Electrical

300W Pure Sine Wave Inverter - 12VPST Series (120 VAC)This high efficiency DC-AC inverter converts 12 Volts DC to 300 Watts of pure sine-wave AC power at 120 Volts, 60 Hz. The unit comes with detachable cable with 12V plug adaptor and cable with battery clamps. Features include overload protection, low battery alarm / shut down, low idle power draw of less than 0.5 Amps. AC power is available from a NEMA-20R GFCI duplex outlet on the front panel. Safety certified to UL standards.Features: High efficiency Temperature controlled cooling fan – reduces energy consumption Low interference Wide operating DC input range: 10.5 - 16.5 VDC LED indicators for power and protections Low idle power draw Dual GFCI protected AC outlets Commercial grade design suitable for heavy duty loads, long periods of continuous operation & for emergency back up UPC – Universal Protection Circuit: low voltage, over voltage, over temperature, over load and short circuit Detachable cable with 12V plug adapter Detachable cable with battery clamps Safety certified to UL standards, FCC compliant Specifications: Input: 12 VDC Output: 120 VAC Watts: 300 Surge: 500 Watts Outlets: 2 Weight: 3.46 (lbs) Weight: 1.57 (kg) Dimensions: 6.1 x 9.69 x 2.58 (in) Dimensions: 155 x 246 x 65.5 (mm) Safety: ETL to UL Standard Warranty: 2 Year Limited Applications: Service vehicles Mobile Offices Boats Recreation Vehicles, Camping Telecommunication Field work / Construction sites Solar power systems Emergency backup power Home electronics: TV, VCR, video games Computers, printers WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Inverter Cont. Output Wattage: 300w Outlet Qty: 2 Duplex GFCI Inverter Input Voltage: 12v Waveform: Pure Sine Wave Box Dimensions: 4"H x 8"W x 12"L WT: 4.9 lbs UPC: 622988072130 Owner's Manual (pdf)Brochure (pdf)

Read more less

50 AMP Inlet and Female Cord Connector Combo - White The SmartPlug Combo Kit includes both a 50 AMP 125/250 V Male inlet connector and Female Cord End Connector. The Female Cord End Connector is designed to be used with your existing cord.  This package offers superior performance and ease of use. Features: Eliminates Overheating – Increased pin and clip surface area greatly improves electrical conductivity during high amperage demand. Ease of Use – No twist required, the unique plug body shape and push-in design means it only goes in the right way every time – even in the dark. Multi-Point Locking System – Side clips and inlet cover lock the plug body securely into the inlet which eliminates any stress on the electrical components by movement of the power cord. Weather Resistant Seals – Silicone gaskets installed in the inlet cover and the plug body eliminates moisture penetration. Quick and Easy Installation. *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

30 AMP Male Non-Metallic Inlet Cover - WhiteSmartPlug’s 30 AMP 125 V inlets provide 20X’s more electrical contact area eliminating the overheating conditions seen with twist-type connectors.  The solid sleeve connection and weatherproof seal makes it a preferred option.  The mounting flange holes match existing inlets so it can be easily installed to replace the old twist-type inlet products in minutes. Features: Reduces Overheating – Increased pin & clip surface area greatly improves electrical conductivity during high amperage demand. Ease of Use – No twist required, the unique plug body shape and push-in design means it only goes in the right way every time-even in the dark! Multi-Point Locking System – Side clips lock the plug securely into the inlet which eliminates any stress on the pins from movement of the power cord. Weatherproof Seals – Superior gaskets installed in the inlet cover and interior of the plug body eliminates moisture penetration. Quick and Easy Installation – Inlet mounting flange holes match twist-type holes for an installation that is typically finished in 30 minutes. *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

30 AMP Male Non-Metallic Inlet Cover - GreySmartPlug’s 30 AMP 125 V inlets provide 20X’s more electrical contact area eliminating the overheating conditions seen with twist-type connectors.  The solid sleeve connection and weatherproof seal makes it a preferred option.  The mounting flange holes match existing inlets so it can be easily installed to replace the old twist-type inlet products in minutes. Features: Reduces Overheating – Increased pin & clip surface area greatly improves electrical conductivity during high amperage demand. Ease of Use – No twist required, the unique plug body shape and push-in design means it only goes in the right way every time-even in the dark! Multi-Point Locking System – Side clips lock the plug securely into the inlet which eliminates any stress on the pins from movement of the power cord. Weatherproof Seals – Superior gaskets installed in the inlet cover and interior of the plug body eliminates moisture penetration. Quick and Easy Installation – Inlet mounting flange holes match twist-type holes for an installation that is typically finished in 30 minutes. *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Main + 8 Positions(1) 30A Double Pole Circuit Breaker(5) 15A Single Pole Circuit Breaker(1) 8247 AC Digital Multimeter w/ Alarm Red reverse polarity indicating LED All hot, neutral and safety ground buses installed, fully pre-wired All circuit label positions are backlit on standard panels - No kit required "ON" indicating LEDs installed in all circuit positions Maximum panel amperage - 50 Amperes MIL-C-5541C or equivalent immersion undercoating for lifetime corrosion resistance Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Industry standard height and width Countersunk mounting holes throughout Detailed installation instructions and cutout template included Includes set of 30 common Large Format Labels Over 500 individual Labels available WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Voltage: 120v Max Breaker Quantity: 8 AC/DC: AC Box Dimensions: 5"H x 9"W x 11"L WT: 3.5 lbs UPC: 632085084066 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

