Tinned Lug 6 AWG - 1/4" Stud Size - 10 PackCreating a strong connection is essential to every electrical system. By using closed-end lugs, users get not only durability but longevity as well. Pacer's closed-end lugs are tin-plated and have no exposed seams. This means that they are ideal for marine applications. What makes them ideal is the fact that they can be used to create waterproof connections. When used with epoxy heat shrink, the closed end lug will fully envelop the conductor. This leaves nothing exposed to the elements. To use, simply strip your wire or cable to the proper length. Once this is complete, slide the lug over the exposed wire, making sure the insulation butts up to the edge of the lug.Now, crimp the lug using the correct tool, and you're done. Add epoxy lined heat shrink for added durability. Pacer's closed-end lugs are available in 8 AWG to 4/0 AWG wire sizes. The available stud sizes include #10, 1/4", 5/16", 3/8", and 1/2". Selecting the correct closed-end lug isn't an easy task. Contact a Pacer expert today with any questions that you may have.Features: Tin Plated No exposed seams Rated for 600V Made from seamless tubes of 99.9% copper for higher conductivity Designed for stranded copper wires Larger pad area for better contact Cable size and stud hole stamped on pad Can be crimped or soldered Highly controlled flare to allow easy cable insertion Tight barrel to pad transition provides longer usable barrel length Compliances: E.T.P. (Electrolytic Tough Pitch) CDA-110 ASTM-B-152 copper rated at 100% conductivity UL & CSA Approved RoHS Compliant Exceeds SAE Conductivity STD J163 & J1811 Specifications: Wire AWG: 6 Stud Size: 1/4” Length: 1.266” Width: 0.438” Clearance: 0.344” Package Size: 10 Specifications: Gauge: 6 AWG Heat Shrink: No Package Qty: 10 Post Size: 1/4" Type: Lugs Box Dimensions: 0"H x 5"W x 9"L WT: 0.15 lbs UPC: 840248209830 Brochure (pdf)

Read more less

Tinned Lug 6 AWG - #10 Stud Size - 10 PackCreating a strong connection is essential to every electrical system. By using closed-end lugs, users get not only durability but longevity as well. Pacer's closed-end lugs are tin-plated and have no exposed seams. This means that they are ideal for marine applications. What makes them ideal is the fact that they can be used to create waterproof connections. When used with epoxy heat shrink, the closed end lug will fully envelop the conductor. This leaves nothing exposed to the elements. To use, simply strip your wire or cable to the proper length. Once this is complete, slide the lug over the exposed wire, making sure the insulation butts up to the edge of the lug.Now, crimp the lug using the correct tool, and you're done. Add epoxy lined heat shrink for added durability. Pacer's closed-end lugs are available in 8 AWG to 4/0 AWG wire sizes. The available stud sizes include #10, 1/4", 5/16", 3/8", and 1/2". Selecting the correct closed-end lug isn't an easy task. Contact a Pacer expert today with any questions that you may have.Features: Tin Plated No exposed seams Rated for 600V Made from seamless tubes of 99.9% copper for higher conductivity Designed for stranded copper wires Larger pad area for better contact Cable size and stud hole stamped on pad Can be crimped or soldered Highly controlled flare to allow easy cable insertion Tight barrel to pad transition provides longer usable barrel length Compliances: E.T.P. (Electrolytic Tough Pitch) CDA-110 ASTM-B-152 copper rated at 100% conductivity UL & CSA Approved RoHS Compliant Exceeds SAE Conductivity STD J163 & J1811 Specifications: Wire AWG: 6 Stud Size: #10 Length: 1.266” Width: 0.438” Clearance: 0.344” Package Size:10 Specifications: Gauge: 6 AWG Heat Shrink: No Package Qty: 10 Post Size: #10 Type: Lugs Box Dimensions: 0"H x 5"W x 9"L WT: 0.15 lbs UPC: 840248209823 Brochure (pdf)

