Electrical

6006m-Series (Mini) Battery Switch Single Circuit ON/OFF Switches a single battery to a single load group Multiple switches can be used to manage several isolated circuits including cross conntecting for emergency paralleling Ignition protected - Safe for installation aboard gasoline powered boats Case design allows surface, front panel, or rear panel mounting Isolating cover with snap-on sections protects rear contacts 3/8"-16 tin-plated copper studs for maximum conductivity and corrosion resistance, accepts 3/8" and M10 ring terminals 7/8" (22.22mm) stud length to accept multiple cable terminals Ideal for marine or RV applications All non-corrosive marine grade metals Molded in durable reinforced polycarbonate Tactile textures indicate knob position by feel only Label with international ON/OFF legends Removable key or knob remains positively retained ICON label set included for circuit identification WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Positions: 1 Lockable: Yes Continuous Amperage: 700a Box Dimensions: 2"H x 4"W x 7"L WT: 0.65 lbs UPC: 632085060060 Owner's Manual (pdf)

Read more less

Programmable Automatic Charging Relay (ACR) 160A, 12VThis 160A Egis charging relay is automatic and programable. The relay eliminates dead start batteries by sharing charging on either of two batteries and isolating batteries when no charge sources are present.Applications: Supports multiple engines or independent charge systems by incorporating two independent start or engine isolation inputs to allow isolation of charge sources when both are active to maximize charging performance. Protects Electrical System Cascading Faults with an optional lock-out from closing if one terminal is connected to a battery with a shorted cell. Features: Ultra-Low Power Draw Compared to typical ACRs (7-10 mA) vs 7610 ACR @ 1.3 mA, will not deplete batteries even after extended electrical system downtime. Simple and robust installation - The integrated sealed plug eliminates corrosion and includes a Deutsch/Amphenol DTM connector harness Start Assist input option to ensure maximum cranking amps are available by allowing the manual connection of batteries via a remote switch. Bullet-proof construction - Sealed unit, stainless steel hardware, and high-temperature materials allow mounting anywhere. Integrated thermal overload shutdown protection. Additional low-amp output can be used to report device status remotely or drive a secondary relay for charging a battery bank without a charge source (see example) Specifications: Continuous Current (Amps): 160 Voltage Range: 8-18 VDC Off-State Current Draw mA: 1.3 Interrupt Current (Amps): 240 ACR Closing Voltage (VDC): 12.9-13.6 ACR Opening Voltage (VDC): 12.1-12.8 Focal Features:Top Side Dip SwitchesAccessible after mounting for programming voltage settings and determining active features. Protected by self-retained cover.Stainless Steel Self-Locking Hardware100% Non-ferrous corrosion-resistant materials. All attachment screws and nuts are self-locking.Integral I/O ConnectorSealed Molex MX-150 connector eliminates the susceptibility to corrosion and vibrating loose of 1/4" quick connect terminals on competitive products.Connection OptionsComes standard with a Deutsch DT/AT style connector harness. Provides three connection options (MX-150, DT/AT, and wire leads).Easy Integration with RT Fuse Blocks (24 HR Circuits)Optional EasyLink bus bars reduce the space and cost of connecting TH Series relays with RT Series Fuse Blocks.LED DiagnosticsProvides an indication of pending relay ON/OFF, under voltage, over voltage/temp, start isolation/assist, and output on/off status.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Lockable: Yes Box Dimensions: 3"H x 4"W x 8"L WT: 0.85 lbs UPC: 850035199633 Quick Guide (pdf)

