Heavy Duty Lugs - 6 Gauge Wire - 3/8" Post - 2-PackCable Gauge: 6Screw Size: 3/8" ANCOR Marine Grade™ lugs are manufactured from heavy duty annealed tinned copper, providing for maximum current flow 100% tin plated copper resists corrosion from salt and moisture Seamless barrel design allows for maximum strength when crimped Closed end design seals out moisture so cables stay dry and corrosion free WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Lugs Post Size: 3/8" Package Qty: 2 Heat Shrink: No Gauge: 6 AWG Box Dimensions: 1"H x 1"W x 2"L WT: 0.1 lbs UPC: 091887252088 Quick Guide (pdf)

Read more less

MultiPlus Inverter/Charger 12VDC - 3000VA - 120VAC with 120AMP Battery Charger - 50AMP Transfer Switch Features: Multifunctional -The MultiPlus, as the name suggests, is a combined inverter and charger in one elegant package. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology, plus multiple system integration features. Unique PowerAssist feature - The MultiPlus will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery Uninterrupted AC power (UPS function) -  In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. Virtually unlimited power thanks to parallel operation -Up to 6 Multis can operate in parallel to achieve higher power output. Three-phase or split phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split phase capabilities. Remote Monitoring and Control - Monitor and control your MultiPlus and system or systems locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your MultiPlus to setting a Geofence for-hire vehicles and more... Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 94-140v Charger Output - Amps: 120a Charger Output Voltage: 12v Charging Banks: 1+1 Inverter Cont. Output Wattage: 3000w Inverter Input Voltage: 9.3-17v Inverter Output Voltage: 120v Outlet Qty: None Box Dimensions: 13"H x 14"W x 18"L WT: 49.5 lbs UPC: 8719076023968 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Isolation Transformer 4500W Auto 115/230VSafety and prevention of galvanic corrosion - The Isolation Transformer eliminates any electrical continuity between AC shore power and the boat. It is essential for safety and eliminates the need for galvanic isolators and polarity alarms.Safety is taken for granted in the case of a normal onshore installation. A circuit breaker or a GFCI (Ground-Fault Circuit Interrupter) will trip in the event of a short circuit or current leakage to ground. Connecting the ground wire of the shore-side supply to the metal parts of the boat will result in galvanic corrosion (see below). Bringing only the live and neutral wire on board results in an unsafe situation because GFCIs will not work, nor will a fuse blow in case of a short circuit to a metal part on the boat.Galvanic corrosion occurs when two dissimilar metals in electrical contact are simultaneously exposed to an electrically conducting fluid. Seawater and, to a lesser extent, fresh water are such fluids. In general, the more active alloy of the couple corrodes preferentially while the less active (more noble) material is cathodically protected. The rate of galvanic corrosion is a function of several variables including area ratios, conductivity of the fluid, temperature, nature of the materials, etc.It is a misunderstanding that galvanic corrosion occurs only in metal and aluminium hulls. In fact it can occur on any boat as soon as a metallic part (the shaft and propeller) is in contact with water. Galvanic corrosion will quickly dissolve your sacrificial anodes, and attack the shaft, propeller and other metal parts in contact with water as soon as the boat is connected to the shore -side supply.It might therefore be tempting not to connect the ground conductor: this is however e xtremely dangerous because GFCIs will not work nor will a fuse blow in case of a short circuit to a metal part on the boat.The best solution to avoid galvanic corrosion and at the same time prevent any uns afe situation is to install an Isolation Transformer to connect to the shore-side supply.The Isolation Transformer eliminates any electrical continuity between shore power and the boat. The shore power is fed to the primary side of the transformer and the ship is connected to the secondary.The Isolation Transformer completely isolates the boat from the shore ground. By connecting all metal parts to the neutral output on the secondary side of the transformer, a GFCI will trip or a fuse will blow in case of a short circuit.Soft start is a standard feature of a Victron Energy isolation transformer. It will prevent the shore power fuse from blowing due to the inrush current of the transformer, which would otherwise occur.It is also recommended, for optimal safety, to connect the secondary neutral of the transformer to ground when the boat is out of the water.4500 Watt Auto 115/230 V - This model will automatically switch to 115 V or 230 V supply, depending on input voltage.Supply 88 V – 130 V: switches to 115 V supplySupply 185 – 250 V: switches to 230 V supply range.Note: The AC input voltage is raised by 1:1.05 ratio at the AC output.Please contact your dealer for any returns, repairs or support issues related to this product. Owner's Manual (pdf)Brochure (pdf)

