Electrical

Spare key for m-series (mini) Switch (6005)WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Orion XS 12/12-50A DC-DC Battery Charger (for marine applications with VHF interference fixed)The Orion XS, engineered from the ground up, redefines DC-DC battery-to-battery charging. Ideal for dual battery systems charged by an intelligent alternator.This device not only ensures top-tier performance but also guarantees the safety of your system.Stay in charge with configurable input and output currents and rest assured that your Orion XS will run at full capacity up to 40°C. The 98,5% efficient aluminum circuit board technology means less heat, without the need for fans.As an integral part of your Victron system, the Orion XS offers full (remote) monitoring and control capabilities, giving you complete command of your device and system.Parallel to increasing output currentAn unlimited number of Orion XS devices can be connected in parallel, for easy output current scaling to meet system requirements.Smart alternator compatibilityWith its built-in engine running detection, the Orion XS guarantees the charger only draws power when the engine is running. It also helps retrieve a proper charge current from intelligent alternators as found in Euro 5 & Euro 6 engines.Adaptive charge algorithmThe Orion XS features customizable and preset charging algorithms for lithium and lead-acid batteries, ensuring optimal recharging, for both shallow and deep discharges.Complete electronic protectionThe Orion XS comes equipped with comprehensive electronic protection against overload, short circuits, and excessive temperatures. It will automatically reduce the output power when the maximum product temperature is reached.Low-temperature shutdown & under voltage protectionTo prevent damage to lithium batteries, the charger will turn off automatically at low temperatures and when the input voltage drops below a user-configurable lockout value, protecting the starter battery from deep discharge.Dust & waterproofThe Orion XS is designed to withstand dust and water pollution and has an IP65 classification.Safely combine any alternator with any batteryWhen the engine is off, the Orion XS isolates the service battery, so no power is drawn from the starter battery. Turn the engine on.Smart has never looked so simpleWith multiple automated safety and efficiency features, the Orion XS is truly a smart addition to any vehicle or marine system with dual batteries. That doesn’t mean that it should be a complicated one. We made sure integrating and controlling are as simple as can be.Features: Fully configurable Efficient cooling Engine running detection Works with VictronConnect Intelligent charge algorithms Remote monitoring optional Specifications:5 Year WarrantyApplications: Professional Vehicles - As the world market leader in power supplies for ambulances, our decades of know-how translate into robust, professional systems for on the road. Marine - Coming from the world of marine power systems, customer feedback, and innovation has led us to offer the most complete range of onboard energy solutions. Please contact your dealer for any returns, repairs or support issues related to this product. Owner's Manual (pdf)Brochure (pdf)

