Electrical

40A Push Button Circuit Breaker - Reset OnlyFeatures: Weatherproof Against Dust & Water Intrusion to ensure reliable circuit protection for the life of the electrical system installation 32 Vdc Rating easily supports 12 and 24 Vdc applications. Meets ABYC E-11 Interrupt Requirements High Interrupt Current safely protects circuits connected to large paralleled battery banks with significant available power Ignition-protected safe for installation in closed compartments with potential explosive gases Harsh Environment design with shock and vibration resistance is ideal for marine and vehicle electrical systems. Trip-Free Design cannot be forced during a fault condition. This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 40a Box Dimensions: 3"H x 5"W x 6"L WT: 0.25 lbs UPC: 850053879203 Brochure (pdf)

Read more less

TRUEcharge™3 20A 3 Bank Battery Charger - 24VTRUEcharge3 battery chargers lead the industry with a small footprint and ultra-compact design. In addition to meeting global safety and regulatory standards, they feature low electrical interference and efficient power factor-corrected multistage charging. The TRUEcharge3 Chargers can be mounted in multiple positions thanks to their inherent drip-proof design characteristics. Unlike its predecessors, TRUEcharge3 is lithium-ion battery compatible.Designed for recreational and commercial applications worldwide, TRUEcharge3 accepts 90–265 Vac, and 47–63 Hz, which makes traveling abroad and handling poor-quality power a breeze. The easy-to-read display of the TRUEcharge3 24 V models can be enhanced with an optional remote panel. Each model has built-in protection against surges and spikes on the AC power line.Features: Microprocessor-controlled, multistage charging algorithms Settings for two and three-stage charging Battery-equalization feature Settings for flooded, gel, AGM, or lithium-ion batteries Equipped with parallel stacking (remote panel required) Ability to charge batteries drained to extremely low voltage Added quiet mode Protection Features: Reverse-battery polarity protection Drip-proof design DC over-voltage protection Over-temperature protection Circuit breaker protection Three-Stage ChargingMultistage charging ensures batteries receive optimum charging, but with minimal wear and tear, regulating the voltage and current delivered to the batteries in three automatic stages: Bulk: Replaces 70–80% of the battery’s state-of-charge at the fastest possible rate Absorption: Replenishes the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate Float: Voltage is reduced and held constant to prevent damage and maintain batteries at a full charge for the remaining 20–30% of charge, bringing the battery to a full charge at a slow, safe rate Power Factor Corrected (PFC) ChargingLess shore power is required for charging batteries, freeing up more usable AC power for running electrical devices and appliances and reducing the likelihood of tripping shore power breakers.Electrical Specifications (@ 25 degrees C unless otherwise noted): Output Current (nominal): 20 A  Output Voltage (nominal, depending on settings): Charge 28.4–31.0 Vdc; Float 26.8–27.6 Vdc; 32 Vdc DC Output Connections: Three AC Input Voltage: 90–265 Vac; 47–63 Hz 120 Vac, 230 Vac, 240 Vac nominal Temperature Compensation: Three settings  Charger Efficiency: > 80% Battery Type: Gel, Flooded, AGM, LiFePO4  Minimum Recommended Battery Bank Size: 40 Ah  General Specifications: Operating Temperature Range: 0–60°C (32–140°F)  Storage Temperature -40–80°C (-40–176°F) Battery Connection: Three positive terminals and one negative terminal Dimensions (H x W x L): 70 x 170 x 250 mm (2.8 x 6.7 x 9.8”) Weight 2.2 kg (4.8 lb) Regulatory Approvals Meets CSA 60335-2-29, UL1564, IEC 60335-2-29, IP32 per EN.IEC 60529, FCC Part 158, Canada ICES-003 Class B emissions limits, ABYC A-31, and DOE/CEC energy efficiency compliant.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Output - Amps: 20a Charger Output Voltage: 24v Charging Banks: 3 Portable: No Box Dimensions: 6"H x 11"W x 13"L WT: 6.15 lbs UPC: 715535920937 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

XPLORE Battery Charger - 12V - 120 Amp - 6-BankThe XPLORE 120/12 battery charger is the largest and most powerful charger on the market today. The universal, auto-ranging AC input and 120 amps of output current ensure ultra-fast and reliable worldwide charging. With up to six output banks of simultaneous charging combined with the ability to charge two battery banks with differing chemistries, the XPLORE 120/12 eliminates the need to have separate single-chemistry chargers and minimizes installation and wiring costs for your house bank and engine bank.It is also equipped with an easy-to-read front panel LED display for basic configuration and status information. Advanced monitoring and configuration are enabled by NMEA 2000 protocol or Xantrex app using the Xantrex BLE module.Performance Features: 6 Battery Banks and Dual-Chemistry Charging Xantrex Lithium and Custom Battery Charging NMEA 2000 Connectivity Xantrex App Connectivity Auto-ranging universal input voltage (80-265 Vac, 45-65 Hz) Power Share: automatically reduces charging output to prevent nuisance tripping of the AC input breaker. Quiet Mode: when enabled, the internal fan is turned off and the charger operates at a reduced output when quietness is needed. Storage Mode: automatically refreshes your batteries once every several days of non-use to ensure optimal battery condition. Dead Battery Charging: the ability to charge a battery as low as 0V back to full-charge  Protection Features: Reverse battery polarity protection Drip-proof design Over and under-temperature protection DC over-voltage protection Battery overcharging protection This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

VE. Direct to USB InterfaceThe VE.Direct to USB interface connects products with a VE.Direct connection to devices with a USB port, for example, a computer. With this cable, it is also possible to connect more than two VE.Direct products to a single CCGX. Measures 70.5" in length; 5' 10".WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