Read more less

BI-200 Battery IntegratorCharging multiple battery banks without the use of diode isolators dictates that the batteries be connected or “integrated” only whenever a charge voltage is present so that they may be charged simultaneously, then disconnected or “isolated” when the charge voltage is no longer present to allow for selective discharge and avoid having the secondary or standby battery drain into the primary battery.Battery integrators perform this function automatically, acting as a “smart” switch to connect independent battery banks only when a charging voltage is present. Otherwise, they are isolated, and discharge between banks is prevented.The Battery Integrator causes no voltage drop in the charging system, while the multiple batteries are charged as a single bank whenever a charging source of approximately 13.2 VDC or 26.4 VDC or greater is present (depending on the model).When the alternator or charger is off or a large load causes the voltage to drop below the disconnect point, the unit breaks the common tie between the banks. This allows selective battery discharge and prevents the “dumping” of a higher-charged bank into a lower-charged bank. The unit may also be remotely activated to connect other batteries through the key starter or a manual switch to provide an added “boost” from the secondary battery whenever the starter is engaged and the unit senses there is sufficient voltage in that battery to provide an assist.Features: Enables charging of two separate banks without voltage drop yet maintains 100% isolation at all other times. For systems of three banks or more, an additional unit must be installed for each additional bank Heavy-duty silver-plated contactor, continuous duty rated to 100 Amps or 200 Amps depending on model Voltage sense circuits, epoxy-encapsulated, and heavy-duty continuous-rated solenoids are all designed for use in marine environments Has ignition protection rating Easy three-wire hookup for two bank systems (BATT +, BATT +, GROUND) Terminal for optional wiring of a remote light indicating when battery banks are integrated Optional internal connections can be wired through the key starter or manual override switch, tying battery banks together for an extra boost during engine start Specifications: Terminals: Battery Connections: 5/16 in. copper alloy stud Approvals: CE Marked Dimensions (H x W x D): 200 Amp Models: 4 x 3.3 x 4.1 inches Weight: 2 lb. Operating Temperature: Control: -40 to +85 degrees C and Solenoid: -28 to +48 degrees C Voltage: 12 VDC Battery Integration Point: 13.2 VDC     Battery Disconnect Point: 12.8 VDC Max. Continuous Current: 200 Amps     Peak Maximum Current: 600 Amps