Read more less

TRUEcharge™3 10A 3 Bank Battery Charger - 24VTRUEcharge3 battery chargers lead the industry with a small footprint and ultra-compact design. In addition to meeting global safety and regulatory standards, they feature low electrical interference and efficient power factor-corrected multistage charging. The TRUEcharge3 Chargers can be mounted in multiple positions thanks to their inherent drip-proof design characteristics. Unlike its predecessors, TRUEcharge3 is lithium-ion battery compatible.Designed for recreational and commercial applications worldwide, TRUEcharge3 accepts 90–265 Vac, and 47–63 Hz, which makes traveling abroad and handling poor-quality power a breeze. The easy-to-read display of the TRUEcharge3 24 V models can be enhanced with an optional remote panel. Each model has built-in protection against surges and spikes on the AC power line.Features: Microprocessor-controlled, multistage charging algorithms Settings for two and three-stage charging Battery-equalization feature Settings for flooded, gel, AGM, or lithium-ion batteries Equipped with parallel stacking (remote panel required) Ability to charge batteries drained to extremely low voltage Added quiet mode Protection Features: Reverse-battery polarity protection Drip-proof design DC over-voltage protection Over-temperature protection Circuit breaker protection Three-Stage ChargingMultistage charging ensures batteries receive optimum charging, but with minimal wear and tear, regulating the voltage and current delivered to the batteries in three automatic stages: Bulk: Replaces 70–80% of the battery’s state-of-charge at the fastest possible rate Absorption: Replenishes the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate Float: Voltage is reduced and held constant to prevent damage and maintain batteries at a full charge for the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate Power Factor Corrected (PFC) ChargingLess shore power is required for charging batteries, freeing up more usable AC power for running electrical devices and appliances and reducing the likelihood of tripping shore power breakers.Electrical Specifications (@ 25 degrees C unless otherwise noted): Output Current (nominal): 10 A  Output Voltage (nominal, depending on settings): Charge 28.4–31.0 Vdc; Float 26.8–27.6 Vdc; 32 Vdc DC Output Connections: Three AC Input Voltage: 90–265 Vac; 47–63 Hz 120 Vac, 230 Vac, 240 Vac nominal Temperature Compensation: Three settings  Charger Efficiency: > 80% Battery Type: Gel, Flooded, AGM, LiFePO4  Minimum Recommended Battery Bank Size: 20 Ah General Specifications: Operating Temperature Range: 0–60°C (32–140°F)  Storage Temperature -40–80°C (-40–176°F) Battery Connection: Three positive terminals and one negative terminal Dimensions (H x W x L): 70 x 170 x 250 mm (2.8 x 6.7 x 9.8”) Weight 2.2 kg (4.8 lb) Regulatory Approvals Meets CSA 60335-2-29, UL1564, IEC 60335-2-29, IP32 per EN.IEC 60529, FCC Part 158, Canada ICES-003 Class B emissions limits, ABYC A-31, and DOE/CEC energy efficiency compliant.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Output - Amps: 10a Charger Output Voltage: 24v Charging Banks: 3 Portable: No Box Dimensions: 5"H x 11"W x 13"L WT: 5.95 lbs UPC: 715535920890 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Energy Meter VM-3P75CT Single + 3-PhaseThe Victron VM-3P75CT energy meter is a standard device to measure the power and energy of single- and three-phase applications and calculates each phase's power values and broadcasts this over VE.Can or Ethernet with a high rate.  It has built-in Ethernet and VE.Can ports for connecting to a GX device and the split-core current transformers enable easy and quick installation without modifying existing wiring.The energy meter works out of the box (the firmware may need to be updated; details can be found in the Firmware Updates chapter) as a grid meter for systems with a MultiPlus and Quattro. Configuration (via VictronConnect) is only required for changing the role and manual IP configuration, rather than the default DHCP.  Its data is displayed on a GX device such as the Cerbo GX or Ekrano GX, as well as in VictronConnect and the VRM Portal.Specifications: Voltage connection: Direct Input voltage range L-N: 85 to 265VAC Input voltage range L-L:150 to 460VAC Frequency: 50/60Hz Current connection: Via current transformers (included - wire length 640mm (25.2in) Rated current: 75A VE.Can communication port: Two RJ45 connectors (VE.Can terminators included) Ethernet communication port: One RJ45 connector, Modbus UDP Refresh rate: 100ms Type: Self-power supply via L1-N Switch or circuit breaker: Required as a means of a disconnecting device - not included External fuse [1]: Required in the neutral conductor - 500mA, not included Consumption: 1.45W / 3.1VA Frequency: 50/60Hz Material & Color: Polycarbonate, blue (RAL5012) Voltage connection: Screw terminals 0.25 - 1.5mm2 (24 - 16AWG) Current transformer connection: Pluggable screw terminals (included) Protection category: IP20 Weight: 370g (including packaging) Dimensions: 90 x 71 x 59mm (3.5 x 2.8 x 2.3in) Indoor/outdoor usage: Indoor only Operating temperature: From -10 to +55 °C Storage temperature: From -20 to +70 °C Relative humidity: < 90% non-condensing Altitude: 2000m (6562ft) Mains supply voltage fluctuations: ±0.1Vin Overvoltage category: Cat. III Pollution degree: 2 What's In The Box? Victron VM-3P75CT with 3 input terminal blocks 3x Split-core current transformer, wired ready for connection Wire length: 640mm (25.3") VE.Can terminators (2-pieces) Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