Read more less

ProSportHD 20 Plus Gen 4 - 20 Amp - 3 Bank Battery ChargerProSportHD Generation 4 boasts a tri-surface heatsink design. This heavy-duty lightweight design delivers significantly faster charging through optimal cooling, while delivering true rated amp output during charge mode. ProSportHD's enhanced microprocessor and software provides digital features including: fuel gauge style Charge Completion Monitor, Charge Mode, individual Fault indicators and three digitally selectable performance charge profiles for Flooded (lead acid), AGM and GEL batteries. HP AGM profile on ProSportHD 20 Dual only. Fully automatic 5-stage charging enhances battery performance while extending battery life. System Check OK and Battery Status indicators provide real time installation and battery fault status. Designed for use in harsh environments with our industrial grade jacketed DC and AC power cables which include molded strain reliefs and wire splitters. Features: ProMar Digital Technology Microprocessor and software controlled charging technology for fast, precise charging Distributed-On-Demand™ Technology 100% of all available charging amps are utilized by distributing unused charging amps to any one or combination of all batteries as needed Heavy Duty Tri-Surface Extruded Heat Sink Design Upper, lower and rear facing heat sink design for optimal cooling while delivering true rated constant current charging amps during its two charge mode Expanded LED Display with Completion Status Gauge LED fuel gauge style completion status. Four color multi-stage mode LED status bar. Multi-stage Charge Mode, System Check OK, individual Battery Status and Battery Type indication Lightweight Design Up to 40% lighter compared to an epoxy filled charger Auto-Maintain Energy Saver Mode Monitor and auto maintain batteries only when needed to maintain full state of charge. This significantly reduces AC power consumption Fully Automatic 5-Stage Digital Performance Charging 5 Stages: Analyzes, charges, conditions, auto maintains and reconditions batteries once a month during storage periods. Fully charges and extends battery life Built-in Quality and Safety Dual inline waterproof fuses, reverse polarity, over-temperature, over-current, over-voltage and ignition protection. Certified to Marine UL 1236. CEC and DOE listed. FCC Class B Easy Installation and Operation Pre-wired with 6’ AC and DC cables Battery Type: Group 24–31 Flooded, AGM, HP AGM and GEL batteries 3 Year Warranty WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Portable: No Charging Banks: 3 Charger Output Voltage: 12/24/36v Charger Output - Amps: 20a Charger Input - Voltage: 120v Box Dimensions: 7"H x 9"W x 16"L WT: 9.5 lbs UPC: 031669440210

Read more less

3131 Surface Mount Circuit Breaker EnclosureSurface mount option for mounting single and double pole circuit breakers Surface mount box for mounting single and double pole circuit breakers Accepts A-Series toggle and A and C-Series Flat Rocker Circuit Breakers Accommodates optional LEDs and square format labels Wire glands and fasteners are included WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

C-Series Flat Rocker Circuit Breaker - Single Pole - 60AFeatures: Rocker actuator is flush in the "ON" position, eliminating the risk of accidential switching Color actuator indicates "OFF" position Provides overcurrent protection for inverters, bow thrusters, and windlasses Combines switching and circuit protection into a single device "Trip Free" - cannot be held closed after trip Ignition protectedsafe for installation aboard gasoline powered boats Specifications: Amperage: 60A AC / 60A DC Actuator Style: Flat Rocker Poles: 1 Maximum Voltage: 240V AC / 48V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Terminal Stud Torque: 35 in-lb (3.95 Nm) Interrupt Capacity: 3000A @ 120V AC / 3500A @ 240V AC / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Switching Cycles: 10000 Terminal Stud: 1/4-20 Tin-Plated Brass Weight: 0.38lb (0.17 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 60a Box Dimensions: 2"H x 2"W x 4"L WT: 0.5 lbs UPC: 632085075477

Read more less

A-Series Raised Rocker Circuit Breaker - Double Pole - 32AFeatures: Color actuator indicates "OFF" position "Trip Free" design cannot be held "ON" during a fault current condition International ON/OFF symbols support vertical or horizontal mounting Specifications: Amperage: 32A AC / 32A DC Actuator Style: Raised Rocker Poles: 2 Maximum Voltage: 120V AC / 240V AC / 32V DC Circuit Breaker Type: Magnetic Hydraulic - trip free Interrupt Capacity: 3000A @ 240V AC / 1500A @ 240V AC[TUV] / 5000A @ 32V DC Minimum Operating Temperature: -40° C Maximum Operating Temperature: 85° C Mounting Screw: #6-32 Stainless Steel Mounting Screw Torque: 6 in-lb (0.68 Nm) Screw Terminal Torque: 14 in-lb (1.58 Nm) Switching Cycles: 10000 Terminal Screw: #10-32 Stainless Steel Weight: 0.38lb (0.17 kg) WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 32a Box Dimensions: 2"H x 3"W x 5"L WT: 0.35 lbs UPC: 632085075750