Read more less

MultiPlus-II 12/3000 120-50 2X 120VThe MultiPlus-II combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A).It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.PowerAssistThe MultiPlus-II will prevent overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shore side supply with power taken from the battery.ESS: Energy Storage SystemsThe MultiPlus-II is the key component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters. For examples and more detailed information see the ESS (Energy Storage System) manual.Uninterrupted AC power (UPS function)In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.Remote Monitoring and ControlWhen coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, from adjusting your Multi to auto-starting a backup generator and more.Specifications:  PowerControl & PowerAssist: Yes Transfer Switch: 50A Maximum AC Input Current: 50A (each leg) Inverter Specifications: DC Input Voltage Range: 9,5 – 17 V Output: Output Voltage 120 VAC ± 2% / Frequency 60 Hz ± 0,1% (1) Continuous Output Power at 25°C (3): 3000 VA Continuous Output Power at 25°C: 2400 W Continuous Output Power at 40°C: 2200 W Continuous Output Power at 65°C: 1700 W Maximum Apparent Feed-In Power: 2500 VA Peak Power: 5500 W Maximum Efficiency: 93% Zero Load Power: 13W Zero Load Power in AES Mode: 15W Zero Load Power in Search Mode: 4W Charger Specifications: AC Input (Split Phase): 180-280 VAC 45 – 65 Hz AC Input (Single Phase): 90-140 VAC 45 – 65 Hz Charge Voltage 'Absorption': 14,4 V Charge Voltage 'Float': 13,8 V Storage Mode: 13,2 V Maximum Battery Charge Current (4): 120 A Battery Temperature Sensor: Yes General Specifications: Auxiliary Output: 35 A Each leg External AC Current Sensor (optional): 100 A Programmable Relay (5): Yes Protection (2): a – g VE.Bus Communication Port: For parallel, split phase and three phase operation, remote monitoring and system integration General Purpose Com. Port: Yes, 2x Remote On-Off: Yes Operating Temperature Range: -40 to +65°C (-40 – 150 °F) (fan assisted cooling) Humidity (Non-Condensing): Max 95% Enclosure Specifications: Material & Color: Steel, blue RAL 5012 Protection Category: IP22 Battery-Connection: 2x2 M8 bolts 120 V AC-Connection: Screw terminals 21 mm² (4 AWG) Weight: 22 kg Dimensions (hxwxd) (mm): 578 x 275 x 148 Standards: Safety: EN-IEC 60335-1, EN-IEC 60335-2-29,  Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 *Note: For a short period of time this product was called MultiGrid-II.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

MultiPlus-II 12/3000 - 120-50 - 120VThe MultiPlus-II combines the functions of the MultiPlus and the MultiGrid. It has all the features of the MultiPlus, plus an external current transformer option to implement PowerControl and PowerAssist and to optimize self-consumption with external current sensing (max. 32A).It also has all the features of the MultiGrid with built-in anti-islanding and an increasingly long list of country approvals.PowerAssistThe MultiPlus-II will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload occurs. The second level will boost the output of a generator or shoreside supply with power taken from the battery.ESS: Energy Storage SystemsThe MultiPlus-II is the critical component in a Victron ESS system, providing the flexibility to combine with MPPT Solar Chargers or Grid-tie PV Inverters. For examples and more detailed information see the ESS (Energy Storage System) manual.Uninterrupted AC power (UPS function)In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.Remote Monitoring and ControlWhen coupled with a GX device (e.g. Cerbo GX) you can monitor and control your Multi and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, from adjusting your Multi to auto-starting a backup generator and more. Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

