Deutsch 6 AWG DTHD Power Plug & Receptacle with Pin & SocketDTHD power plugs and receptacles are single connectors for heavy-duty applications. Easy to install, environmentally sealed, and compact they are a simple, field-serviceable alternative to a splice. Contact a Pacer expert with any questions that you may have.Features: Environmentally sealed disconnectable power wire splicing 60-100 Amps at 125°C Easy to install Field serviceable Applications: Wire-to-wire applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics: Redundant Silicone Seals Contacts are hand-insertable Compliances: Ingress Protection (IP) Level: IP67 EU RoHS/ELV Specifications: Kit Contents: (1) DTHD Plug, (1) Size 4 Socket, (1) DTHD Receptacle, (1) Size 4 Pin, (2) Reducer Crimp Sleeves for 10 or 8 AWG Deutsch Series: DTHD Wire Range: 6 AWG Connector Types: Plugs & Receptacles Brochure (pdf)

Read more less

Deutsch DT Receptacle & Wedge Lock Kit - 12 Position - 5 PackProtecting electrical connections is an absolute must, and Deutsch Connectors are built for just that. DT Kit connectors are designed to create environmentally sealed electrical connections. Waterproof and resistant to vibration and shock, these Kits are built to last. What are DT series connectors? Well, DT Series connectors are specifically designed for 20-14 AWG applications. These connectors offer users the ability to use multiple size 16 contacts (20-14 AWG). These DT kits are perfect for field use. They are easy to install, connect, and disconnect. Pacer's DT Kits contain housing and wedge lock only. Pins and sockets to accompany these kits are sold separately. Contact a Pacer expert today with any questions that you have.Features:Kits with cavities (6, 8, or 12) include housing (5 pieces) and wedge lock (5 pieces)Applications: Wire-to-wire applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics: Wedgelocks ensure contact alignment and retention Redundant Silicone Seals Hand-insertable and removable contacts Compliances: Ingress Protection (IP) Level: IP67 EU RoHS/ELV Standard UL-94 Recognized Specifications: Number of Cavities: 12 Cavity Style: Receptacle (Pin) Package Size: 5 Housing: Rectangular Receptacle, Plastic reinforced with glass fiber Contact Size: 16 (13 Amp) Wire Size: 20-14 AWG Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

Deutsch DT Receptacle & Wedge Lock Kit - 8 Position - 5 PackProtecting electrical connections is an absolute must, and Deutsch Connectors are built for just that. DT Kit connectors are designed to create environmentally sealed electrical connections. Waterproof and resistant to vibration and shock, these Kits are built to last. What are DT series connectors? Well, DT Series connectors are specifically designed for 20-14 AWG applications. These connectors offer users the ability to use multiple size 16 contacts (20-14 AWG). These DT kits are perfect for field use. They are easy to install, connect, and disconnect. Pacer's DT Kits contain housing and wedge lock only. Pins and sockets to accompany these kits are sold separately. Contact a Pacer expert today with any questions that you have.Features:Kits with cavities (6, 8, or 12) include housing (5 pieces) and wedge lock (5 pieces)Applications: Wire-to-wire applications Enclosed connectors offer field-proven reliability and rugged quality Characteristics: Wedgelocks ensure contact alignment and retention Redundant Silicone Seals Hand-insertable and removable contacts Compliances: Ingress Protection (IP) Level: IP67 EU RoHS/ELV Standard UL-94 Recognized Specifications: Number of Cavities: 8 Cavity Style: Receptacle (Pin) Package Size: 5 Housing: Rectangular Receptacle, Plastic reinforced with glass fiber Contact Size: 16 (13 Amp) Wire Size: 20-14 AWG Operating Temperature: -55°C to 125°C Brochure (pdf)

Read more less

360 Panel Conversion Kit - 12 to 24 V DCFeatures: Convert a 12 Volt DC 360 Panel with rocker or toggle circuit breakers to a 24 Volt panel Requires one kit per 12 Volt DC circuit breaker module Includes wire harness and panel identification label

Read more less

Panel Switch PN: 8211 Type: Toggle Pole / Throw: DPDT Action ( ) = momentary: ON - OFF - ON Features: Perfect for generator starters, bilge pumps, horns, wipers, engine controls and any other application that requires switching action other than ON-OFF or different pole configuration separate from circuit protection All panel switches mount in Blue Sea Systems toggle type circuit breaker panels Supplied with mounting adapter for standard 5/8" circuit breaker mounting hole Nickel-plated brass and phenolic non-corrosive construction Specifications   Rating 250V AC 10 Amperes Rating 125V AC 15 Amperes Rating 32V DC 15 Amperes Terminal Size 0.25" (6.35mm) Terminal Type Quick Connect Tab Actuator Color White WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

8022 DC Analog Ammeter - 2-3/4 Face, 0-50 AMP DCShunt Type: ExternalFeatures: Simple 2-wire connection Meter Senses Powers from same connection Includes DC shunt Backlit meter face WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

Single Jack HDMI ConnectorBuild or expand a SmartPlug data port with this single-jack HDMI connector.Features:Single HDMI connector portSpecifications: Material: Non-metallic Color: Black Quick Guide (pdf)

