Electrical

8" Cable Tie - Black - 50lb Tensile Strength - 2" Bundle Diameter - 100 Piece BagCable ties are used in a variety of industries to secure wire bundles, cables, or other surfaces. They can be installed quickly and easily and are built to last in tough environments. Made from Nylon 6.6, white cable ties are built for indoor use while the black cable ties are meant for both indoor and outdoor usage. Cable ties are one of the most widely used and versatile bundling and harness materials available.Features: Natural: For indoor use Black: For indoor or outdoor use (UV resistant) The curved tip is easy to pick up from flat surfaces and allows faster initial threading to speed up installation Applications: Cable ties are the most widely used and versatile bundling and harnessing material available Used to secure a cable bundle to another surface such as a control panel, communication rack, wall, or ceiling Compliances: UL Listed, CSA Flammability UL 94V-2 RoHS & CE compliant Characteristics: 6.6 Nylon (Nat. & UV res. Black) Max. Cont. Temp. 185 °F (85 °C) Min. Cont. Temp. -76 °F (-60 °C) Specifications: Type: Cable Ties Box Dimensions: 1"H x 6"W x 9"L WT: 0.3 lbs UPC: 840248216531 Brochure (pdf)

Read more less

Battery Cable Heavy Wall Heat Shrink Tubing - 1" x 12" - Black (2-Pieces)BHW is coated internally with a dual-purpose thermoplastic liner which flows and encapsulates when heated.  When cooled, the tubing offers the mechanical strength of a superior adhesive and the corrosion protection of a high-quality mastic.  Insulation varies with different types of wires, different diameters or tubing may be required.  When choosing a size, consider any components or connectors that may need to be covered.Features: Highly abrasion and impact-resistant Easy installation, shrinks when heated over 120 °C The thermoplastic liner will adhere to PVC, neoprene and polyolefin, EPR, steel, and aluminum A sturdy, heavy wall tubing with excellent insulating, abrasion-resisting, and strain-relieving properties. The thermoplastic adhesive provides superior environmental protection. Any connection in harsh conditions Adhesive lining provides a barrier against contaminants Excellent resistance to acids and alkalis Good resistance to fuel, oil, and solvents Applications: Splice sealing Primary insulation Cable/jacket repair Direct burial/submersible Strain relief Compliances:MIL-I-23053/15 Class 2 Specifications: Type: Heat Shrink Box Dimensions: 1"H x 3"W x 12"L WT: 0.1 lbs UPC: 840248214360 Brochure (pdf)

Read more less

Tinned Lug 6 AWG - 5/16" Stud Size - 10 PackCreating a strong connection is essential to every electrical system. By using closed-end lugs, users get not only durability but longevity as well. Pacer's closed-end lugs are tin-plated and have no exposed seams. This means that they are ideal for marine applications. What makes them ideal is the fact that they can be used to create waterproof connections. When used with epoxy heat shrink, the closed end lug will fully envelop the conductor. This leaves nothing exposed to the elements. To use, simply strip your wire or cable to the proper length. Once this is complete, slide the lug over the exposed wire, making sure the insulation butts up to the edge of the lug.Now, crimp the lug using the correct tool, and you're done. Add epoxy lined heat shrink for added durability. Pacer's closed-end lugs are available in 8 AWG to 4/0 AWG wire sizes. The available stud sizes include #10, 1/4", 5/16", 3/8", and 1/2". Selecting the correct closed-end lug isn't an easy task. Contact a Pacer expert today with any questions that you may have.Features: Tin Plated No exposed seams Rated for 600V Made from seamless tubes of 99.9% copper for higher conductivity Designed for stranded copper wires Larger pad area for better contact Cable size and stud hole stamped on pad Can be crimped or soldered Highly controlled flare to allow easy cable insertion Tight barrel to pad transition provides longer usable barrel length Compliances: E.T.P. (Electrolytic Tough Pitch) CDA-110 ASTM-B-152 copper rated at 100% conductivity UL & CSA Approved RoHS Compliant Exceeds SAE Conductivity STD J163 & J1811 Specifications: Wire AWG: 6 Stud Size: 5/16” Length: 1.266” Width: 0.438” Clearance: 0.344” Package Size: 10 Specifications: Gauge: 6 AWG Heat Shrink: No Package Qty: 10 Post Size: 5/16" Type: Lugs Box Dimensions: 0"H x 5"W x 9"L WT: 0.15 lbs UPC: 840248205894 Brochure (pdf)