MultiPlus-II 48/3000 35-50 120VThe MultiPlus-II is a multifunctional inverter/charger with all the features of the MultiPlus, plus an external current sensor option, which extends the PowerControl and PowerAssist functions to 100A.PowerControl & PowerAssist - Boosting the Capacity of the Grid or a Generator A maximum grid or generator current can be set. The MultiPlus-II will then take into account other AC loads and use whatever is extra for battery charging, thus preventing the generator or grid from being overloaded (PowerControl function).PowerAssist takes the principle of PowerControl to a further dimension. Where peak power is so often required only for a limited period, the MultiPlus-II will compensate for insufficient generator, shore, or grid power with power from the battery. When the load reduces, the spare power is used to recharge the battery.Solar Energy: AC Power Available Even During a Grid Failure The MultiPlus-II can be used in off-grid as well as grid-connected PV and other alternative energy systems. It is compatible with both solar charger controllers and grid-tie inverters.Two AC Outputs The main output has no break functionality. The MultiPlus-II takes over the supply to the connected loads in the event of a grid failure or when shore/generator power is disconnected. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.The second output is live only when AC is available on the input of the MultiPlus-II. Loads that should not discharge the battery, like a water heater, for example, can be connected to this output.Virtually Unlimited Power Thanks to Parallel, Split Phase, and Three Phase Operation Up to 6 Multis can operate in parallel to achieve higher power output. Six 48/3000/35 units, for example, will provide 15 kW / 18 kVA output power with 210 Amps charging capacity.In addition to parallel connection, two units of the same model can be connected for a 240V split-phase output, and three units of the same model can be configured for three-phase output. But that’s not all: up to 6 sets of three units can be connected in parallel per phase.On-Site System Configuring, Monitoring, and Control Settings can be changed in a matter of minutes with VEConfigure software (computer or laptop and MK3-USB interface needed).Several monitoring and control options are available: Color Control GX, Venus GX, Octo GX, CANvu GX, laptop, computer, Bluetooth (with the optional VE.Bus Smart dongle), Battery Monitor, Digital Multi Control Panel.Remote Configuring and Monitoring Install a Color Control GX or other GX product to connect to the internet. Operational data can be stored and displayed on our VRM (Victron Remote Management) website, free of charge. When connected to the internet, systems can be accessed remotely, and settings can be changed.Specifications:  PowerControl & PowerAssist: Yes Transfer Switch: 50A Maximum AC Input Current: 50A Inverter Specifications: DC Input Voltage Range: 38 -66 V Output: Output Voltage 120 VAC ± 2% / Frequency 60 Hz ± 0,1% (1) Continuous Output Power at 25°C (3): 3000 VA Continuous Output Power at 25°C: 2400 W Continuous Output Power at 40°C: 2200 W Continuous Output Power at 65°C: 1700 W Peak Power: 5500 W Maximum Efficiency: 95% Zero Load Power: 11 W Zero Load Power in AES Mode: 7 W Zero Load Power in Search Mode: 2 W Charger Specifications:AC Input: Input Voltage Range 90-140 VAC / Input Frequency: 45 – 65 HzCharge Voltage 'Absorption': 57,6 VCharge Voltage 'Float': 55,2 VStorage Mode: 52,8 VMaximum Battery Charge Current: 35 ABattery Temperature Sensor: YesGeneral Specifications: Auxiliary Output: 32 A External AC Current Sensor (optional): 100 A Programmable Relay: Yes Protection: a – g VE.Bus Communication Port: For parallel, split-phase, and three-phase operation, remote monitoring, and system integration General Purpose Com. Port: Yes, 2x Remote On-Off: Yes Operating Temperature Range: -40 to +65°C (-40 – 150 °F) (fan-assisted cooling) Humidity (Non-Condensing): Max 95% Enclosure Specifications: Material & Color: Steel, blue RAL 5012 Protection Category: IP22 Battery-Connection: M8 bolts 120 V AC-Connection: Screw terminals 13 mm² (6 AWG) Weight: 19 kg / 42 lb. Dimensions (hxwxd): (mm) 572 x 277 x 147 / (inch) 22.5” x 10.9” x 5.8” Standards: Listings: UL1741 pending Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, CSA 22.2 107.1-16 Emission, Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3 *Note: For a short period of time this product was called MultiGrid-IIPlease contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Red 1 AWG Battery Cable - Sold By The Foot Pacer's 1 AWG Marine Battery Cable meets and exceeds the most stringent specifications. This UL-approved marine cable is manufactured in the USA to ensure high quality.  Oftentimes, marine applications are in enclosed areas with sharp turns. Installation can become difficult. Pacer simplified this process by developing flexible yet tough marine cables. This 1 AWG marine battery cable is built to handle the harshest conditions. All our marine cable is made from Type III tinned copper. The copper resists corrosion and ensures the longevity of the cable.  It is then insulated with a durable and pliable PVC jacket. These things together make it the highest quality marine battery cable available. Features: Easy to strip, bend, and route Excellent flexibility with the durable properties of PVC Technical Specifications: Conductor - Annealed fine stranded tinned copper ASTM B172 Class K Insulation  -20 °C to 105 °C Flexible, Color Coded PVC Temperature Rating - 105 °C Dry, 75 °C Wet, 60 °C Oil Voltage Rating - 600V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil, and Moisture *Sold by the Foot Specifications: Color: Red Gauge: 1 AWG Length (Feet): Sold By The Foot Box Dimensions: 1"H x 1"W x 12"L WT: 0.1 lbs Brochure (pdf)

