7056Push Button Thermal with Quick Connect Terminals15A Ideal for 24-hour circuit protection Incorporated into Blue Sea Systems' Waterproof Circuit Breaker panels and main Battery Main Distribution Panels Push to reset operation "Trip Free" design cannot be held "ON" during fault current condition Ignition protected - Safe for installation aboard gasonline powered boats With male quick connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 15a Box Dimensions: 1"H x 3"W x 5"L WT: 0.05 lbs UPC: 632085070564

Read more less

PT-24-8W Battery Charger“Smart” marine battery charging technology for 24-volt systems aboard workboats, military vessels, commercial vessels, and recreational craft. This charger interacts with batteries, providing the optimum three-stage charge process for fast recovery and conditioning, maximizing performance, and extending battery life.A selector switch adjusts output voltage to adapt to gel-cell, flooded lead-acid, or AGM battery types. An optional temperature compensation sensor also adjusts output for ideal voltage based on changes in the batteries’ ambient temperature. All models are housed in a rugged stainless steel case with a durable white powder coat finish, and the internal circuitry is polyurethane coated for maximum corrosion resistance.Features: 24-volt model “Smart” circuitry provides three-stage charging – bulk, absorption, float Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum charge/float voltages Multiple isolated output banks; ammeter indicates total output current The optional sensor adjusts output voltage based on battery temperature Current limiting prevents damage from overloading Use as a power supply; can power loads without a battery in line Built to last – rugged stainless steel case with a durable white powder coat finish with an optional drip shield and marinized internal circuitry Protection: Current Limiting, Thermal Protection, Forced Air Cooling, Drip Shield Install in conjunction with PT-MCU for additional control and monitoring ABS-type approval for battery charging and power supplies Specifications: Input VAC (50-60 Hz.): 85 – 264 Input Amps @ Full Load: @ 115 VAC: 2.8, @ 230 VAC: 1.4 Power Factor: .98@115V and .93@230V Max Output Amps: 8 Output Banks: 3 Battery Capacity (Amp-Hours): 16 – 80 Operating Temp. Rating Reference: T-1 Case Size Reference: A-1 Case Size (H x W x D): 11.2A x 7.7 x 4.75A inches (28.4A x 19.6 x 12.1A centimeters) *Note with Dripshield installed A add 1.1” (2.8 cm) to height and .92” (2.3 cm) to depth Weight Lbs./Kg: 8/4 Optional Temp. Sensor Model: TCS-12/24         Remote Panel Model: RP Compliance Reference: CG, CE, ABS Temperature Rating References: Temperature: -10 degrees C to +60 degrees C Derate Linearly From 100% @ 40 degrees C to 60% @ 60 degrees C Nominal Output Voltages at Gel/Flooded Switch Settings (without Temperature Compensation): Gel-Cell: 28.0 VDC Charge @ 50% load and 27.2 VDC Float @ .5 amp load Flooded/AGM: 28.4 VDC Charge @ 50% load and 26.8 VDC Float @ .5 amp load Compliance References: UL: UL 1950 (per DNB report) CG: USCG CFR 183.410 (Ignition protected) EN: EN 60335-1 CE: Carries the CE mark ABS: PT Series meets SVR 2009 4-8-3/5.9, Under 90 meters Rules 2006 4-6-4/7.19, and HSNC 2007 4-8-3/5.13. Options:Remote Panel, model RP, for use with all models except PT-24-20U, PT-24-60, and PT-32-25 (LEDs indicate charger output stage. Manual re-initialization of three-stage charge cycle. With 25′ of cable. Panel dimensions: 3″ H x 4.75″ W)This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Specifications: Charger Input - Voltage: 115/230v Charger Output - Amps: 8a Charger Output Voltage: 24v Charging Banks: 3 Portable: No Inverter Input Voltage: 115/230v Inverter Output Voltage: 24v Outlet Qty: Hardwire Box Dimensions: 10"H x 10"W x 16"L WT: 8.3 lbs Quick Guide (pdf)Owner's Manual (pdf)

Read more less

Red 4/0 AWG Battery Cable - Sold By The FootPacer's 4/0 AWG Marine Battery Cable meets and exceeds the most stringent specifications. This UL-approved marine cable is manufactured in the USA to ensure high quality.  Marine installations can occur in tight, enclosed spaces that have sharp turns where the installation process can quickly become difficult. Pacer makes the installation process easier.  How?  By creating a flexible yet tough marine cable.  This 4/0 AWG marine battery cable can handle the toughest environments.  This marine battery cable is made from Type III tinned copper.  The copper resists corrosion and helps to extend the life of the marine cable. Then, the cable is insulated with a durable and flexible PVC jacket.  These things all come together to make the highest quality marine cable available.Features: Easy to strip, bend, and route Excellent flexibility with the durable properties of PVC Technical Specifications: Conductor - Annealed fine stranded tinned copper ASTM B172 Class K Insulation  -20 °C to 105 °C Flexible, Color Coded PVC Temperature Rating - 105 °C Dry, 75 °C Wet, 60 °C Oil Voltage Rating - 600V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil, and Moisture *Sold by the Foot Specifications: Color: Red Gauge: 4/0 AWG Length (Feet): Sold By The Foot Box Dimensions: 1"H x 1"W x 12"L WT: 0.85 lbs Brochure (pdf)

