7620Manual Control: NoCoil Voltage: 12V DC Combines battery banks during charging and isolates under discharge 500 Ampere continuous rating suitable for use with large battery banks, starters, alternators, and inverter/chargers Includes ML-Series Remote Control Contura Switch PN 2146 Silver alloy contacts provide high reliability 3/8" copper studs, using Blue Sea Systems superior one piece stud technology, suitable for 300 Ampere continuous rating and large cable connections WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)Brochure (pdf)

Read more less

ProSafe FAILSAFE 60amp Galvanic IsolatorProSafe FS installs easily and does not require a dedicated monitor to verify the operational status of the galvanic isolator as required by non FailSafe Certified galvanic isolators.ProSafe FS 60 is built on robust FlatPack semiconductor platforms ensuring that in the event of a failure, the failure is safe by not compromising the ground continuity on-board when connected to AC Shore Power. ABYC A-28 July '08 Compliant and Fail Safe CertifiedCertified by Underwriters Laboratories (UL). Insures shore power safety ground wire is maintained through the isolator. Flat Pack High Power SemiconductorsRobust high power diodes allow the FS Series to meet the new FailSafe criteria for conducting inrush currents of 3,000 amps for the required duration period. Ignition ProtectedMeets ISO 8846 and can be mounted within an engine compartment. Gold Plated Terminations WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

2121 Marine Grade Plug & Socket - 12VFor all Scotty High Performance Downriggers, Depthpower Downriggers, and Line Pullers.Features: IP67-rated 12V 30A marine-grade electric plug and socket Comes with flush mount and 90° mounting brackets with a watertight socket cap Rated for use with 10 – 14 gauge wire Recommended use of Premium 10 Gauge 2 Conductor Downrigger Power Wire for wiring your downrigger socket Brochure (pdf)

Read more less

T-H FLEX™ 1-1/4" Expandable Braided Sleeving - 50' RollT-H FLEX™ is a lightweight, braided jacketing for bundling and protecting wires, cables and hoses. Braided from high temperature yarns, T-H FLEX™ offers total protection for wire and cable assemblies. The unique expansion characteristics makes T-H FLEX™ easy to slip on. Only a few sizes are needed to cover a large diameter range, since each size of T-H FLEX™ expands up to four times its normal diameter.  The sleeving cuts easily and cleanly with a hot knife and once installed, will beautify and protect any wire, hose or cable application.Features: Lightweight Protective Sleeving Protects Wire, Cables and Hoses Braided from High Temperature Yarns Chemical Resistant Simplifies and beautifies any rigging application Specifications: Type: Misc Box Dimensions: 6"H x 9"W x 10"L WT: 1.45 lbs UPC: 733572036756

Read more less

Orion 24/12-70A DC-DC Converter with Binding Posts - IP20Remote On-Off ConnectorThe remote on-off eliminates the need for a high-current switch in the input wiring. The remote on-off can be.operated with a low-power switch or by the engine run/stop switch (see manual).All Models with Adjustable Output Can Also Be Used as a Battery ChargerFor example, charge a 12 Volt starter or accessory battery in an otherwise 24V system.All Models with Adjustable Output Can Be Paralleled to Increase Output CurrentUp to five units can be connected in parallel.Easy to InstallDelivery includes four Insulated Fastons Female Crimp 6.3mm.Specifications: Input Voltage Range (V): 18-35 Under Voltage Shutdown (V): 14 Under Voltage Restart (V): 18 Output Voltage Adjustable with Potentiometer: Yes Output Voltage (V): Adjustable, 10–15V, F set 13,2V Efficiency (%): 92 Suitable to Buffer-Charge a Battery: Yes Can Be Connected in Parallel: Yes Continuous Output Current (A): 70 Max. Output Current (A): 85 Fan-Assisted Cooling (Temp. Controlled): Yes Galvanic Isolation: No Off Load Current: < 20mA Remote On-off: Yes  Operating Temperature Range (Derate 3% Per °C above 40°C): -20 to +55°C DC Connection: M6 bolts Weight: 0,9 kg / 2.0 lbs Dimensions (H x W x D): (mm) 65 x 88 x 195 / (inch) 2.6” x 3.5” x 7.7”  Safety Standards: EN 60950  Emission Standards: EN 61000-6-3, EN 55014-1  Immunity Standards: EN 61000-6-2, EN 61000-6-1, EN 55014-2  Automotive Directive Standards: ECE R10-4 Please contact your dealer for any returns, repairs or support issues related to this product. Quick Guide (pdf)