Read more less

Data Port Case/Inlet Only - White Cover with One Blank Plug & One Open PortSmartPlug data ports are the perfect complement to SmartPlug's stainless shore power inlets. It offers the same look and quality as marine-grade stainless steel components. This particular data port case has one blank plug and one open port.*All single data port inlets are supplied with one connector and one blank insert.Features: Weatherproof Seal, which seals against a closed-cell foam gasket in the inlet lid Locks into the edge of the SmartPlug mounting flange Only requires 4 screws to mount Silicone gasket included/no messy caulk Specifications: Material: Non-metallic Color: White Quick Guide (pdf)

Read more less

Weather Door - Vertical SmartPlug receptacles can be installed in industry standard outdoor electrical boxes when used in conjunction with our spring loaded weather doors.  SmartPlug plugs self-align with these receptacles and have an automatic lock system when engaged.  The push in design provides self cleaning for the pins and clips which insures clean power transfer.Compatible With:SmartPlug 30 and 50  AMP Receptacles Features: Weatherproof cover design Vertical positioning  *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Parts Box Dimensions: 3"H x 3"W x 6"L WT: 0.3 lbs UPC: 682500440953 Brochure (pdf)

Read more less

10W Battery Maintainer Portable SunChargerThe SC-10 SunCharger maintains the charge in any 12V battery using energy from the sun. Panel connects through 12V power plug or directly to battery with ring terminals. Perfect for battery maintenance when your car, boat, truck, ATV or RV is in storage.Features: Maximum efficiency Prevents back flow of current from the battery to the panel Direct charging – no need for additional Charge Controller Semi-flexible panel construction Rugged, weather-proof design 10' cable attached 1' cable with 12V power plug  1' cable with ring terminals for battery Specifications: Weight - 2.2 (lbs) Weight - 0.99 (kg) Dimensions - 12 x 15 x 0.53 (in) Dimensions - 30.5 x 38.1 x 1.35 (cm) Warranty - 2 Years (Canada/US) Applications: Recreational Vehicles Boats ATVs Cars Trucks WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

1000W Pure Sine Wave Inverter - 24VPST Series (120 VAC)This high efficiency DC-AC inverter converts 24 Volts DC to 1000 Watts of pure sine-wave AC power at 120 Volts, 60 Hz. The unit comes with pin-type battery cable lugs. Features include overload protection, low battery alarm / shut down, low idle power draw of less than 0.85 Amps. AC power is available from a NEMA-20R GFCI duplex outlet on the front panel. Safety certified to UL standards.Features: High efficiency Temperature controlled cooling fan – reduces energy consumption Low interference Wide operating DC input range: 21.0 - 33.0 VDC Commercial grade design suitable for heavy duty loads, long periods of continuous operation & for emergency back up UPC – Universal Protection Circuit: low voltage, over voltage, over temperature, over load and short circuit Low idle power draw Dual GFCI protected AC outlets Optional remote control (sold separately): Model RC-15A Comes with pin-type battery cable lugs Safety certified to UL standards, FCC compliant Specifications: Input: 24 VDC Output: 120 VAC Watts: 1000 Surge: 2000 Watts Remote Control: RC-15A sold separately Weight: 8.8 (lbs) Weight: 4.0 (kg) Dimensions: 9.37 x 15.63 x 3.23 (in) Dimensions: 238 x 397 x 82 (mm) Safety: ETL to UL Standard Warranty: 2 Year Limited Applications: Service vehicles Mobile Offices Boats Recreation Vehicles, Camping Telecommunication Field work / Construction sites Solar power systems Emergency backup power Home electronics: TV, VCR, video games Computers, printers WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Inverter Cont. Output Wattage: 1000w Outlet Qty: 2 Duplex GFCI Inverter Input Voltage: 24v Waveform: Pure Sine Wave Box Dimensions: 6"H x 12"W x 18"L WT: 10.4 lbs UPC: 622988072185 Owner's Manual (pdf)Brochure (pdf)
