WT: 0.3 lbs UPC: 632085070540

Read more less

WeatherDeck™ Water Resistant Circuit Breaker PanelPN: 4376Color: GrayFeatures: Rated IP67-temporary immersion for 30 minutes Designed for flybridge and open cockpit applications Independent label backlighting allows switching and dimming Compatible with all Blue Sea Systems Digital Dimmers Each panel can be mounted in four different orientations Green LEDs aid low-light readability. All labels will be lit when the panel is powered, regardless of individual switch position. Specifications: Weatherproof: Waterproof Positions: 6 Nominal Voltage: 12v / 24v DC Circuit Protection: Circuit Breaker Maximum Amperage: 15A @ 12v DC (per circuit) / 9A @ 24v DC (per circuit) Panel Cumulative Rating: 45A Backlit Label: Green LED Backlighting Amperage: 10mA/Illuminated Circuit Backlighting Voltage: 12 or 24v DC Height: 6.0" Width: 4.25" Depth: 3.5" Included: (6) 4135 Push Button Reset Only Circuit Breaker Boot - Clear (6) 4138 WeatherDeck® Toggle Switch Boot - Black (6) 4150 WeatherDeck® Toggle Switch SPST - ON-OFF (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1 (6) 7056 Push Button Reset Only Quick Connect Circuit Breaker - 15 Amps WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Waterproof: Waterproof Voltage: 12v AC/DC: DC Max Breaker Quantity: 6 Box Dimensions: 4"H x 6"W x 9"L WT: 1.4 lbs UPC: 632085043766 Quick Guide (pdf)

Read more less

4154WeatherDeck Toggle Switch Pole/Throw SPDT Action (ON)-OFF-(ON) Specially manufactured by Carling Technologies for use in Blue Sea Systems' WeatherDeck™ Panels When mounted with a WeatherDeck Toggle Switch Boot Rated IP67-temporay immersion for 30 minutes Nickel-plated brass and phenolic non-corrosive construction WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Throw/Pole: SPDT Action: (ON)-OFF-(ON) Box Dimensions: 1"H x 3"W x 4"L WT: 0.09 lbs UPC: 632085041540

Read more less

8262 Waterproof Panel 4 Position - Slate GreyFeatures: Will withstand the water exposures normally encountered in above deck applications: salt spray, rain, hose washdowns, momentary immersions Designed for flybridge and open cockpit applications ON-OFF Contura Switches ON indicating LEDs embedded in switches Watertight mounting gasket included Countersunk mounting holes throughout Two-part polyurethane slate gray finish Industry standard height and width Mil-Spec chemical treatment via immersion to protect every surface detail from corrosion Completely wired and ready to install Specifications: Weatherproof: Water Resistant Positions: 4 Nominal Voltage: 12v / 24v Panel Cumulative Rating: 45A Switch Rating: 20A @ 12v DC / 15A @ 24v DC Height: 3.75" Width: 5.25" Depth: 3" Included: (4) 5021 Panel Mount AGC/MDL Fuse Holder (1) 8214 Black 60 Label Set (4) 8230 Contura Switch SPST Gray - Off-On WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Waterproof: Resistant AC/DC: DC Max Breaker Quantity: 4 Voltage: 12/24v Box Dimensions: 5"H x 7"W x 9"L WT: 0.8 lbs UPC: 632085082628 Owner's Manual (pdf)

Read more less

7057Push Button Thermal with Quick Connect Terminals20A Ideal for 24-hour circuit protection Incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels Push to reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasonline powered boats With male quick connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 20a Box Dimensions: 1"H x 3"W x 5"L WT: 0.03 lbs UPC: 632085070571

Read more less

5025 ST Blade Fuse Block with Cover - 6 Circuit with Negative Bus Features: Clear insulating cover with label recesses accept Small Format Labels Cover Satisfies ABYC/USCG requirements for insulation Tin-plated copper buses and fuse clips give 30 Amperes rating per circuit Accepts ATO and ATC fast acting blade fuses 20 write-on circuit labels included WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

2002 PowerPost High Amperage Cable Connector 5/16" Stud Insulated single stainless steel stud terminates multiple large conductors.Features: Connects high amperage cables securely Stud dimensions: 5/16" x 7/8" Base Material is PBT UL94 V0 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less