A Series Red Toggle Panel Mount Circuit Breaker - Single Pole 15AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 15a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.15 lbs UPC: 850074331025 Brochure (pdf)

Read more less

Terminal Block 20A - 4 CircuitFeatures: Marine Grade Materials Ensure Long Lasting Reliability In Harsh Environment Applications. Screw Terminal Connection Pairs Provide One Input And One Output. Screw Connected To Separate Copper Alloy Bus Bars For Each Matching Connecting Pair. 125V AC or DC Rated Easily Supports 12, 24, 36, 48 Vdc Systems, As Well As 120/240 VAC Applications. Specifications: Type: Electric Box Dimensions: 2"H x 3"W x 10"L WT: 0.15 lbs UPC: 850074331360

Read more less

A Series Black Toggle Panel Mount Circuit Breaker - Single Pole 5AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 5a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.1 lbs UPC: 850067590996 Brochure (pdf)

Read more less

A Series White Toggle Panel Mount Circuit Breaker - Single Pole 5AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 5a Box Dimensions: 2"H x 4"W x 4"L WT: 0.15 lbs UPC: 850074331179 Brochure (pdf)

Read more less

A Series White Toggle Panel Mount Circuit Breaker - Single Pole 15AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 15a Box Dimensions: 2"H x 4"W x 4"L WT: 0.2 lbs UPC: 850074331100 Brochure (pdf)

Read more less

A Series Red Toggle Panel Mount Circuit Breaker - Single Pole 5AFeatures: Easily Mounts In Standard Panels, accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws. AC & DC Rated to cover a wide range of system application needs. Toggle-Style Actuator for easy on/off switching control, combined with circuit protection. High Voltage Rating easily supports 12 and 24 Vdc applications while offering advanced protection for 36 and 48 Vdc applications. High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current. High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power. Toggle Guard and Panel Plug accessories pair with A-Series breakers to protect against accidental switching and fill unused panel slots. Specifications: Amperage: 5a Type: Electric Box Dimensions: 2"H x 4"W x 4"L WT: 0.2 lbs UPC: 850074331087 Brochure (pdf)

Read more less

32-12-35 DC ConverterConvert 20-50 VDC input to 12 VDC negative ground output for powering communication and navigation equipment on negative ground systems. (See Isolated Series for positive ground applications.)Features: Excellent Regulation: Output voltage maintained within 1% under all line and load conditions within the rating The heat generated by semi-conductors is extracted and dissipated by large heat sink fins that maximize air contact for cool operation and the long life of components Polyurethane conformal coating on PC boards and corrosion-resistant anodized aluminum cases with heavy-duty shock mounts assure survival in hostile environments Numerous Converter & Load Protection Circuits: Current limiting Automatic thermal shutdown Short circuit proof Reverse polarity Overvoltage protection Carries CE mark Specifications: Input Voltage: 20-50 Output Voltage: 13.6 Output Amps (Intermittent): 35 Output Amps (Continuous): 30 Case Size (H x W x D): 6.0 x 4.7 x 16.0 inches (15.2 x 11.9 x 40.6 centimeters) Weight: 12 lb. (5.5 kg) Output: 13.6 VDC (internally adjustable 12.6 -14.5) or 24.5 VDC (or specify) Ripple: 150 mV P-P maximum Regulation: 1% Line/Load Switching Frequency: 40 kHz Efficiency: 85% – Typical. Isolation: Output/Chassis; Input/chassis: 250 VDC Duty Cycle Ratings*: Intermittent: 20 minutes max on time, 20% duty. current limit set at approx. 105% of intermittent rating. Continuous: 24 hours, 100% duty *24-12-3: 2-minute max. on time Idle Current: Less than 100 mA (including power “ON” light) Operating Temp Specifications: 0-50 degrees C, Derate Linearly From 100% @ 40 degrees C To 50% @ 50 degrees C. Thermal shutdown @ 70 degrees C Case Temperature Model 24-12-3: Full output -25 degrees to +30 degrees C; Derate linearly from 100% @ +30 degrees C to 45% @ +50 degrees C Mechanical Specifications: Powder-coated aluminum heat sink case Front panel terminal block Heavy-duty mounting flange Conformal coated PC board Options: Operation as a battery charger or parallel redundant operation* – derate to continuous duty rating (contact factory) Extreme vibration mounting kit. (Information below) Option: Extreme Vibration Mounting KitThe Extreme Vibration Mounting Kit is available to protect NEWMAR power converters from the extreme stresses of shock and vibration when mounted on high-vibration vehicles. The kit replaces the standard vibration kit provided with the unit. It fits into the unit’s mounting flange to act as a ‘super shock absorber’ for electronics in high-vibration applications. It is available to fit all NEWMAR units from 2 to 70 lbs. Specify KIT L for units that weigh 2–15 lbs. and Kit H for 16–7 lbs.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less