10A Push Button Panel Mount Circuit Breaker - Spade TerminalFeatures: Push-To-Reset allows for easy identification of a tripped breaker as well as an easy reset of the breaker to the on position. Includes Knurled Nut & Palnut for easy and clean panel mount Ignition-protected safe for installation in closed compartments with potential explosive gases. This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 10a Box Dimensions: 2"H x 4"W x 4"L WT: 0.12 lbs UPC: 850053879265

Read more less

Class T Fuse Block 70-100A SealedFeatures: Ignition Protected to support installation in potentially hazardous gasous environments. Height is compatible with other Flex System Components. Includes Protective Transparent Cover with break-away tabs for easy inspection. This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Fuse Type: Class T Type: Fuse Blocks Box Dimensions: 3"H x 6"W x 8"L WT: 0.68 lbs UPC: 850067590705

Read more less

Class T Fuse Block 225-400 A - SealedApplications/Problems This Solves: Separate Stud Connections for Cable Mounting allow heavier gauge cables and their terminals to feed in and out of the fuse, which would otherwise land on the fuse tab itself. Ignition Protected to support installation in potentially hazardous gaseous environments such as LPG or on gas boats. Features: Tin-plated copper busbar delivers superior electrical performance with minimal voltage drop. Stainless Steel Self-Locking Hardware ensures robust connections & long-term connection reliability. Bulletproof construction from glass-filled nylon delivers the highest longevity in demanding environments.  4 Year Warranty Specifications: Maximum Amperage: 225-400A Max Voltage: 80 VDC Ingress Protection Ratings: IP66, IP67, IP6K9K Mounting Holes: 4x #10 (M5) & 2x 1/4" (M6) Mounting Screw Max Torque: 50 in-lbs (5.5 N-m) Busbar Material: Tin-Plated Copper This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Read more less

60A Surface Mount Circuit Breaker - 285 SeriesThis 60A Egis circuit breaker protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction.Applications: Automatic circuit protection and manual on/off switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems regardless of the location Features: Sealed against dust and water intrusion to ensure reliable circuit protection for the life of the electrical system installation  High Voltage (48 Vdc) Rating - easily supports 12 and 24 VDC applications while offering advanced protection for 36 and 48 VDC High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current High Interrupt Current - safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 60 Max Voltage: 48 Cycling Endurance: 6,000 Interrupt Current @16 VDC (Amps): 5,000 Interrupt Current @28 VDC (Amps): 3,000 Ingress Protection Rating: IP67 Focal Features:ON/OFF High Visibility ControlsSealed against dust and moisture penetration. The high temperature rating for all installation locations.Integrated Terminal InsulatorsProtects against inadvertent shorts from positive terminals to adjacent grounded surfaces.Stainless Steel Hardware / Serrated Flange NutsCorrosion and vibration resistance for harsh environment applications.Proudly Made in the USAMade in the USA of high-quality components.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Amperage: 60a Box Dimensions: 3"H x 3"W x 5"L WT: 0.4 lbs UPC: 850035199145 Quick Guide (pdf)

Read more less

7700100 ML Solenoid 12V 500A with Manual Control & Deutsch Connector500 Amp magnetic latching switch provides high amperage switching under load, manually or from remote locations.Features: Manual override knob provides an added level of safety allowing control with or without power and offering LOCKED OFF capability for servicing LED output to remotely indicate switch state - requires optional LED 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance 7/8" (22 mm) stud length accepts multiple cable terminals Label recesses for circuit identification Silver alloy contacts provide high reliability for switching live loads Specifications: Control Circuit Connection: Deutsch DTM Nominal Voltage: 12VDC Coil Function: Bi-Stable Mounting: #10 Amperage Operating Current Continous: 0mA Terminal Stud Torque: 140 in-lb (15.82 Nm) Continuous Rating: 500A Intermittent Rating: 700A (5 min) Cranking Rating 30 Seconds: 1450A DC Cable Size to Meet Ratings: 2x (4/0) Live Current Switching: 300A@12VDC Master Control Switch Capability: No Mechanical Endurance: 100,000 Cycles Terminal Ring Diameter Clearance: 1.18" (29.97 mm) Terminal Stud Length: 0.875" (22.23 mm) Terminal Stud Size: 3/8" - 16 (M10) Weight: 1.75lb (0.79 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Interface MK3-USB (VE. BUS to USB) ModuleThe MK3-USB allows the following products to connect to a computer for configuration and firmware updates:Multi, MultiGrid, MultiPlus, MultiPlus-II, Quattro, Inverter/Charger settings in ECOmulti, EasySolar, EasyPlus, and Inverters with a VE.Bus communication portWarranty InfoWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Panel-Mounted Battery Master SwitchPanel-mounted switches are designed specifically for panel mount applications. This range gives a very compact, versatile solution. Compact, lightweight Removable key Countersunk recesses for surface mount application Standard 2-1/16" (52 mm) hole cut out (same as standard gauge hole) Inside: captive inserts for 3/16" (4.8 mm) nuts providing full access for cables with no restrictions Standard interchange label system Molded in high temperature, fiber reinforced plastics WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

Class T Fuse Holder with 2 Additional Studs 225-400A Providing high-capacity fusing, fast response and very high interrupt ratings (ANL up to 6,000 Amps, Class-T up to 20,000 Amps), these fuse holders are ideal for protecting today's demanding onboard power electronics technology including inverters and battery chargers. They also protect wiring from short circuits. Pro Installer fuse holders' durable construction allow fuses to run at maximum load. Radiused ends improve cable routing options Class-T: 225-400 Amp WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: Class T Type: Fuse Blocks Box Dimensions: 2"H x 7"W x 8"L WT: 0.93 lbs UPC: 870216043500 Brochure (pdf)

Read more less