CYRIX-CT 12/24V-120A Intelligent Battery CombinerThe Cyrix Battery Combiner is a microprocessor controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged) and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is that there is virtually no voltage loss so the output voltage of alternators or battery chargers does not need to be increased.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Orion-TR 48/24-16A (380W) Isolated DC-DC ConverterIsolated Model - separate in and out (-) leads Remote On/Off TerminalThe remote on/off terminal eliminates the need for a high current switch in the input wiring. The remote on/off can be operated with a low power switch or for example the engine run/stop switch. All Models Are Short Circuit Proof and Can Be Paralleled to Increase Output CurrentAn unlimited number of units can be connected in parallel.  High Temperature Protected The output current will reduce at high ambient temperatures.  IP43 Protection When installed with the screw terminals oriented downward.  Screw Terminals No special tools are needed for installation.  Input Fuse (not replaceable) On 12 V and 24 V input models only.  Adjustable Output Voltage Not intended for battery charging (consider using an Orion-Tr Smart for battery charging).Specifications: Input Voltage Range: 40-70 V Under Voltage Shut Down: 28 V Under Voltage Restart: 30 V Nominal Output Voltage: 24.2 V Output Voltage Adjust Range: 20-30 V Output Voltage Tolerance: +/- 0,2 V Output Noise: 2 mV rms Cont. Output Current at Nominal Output Voltage and 40 Degrees C: 16 A Maximum Output Current (10 S) at Nominal Output Voltage: 25 A Short Circuit Output Current: 40 A Cont. Output Power at 25 Degrees C: 430 W Cont. Output Power at 40 Degrees C: 380 W Efficiency: 89 % No Load Input Current (2): < 80 mA  Galvanic Isolation: 200 VDC between input, output, and case Operating Temperature Range: -20 to +55 Degrees C (derate 3 % per °C above 40 °C) Humidity: Max. 95 % non-condensing DC Connection: Screw terminals Maximum Cable Cross-Section: 16 mm² AWG6 Weight: 1.6 kg (3.5 lb) Dimensions (H x W x D): 130 x 186 x 70 mm (5.1 x 7.3 x 2.8 inch) Safety Standards: EN 60950 Emission Standard: EN 61000-6-3, EN 55014-1 Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2 Automotive Directive Standards: ECE R10-5 Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Charger Input - Voltage: 48v Charger Output - Amps: 16a Charger Output Voltage: 24v Box Dimensions: 4"H x 6"W x 9"L WT: 3.45 lbs UPC: 8719076038887 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

AC Rotary Switch Panel 65 Ampere 2 positions + OFF, 3 PolePoles: 3Voltage: 120/240vAmperage: 65Positions: 2 + OFF Switches 3 - 230 Volt AC sources Includes 9019 heavy duty industrial rated switch Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Red reverse polarity LED indicators Green power available LED indicators Compact solution when circuit protection is provided elsewhere WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Max Breaker Quantity: 2 +OFF Voltage: 240v Box Dimensions: 4"H x 9"W x 12"L WT: 1.8 lbs UPC: 632085083632 Owner's Manual (pdf)

Read more less

8 AWG Heat Shrink Ring Terminal - 3/8" Stud Size - 25 PackRing terminals are a trusted way to create an electrical connection. By using ring terminals, users don't need to worry about the connector coming off. The ring fits over a stud or screw and doesn't pull loose as other terminals may. Pink ring terminals are for 8 AWG wires. They are easy to use and offer long-term protection. Heat shrink ring terminals protect against the elements in the most challenging of environments. This makes them the best moisture protection available. Heat shrink ring terminals possess a heat-activated adhesive liner. This liner is built to provide a durable, rugged, environmentally sealed connection for 8 AWG wires. Selecting the correct ring terminal isn't always an easy task. Contact a Pacer expert with any questions that you may have.Features: Protects terminations from water, condensation, salt spray, and corrosion Added vibration protection in rugged environments Provides strain relief Translucent, adhesive-lined polyolefin tubing is a durable insulator that provides a seal that keeps out moisture and contaminants and prevents wire corrosion Conforms to automotive manufacturers’ specifications for wiring repairs Color-coded tubing with wire gauge imprint provides easy identification of the correct part for the job Compliances: UL CSA RoHS Characteristics: Shrink Ratio: Approx. 3:1 at 135 °C Operating Temp: -55 °C - 125 °C Vol. Resistivity: 1015 Ohm-cm3 Dielectric Strength: 900-V/mil Voltage Rating: 600-V Specifications: Stud Size: 3/8” Terminal Pad Width: 0.59” Package Size: 25 Specifications: Gauge: 8 AWG Heat Shrink: Yes Package Qty: 25 Post Size: 3/8" Type: Heat Shrink Box Dimensions: 1"H x 2"W x 3"L WT: 0.2 lbs UPC: 840248210140 Brochure (pdf)