Read more less

Blue 18 AWG UL Marine Wire - 35'Pacer's marine wire is designed to handle the harshest marine environments. It is manufactured to meet and exceed the most stringent specifications. This 18 AWG marine wire is constructed in-house in Sarasota, FL, USA, to achieve the highest level of quality. Built from Type III class K tinned copper, Pacer marine wire offers excellent corrosion resistance and flexibility. After the copper is tinned, it is then insulated with a durable and flexible proprietary PVC jacket. The jacket makes this 18 AWG marine wire resistant to alkali, abrasion, acid, gas, oil, flame, and moisture. All marine wire needs to be durable enough to handle the toughest conditions, and Pacer marine wire does just that. Pacer's marine wire meets or exceeds the requirements and standards of UL, ABYC, and NMMA.Features: Stranded, tinned copper conductors Highly flexible color-coded insulation Compliances: AWM 1015/1230  CSA: TEW Temperature Rating: 105 °C Dry, 60 °C Wet Characteristics: Conductor: Type III annealed finely stranded tinned copper ASTM B172 Class K Insulation: -20 °C to 105 °C flexible, color-coded PVC Voltage Rating: 600-V Resistant to: Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture Applications: Point to point wiring Internal wiring of panels and motors Specifications: AWG: 18 Length: 35 ft. Color: Blue Cond. Stranding: 16/0.0100 Nom. Ins. Thickness: 0.030 Nom. O.D.: 0.114 Nom. Circular Mils: 1600 Approximate LB/M: 10.3 Specifications: Color: Blue Gauge: 18 AWG Length (Feet): 35' Box Dimensions: 2"H x 4"W x 4"L WT: 0.5 lbs UPC: 840248215763 Brochure (pdf)

Read more less

Battery Cable Heat Shrink Tubing - 1/2" x 12" - Black (5-Pieces)BHW is coated internally with a dual-purpose thermoplastic liner which flows and encapsulates when heated.  When cooled, the tubing offers the mechanical strength of a superior adhesive and the corrosion protection of a high-quality mastic.  Insulation varies with different types of wires, different diameters or tubing may be required.  When choosing a size, consider any components or connectors that may need to be covered.Features: Highly abrasion and impact-resistant Easy installation, shrinks when heated over 120 °C The thermoplastic liner will adhere to PVC, neoprene and polyolefin, EPR, steel, and aluminum A sturdy, heavy wall tubing with excellent insulating, abrasion-resisting, and strain-relieving properties. The thermoplastic adhesive provides superior environmental protection. Any connection in harsh conditions Adhesive lining provides a barrier against contaminants Excellent resistance to acids and alkalis Good resistance to fuel, oil, and solvents Applications: Splice sealing Primary insulation Cable/jacket repair Direct burial/submersible Strain relief Compliances:MIL-I-23053/15 Class 2 Specifications: Type: Heat Shrink Box Dimensions: 1"H x 4"W x 13"L WT: 0.1 lbs UPC: 840248214469 Brochure (pdf)

Read more less

Red 16 AWG Wire Ferrule - 8mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features: Prevent strand separation while minimizing strand breakage Insulated ferrules provide additional electrical insulation Increase connection reliability when terminating stranded wire in terminal blocks Specifications: Package Size: 25 Wire Size (AWG): 16 Insulation Color: Red Ferrule Length: 8mm (0.31 in.) Stripping Length: 10mm (0.39 in.) Quick Guide (pdf)

Read more less

Green 6 AWG Wire Ferrule - 12mm Length - 10 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features: Prevent strand separation while minimizing strand breakage Insulated ferrules provide additional electrical insulation Increase connection reliability when terminating stranded wire in terminal blocks Specifications: Package Size: 10 Wire Size (AWG): 6 Insulation Color: Green Ferrule Length: 12mm (0.47 in.) Stripping Length: 14mm (0.59 in.) Quick Guide (pdf)

Read more less

Grey 12 AWG Wire Ferrule - 10mm Length - 25 PackWire fraying can quickly become a problem when dealing with IEC (European)-style terminal blocks. As the wire frays, the connection becomes weaker, and the problem will need to be addressed. But all that can be prevented. How? By utilizing wire ferrules. Wire ferrules are a type of terminal that prevents wire fraying. It covers the stranded wire and creates a solid, connected piece. In a sense, wire ferrules make stranded wire behave like solid wire. This is important, especially when working with IEC terminal blocks.How are wire ferrules properly used? The first step is to strip the wire to the correct length. Now slide the ferrule over the exposed wire. Make sure that the nylon casing butts up to the wire insulation. Once set, crimp using the proper tool. Using the proper tool is important, as, without the proper pressure, the wire may not create a solid connection. Proper crimping pressure and technique are key to ensuring continued performance. Once properly crimped, users can add heat shrink for added protection if they choose. Features: Prevent strand separation while minimizing strand breakage Insulated ferrules provide additional electrical insulation Increase connection reliability when terminating stranded wire in terminal blocks Specifications: Package Size: 25 Wire Size (AWG): 12 Insulation Color: Grey Ferrule Length: 10mm (0.39 in.) Stripping Length: 12mm (0.47 in.) Quick Guide (pdf)

