SPDT Sealed Toggle Switch - ON/OFF/ONSingle pole, double throw toggle switch turns one of two circuits on and off. Common applications include combining nav lights and anchor light with independent bulbs. Completely sealed switches built to stand up to the most extreme conditions. Engineered to IP67 specifications utilizing a double o-ring within a bushing at the toggle and a full epoxy seal at the back.Features: Nominal voltage is 12V/24V DC Rated for 25A at 12V DC, 15A at 24V DC 8" 16 AWG wire lead terminals Mounting stem 15/32" fits panels up to 1/4" thick Same as Cole Hersee part number 55036-14 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Action: On/Off/On Throw/Pole: SPDT Box Dimensions: 2"H x 3"W x 5"L WT: 0.2 lbs UPC: 870216046709

Read more less

m-Series Battery Switch Paralleling Link Bus Material: Tin-Plated Copper Continuous Rating: 250 Amperes DC WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

5112 110A Class T Fuse Features: Extremely fast short-circuit response 20,000 Ampere Interrupt Capacity (AIC) UL listed to standard 248-15 DC Tested to UL standard 198L WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Fuses Fuse Type: Class T Amperage: 110a Box Dimensions: 2"H x 4"W x 6"L WT: 0.2 lbs UPC: 632085051129

Read more less

Mains Cord NEMA 5-15P 120VAC for Smart IP43 SKYLLA-S Phoenix - 2M Power CordThis plug is for 120V systems.  One end plugs into the Phoenix Smart IP43 charger.  The cord is 2M long and the male plug end is a NEMA 5-15P plug.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

10/2 AWG Duplex Cable - Flat Cable - Red/Black - 100'Duplex Boat Cable is used in low voltage AC applications as well as DC circuits.  Pacer manufactures 10 AWG Duplex boat cable in house in the USA for the best quality.  First, the cable is built from finely stranded, Type III tinned copper conductors.  These conductors allow for flexibility and help to prevent corrosion. The PVC jacket helps 10 AWG Duplex Boat Cable to be flexible while preventing moisture from accumulating.  How does it do that?  During the extrusion process, the spaces between wires are filled.  This leaves no space for moisture or air to accumulate.  After that, a talcum powder coating is given to the interior wires. This coating is used to allow the outer jacket to be easily removed.  Just another reason 10 AWG Duplex boat cable is perfect for marine use. Pacer's marine wire exceeds the requirements and standards of UL, ABYC, and NMMA.Features: Extruded exterior cable insulation with no gaps Highly flexible color coded wire insulation Stranded, tinned copper conductors Annealed Finely Stranded Tinned Copper ASTM B172 Class K Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil, Moisture Compliances: UL Standard - 1426  U.S.C.G - 33 CFR part 183  ABYC - E-11.14  Technical Specifications: Conductor - Type III annealed finely stranded tinned copper ASTM B172 Class K Insulation -20 °C to 105 °C flexible, color-coded PVC Voltage Rating - 600-V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture No. of Conductors - 2 Type of Cable - Duplex  *Sold as an Individual Specifications: Color: Red/Black Gauge: 10/2 AWG Length (Feet): 100' Box Dimensions: 7"H x 7"W x 7"L WT: 12.5 lbs UPC: 840248200004 Brochure (pdf)

Read more less

Tinned Copper Battery Cable, 3/0 AWG (81mm²) - Black - Sold By The FootAncor Marine Grade wire products are the longest lasting and most rugged available, exceeding UL 1426, ABYC, and US Coast Guard Charter boat (CFR Title 46) standards. They are constructed with premium vinyl insulation that is rated at 600 volts, 105 deg C dry and 75 deg C wet, stays flexible even in extreme cold (-40 deg F/C), and resists salt water, battery acid, oil, gasoline, heat, abrasion, and ultra-violet radiation. The highest quality ultra flexible (Type 3) tinned copper stranding provides maximum protection against corrosion and electrolysis while resisting fatigue due to vibration and flexing.Features: Manufactured from tinned copper stranding for maximum protection against corrosion and electrolysis Ultra flexible (Type 3) stranding resists fatigue due to vibration and flexing Stays flexible even in extreme cold (-40 deg C) and resists salt water, battery acid, oil, gasoline, and ultra-violet radiation Specifications: Length (Feet): Sold By The Foot Gauge: 3/0 AWG Color: Black Box Dimensions: 1"H x 1"W x 12"L WT: 0.1 lbs Brochure (pdf)

