Deck Fill for Pressure Relief Systems - Angled Body & Scalloped Black Plastic CapPressure relief systems are designed with automatic diurnal emission control and overpressure relief safety valves built into the cap of the fill. The overpressure relief safety valves are engineered to release pressure above 1 psi. The high-flow vacuum valves allow fresh air to enter the fuel tank to replace the fuel being consumed by the engine. Other components of a pressure relief system are designed to ensure the tank fills to the proper level every time without spit-back or well-back. All Attwood pressure relief systems are designed to ensure water does not enter the fuel tank and are compatible with Jerry Can and marine nozzle refueling.Features:
Fits 1-1/2 (inch) fill hose and 5/8 (inch) vent hose
Triple high-flow vacuum valves ensure maximum make-up airflow (compatible with high HP applications)
Dual 1 psi diurnal emission control and overpressure relief safety valves built into the cap
Automatic nozzle shutoff 4-18 gpm
Black Composite finish
An essential component of VaporTec and SecureStop
Designed and tested to prevent water from entering the fuel system
EPA / CARB Certified
Hinged audible click cap meets EPA requirements
Meets CARB 13 CCR 2235 and ISO 13331 nozzle mating and retention standards
*Compatible with Ethanol blended fuels Quick Guide (pdf)
Deck Fill for Pressure Relief Systems - Straight Body & Scalloped Stainless Steel CapPressure relief systems are designed with automatic diurnal emission control and overpressure relief safety valves built into the cap of the fill. The overpressure relief safety valves are engineered to release pressure above 1 psi. The high-flow vacuum valves allow fresh air to enter the fuel tank to replace the fuel being consumed by the engine. Other components of a pressure relief system are designed to ensure the tank fills to the proper level every time without spit-back or well-back. All Attwood pressure relief systems are designed to ensure water does not enter the fuel tank and are compatible with Jerry Can and marine nozzle refueling.Features:
Fits 1-1/2 (inch) fill hose and 5/8 (inch) vent hose
Triple high-flow vacuum valves ensure maximum make-up airflow (compatible with high HP applications)
Automatic nozzle shutoff 4-18 gpm
Stainless Steel finish
An essential component of VaporTec and SecureStop
Designed and tested to prevent water from entering the fuel system
EPA / CARB Certified
Hinged audible click cap meets EPA requirements
Meets CARB 13 CCR 2235 and ISO 13331 nozzle mating and retention standards
*Compatible with Ethanol blended fuels Quick Guide (pdf)
Command Ratchet Hinges - 9-3/8" - Polished 316 Stainless Steel - PairConstructed from high-grade stainless steel and brass, our Command Ratchet Hinge is ideal for sunpads, bolsters and lounge backrests. This heavy-duty specialty hinge has a 15-degree locking inclination and ratchets up to four positions.Features:
Highly polished marine-grade stainless-steel Type-316L
All brass bearings for durability
Meets ABYC H-31 standards class B* application, 250lb ft of torque load for pair
15-degree locking inclination increments starting at 30 degrees
Easily adaptable to many applications
Designed for up to 4" thick cushions
Returns to horizontal position at 100 degrees
Countersunk for #10 fastener or 1/4-20 bolt
Sold in pairs
5-year limited warranty
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns. Brochure (pdf)
Flat Deck Hinge with Pin & Lanyard - 7/8"-1-1/4"Features:
Offered in concave and flat mounts
Secure fit with removable pin and lanyard or turn and lock D-ring
This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.
Black Flush Lock - 2.5" x 2.5" w/Offset Cam Bar & Flexible Polymer StrikeFeatures:
Black Polymer
Chrome Plated Zinc Alloy
Stainless Steel Stem and Lock Nut
Detents Indicate Open or Closed Position
Installs in a 2" Diameter Hole
For Door Thickness 1/4" to 1-1/8"
Combination Vented Gas Fill/Tank for 1-1/2" Hose - 35° Angled Neck Features:
35° Angled Neck
Black Polymer
Integral Tank Vent with Flame Arrestor
No Ground Wire Required
Flip Top Cap
Specifications:
For Hose Size: 1-1/2"
For Vent Size: 5/8"
Neck Length: 2-7/16 "
Screw Size: #10
