Electrical

AC Rotary Switch Panel 65 Ampere 3 positions + OFF, 3 PolePoles: 3Voltage: 120/240vAmperage: 30Positions: 3 + OFF Switches 3 - 230 Volt AC sources Includes 9011 heavy duty industrial rated switch Two-part polyurethane slate gray finish Heavy 1/8" aluminum 5052 alloy Red reverse polarity LED indicators Green power available LED indicators Compact solution when circuit protection is provided elsewhere WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: AC Max Breaker Quantity: 3 +OFF Voltage: 240v Box Dimensions: 5"H x 9"W x 12"L WT: 2.3 lbs UPC: 632085083618 Owner's Manual (pdf)

Read more less

MEGA Fuse 250A/80V (Package of 5 Pieces)Victron Energy supplies a range of fuse holders and fuses to suit a wide range of installations, and the MEGA fuses are frequently used in Victron Energy DC distribution systems. This particular pack of ceramic Victron MEGA fuses contains FIVE 80 AMP fuses.Features:For 80V productsSpecifications: Max Current Rating: 250 AMP Max Voltage Rating: 80V

Read more less

MEGA Fuse 200A/80V (Package of 5 Pieces)Victron Energy supplies a range of fuse holders and fuses to suit a wide range of installations, and the MEGA fuses are frequently used in Victron Energy DC distribution systems. This particular pack of ceramic Victron MEGA fuses contains FIVE 200 AMP fuses.Features:For 80V productsSpecifications: Max Current Rating: 200 AMP Max Voltage Rating: 80V Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: Amperage: 200a Type: Fuses Box Dimensions: 0"H x 6"W x 6"L WT: 0.25 lbs UPC: 8719076061700

Read more less

Busbar 150A 2P with 10 Screws & CoverBusbars are used for high current distribution and at the same time they provide connections for batteries and/or DC equipment.We offer a number of busbars with different current ratings, and a different number of connection terminals. Each busbar is fitted out with a removable protective cover. Quick Guide (pdf)

Read more less

CYRIX-LI-CHARGE 12/24-120A Intelligent Charge Relay Cyrix LI ChargeThe Cyrix Battery Combiner is a microprocessor-controlled heavy duty relay that automatically connects batteries in parallel when one of them has reached a pre-set voltage (indicating that the battery is being charged) and disconnects when the voltage decreases below float level (indicating that one or more batteries are being discharged). Cyrix Battery Combiners are an excellent replacement for diode isolators. The main feature is that there is virtually no voltage loss so that the output voltage of alternators or battery chargers does not need to be increased.Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less

12V DC 4 PositionFeatures: 4 to 32 branch circuits with installed 15 Ampere circuit breakers Available with voltmeters, ammeters, and digital multimeters Includes 4205-Square Format Label Set Specifications: Positions: 4 Nominal Voltage: 12V DC Maximum Amperage*: 100A Height: 4.75" (120.65mm) Width: 4.88" (123.95mm) Depth: 3.00" (76.2mm) Weight: 1.35lb (0.61kg) * Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.Includes:(4) - 7403 - A-Series Flat Rocker Circuit Breaker - Single Pole 15A(1) - 4205 - Basic DC Label Kit - 30 Black Square Labels [LABEL]WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: AC/DC: DC Box Dimensions: 6"H x 7"W x 9"L WT: 1.5 lbs UPC: 632085012168 Quick Guide (pdf)Owner's Manual (pdf)

Read more less

22-18 Gauge - #8 Heat Shrink Ring Terminal - 100-PackGauge Size: 22-18Screw Size: #8 Quantity: 100Features: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC. Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief. Nylon insulator, preferred by experts, for Marine Grade resistance to sunlight, water, oil, chemicals, vibration and cut-through damage. UL Listed and CSA Recognized Highest shrink ratio - shrinks to 1/3 original size. Shrinks at 257 deg. F/125 deg. C. Operating temperature range 40 deg. C to 110 deg. C. ANCOR heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing= Shrinks to form a water tight seal and the ultimate vibration and strain relief. Tinned for corrosion resistance. Pure copper for maximum current flow. Brazed seam for maximum strength. Wire Range: 22-18 mm: 0.3-0.8 WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 22-18 AWG Type: Ring Terminals Package Qty: 100 Heat Shrink: Yes Box Dimensions: 1"H x 2"W x 4"L WT: 0.2 lbs UPC: 091887311006 Quick Guide (pdf)Brochure (pdf)

Read more less

DC Analog AmmeterShunt Type: External Simple 2-wire connection Meter Senses Powers from same connection Includes DC Shunt Backlit meter face WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

AC Digital Ammeter Displays amperage from 0 to 150 Amps 3 levels of display brightness Splashproof front Includes current transformer Manual sleep mode blanks display for power conservation WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

5114 150A Class T Fuse Features: Extremely fast short-circuit response 20,000 Ampere Interrupt Capacity (AIC) UL listed to standard 248-15 DC Tested to UL standard 198L WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Type: Fuses Fuse Type: Class T Amperage: 150a Box Dimensions: 2"H x 4"W x 6"L WT: 0.2 lbs UPC: 632085051143