Read more less

50 AMP Dual Configuration Cordset - 50'For many years boaters have experienced the safety, security and simplicity of SmartPlug products on the boatside while still dealing with the same old issues created by legacy twist-type products on the dockside.  Those days are changing with the introduction of SmartPlug's new dockside product offering.  SmartPlug has applied decades of experience and customer feedback to create a product that allows you to upgrade your shore power connection with SmartPlug technology. The 50 AMP 125/250 V cordset provides a complete weatherproof power solution. The cordset includes the SmartPlug connector for the Boat Side and a Twist Type Dockside connector.Features: Multi-Point Locking System - Side clips lock the body securely into the inlet, which eliminates any stress on the electrical connection from movement of the power cord. Weatherproof Seals - Silicone gaskets installed in the interior of the plug body eliminate any water penetration when plug is connected to inlet. LED Power Indicator Light – On the top of all SmartPlug female ends, two LED indicator lights.  One Red and one Blue LED light for Safe/Unsafe Electrical Power Indication under Reverse Polarity Conditions. Tinned Wire – All SmartPlug marine cords have tinned wire to minimize corrosion. Technical Specifications: Length - 50' Color - Orange Boatside Connection - 50 AMP/125/250 V SmartPlug Dockside Connection - 50 AMP/125/250 V Twist Type Plug *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50 Length: 50' Type: Cordset Voltage: 125/250 Box Dimensions: 9"H x 19"W x 19"L WT: 40.6 lbs UPC: 682500440137 Owner's Manual (pdf)

Read more less

Push/Pull Switch Three-PositionThree-position, off/on/on. For operating running lights and anchor lights separately.These switches have large, easy-to-pull handles. They are commonly used for operating lights. 3/4" diameter chrome-plated knob, brass case. Include screw terminals for connection without a wire lug. For 12-volt D.C. only. Not external ignition protected.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Action: On/On/Off Color: Chrome Plated Box Dimensions: 1"H x 4"W x 7"L WT: 0.2 lbs UPC: 022697759436

Read more less

50 AMP Male Stainless Steel Combo KitThe SmartPlug 50 AMP Combo kit includes the 50 AMP Stainless Steel inlet (BM50S) and 50AMP connector (BF50), everything you need to protect your boat from shore power overheating.  Installation of both components is easy.  The kit is designed to fit on 125/250 V systems with multiple seals on the connector to ensure a watertight fit on an existing cordset.Features Reduces Overheating – Increased pin and clip surface area greatly improves electrical conductivity during high amperage demand. Ease of Use – No twist required, the unique plug body shape and push-in design means it only goes in the right way every time-even in  the dark. Multi-Point Locking System – Side clips lock the plug securely into the inlet which eliminates any stress on the pins from movement of the power cord. Weatherproof Seals – Superior gaskets installed in the inlet cover and interior of the plug body eliminates moisture penetration. Quick and Easy Installation – Inlet mounting flange holes match twist-type holes for an installation that is typically finished in 30 minutes. *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

BF30 30 AMP Female ConnectorThe 30 AMP 125 V connector has been designed to be used with 3-wires (125 V) in a single connector.  This retro-fit connector offers superior performance and ease of use.  The SmartPlug connector is designed to use your current cordset.  You simply cut off the cord plug on your RV/Boat 30 AMP cord.  The connector has mechanical cord restraint, color coded wire guides, a water resistant cord seal and spring loaded side levers that automatically lock into the slots on the inlet housing.Features: Eliminates Overheating – Increased pin and clip surface area greatly improves electrical conductivity during high amperage demand Ease of Use – No twist required, the unique plug body shape and push-in design means it only goes in the right way every time – even in the dark. Multi-Point Locking System – Side clips lock the plug securely into the inlet which eliminates any stress on the pins from movement of the power cord. Weatherproof Seals – Multi-fin silicone gaskets installed in the inlet cover and interior of the plug body eliminates moisture penetration. *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

30 AMP SmartPlug/Twist Type Cordset with Carry Case - 25'For many years boaters have experienced the safety, security and simplicity of SmartPlug products on the boatside while still dealing with the same old issues created by legacy twist-type products on the dockside.   Those days are changing with the introduction of SmartPlug's new dockside product offering.  SmartPlug has applied decades of experience and customer feedback to create a product that allows you to upgrade your shore power connection with SmartPlug technology. The 30 AMP 125 V cordset provides a complete weatherproof power solution. The cordset includes the SmartPlug connector for the Boatside and a Twist Type Plug connector for the Dockside.Includes soft carry case for the ultimate storage solution.Features: Multi-Point Locking System - Side clips lock the body securely into the inlet, which eliminates any stress on the electrical connection from movement of the power cord. Weatherproof Seals - Silicone gaskets installed in the interior of the plug body eliminate any water penetration when plug is connected to inlet. LED Power Indicator Light – On the top of all SmartPlug female ends, two LED indicator lights.  One Red and one Blue LED light for Safe/Unsafe Electrical Power Indication under Reverse Polarity Conditions. Tinned Wire – All SmartPlug marine cords have tinned wire to minimize corrosion. Technical Specifications: Length - 25' Color - Orange Boatside Connection - 30 AMP/125 V SmartPlug Dockside Connection - 30 AMP/125 V Twist Type Plug *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Length: 25' Voltage: 125 Type: Cordset Amperage: 30 Box Dimensions: 5"H x 14"W x 14"L WT: 8.1 lbs UPC: 798304074284 Owner's Manual (pdf)Brochure (pdf)