Read more less

Yellow 2/0 AWG Battery Cable - Sold By The Foot Pacer's 2/0 AWG Marine Battery Cable meets and exceeds the most stringent specifications. This UL-approved marine cable is manufactured in the USA to ensure high quality.  Marine installations can occur in tight, enclosed spaces that have sharp turns where the installation process can quickly become difficult. Pacer makes the installation process easier.  How?  By creating a flexible yet tough marine cable.  This 2/0 AWG marine battery cable can handle the toughest environments.  This marine battery cable is made from Type III tinned copper.  The copper resists corrosion and helps to extend the life of the marine cable. Then, the cable is insulated with a durable and flexible PVC jacket.  These things all come together to make the highest quality marine cable available.Features: Easy to strip, bend, and route Excellent flexibility with the durable properties of PVC Technical Specifications: Conductor - Annealed fine stranded tinned copper ASTM B172 Class K Insulation  -20 °C to 105 °C Flexible, Color Coded PVC Temperature Rating - 105 °C Dry, 75 °C Wet, 60 °C Oil Voltage Rating - 600V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil, and Moisture *Sold by the Foot Specifications: Color: Yellow Gauge: 2/0 AWG Length (Feet): Sold By The Foot Box Dimensions: 1"H x 1"W x 1"L WT: 1 lbs Brochure (pdf)

Read more less

7441 UL-489 Circuit Breaker - 10A Flat RockerSuitable for use when UL-489 specifications are required (Navy, Army, or Coast Guard vessels, and other vessels covered under CFR 46).Specifications: Amperage: 10A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 80V DC Circuit Breaker Type: Magnetic Hydraulic - Trip Free Terminal Type:  #10-32 Screw Tin-Plated Brass  Interrupt Capacity: 10000A Specifications: Amperage: 10a Box Dimensions: 2"H x 3"W x 4"L WT: 0.26 lbs UPC: 632085074418

Read more less

4160 SS Push Button Switch - Off-On - Blue - 10A 10A continuous Single Pole Double Throw or Single Pole Single Throw Can be wired for normally open or normally closed Installs with .110inch quick connects (included in retail package) Specifications Action: OFF-ON Amperage: 10A @ 12V DC Nominal Voltage: 12V DC Maximum LED Operating Current: 20mA Minimum Operating Temperature: -10° C Maximum Operating Temperature: 70° C Minimum Storage Temperature: -55° C Maximum Storage Temperature: 85° C Illumination: Independent – Separate contacts for LED power Mounting Hole: 19mm Switching Cycles: 18,000 Termination: 5 – 0.110inch Quick Connect terminals WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Stainless Action: ON-OFF Box Dimensions: 2"H x 3"W x 5"L WT: 0.05 lbs UPC: 632085041601

Read more less

C-Series Flat Rocker Circuit Breaker - Single Pole - 5AFeatures: Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching Color actuator indicates "OFF" position Provides overcurrent protection for inverters, bow thrusters, and windlasses Combines switching and circuit protection into a single device "Trip Free" - cannot be held closed after trip Ignition protectedsafe for installation aboard gasoline powered boats Specifications: Amperage: 5A AC / 5A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC / 48V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Terminal Stud Torque: 35 in-lb (3.95 Nm) Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Switching Cycles: 10000 Terminal Stud: 1/4-20 Tin-Plated Brass Weight: 0.38lb (0.17 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 5a Box Dimensions: 2"H x 3"W x 4"L WT: 0.29 lbs UPC: 632085075408

Read more less

Contura II Switch DPDT Black - ON-OFF-ONVibration, shock, thermoshock, moisture and salt spray resistantMounts in Blue Sea Systems Contura Water Resistant Panels and Contura Switch Mounting PanelsSpecifications: Action: ON-OFF-ON Pole/Throw: DPDT - Double Pole/ Double Throw Actuator Color: Black - Contura II Common Applications: Combining Nav lights or anchor light with shared bulb Maximum Amperage: 20A @ 12V / 15A @ 24V Amperage Operating Current: 18mA (LED) Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Actuator Position to Light LED: ON Embedded LEDs: 2 Lighting: LED rated 100,000 hours 1/2 half Seals: Internal and external gasket panel seal Weight: 0.09lb (0.04 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Action: ON-OFF-ON Color: Black Throw/Pole: DPDT Box Dimensions: 2"H x 3"W x 4"L WT: 0.1 lbs UPC: 632085079369

Read more less

285-Series Thermal Circuit Breaker Surface Mount, 60A Drop-in replacement for 185-series Circuit Breakers Visible reset lever shows open condition "Trip Free" - cannot be held closed after tripWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 60a Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 632085171841 Brochure (pdf)

Read more less

1011Features: Features watertight cap, easy installation, and twist locks securely with plug Designed to withstand the rigors of wet environments and constant vibration Large contact surfaces for good electrical connection Twist lock system-plug locks securely into socket Internal strain relief and cord seal Nickel plated copper alloy used for all current carrying components Front panel, rear panel, or surface mount WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

7700 Includes ML-Series Remote Control Contura Switch 2145 Manual control switch provides an added level of safety allowing control with or without power, and offering "Locked Off" capability for servicing 500 Ampere continuous rating for engine, inverter, house loads, and emergency battery combine Magnetic latching draws no current in "ON" or "OFF" state, only draws current when changing state of switch Silver alloy contacts provides high reliability for switching live loads 3/8" -16 tin-plated copper studs for maximum conductivity and corrosion resistance 7/8" (22mm) stud length accepts multiple cable terminals Label recesses for circuit identification WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

9011Switch, AC 120VAC Amperes 65 Positions 2+OFF Poles 2 Switches 2 - 120 or 230 Volt AC sources Compact solution when circuit protection is provided elsewhere Allows connecting one of two different AC sources to one circuit Mounts in panels up to 0.16" (4.00mm) thick Heavy duty industrial rated switch Intuitive function - One hand operation UL listed 600 Volt AC max WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Box Dimensions: 4"H x 6"W x 7"L WT: 1 lbs UPC: 632085090111 Owner's Manual (pdf)

Read more less