Read more less

Centaur Charger - 24 VDC - 60AMP - 3-Bank - 120-240 VACFeatures: Quality without compromise -  Aluminium epoxy powder coated cases with drip shield and stainless steel fixings withstand the rigors of an adverse environment: heat, humidity and salt air. Circuit boards are protected with an acrylic coating for maximum corrosion resistance. Temperature sensors ensure that power components will always operate within specified limits, if needed by automatic reduction of output current under extreme environmental conditions. Universal 90-265V AC input voltage range and also suitable for DC supply (AC-DC and DC-DC operation) All models will operate without any adjustment needed over a 90 to 265 Volt input voltage range, whether 50 Hz or 60 Hz.  The chargers also accept a 90-400 V DC supply.  Three outputs that each can supply the full output current Three isolated outputs to simultaneously charge 3 battery banks Each output is capable to supply the full rated current.  Three-stage charging, with temperature compensation The Centaur charges at bulk rate until the output has reduced to 70% of the rated Amps, at which a 4 hour timer begins. After the timed period the charger switches to float rate. An internal temperature sensor is used to compensate the charge voltage with – 2 mV/ºC (– 1 mV/ºF) per cell. A DIP switch is available to select the optimum charge/float voltages for Flooded Lead-acid, Gel or AGM batteries Warranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Portable: No Charger Output Voltage: 24v Charger Output - Amps: 60a Charger Input - Voltage: 120/240v Charging Banks: 3 Box Dimensions: 9"H x 14"W x 25"L WT: 22.05 lbs UPC: 8719076021575 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

275A Cont Motorized Dual Operation VSS (Voltage Sensitive Switch) - Deutsch ConnectorThese Voltage Sensitive Switches (VSS) automatically sense connected battery bank voltages and provide optimal, efficient charging of the second bank. The VSS allows for independent battery banks to be combined or isolated based on the presence of a charging source (such as an engine alternator or battery charger), while also offering remotely activated, high current, emergency parallel connection. Features: Deutsch Connector Dual battery sensing Manual override option Designed and constructed for longevity in the marine environment with tinned copper conductors, stainless steel nuts, and high temperature, fiber reinforced plastics Features (Engine Run Sensing):VSS will engage when the voltage on either start or house battery reaches 13.7 volts. If the combined battery voltage drops below 13.0 volts and the engine is not running, after 5 seconds the contacts will open and stay open until the start or house battery voltage exceeds 13.7 volts. If the combined battery voltage drops below 12.2 volts and the engine is running, after 5 minutes the contacts will open and stay open until the start or house battery voltage exceeds 13.7 volts. If voltage drops below 13 volts and stays above 12.2 volts on either start or house battery while engine is running, the VSS will stay engaged. Features (Remote Emergency Parallel Function): The 701-MDVS-D can be operated through a momentary button on the dash which will parallel the batteries for a present time of 10 minutes Once this 10 minutes has passed, if the voltage is up high enough for the voltage sensitive switch to operate, it will stay engaged. If not, it will disengage The advantages of using a high current VSS is that it will cover your dual battery charging requirements and emergency parallel operation in one unit Specifications: Continuous Rating: 275 Amps DC Intermittent Rating: 455 Amps DC Cranking Rating: 1250 Amps DC Voltage Rating: 9.5 - 32 Volts Operation: On / Off Mounting: Recessed or surface Ignition: Protected Stud Size: 2 x 10mm / (3/8-inch) Power Draw: Switch off 12mA; Switch on 15mA; Switch operating 120mA for 3 seconds at 12v nomial Specifications: Continuous Amperage: 275 Amps DC Positions: 2 Box Dimensions: 3"H x 3"W x 4"L WT: 0.65 lbs UPC: 870216038360

Read more less

EEL "Y" AdaptersThese adapters are equipped with sealing collars and are for use in wet locations.Boat SideFemale Connector: Attaches to boat inlet or cordset(2)30A-125V Locking w/ Sealing Collar SystemDock SideMale Plug: Attaches to dockside receptacle or cordset(1)50A-125/250V LockingWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Y-Adapter Box Dimensions: 5"H x 12"W x 13"L WT: 7.2 lbs UPC: 093344051845 Owner's Manual (pdf)

Read more less

7157 Short Stop Circuit Breaker - 50A Corrosion Resistant Material IP 64 Water Resistant Boot Push to Reset Only Interrupt Capacity: 2,500A @ 28VDC Red insulating boot included in retail package Specifications Amperage: 50A DC Maximum Voltage: 28V DC Interrupt Capacity: 2500A @ 28V DC Minimum Operating Temperature: -10º C Maximum Operating Temperature: 60º C Screw Terminal Torque: 24 in-lb (2.71 Nm) Terminal Stud: #10-32" WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 2"H x 3"W x 7"L WT: 0.1 lbs UPC: 632085071578

Read more less

30 Amp 125 Volt Power Inlet (White)301EL-BProduct Features: Marine grade UV stabilized glass-filled polyester construction Easy Lock System Watertight cap 4-way right angle rear safety enclosure Stainless steel trim WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Inlets Box Dimensions: 4"H x 6"W x 9"L WT: 0.7 lbs UPC: 093344005152 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

Description: 304 S.S. Shore Power Cable HolderTube Diameter: 1-1/4"Overall Height: 27"Inside Ring Diameter: 3/4"Fits all standard shore power cables. Tube bottom has 2 slots for multiple positions. Specifications: Type: Misc Box Dimensions: 1"H x 4"W x 28"L WT: 2.15 lbs UPC: 725060624118

Read more less
