MasterShunt 500 CZoneMasterShunt is the heart of every battery powered energy system. This integrated battery monitor shares information about the battery bank with other MasterBus, CZone or NMEA 2000 enabled devices such as battery chargers, inverter/chargers and displays. No surprises: allowing complete automation of your system, MasterShunt improves comfort, prolongs battery life and extends your runtime.The MasterShunt 500 provides all information needed for monitoring your battery bank and control of your system, such as voltage, current, state of charge and time remaining. All information is made available to the system by a single MasterBus or CZone cable. Extremely accurate measurement of current flow over state of charge enables the MasterShunt to precisely determine the time remaining.Programmable events and an integrated real time clock make it possible to fully automate your system. Examples are to start your generator automatically when the battery bank is low (or just delaying at night!), or to automatically generate a warning at a certain depth of discharge. The proven MasterShunt design has been upgraded to obtain an even higher level of accuracy and control. Taking into account battery specific parameters, MasterShunt takes reading accuracy to a whole new level.The MasterShunt 500 CZone allows freedom of choice with regards to fuse type, rating and location. The battery monitor is supplied with an internal bus bar, to be used in situations where an external fuse holder is selected. In case the MasterShunt is installed close to the battery, the bus bar may be replaced by either an ANL type or Class T main fuse, saving both space and cost.Features: MasterBus, CZone and NMEA 2000 communication. Fits in a CZone system including setup tools and configuration file. Digital shunt providing the energy system with extensive information and historical data. Very accurate and reliable determination of State of Charge (SOC). Service mode prevents memory loss during system maintenance. Realistic and precise indication of the time remaining. For higher current, multiple MasterShunt models may be installed in parallel. MasterConnect system makes connecting to the DC Distribution product very easy. Straight forward, easy to install. Freedom of choice for fuse type, rating and location. Suitable for T-fuse and ANL-fuse (to be ordered separately). Robust housing with isolation of the DC connections. Applications:Any application in marine, mobile, industrial, infrastructure where batteries need to be monitored for increased reliability, battery life, comfort and runtime. Owner's Manual (pdf)

Read more less

Digital Multi Control 200/200AThis panel is intended both for Multis and Quattros. It allows PowerControl and PowerAssist current limit setting for two AC sources: a generator and shore side current for example. Setting range: up to 200 Amps. The brightness of the LEDs is automatically reduced during night time.Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

SmartPlug/15 AMP Cordset - 4'This 30 AMP Female SmartPlug to 15 AMP Male Standard Wall Plug (3-pin connector) cordset comes with a Cool Blue LED Power indicator light that glows when power is on.  This cord set provides a super flexible cord that can be tightly coiled even in cold weather. Features: Multi-Point Locking System – Side clips lock the plug body securely into the inlet which eliminates any stress on the electrical connection from the movement of the power cord. Weatherproof Seals - Silicone gaskets installed in the interior of the plug body eliminate any water penetration when plug is connected to inlet. Technical Specifications: Length - 4' Color - Orange Boatside Connection - 30 AMP/115 V Female SmartPlug Dockside Connection - 15 AMP/115 V Male Standard Wall Plug *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Voltage: 115 Type: Cordset Length: 4' Amperage: 30/15 Box Dimensions: 4"H x 10"W x 13"L WT: 2.55 lbs UPC: 682500440458 Brochure (pdf)

Read more less

OLED Voltmeter - RoundThe OLED (Organic LED) Voltmeter is designed to withstand constant vibration and the rigors of a marine environment. Monitors voltage on a bright, waterproof, daylight readable OLED screen. High contrast and resolution make this screen visible from a wide viewing angle, even with polarized sunglasses. Reverse polarity protected. Constructed of injection molded nylon with terminal spade contacts. Installation is as easy as drilling a 1-1/8" hole, inserting the socket body, tightening the locking nut, and connecting the wires. Also fits Sea-Dog® Power Socket Shell (426100) and Mounting Bracket (426105). Input 8-60VDC. IP66 rating.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

BF30 Female Connector/Gasket Kit This SmartPlug service kit provides electrical components, hardware and gaskets. Compatible With:BF30 SmartPlug Features: Ease of Use – Easily replaces missing or damaged pieces Interchangeable with SmartPlug Connectors *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Parts Box Dimensions: 4"H x 5"W x 8"L WT: 0.2 lbs UPC: 682500440397