Read more less

16-14 Gauge - 5/16" Heat Shrink Ring Terminal - 3-PackWire Range:16-14Screw Size:5/16"Quantity: 3Product Features: Cross Linked polyolefin tubing is much stronger than PVC tubing and will not burn like PVC Heat activated adhesive lining provides impervious seal to salt water, oil, acids, and sunlight as well as providing strain relief Nylon insulator, preferred by experts, for Marine Grade™ resistance to sunlight, water, oil, chemicals, vibration and cut-through damage UL Listed and CSA Recognized Highest shrink ratio - shrinks to 1/3 original size Shrinks at 257° F/125° C Operating temperature range 40° C to 110° C ANCOR heat shrink connectors offer heat activated adhesive built into the sleeve of the heat shrink tubing Shrinks to form a water tight seal and the ultimate vibration and strain relief Tinned for corrosion resistance Pure copper for maximum current flow Brazed seam for maximum strength WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Gauge: 16-14 AWG Package Qty: 3 Heat Shrink: Yes Type: Ring Terminals Post Size: 5/16" Box Dimensions: 1"H x 1"W x 1"L WT: 0.1 lbs UPC: 091887313147 Quick Guide (pdf)

Read more less

Single XD - NMEA 2000 - Relay with Knobs - 4 Position DTFeatures: Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware. 500A continuous / 1600A cranking (per switch) - supports all standard marine electrical systems. Intuitive Manual Control option simplifies operation and awareness of the state of manual override and whether the device is being left in a locked off or locked on state (not available on competitive solutions) Simple Programmability via simple dip switches allows each relay function significant flexibility for OEMs and installers.  90-95% Less Off-State Current: Compared to competitive products and system solutions that require multiple devices for similar functionality Applications: Seamless NMEA 2000 Integration – Control switches, monitor switch status, and battery voltage. Flexible Control Options – Operate via NMEA 2000 or discrete analog inputs for added versatility. 35-75% Reduction in Mounting Space & Product Weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts. Eliminates Dead Start Batteries by sharing charging on either of two batteries and isolating batteries when no charge sources are present. Expandable with Link and Cross-Link Busbars to Additional Dual, Triple, or Single XD Relays: Supports 2 or 3 battery systems with standard busbar interconnect accessories. Specifications: Type: Electric Box Dimensions: 3"H x 4"W x 8"L WT: 1.2 lbs UPC: 850067590200

Read more less

XD Series Single 500 Amp Heavy Duty Battery Switch/Mechanical ContactorFeatures: Silver Alloy Contact Points support high ampere/full voltage switching capability versus legacy rotary style switches. Expandable: Integrate the 8700 XD Battery Disconnect easily with XD Series FLEX/ACR/LVD relays via using optional 8790 Link and 8791 Cross Link Busbars for easy integration with other Single, Dual, or Triple Circuit XD relays. Terminal Stud Protection: Included protective cover with convenient label recesses ensures no accidental shorts occur and allows for easy identification of circuits long term. Bullet-proof Construction: Sealed to IP67/IP6K9K, high-temperature electronics and materials allow mounting anywhere. Stainless steel cable lug studs. Large mounting holes accept 1/4-20 / M6 attachment hardware.  Intuitive Manual Control: Bright yellow knob and intuitively easy-to-read on/off label simplifies operation and awareness of the state of manual override and whether the device is being left in a locked off or locked on state. Ignition Protected: Safe for installation in gasoline-powered boats and other combustible installation environments. Sealed IP67 Construction keeps moisture out, and the integrated Gore-Tex pressure regulation vent increases its ability to operate reliably for long-term harsh environment operation.  Compact Case Design allows for easy surface mount or rear panel installs, and the rectangular shape (narrower than competing products) makes finding a mounting location easy. Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Terminal Stud Size (mm): M10 Voltage Range (VDC): 8-36 Ingress Protection: IP67/IP6K 9K Contact Materials: Silver Alloy Focal Features:High Visibility KnobForce each individual relay Open or Closed and optionally leave knob in either position to lock relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for included weatherproof label set makes circuit and relay identification easy. Blank labels for custom applications.Protective Cover IncludedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground.Stainless HardwareCorrosion is no issue with quality stainless steel studs and self locking flanged nuts.Smaller FootprintXD Relays offers high Amp rating in a smaller package than competitive solutions, reducing install space requirements to a minimum.Integrated VentHigh quality Gortex vent regulates internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments. Brochure (pdf)

