7610120 Amp SI-Series Automatic Charging Relay Allows temporary isolation of house loads from engine circuit during engine cranking to protect sensitive electronics Automatically combines battery banks during the charging cycle and isolates under discharge 12/24 Volt auto ranging voltage input Waterproof rated IP67 - temporary immersion for 30 minutes Ignition protected - safe for installation aboard gasoline powered boats Remote LED output indicates relay state away from ACR LED light indicates when batteries are combined LED blinks in undervoltage lockout and starting lockout Supports high-output alternators up to 120 Amperes Included with the ADD A BATTERY Dual Circuit System Automatically combines battery banks during the charging cycle and isolates under discharge Ignition protected - safe for installation aboard gasoline-powered boats Activates from any charging source - alternators, battery chargers, or solar panels Hermetically sealed contacts / vaporproof Side and bottom knockouts for power cable connections Clip-on cover protects and insulates terminal connections Tin-plated copper studs for maximum corrosion resistance 7/8" (22.22mm) stud length to accept multiple cable terminals 1/4" x 0.031" male quick connect terminals for ground and remote LED and starting interrupt WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

9011Switch, AC 120VAC Amperes 65 Positions 2+OFF Poles 2 Switches 2 - 120 or 230 Volt AC sources Compact solution when circuit protection is provided elsewhere Allows connecting one of two different AC sources to one circuit Mounts in panels up to 0.16" (4.00mm) thick Heavy duty industrial rated switch Intuitive function - One hand operation UL listed 600 Volt AC max WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Black Box Dimensions: 4"H x 6"W x 7"L WT: 1 lbs UPC: 632085090111 Owner's Manual (pdf)

Read more less

5005 ANL 35-300AMP Fuse Block with CoverFeatures: Insulating cover satisfies ABYC/USCG requirements and cover breakouts allow access in any direction For use on systems up to 32V DC Large 5/16" - 18 studs accept 5/16" (M8) ring terminals, 14 AWG to 2/0 AWG wire WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Fuse Type: ANL Type: Fuse Blocks Box Dimensions: 2"H x 4"W x 8"L WT: 0.4 lbs UPC: 632085050054

Read more less

WeatherDeck™ Water Resistant Circuit Breaker PanelPN: 4376Color: GrayFeatures: Rated IP67-temporary immersion for 30 minutes Designed for flybridge and open cockpit applications Independent label backlighting allows switching and dimming Compatible with all Blue Sea Systems Digital Dimmers Each panel can be mounted in four different orientations Green LEDs aid low-light readability. All labels will be lit when the panel is powered, regardless of individual switch position. Specifications: Weatherproof: Waterproof Positions: 6 Nominal Voltage: 12v / 24v DC Circuit Protection: Circuit Breaker Maximum Amperage: 15A @ 12v DC (per circuit) / 9A @ 24v DC (per circuit) Panel Cumulative Rating: 45A Backlit Label: Green LED Backlighting Amperage: 10mA/Illuminated Circuit Backlighting Voltage: 12 or 24v DC Height: 6.0" Width: 4.25" Depth: 3.5" Included: (6) 4135 Push Button Reset Only Circuit Breaker Boot - Clear (6) 4138 WeatherDeck® Toggle Switch Boot - Black (6) 4150 WeatherDeck® Toggle Switch SPST - ON-OFF (1) 4215 Waterproof DC Label Kit - 30 Black Square Labels V1 (6) 7056 Push Button Reset Only Quick Connect Circuit Breaker - 15 Amps WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Waterproof: Waterproof Voltage: 12v AC/DC: DC Max Breaker Quantity: 6 Box Dimensions: 4"H x 6"W x 9"L WT: 1.4 lbs UPC: 632085043766 Quick Guide (pdf)

Read more less

7202 AC/DC Single Pole Magnetic World Circuit Breaker - 5AMPC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.Features: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 5a Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085072025

Read more less

AC / DC Single Pole Magnetic World Circuit BreakerThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.PN:   7220Color:   BlackAmperage:   30 AmpDelay:   StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition Specifications    Circuit Breaker Type Magnetic Hydraulic - Trip Free Maximum Voltage 277 Volts AC / 65 Volts DC Rated Switch Cycles 10,000@rated amperage and voltage WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 30a Box Dimensions: 1"H x 3"W x 5"L WT: 0.2 lbs UPC: 632085072209

Read more less

2102 PowerPost Plus Cable Connector - 5/16" StudEnables connection of multiple smaller wires in spaces where a traditional bus bar may not fit.Features: 150 Ampere bus allows small wire connections at high amperage cable connections Connects high amperage cables securely Stud dimensions: 5/16" x 3/4" Base Material is Black Nylon 8231 GHS WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

2402 Terminal Black 20AMP - 2 CircuitFeatures: Closed back design completely insulates power from the mounting surface Each screw pair is 1 isolated circuit Jumpers allow creation of common circuits WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

2003 PowerPost High Amperage Cable Connector 3/8" StudInsulated single stainless steel stud terminates multiple large conductors.Features: Connects high amperage cables securely Stud dimensions: 3/8" x 7/8" Base Material is PBT UL94 V0 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

MIDI-Fuse 60A/58V-M6 (Package of 5)Victron Energy's MIDI fuses are essentially a smaller version of the MEGA fuses and are known to have low voltage drop and cold resistance. This particular pack of Victron MIDI fuses contains five 100-amp fuses.Specifications: Max Current Rating: 60 amps Max Voltage Rating: 58 volts Approximate Voltage Drop: 70 mV Cold Resistance: 0,9 mΩ Please contact your dealer for any returns, repairs or support issues related to this product.

Read more less

3113 - SMS Panel Enclosure with 6 Blank CircuitsThe 3113 panel enclosure is built for main circuit breakers and other large frame devices.  Meets ABYC E-11 when used with an ELCI Main circuit breaker and mounted within 10' of AC shore power inlet. Features: Blank apertures for custom breaker loading Glass filled polycarbonate mounting box Clear cover allows easy view of circuit breaker status Overlapping cover for strength and increased gasket protection Oversized, formed in place seamless PUR gasket Easily removable stainless steel hinge pin for unobstructed installation Stainless steel latch secures cover without penetrating the enclosure Blank circuit positions accommodate Carling Technologies™ A- and C- Series Flat Rocker and ELCI Main circuit breakers Technical Specifications: Dimensions (Overall) (H x W x D) - 7.6" x 7.4"" x 4.7" (192 x 188 x 120mm) Dimensions  (Enclosure) (H x W x D) - 6" x 6" x 4" (152 x 152 x 102mm) LEDs Installed - 1 x Red (Reverse Polarity - 230V AC and 3 x Green ON (230V AC) In the Box: 3123 Enclosure Mounting hardware Instruction manual *Sold as an IndividualWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Brochure (pdf)

Read more less

Active GPS Antenna for GX LTE ModemThis antenna is for the GX LTE Modem.Specifications: Mounting Option: Magnet Cable Type: RG-74 Cable Length: 3.0 m Connector: SMA male straight Frequencies: 1575.42 MHz Signal Gain: 50 Ω Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)

Read more less