Read more less

5119 300AMP Class T FuseFeatures: Extremely fast short-circuit response 20,000 Ampere Interrupt Capacity (AIC) UL listed to standard 248-15 DC Tested to UL standard 198L WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 300a Fuse Type: Class T Type: Fuses Box Dimensions: 3"H x 8"W x 9"L WT: 0.25 lbs UPC: 632085051198

Read more less

Phoenix Inverter 12/1600 120V VE.Direct NEMA 5-15RInverters allow users to power domestic equipment, requiring 230V/120V AC, using 'leisure' or 'automotive' batteries rated at 12V, 24V, or 48V DC.VE.Direct Communication PortThe VE.Direct port can be connected to: A computer (VE.Direct to USB interface cable needed) Apple and Android smartphones, tablets, MacBooks, and other devices (VE.Direct Bluetooth Smart dongle needed) Fully Configurable: Low battery voltage alarm trip and reset levels Low battery voltage cut-off and restart levels Dynamic cut-off: load-dependent cut-off level Output voltage 210 - 245V Frequency 50 Hz or 60 Hz ECO mode on/off and ECO mode sense level Monitoring:In and output voltage, % load, and alarmsProven ReliabilityThe full bridge plus toroidal transformer topology has proven its reliability over many years.The inverters are short-circuit proof and protected against overheating, whether due to overload or high ambient temperature.High Start-Up PowerNeeded to start loads such as power converters for LED lamps, halogen lamps, or electric tools.ECO ModeWhen in ECO mode, the inverter will switch to standby when the load decreases below a preset value (min load: 15W). Once on standby, the inverter will switch on for a short period (adjustable, default: every 2,5 seconds). If the load exceeds a preset level, the inverter will remain on.Remote On/OffA remote on/off switch can be connected to a two-pole connector, or between the battery plus and the left-hand contact of the two-pole connector.LED DiagnosisTo Transfer the Load to Another AC Source: The Automatic Transfer SwitchFor Victron’s low-power inverters, they recommend the Filax Automatic Transfer Switch. The Filax features a very short switchover time (less than 20 milliseconds) so that computers and other electronic equipment will continue to operate without disruption. Inverter Specifications: Cont. Power at 25 degrees C: (1) 250VA  Cont. Power at 25 degrees C / 40 degrees C: 200 / 175W  Peak Power: 400W  Output AC Voltage / Frequency (adjustable): 230VAC or 120VAC +/- 3% 50Hz or 60Hz +/- 0,1% Input Voltage Range: 9,2 - 17 / 18,4 - 34,0 / 36,8 - 62,0V DC Low Shut Down (adjustable): 9,3 / 18,6 / 37,2V Dynamic (load dependent) DC Low Shut Down (fully configurable): Dynamic cut-off, see https://www.victronenergy.com/live/ve.direct:phoenix-inverters-dynamic-cutoff DC Low Restart & Alarm (adjustable): 10,9 / 21,8 / 43,6V Battery Charged Detect (adjustable): 14,0 / 28,0 / 56,0V Max. Efficiency: 87 / 88 / 88%  Zero-Load Power: 4,2 / 5,2 / 7,9W  Default Zero-Load Power in ECO Mode (default retry interval: 2,5 s, adjustable): 0,8 / 1,3 / 2,5W  ECO Mode Stop & Start Power Setting: Adjustable Protection (2): a - f Operating Temperature Range -40 to +65 degrees C (fan-assisted cooling)  Enclosure Specifications: Material & Color: Steel chassis and plastic cover (blue Ral 5012) Battery-Connection: Screw terminals Maximum Cable Cross-Section: 10mm² / AWG8  Standard AC Outlets: 120V: NEMA 5-15R Protection Category: IP 21 Weight: 2,4kg / 5.3 lbs  Dimensions (H x W x D, mm); (H x W x D, inch): 86 x 165 x 260; 3.4 x 6.5 x 10.2 Accessories: Remote On-off: Yes Automatic Transfer Switch: Filax Standards: Safety: EN-IEC 60335-1 / EN-IEC 62109-1 / UL 458 (3) EMC: EN 55014-1 / EN 55014-2 / IEC 61000-6-1 / IEC 61000-6-2 / IEC 61000-6-3 Automotive Directive ECE R10-4: 1) Nonlinear load, crest factor 3:1; 2) Protection key: a) output short circuit b) overload c) battery voltage too high d) battery voltage too low e) temperature too high f) DC ripple too high Please contact your dealer for any returns, repairs or support issues related to this product. Specifications: AC Connection Type: Outlet DC Connection Type: Hardwire GFCI: No Inverter Cont. Output Wattage: 1280W Inverter Input Voltage: 12VDC Inverter Output Voltage: 120VAC Inverter Surge Rating: 1600 Outlet Qty: Hardwire Waveform: True Sine Wave Box Dimensions: 8"H x 11"W x 17"L WT: 19.75 lbs UPC: 8719076071921 Quick Guide (pdf)Owner's Manual (pdf)Brochure (pdf)

Read more less