Read more less

40A Surface Mount Circuit Breaker - 285 SeriesThis 40A Egis circuit breaker protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction.Applications: Automatic circuit protection and manual on/off switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems regardless of the location Features: Sealed against dust and water intrusion to ensure reliable circuit protection for the life of the electrical system installation  High Voltage (48 Vdc) Rating - easily supports 12 and 24 VDC applications while offering advanced protection for 36 and 48 VDC High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current High Interrupt Current - safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 40 Max Voltage: 48 Cycling Endurance: 6,000 Interrupt Current @16 VDC (Amps): 5,000 Interrupt Current @28 VDC (Amps): 3,000 Ingress Protection Rating: IP67 Focal Features:ON/OFF High Visibility ControlsSealed against dust and moisture penetration. The high temperature rating for all installation locations.Integrated Terminal InsulatorsProtects against inadvertent shorts from positive terminals to adjacent grounded surfaces.Stainless Steel Hardware / Serrated Flange NutsCorrosion and vibration resistance for harsh environment applications.Proudly Made in the USAMade in the USA of high-quality components.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Box Dimensions: 3"H x 3"W x 5"L WT: 0.35 lbs UPC: 850035199121 Quick Guide (pdf)

Read more less

40A Surface Mount 87 Series Circuit BreakerThis 40A Egis circuit breaker protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction.Applications: Automatic circuit protection and manual on/off switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems regardless of the location Features: IP66 sealed against dust and water intrusion to ensure reliable circuit protection for the life of the electrical system installation   High Voltage (48 Vdc) Rating - easily supports 12 and 24 VDC applications while offering advanced protection for 36 and 48 VDC High Electrical / Manual Switching Endurance delivers 2,000 cycles at full current High Interrupt Current - safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 40 Max Voltage: 48 Cycling Endurance: 2,000 Interrupt Current @14 VDC (Amps): 5,000 Interrupt Current @28 VDC (Amps): 3,000 Ingress Protection Rating: IP66 Focal Features:ON/OFF High Visibility ControlsSealed against dust and moisture penetration. The high-temperature rating for all installation locations.Reinforced Mounting Ensures long-term structural reliability with reinforced mounting tabs built to withstand the stress of vibration. Stainless Steel Hardware / Serrated Flange NutsCorrosion and vibration resistance for harsh environment applications.Proudly Made in the USAMade in the USA of high-quality components.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 40a Box Dimensions: 3"H x 3"W x 5"L WT: 0.6 lbs UPC: 850035199305 Quick Guide (pdf)