Read more less

Tinned Lug 2/0 AWG - 5/16" Stud Size - 10 Pack Creating a strong connection is essential to every electrical system. By using closed-end lugs, users get not only durability but longevity as well. Pacer's closed-end lugs are tin-plated and have no exposed seams. This means that they are ideal for marine applications. What makes them ideal is the fact that they can be used to create waterproof connections. When used with epoxy heat shrink, the closed end lug will fully envelop the conductor. This leaves nothing exposed to the elements. To use, simply strip your wire or cable to the proper length. Once this is complete, slide the lug over the exposed wire, making sure the insulation butts up to the edge of the lug.Now, crimp the lug using the correct tool, and you're done. Add epoxy lined heat shrink for added durability. Pacer's closed-end lugs are available in 8 AWG to 4/0 AWG wire sizes. The available stud sizes include #10, 1/4", 5/16", 3/8", and 1/2". Selecting the correct closed-end lug isn't an easy task. Contact a Pacer expert today with any questions that you may have.Features: Tin Plated No exposed seams Rated for 600V Made from seamless tubes of 99.9% copper for higher conductivity Designed for stranded copper wires Larger pad area for better contact Cable size and stud hole stamped on pad Can be crimped or soldered Highly controlled flare to allow easy cable insertion Tight barrel to pad transition provides longer usable barrel length Compliances: E.T.P. (Electrolytic Tough Pitch) CDA-110 ASTM-B-152 copper rated at 100% conductivity UL & CSA Approved RoHS Compliant Exceeds SAE Conductivity STD J163 & J1811 Specifications: Wire AWG: 2/0 Stud Size: 5/16” Length: 2.063” Width: 0.813” Clearance: 0.500” Package Size: 10 Specifications: Gauge: 2/0 AWG Heat Shrink: No Package Qty: 10 Post Size: 5/16" Type: Lugs Box Dimensions: 0"H x 5"W x 9"L WT: 0.55 lbs UPC: 840248205559 Brochure (pdf)

Read more less

Tinned Lug 4/0 AWG - 5/16" Stud Size - 10 PackLugs are connection points that are created by crimping the connector onto a wire or cable. This connection, commonly referred to as a cold weld, creates a solid, long-lasting connection. Pacer lugs are made from 100% pure copper for high conductivity. This copper is fully annealed to prevent cracking while being crimped and while in service. These terminals are also tin-plated to prevent corrosion and many of these lugs are general-purpose seamless electrical terminals. They are commonly used with battery cables.Features: Tin-plated copper with no exposed seams offering 100% long-term conductivity Tinned copper Highly durable Multitude of sizes Easily terminated Infield applications Long-lasting Compliances: E.T.P. (Electrolytic Tough Pitch) CDA-110 ASTM-B-152 Copper RoHS Compliant CSA Approved UL Approved Specifications: Wire AWG: 4/0 AWG Stud Size: 5/16" Length (inch): 2.344" Width (inch): 0.984" Clearance (inch): 0.547" Package Size: Ten included Specifications: Gauge: 4/0 AWG Heat Shrink: No Package Qty: 10 Post Size: 5/16" Type: Lugs Box Dimensions: 1"H x 4"W x 7"L WT: 0.9 lbs UPC: 840248205757 Quick Guide (pdf)

Read more less

Brown 18 AWG Primary Wire - 500' Pacer's marine wire is designed to handle the harshest marine environments.  It is manufactured to meet and exceed the most stringent specifications.  This 18 AWG marine wire is constructed in the USA to achieve the highest level of quality. Built from Type III class K tinned copper, this wire offers excellent flexibility.  The tinned copper also resists corrosion adding to the life of the wire.  What about the insulation?  After the copper is tinned it is then insulated with a durable and flexible PVC jacket.  The jacket makes this 18 AWG marine wire resistant to alkali, abrasion, acid, gas, oil, flame, and moisture.  What standards and compliances does this wire meet?  Pacer's marine wire exceeds the requirements and standards of UL, ABYC, and NMMA. Features: Built for durability, flexibility, and longevity in the harshest marine environments  So flexible that you can tie it into a knot without compromising any of its qualities  Proprietary insulation ensures the highest level of protection available  Ease of installation and the longevity of its design have helped solidify this marine wire as the choice of boating professionals Compliances: UL Standard - 1426 BC-5W2 U.S.C.G - 33 CFR part 183  ABYC - E-11.14  Technical Specifications: Conductor - Type III annealed finely stranded tinned copper ASTM B172 Class K Insulation -20 °C to 105 °C flexible, color-coded PVC Voltage Rating - 600-V Resistant to - Acid, Alkali, Abrasion, Flame, Gasoline, Oil and Moisture *Sold as an Individual Specifications: Color: Brown Gauge: 18 AWG Length (Feet): 500' Box Dimensions: 4"H x 7"W x 7"L WT: 6 lbs UPC: 840248200950 Brochure (pdf)

Read more less

Master Battery Switch Spare KeySpare key for 150 Amp Battery Master SwitchKey can be removed in the OFF position, current interrupted. Specifications: Color: Red Box Dimensions: 1"H x 5"W x 5"L WT: 0.2 lbs UPC: 4082300200560

Read more less

1 Bank On/Off Board Battery Charger - 36V - 15 AmpThe Pro-Guide PGC-3615 is a 36V LiFePO4 battery charger! With a quick-connect Anderson plug and with a 15A charging output, you will have your battery recharged and ready to go in no time!Specifications: Voltage: 36 Volts Connector: Anderson Plug with Eyelets & other plugs sold separately Chemistry: Lithium Amps: 15 Amps Length: 7.19" Width: 4.13" Height: 4.13" Weight: 3.75lbs Specifications: Charger Input - Voltage: 120v Charger Output - Amps: 15a Charger Output Voltage: 36v Charging Banks: 1 Portable: Yes Box Dimensions: 6"H x 9"W x 11"L WT: 5.1 lbs UPC: 810145911235