Read more less

7601 DC Mini ACR Automatic Charging Relay - 65 AmpFeatures: 65 Amp continuous rating manages the charging current from alternators up to 65 Amps found on most outboards and many inboard engines Compact case design allows surface and panel mounting Senses charging on two battery banks Snap-on cover insulates terminal connections LED indicates ACR status 1/4" x .032" male quick connect terminal for ground 5/8" (16 mm) stud length to accept multiple cable terminals 12V DC voltage input Specifications: Intermittent Rating: 5 min.: 115A Terminal Stud Size: 1/4"-20 Relay Contact Position: Open (30 sec.): 12.75V DC Continuous Rating: 65A Maximum Torque: 75 in-lb (8.5 Nm) Relay Contact Position - Open High: 16.0V DC Amperage Operating Current: 175mA (Combine) Relay Contact Position: Combine (30 sec.): 13.0V DC Under Voltage Lockout: 9.5V DC Amperage Operating Current: 15mA (Open) Relay Contact Position: Combine (2 min.): 13.6V DC Maximum Cable Size: 1/0 AWG Relay Contact Position: Open (10 sec.): 12.35V DC WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Continuous Amperage: 65a Box Dimensions: 3"H x 4"W x 7"L WT: 0.6 lbs UPC: 632085076016 Owner's Manual (pdf)

Read more less

50 AMP Male Stainless Steel Combo KitThe SmartPlug 50 AMP Combo kit includes the 50 AMP Stainless Steel inlet (BM50S) and 50AMP connector (BF50), everything you need to protect your boat from shore power overheating.  Installation of both components is easy.  The kit is designed to fit on 125/250 V systems with multiple seals on the connector to ensure a watertight fit on an existing cordset.Features Reduces Overheating – Increased pin and clip surface area greatly improves electrical conductivity during high amperage demand. Ease of Use – No twist required, the unique plug body shape and push-in design means it only goes in the right way every time-even in  the dark. Multi-Point Locking System – Side clips lock the plug securely into the inlet which eliminates any stress on the pins from movement of the power cord. Weatherproof Seals – Superior gaskets installed in the inlet cover and interior of the plug body eliminates moisture penetration. Quick and Easy Installation – Inlet mounting flange holes match twist-type holes for an installation that is typically finished in 30 minutes. *Sold as an Individual WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

DC Analog Voltmeter Backlit meter face Simple 2-wire connection Meter Senses Powers from same connection WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Owner's Manual (pdf)

Read more less

C-Series Toggle Single PolePN: 7246Poles: 1Color: WhiteAmperage: 60AFeatures: Provides overcurrent protection for inverters, bow thrusters, and windlasses Combines switching and circuit protection into a single device "Trip Free" - cannot be held closed after trip WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 60a Box Dimensions: 2"H x 3"W x 5"L WT: 0.4 lbs UPC: 632085072469

Read more less

4011 CableCap - Black 0.70 to 0.30 StudFeatures:Insulate stud type connectors on alternators, starters, windlasses and other high amperage devicesWARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Read more less

7210 AC/DC Single Pole Magnetic World Circuit Breaker - 15AMPThe World Circuit Breaker meets all American Boat and Yacht Council (ABYC) Standards, is UL 1077 Recognized, TUV Certified, CE marked for Europe, and CSA Certified for Canada.Color: WhiteAmperage: 15 AmpDelay:  StandardFeatures: The industry standard circuit breaker for Blue Sea Systems electrical panels Combines switching and circuit protection into a single device Single pole Quick Trip models are designed specifically for electronics protection "Trip Free" design cannot be held "ON" during fault current condition WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Amperage: 15a Box Dimensions: 1"H x 3"W x 4"L WT: 0.16 lbs UPC: 632085072100

Read more less