Read more less

Combo Kit with ELCI Sensor & 30 Amp Breaker Non-Metallic Door - WhiteFeatures: White Sensor 30 Amp Breaker WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Type: Misc Box Dimensions: 6"H x 6"W x 8"L WT: 2 lbs UPC: 682500440830 Brochure (pdf)

Read more less

7440 UL-489 Circuit Breaker - 5A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 5A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type: #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 5a Box Dimensions: 2"H x 3"W x 5"L WT: 0.3 lbs UPC: 632085074401

Read more less

7456 UL-489 Circuit Breaker - 15A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 15A AC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 5000A Specifications: Amperage: 15a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074562

Read more less

7441 UL-489 Circuit Breaker - 10A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 10A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 10a Box Dimensions: 2"H x 3"W x 5"L WT: 0.25 lbs UPC: 632085074418

Read more less

PowerHub 1800A Clean, Green, Backup Power SolutionThe Xantrex PowerHub is a combination of an inverter/charger module capable of delivering up to 1800 watts of household power. It is the first backup power solution to operate with solar and wind inputs. Power from a generator or the utility grid can also be used with the PowerHub system to recharge its batteries. The PowerHub provides an affordable, high-output, primary power solution for an off-grid cottage or cabin, as well as backup power for grid-connected homes when the power goes out. It is scalable up to 400 amp-hours of energy, allowing customers to build their system based on their power requirements.Features: Never worry about running out of power – renewable power sources, solar and wind, sustain the PowerHub’s battery charge indefinitely An excellent alternative to a generator – designed for indoor use, with no fuel, fumes or noise Add it to a grid-tie solar energy system for backup power Modified sine wave inverter/charger with battery box The battery box stores up to 200 amp-hours of battery power (single battery box included; batteries purchased separately) A second battery may be connected to double the battery capacity (additional battery box and batteries sold separately) Designed to include a generator as part of the system; generator power can pass through the unit to the AC outlets, and recharge the batteries Integrated transfer switch 40-amp three-stage charger Four AC outlets with hardwire option Two DC inputs for solar and/or wind connections Full-feature LED display for system monitoring WARNING: This product can expose you to chemicals including Diisononyl Phthalate (DINP) which is known to the State of California to cause cancer, and Di-isodecyl Phthalate (DIDP) which is known to the State of California to cause reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Inverter Cont. Output Wattage: 1440w Charger Input - Voltage: 120v Charging Banks: 1 Charger Output - Amps: 40a AC Connection Type: GFCI Outlet DC Connection Type: Hardwire GFCI: Yes Outlet Qty: 2 Duplex GFCI Inverter Surge Rating: 2880w Inverter Input Voltage: 12v Inverter Output Voltage: 120v Waveform: Modified Sine Wave Charger Output Voltage: 12v Box Dimensions: 17"H x 19"W x 24"L WT: 66.45 lbs UPC: 715535114626

Read more less

12A Non-Isolated Step-Down 24VDC-12VDC Converter - Heavy Duty ApplicationsThis high efficiency switch-mode step-down DC-DC converter converts an input voltage of 24 VDC nominal (range 20 VDC to 35 VDC) to a highly regulated output voltage of 12 VDC nominal (13.8 VDC) at 12 Amps. The SDC-15 DC-DC converter is non-isolated (no galvanic isolation between input and output) and meant for use in negative ground systems. Features include overvoltage/short-circuit protection, temperature compensated current limit, output-side overvoltage protection, input-side overvoltage/ transient protection and input-side reverse polarity protection. The SDC-15 DC-DC converter is designed for heavy duty applications.Features: Advanced switchmode design Mount in almost any location Compact and light weight Reverse polarity protection High efficiency Cycle by cycle current limiting circuit Overvoltage protection Short circuit protection Specifications: Input: 20-35 VDC Output: 13.8 VDC Amps: 12 Amps Weight: 2 (lbs) Weight: 0.9 (kg) Dimensions: 7.75 x 5 x 2.5 (in) Dimensions: 19.7 x 12.7 x 6.4 (cm) Warranty: 2 Year Limited Applications: Earth moving equipment Heavy trucks Buses Marine vehicles CB radios 12 Volt lighting systems AM/FM sound systems WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

60 Series Alternator - Saddle Mount(Dual Foot) - 100A - 12VFeatures: 100A 12V Saddle Mount (Dual Foot) 3.15"  Single Deep Vee Pulley Isolated Ground Hitachi-Style Mounting; Typical for Yanmar, Westerbeke, Lehman & Perkins-Sabre Engines This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Owner's Manual (pdf)