Read more less

30 AMP SmartPlug/Twist Type Cordset - 50'For many years boaters have experienced the safety, security and simplicity of SmartPlug products on the boatside while still dealing with the same old issues created by legacy twist-type products on the dockside.   Those days are changing with the introduction of SmartPlug's new dockside product offering.  SmartPlug has applied decades of experience and customer feedback to create a product that allows you to upgrade your shore power connection with SmartPlug technology. The 30 AMP 125 V cordset provides a complete weatherproof power solution. The cordset includes the SmartPlug connector for the Boatside and a Twist Type Plug connector for the Dockside.Features: Multi-Point Locking System - Side clips lock the body securely into the inlet, which eliminates any stress on the electrical connection from movement of the power cord. Weatherproof Seals - Silicone gaskets installed in the interior of the plug body eliminate any water penetration when plug is connected to inlet. LED Power Indicator Light – On the top of all SmartPlug female ends, two LED indicator lights.  One Red and one Blue LED light for Safe/Unsafe Electrical Power Indication under Reverse Polarity Conditions. Tinned Wire – All SmartPlug marine cords have tinned wire to minimize corrosion. Technical Specifications: Length - 50' Color - White Boatside Connection - 30 AMP/125 V SmartPlug Dockside Connection - 30 AMP/125 V Twist Type Plug *Sold as an IndividualWARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Voltage: 125v Type: Cordset Length: 50' Amperage: 30a Box Dimensions: 4"H x 12"W x 12"L WT: 15.2 lbs UPC: 682500441356 Owner's Manual (pdf)Brochure (pdf)

Read more less

30A MPPT Charge ControllerDesigned to charge lithium-ion batteries including LIFePO4, the 30 A MPPT (Maximum Power Point Tracking) charge controller features an industry-leading 98% charging efficiency and dual bank output to charge and maintain house and starter batteries. The Xantrex Solar MPPT Charge Controller 30 features advanced Maximum Power Point Tracking (MPPT) technology, providing an instant upgrade to your solar system with up to 30% more power compared to PWM charge controllers. Offering greater flexibility, simplicity, and efficiency in PV array designs, higher voltage PV arrays can be used up to 72V (nominal). Equipped with dual-battery bank charging ports ideal for simultaneously charging and maintaining 12V house and starter batteries, best-in-class PV array and battery protection, and a built-in LCD display providing real-time system data. Optional accessories include a remote battery temperature sensor and remote panel. The Xantrex Solar Charge Controllers are compatible with all types and makes of solar panels from all manufacturers. Below is a list of available Xantrex Solar Panel Kits and Expansion Kits. Consider pairing this MPPT charge controller with Xantrex Solar Panels. Features: Advanced Maximum Power Point Tracking (MPPT) technology increasing daily energy harvest by 20-30% compared to PWM technology Dual-battery bank charging to simultaneously charge house and starter batteries Best-in-class PV array and battery protections House battery types supported: Sealed (AGM), Gel, Flooded, Lithium Iron Phosphate(LiFePO4) 5-year warranty

Read more less

AC Universal Plug Holder - WhiteFeatures: White AC Universal Plug Holder is designed for all standard 120V AC plugs Plug clamp insert included - converts plug holder to an AC inlet for battery chargers No cutting, stripping, or rewiring of AC power cord Watertight and UV resistant cover Stainless steel mounting screws included Easy to reach safe AC power cord connections

Read more less

Push-Button Switch 12V Momentary On/Off - Red LEDPush-Button switches and buzzers are built to last with their stainless steel components and silver alloy contacts. The through panel mount switches are ideal for lighting, switch, or dash panels, with colored rings that can be wired to either display power to the system or switch back lighting. The product line includes both switches and warning buzzers.Features: Maximum switch current rating 5 amps IP67 environmental protection switches IP50 environmental protection buzzers 80 decibel buzzer sound intensity Warning buzzers flash red on alarm WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Action: ON-OFF Color: Stainless Box Dimensions: 2"H x 3"W x 4"L WT: 0.2 lbs UPC: 843687005919

Read more less

4/0 AWG Yellow Battery Cable - 25'Tinned Copper Stranded WireBattery Cable is available in all colors in accordance with ABYC standard. 600V 105°C DRY (75°C WET) and oil resistant. UL Listed Boat Cable. Made in the U.S.A.All 4 AWG- 4/0 AWG cables are designed and manufactured for marine use with tinned copper wire for corrosion resistance and improved conductivity. The copper is annealed and finely stranded to offer flexibility and resistance to vibration to ensure reliable performance over time.WARNING: This product can expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov. Specifications: Color: Yellow Gauge: 4/0 AWG Length (Feet): 25' Box Dimensions: 7"H x 11"W x 11"L WT: 20.6 lbs UPC: 035514804066