Read more less

Blue 14 AWG Wire Ferrule - 8mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features: Prevent strand separation while minimizing strand breakage Insulated ferrules provide additional electrical insulation Increase connection reliability when terminating stranded wire in terminal blocks Specifications: Package Size: 25 Wire Size (AWG): 14 Insulation Color: Blue Ferrule Length: 8mm (0.31 in.) Stripping Length: 10mm (0.39 in.) Quick Guide (pdf)

Read more less

12-10 AWG Heat Shrink Ring Terminal - 3/8" Stud Size - 25 PackRing terminals are used to connect wires to a connection point. They can easily be used with two or more wires. They offer a solid connection as the ring is fitted over a stud. This removes the possibility of the terminal disconnecting. Using the proper parts is essential to a high-quality electrical connection. Ring terminals are the most secure type of tongue-style terminal. They are known for their durability and ease of use.Features: Tinned copper 600 Volts The operating temperature is -55°C to 125°C Highly compliant Benefits & Protections: Solid connections Extremely durable Long-lasting Tin-plated Easy to install Specifications: Color: Yellow Wire AWG: 12-10 AWG Stud Size (inch): 3/8" Terminal Pad Width (inch): 0.60” Package Size: Twenty-five included Specifications: Gauge: 12-10 AWG Heat Shrink: Yes Package Qty: 25 Post Size: 3/8" Type: Ring Terminals Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 840248206136 Quick Guide (pdf)

Read more less

18/2 AWG Duplex Cable - Flat Cable - Red/Black - 100'Duplex Boat Cable is used in low voltage AC applications as well as DC circuits.  Pacer manufactures 18 AWG Duplex boat cable in house in the USA for the best quality.  First, the cable is built from finely stranded, Type III tinned copper conductors.  These conductors allow for flexibility and help to prevent corrosion. The PVC jacket helps 18 AWG Duplex Boat Cable to be flexible while preventing moisture from accumulating.  How does it do that?  During the extrusion process, the spaces between wires are filled.  This leaves no space for moisture or air to accumulate.  After that, a talcum powder coating is given to the interior wires. This coating is used to allow the outer jacket to be easily removed.  Just another reason 18 AWG Duplex boat cable is perfect for marine use. Pacer's marine wire exceeds the requirements and standards of UL, ABYC, and NMMA.Features: Extruded exterior cable insulation with no gaps Highly flexible color coded wire insulation Stranded, tinned copper conductors Annealed Finely Stranded Tinned Copper ASTM B172 Class K Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil, Moisture Compliances: UL Standard - 1426  U.S.C.G - 33 CFR part 183  ABYC - E-11.14  Technical Specifications: Conductor - Type III annealed finely stranded tinned copper ASTM B172 Class K Insulation -20 °C to 105 °C flexible, color-coded PVC Voltage Rating - 600-V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture No. of Conductors - 2 Type of Cable - Duplex  *Sold as an Individual Specifications: Color: Red/Black Gauge: 18/2 AWG Length (Feet): 100' Box Dimensions: 5"H x 7"W x 7"L WT: 4.15 lbs UPC: 840248200011 Brochure (pdf)

Read more less

Yellow 2 AWG Battery Cable - 50' Pacer's 2 AWG Marine Battery Cable meets and exceeds the most stringent specifications. This UL-approved marine cable is manufactured in the USA to ensure high quality.  Oftentimes, marine applications are in enclosed areas with sharp turns. Installation can become difficult. Pacer simplified this process by developing flexible yet tough marine cables. This 2 AWG marine battery cable is built to handle the harshest conditions. All our marine cable is made from Type III tinned copper. The copper resists corrosion and ensures the longevity of the cable.  It is then insulated with a durable and pliable PVC jacket. These things together make it the highest quality marine battery cable available. Features: Easy to strip, bend, and route Excellent flexibility with the durable properties of PVC Technical Specifications: Conductor - Annealed fine stranded tinned copper ASTM B172 Class K Insulation  -20 °C to 105 °C Flexible, Color Coded PVC Temperature Rating - 105 °C Dry, 75 °C Wet, 60 °C Oil Voltage Rating - 600V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil, and Moisture *Sold as an Individual Specifications: Color: Yellow Gauge: 2 AWG Length (Feet): 50' Box Dimensions: 7"H x 7"W x 7"L WT: 14.2 lbs UPC: 840248204057 Brochure (pdf)

Read more less