Read more less

16-14 AWG Heat Shrink Female Disconnect - 25 PackDisconnects are a type of terminal intended to be disconnected and reconnected multiple times. This makes them ideal for use where field serviceability is an issue. Disconnects are a great way to protect electrical connections. Whether dealing with mechanical abuse, wire pull-out, or abrasion, they are a solid choice for longevity. Disconnects are sometimes known as quick connects or slip-on connectors.Features: Fully insulated Female disconnect Protects terminations from water, condensation, salt spray, and corrosion Added vibration protection in rugged environments Disconnect & reconnectable Creates solid connections Meets multiple compliances Benefits: Environmentally sealed  Built for durability Tinned Copper  Long Lasting Easy to install Characteristics: Insulation Color: Blue Wire AWG: 16-14 AWG Package Size: Twenty-five included Disconnect Size (inch): 0.250 Shrink Ratio: Approximately 3:1 at 135 °C Operating Temperature: -55 °C - 125 °C Volume Resistivity: 1015 Ohm-cm3 Dielectric Strength: 900-V/mil Voltage Rating: 600-V Specifications: Gauge: 16-14 AWG Heat Shrink: Yes Package Qty: 25 Type: Disconnects Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 840248206976 Quick Guide (pdf)

Read more less

22-18 AWG Heat Shrink Ring Terminal - #8 Stud Size - 100 PackRing terminals are used to connect wires to a connection point. They can easily be used with two or more wires. They offer a solid connection as the ring is fitted over a stud. This removes the possibility of the terminal disconnecting. Using the proper parts is essential to a high-quality electrical connection. Ring terminals are the most secure type of tongue-style terminal. They are known for their durability and ease of use.Features: Tinned copper 600 Volts Operating temperature is -55°C to 125°C Highly compliant Benefits & Protections: Solid connections Extremely durable Long-lasting Tin-plated Easy to install Specifications: Color: Red Wire AWG: 22-18 AWG Stud Size: #8 Terminal Pad Width (inch): 0.32” Package Size: One-hundred included Specifications: Gauge: 22-18 AWG Heat Shrink: Yes Package Qty: 100 Post Size: #8 Type: Ring Terminals Box Dimensions: 2"H x 3"W x 8"L WT: 0.4 lbs UPC: 840248206334 Quick Guide (pdf)

Read more less

16-14 AWG Heat Shrink Ring Terminal - 5/16" Stud Size - 25 PackRing terminals are used to connect wires to a connection point. They can easily be used with two or more wires. They offer a solid connection as the ring is fitted over a stud. This removes the possibility of the terminal disconnecting. Using the proper parts is essential to a high-quality electrical connection. Ring terminals are the most secure type of tongue-style terminal. They are known for their durability and ease of use.Features: Tinned copper 600 Volts Operating temperature is -55°C to 125°C Highly compliant Benefits & Protections: Solid connections Extremely durable Long-lasting Tin-plated Easy to install Specifications: Color: Blue Wire AWG: 16-14 AWG Stud Size (inch): 5/16" Terminal Pad Width (inch): 0.48” Package Size: Twenty-five included Specifications: Gauge: 16-14 AWG Heat Shrink: Yes Package Qty: 25 Post Size: 5/16" Type: Ring Terminals Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 840248206310 Quick Guide (pdf)

Read more less

12-10 AWG Heat Shrink Ring Terminal - 5/16" Stud Size - 25 PackRing terminals are used to connect wires to a connection point. They can easily be used with two or more wires. They offer a solid connection as the ring is fitted over a stud. This removes the possibility of the terminal disconnecting. Using the proper parts is essential to a high-quality electrical connection. Ring terminals are the most secure type of tongue-style terminal. They are known for their durability and ease of use.Features: Tinned copper 600 Volts The operating temperature is -55°C to 125°C Highly compliant Benefits & Protections: Solid connections Extremely durable Long-lasting Tin-plated Easy to install Specifications: Color: Yellow Wire AWG: 12-10 AWG Stud Size (inch): 5/16" Terminal Pad Width (inch): 0.54” Package Size: Twenty-five included Specifications: Gauge: 12-10 AWG Heat Shrink: Yes Package Qty: 25 Post Size: 5/16" Type: Ring Terminals Box Dimensions: 1"H x 3"W x 4"L WT: 0.1 lbs UPC: 840248206167 Quick Guide (pdf)

Read more less