Read more less

XD Series Triple Flex 2 Relay-ACR-Relay with Knobs & 3X DTM ConnectorThe Egis relay replaces three individual high-amp relays with one compact module, reducing space significantly, eliminating the cost of external link cable connections, eliminating the risk of link cable connections vibrating loose, and providing clear, unambiguous awareness of how to operate manual controls and what state the manual controls have forced the relay into.Applications:  Designed to replicate common multi-battery switching and charge management functions - common dual battery load switching via the outer relays and a central automatic charging relay to share charge current are easily implemented Multiple automatic charging relays (ACR) into one device - for 3-4 battery systems that require 2 or 3 ACRs, a single three-relay ACR provides drastic improvements in off-state quiescent current draw, space used, and reduces unnecessary interconnection cables Expandable with link and cross-link busbars to additional dual, triple, or single XD relays - supports 3 or 4 battery systems with standard busbar interconnect accessories Features: Bullet-proof construction - sealed to IP67/IP6K9K, high temperature electronics and materials allow mounting anywhere; stainless steel cable lug studs; large mounting holes accept 1/4-20 / M6 attachment hardware Intuitive manual control option simplifies operation and increases awareness of the state of the manual override and whether the device is being left in a locked-off or locked-on state (not available on competitive solutions) Simple programming via dip switches gives each relay function significant flexibility for OEMs and installers. 35-75% reduction in mounting space and product weight via advanced bi-stable solenoid design and multiple solenoid assemblies that replace common electrical system layouts Plug and play compatible with legacy competitor products - single, dual, and triple relay options are available with DTM/ATM connector pins compatible with ML Series bi-stable relays (This relay has 3x DTM connectors) 90-95% less off-state current compared to competitive products and system solutions that require multiple devices for similar functionality Specifications: Total Continuous Current Amps: 500 Max Cranking Current (Amps): 1500 Mechanical Switching Life: 1,000,000 Cycles Voltage Range (VDC): 8-36 Off-State Current Draw (mA): 1.3 State Change Current: 5A @ 12 VDC; 3A @ 24 VDC Focal Features:Led Status DisplayThe easy-to-see front-facing LED indicator provides visual device status, and the remote LED replicates the local on-device LED. 3-Position Manual overrideForce each relay open or closed, and optionally leave the knob in either position to lock the relay in either condition. 40 Circuit Label Sheet IncludedConvenient recesses for the included weatherproof label set make circuit and relay identification easy. Blank labels for custom applications. Protective Cover includedProtects terminal studs and cable terminal edges from inadvertent shorts to each other or ground. Stainless Hardware Corrosion is no issue with quality stainless steel studs and self-locking flanged nuts.ProgrammableVia dip switches located under the protective cover. An easy-to-use configuration guide on the reverse makes custom settings a breeze to configure for a wide variety of applications. Smaller FootprintXD relays offer a high amp rating in a smaller package than competitive solutions, reducing installation space requirements to a minimum. Integrated VentHigh-quality Gortex vents regulate internal device pressure to eliminate moisture entry across seals and ensure long product life in harsh environments.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Quick Guide (pdf)

Read more less

50A Surface Mount Circuit Breaker - 285 SeriesThis 50A Egis circuit breaker protects electrical circuits from short-circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction.Applications: Automatic circuit protection and manual on/off switching combine dual functionality in one reliable and compact solution Allows for circuit isolation and maintenance of load circuits by providing convenient switching and integral circuit protection capable of mounting adjacent to battery systems, regardless of the location Features: Sealed against dust and water intrusion to ensure reliable circuit protection for the life of the electrical system installation  High Voltage (48 Vdc) Rating - easily supports 12 and 24 VDC applications while offering advanced protection for 36 and 48 VDC High Electrical / Manual Switching Endurance delivers 6,000 cycles at full current High Interrupt Current - safely protects circuits connected to large paralleled battery banks with significant available power 4-Year Warranty - Egis stands behind its product's ability to meet the user's needs Specifications: Continuous Current Amps: 50 Max Voltage: 48 Cycling Endurance: 6,000 Interrupt Current @16 VDC (Amps): 5,000 Interrupt Current @28 VDC (Amps): 3,000 Ingress Protection Rating: IP67 Focal Features:ON/OFF High Visibility ControlsSealed against dust and moisture penetration. The high temperature rating for all installation locations.Integrated Terminal InsulatorsProtects against inadvertent shorts from positive terminals to adjacent grounded surfaces.Stainless Steel Hardware / Serrated Flange NutsCorrosion and vibration resistance for harsh environment applications.Proudly Made in the USAMade in the USA of high-quality components.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 50a Box Dimensions: 3"H x 3"W x 5"L WT: 0.35 lbs UPC: 850035199138 Quick Guide (pdf)
